Custom Dynamics Smart Triple Play GEN-SMART-TPU-UNV User manual

SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pen ing)
Part: GEN-SMART-TPU-UNV
Fits: Universal 12VDC, Non CAN BUS Motorcycles
Important: For this system to be legal you must use RED rear turn signal lamps.
Important: This system is designed to work with single intensity rear turn signals, if you
do not have single intensity rear turn signals do not install this module. ontact Techni-
cal Support.
Important: Remove any existing Run-Brake-Turn or similar modules prior to installing
this unit.
aution: Never install a Load Equalizer Downstream of this unit. Remove any existing
load equalizer prior to installing this unit.
aution: Never install a trailer adapter, trailer harness or trailer controller downstream
of this unit, a trailer adapter, harness or controller must be installed on the input side
of this unit.
aution: This unit is designed for a maximum load of 27 watts per channel. Do no ex-
ceed 27 watts per left turn signal output, 27 watts per right turn signal output, and 27
watts per brake signal output. Overloading unit could cause damage to the unit and
cause the unit to malfunction.
1. Secure motorcycle on level surface. Remove seat. Disconnect negative battery ca-
ble from the battery. Locate and unplug the lighting connector to the rear fender.
2. Wire the Smart Triple Play® Module, in-line, into the rear lighting harness according
to the diagram on page 2 and 3.
3. Re-connect the battery’s negative battery cable to the negative of the battery.
4. Locate a secure place for the Smart Triple Play® unit that will not interfere with the
secure placement of the seat or side cover.
Installation Instructions

SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pen ing)
1: Locate 5 wires going to rear of bike:
Power—Running
Ground
Brake
Left Turn
Right Turn
2: ut the Brake, Left Turn, and Right Turn Wires
Input Side
Input Side
Output Side
Output Side
3. Wire in SMART Triple Play
Smart Triple Play (STP)
Posi Tap
Posi Tap
Blue Running
Orange Running
Black Ground
Black Ground
Posi Tap
Posi Tap
Red Brake
Purple Left Turn
Brown Right Turn
Posi Lock
Posi Lock
Posi Lock
Input Side Wiring (Red Heat Shrink Bundle)
onnect Blue from STP to Running Light Power
onnect Orange STP to Running Light Power
onnect 2 Blacks from STP to Ground
onnect Red from STP to ut Input Brake wire
onnect Purple from STP to ut Input Left Turn
onnect Brown from STP to ut Input Right Turn
Red Brake Output
Purple Left Turn Output
Brown Right Turn Output
Posi Lock
Posi Lock
Posi Lock
Universal Installation Instructions
Output Side Wiring (Black Heat Shrink Bundle)
onnect Red from STP to ut Output Brake wire
onnect Purple from STP to ut Output Left Turn
onnect Brown from STP to ut Output Right Turn

Harley
Ground - Black
Brake - Red (or w/Orange tracer)
Left Turn - Purple
Right Turn - Brown
Tail/Running - Blue
SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pen ing)
Installation Instructions

SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pen ing)
5. Initial Setup and Operation: Locate the two switches and rotary dial. Be sure the rotary
dial is set to position 0. Note there is a screw diver slot to make the dial turn easer, this
is not the pointer, there is small arrow on the dial , this is the pointer that should now be
at position 0. Be sure Switch 1 and Switch 2 are both in the ON position.
6. Turn the ignition key on and check operation as follows:
• Running Lights: Turn Signals and Taillight are now illuminated dimly.
• Apply Right Turn Signal and check operation of right turn signal, should flash off to
bright. Disable turn.
• Apply Left Turn Signal and check operation of left run signal, should flash off to bright.
Disable turn.
• Apply Brake Light. heck to see that all 3 lights flash 4 times then remain bright.
• Apply Left Turn Signal then Apply Brake, heck to see that Only enter Light
Flashes 4 times then remains bright.
Installation Instructions
Off Off
On On
1 2
Rotary

SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pen ing)
7. The Smart Triple Play ® allows you to program the running light brightness of the turn signals so
they are a match to your center taillight.
• Turn ignition key off, be sure Switch 1 and Switch 2 are in the OFF position and the Rotary Dial
in in the 0 position.
• Turn ignition key on, immediately turn Switch 1 On Off On. Turn Switch 2 On OFF On. Turn the
Rotary dial one complete clockwise revolution back past position 0 and stop. Do not depress
Brake or Turns Signals during this action.
• The turn signals should now fade up and down slowly, do not proceed unless this confirmation
takes place.
• Turn the rotary dial clockwise, increasing numbers, to increase the brightness of the running
lights. Match the running light brightness to the taillight. Once happy with the setting, press and
hold the brake for a couple of seconds. The setting will now be saved.
8. Turn ignition key Off and set switches for desired Operation.
Switch 1 On, Switch 2 On: Strobes/Flashes on all three Rear Lights
Switch 1 On, Switch 2 Off: Strobes/Flashes on rear turn signals only
Switch 1 Off, Switch 2 On: Strobes/Flashes on center light only
Switch 1 Off, Switch 2 Off: No Strobes/Flashes
Rotary Switch Setting to set Brake Flash/Strobe Pattern:
Pattern 0: Four Flashes then Solid (Incandescent or LED)
Pattern 1: Four Flashes, Solid for 3 Seconds, Repeat (Incandescent or LED)
Pattern 2: Seven Flashes then Solid (Incandescent or LED)
Pattern 3: Seven Flashers, Solid for 3 Seconds, Repeat (Incandescent or LED)
Pattern 4: Quad Strobe then Solid for 1 Second then Quad Strobe (LED Only)
Pattern 5: Quad Strobe, Solid for 1 Second, then Quad Strobe, Solid for 3 Seconds, Repeat (LED
Only)
Pattern 6: Blaster X Pattern for 3 seconds, then Solid (LED Only)
Pattern 7: onstant Blaster X Pattern (LED Only)
Pattern 8: onstant Fast Strobe 5 Seconds, then Solid (LED Only)
Pattern 9: onstant Fast Strobe Pattern (LED Only)
9. Turn ignition key on and Test Operation based on your desired switch
settings.
10. Reinstall Seat.
Installation Instructions
