CUSTOM POWER DESIGN Handy Mains Series User manual

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
The Popular "Handy Mains" Inverter Series
The "Handy Mains" series of inverters produce AC mains power from a broad range of battery inputs and
some models have now been in production for over 10 years. We have a wealth of experience with inverters
and our designs reflect this, during their life time they have constantly evolved to meet the challenge of
powering most types of equipment, modern and old. With sales to five major distributors the ‘Handy
Mains’ has become one of the foremost inverters in the field.
With power ranges up to 2700W there is sure to be a "Handy Mains" to suit your requirements.
Go to http://www.custompsudesign.com for more information.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
______________________________________________________________________________________________________________________________________________________________
CUSTOM POWER DESIGN
ELECTRONICS CONSULTANTS PROVIDING CUSTOM DESIGN, DEVELOPMENT, TEST & SUPPORT
______________________________________________________________________________________________________________________________________________________________
Tel: + 44 (0)118 983 1222 A DIVISION OF SMET LTD
______________________________________________________________________________________________________________________________________________________________
www.custompsudesign.com Unit 1,The Forge, Reading Road, Burghfield Common, Reading, RG7 3BL. [e-mail]
USER GUIDE FOR 65 WATT BATTERY CONVERTERS
OHMICALLY ISOLATED AND CURRENT LIMITED.
ALLOWS DIRECT POWERING OF NOTEBOOK COMPUTERS INCLUDING BATTERY CHARGING.
OUTPUT 12V BATTERY 24V BATTERY 48V BATTERY
5V at 13A SM4660 SM4670 SM5040
9V at 7.2A SM4661 SM4671 SM5041
12V at 5.4A SM4662 SM4672 SM5042
15V at 4.3A SM4663 SM4673 SM5043
18V at 3.6A SM4664 SM4674 SM5044
21V at 3.1A SM4665 SM4675 SM5045
24V at 2.7A SM4666 SM4676 SM5046
48V at 1.35A SM4667 SM4677 SM5047
13.8V at 4.7A SM4668 SM4678 SM5048
27.6V at 2.3A SM4669 SM4679 SM5049
GENERAL: These small but powerful converters provide a source of stabilised low voltage
suitable for running many different items of equipment. Their output is ohmically isolated from the
system chassis and constant current limited. Continuous operation in current limit is allowed
making them suitable for battery charging. Connection to the system is by a ‘cigar’ plug (12 & 24V
Input) lead or just a flying lead (48V input), and output is by flying lead (5V - 15V units) or 2.5mm
concentric connector (18V - 48V units).
The converters are mainly designed for use with notebook computers that have two wire input.
These converters are current limited above a certain level of demand. The output isolation of the
converter from system ground ensures that earth currents do not flow.
CONNECTION:
Input: For 12V and 24V units, the converter just plugs into a cigar type socket, using the cable
mounted plug provided. Don't leave the converter plugged in when not in use. It will still slowly
discharge the battery. 48V input units must be directly wired to the 48V supply, fused at the battery
source with a 3.15A fuse. The input cable has a YELLOW sleeve fitted close to the case to identify
it. The RED wire connects to battery positive (+) and BLACK wire to battery negative (-).
Output: 15V output or below: Un-terminated cable. 18V output or more, 2.5mm ‘barrel’
connectors, centre positive. Red wire or White stripe positive, Black wire negative. The warranty is
not affected if the purchaser fits a different suitably current rated connector.
BATTERY DRAIN: These converters take about 1A at 12V, 0.5A at 24V or 0.25A at 48V for
every 10 watts of load. Input current may reach 10A (12V), 5A (24V), 2.5A (48V).
Document 4660E996 Issue 7,.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
SPECIFICATION:
Output:
Factory set voltage (10% load): Rated voltage ± 1.7% plus 0.1V. See note 1.
Variation for static 10-90% load change: 0.5% plus drop in output cable. See note 1.
Variation for static 2V input change: 50mV maximum.
Full load current: See table at top of front page.
Current limit: 120% of rated current ± 17%. See note 2.
Low frequency ripple: 200mV maximum.
Voltage temperature coefficient: 0.02%/C of rated voltage. See note 3.
Input: 12V Battery 24V Battery 48V Battery
DC Input Supply Range, continuous: 10.6V to 15V. 21.6V to 30V 43V to 56V
DC Input Supply Range, 1 minute: 10V to 18V. 20V to 36V. 40V to 63V.
Input Current per 10W loading: 1A (guide). 0.5A (guide) 0.25A (guide)
Input Current, No Load: 0.1A typical. 0.07A typical. 0.05A typical.
Fuse rating: 10A T, 5A T. EXTERNAL.
General:
DC input to output isolation: 500Kohm minimum at ± 100VDC maximum.
Protection: Output constant current limit.
Size: Length 111mm by Width 60mm by Height 30mm.
Weight: Weight 380 grams including wires.
Ambient Temp Range: -40 to +30C operating, -40 to +70C storage.
Nominal input lead length: 0.6 metres.
Nominal output lead length: 0.6 metres.
Manufacturer: UK made by SMET Ltd., Reading, Berks.
Specification Notes:
1) The main variation of output voltage with load is due to the resistance of the output cable (0.01
ohms). An internal potentiometer is available to adjust the output voltage to compensate.
2) The output current limit is deliberately made a function of unit temperature to maximise
delivered charge. Output current will fall, still within the quoted range as the unit attains working
temperature.
3) Case temperature change must be taken into account when calculating output variation.
4) The adapter is designed to run with a case temperature approaching 60C under heavy load
conditions.
SAFETY WARNINGS.
Ensure that the battery voltage is correct for the model. Do not reverse the polarity of the input voltage.
Use at least 2mm2wire to connect the converter to the battery. Thin wire will cause fire hazard.
Fuse Battery at source. The case is connected to the negative input (48V input versions floating).
Only operate the unit from a battery. Do not connect the unit to any other power source. For inside use only.
Do not expose to moisture. Do not cover. The unit will run hot when under elevated load.
Disconnect the battery before changing the fuse. Do not operate the unit with the cover off.
Turn off when not in use to avoid battery drain. Not to be used for life support.
Do not use in a moving vehicle without the vehicle manufacturer’s consent.
Do not use for marine or aviation applications without our written agreement.
This equipment is supplied on the basis of the user determining the suitability of use.
We reserve the right to change the specification without notice.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
OTHER CONVERTERS IN RANGE
The range of converter products manufactured in the UK, by SMET Ltd., allow a broad range of battery
voltages to be converted to commonly required output voltages. These converters are suitable for powering
most domestic and professional electrical appliances that have a DC input. Wherever you are you can run
your laptop, power your CD/cassette player, charge your camcorder or simply charge batteries from your
main battery.
One of the most important things, when selecting the right converter, is to know the highest power rating of
the range of equipment you wish to run, and whether use is solely to power a device or to charge the battery
within a device. Converters have different short term and continuous power capabilities, which must be
matched with the equipment they are to run. Note that nearly all low voltage DC devices will have a power
plate stating the required input voltage and current and voltage polarity required. If you have any questions
with respect to choosing the right converter for your application call our Help Line on [phone] and
we will be happy to help you.
Smaller converters are fitted with an input plug to suit cigar lighter sockets, others intended for permanent
installation have short heavy wires for connection to the battery, with a third thin wire to connect to a low
current switch (termed ‘3 wire i/p’) for on/off control. Large converters have heavy duty studs. The outlets
come in a wide range to suit most appliances, be sure to tell us which connector and polarity you require
when ordering.
CAUTION: These adapters are supplied on the basis of the user determining the suitability of use.
NOT FOR LIFE DEPENDENT USE
Go to http://www.custompsudesign.com for more information.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
ITALIANO.
Configurazione: L'uscita è isolata e limitato corrente per permettere caricarsi controllato della batteria.
COLLEGAMENTO:
Input 12V e 24V: Inserisca l'unità lo zoccolo dell'accenditore della sigaretta dell'automobile. Il contatto del centro è
positivo.
Input 48V: Il cavo dell'input ha un indicatore GIALLO. Il legare rosso è il collegamento positivo. Il legare nero è il
collegamento negativo. Fusible 3,15A T.
Connettore Di Uscita: L’uscita 15V o di meno: Unterminated cavo. L'uscita 18V o più grandi, connettori ' del
barilotto ' di 2.5mm, si concentra il positive. Il legare rosso o la linea bianca è il collegamento positivo.
Il legare nero è il collegamento negativo. La garanzia non è influenzata se l'acquirente misura un connettore differente.
SPECIFICA:
Uscita:
Tensione (carico 10%): ± 0,1v del ± 1,7% di tensione nominale.
Regolazione del carico (10-90%): 0,5% differenze de potenziale più in cavo dell'uscita.
Regolazione, cambiamento dell'input 2V: Massimo 50mV.
Corrente di carico completo: Veda la tabella in cima alla prima pagina.
Limite corrente: 120% della corrente di carico completo, ± 17%.
Ondulazione a bassa frequenza: Massimo 200mV.
Input: 12v Batteria. 24v Batteria. 48v Batteria.
Gamma dell'input, continua: 10,6V a 15V. 21,2V a 30V. 43,2V a 56V.
Corrente dell'input per il carico 10W: 1A tipico. 0,5A tipico. 0,25A tipico.
Corrente Dell'Input, Nessun Carico: 0,1A tipico. 0,07A tipico. 0,05A tipico.
Fusibile: 10A T. 5A T. ESTERNO.
Generalità:
Isolamento, input ad uscita: Minimo 500K al massimo ± 100V.
Protezione: Fusibile dell'input. Limite della corrente d'uscita.
Formato: 111mm lungo, 60mm larghi, 30mm alti.
Peso: 380 grammi.
Gamma Di Temperature Ambientale: -40C a +30C che funziona, -40C a +70C immagazzinaggio.
Lunghezza di cavo dell'input: Tipico 0,6M.
Lunghezza di cavo dell'uscita: Tipico 0,6M.
Fornitore: SMET Ltd., Reading, Berkshire, RG7 3BL. GB.
AVVERTIMENTO DI SICUREZZA.
Accertisi che la tensione della batteria sia corretta per il modello. Non inverta la polarità della tensione in ingresso.
Usi almeno il legare 2mm2per collegare alla batteria. Il legare sottile causerà il rischio d'incendio.
Fusibile la batteria vicino alla fonte. Il caso è collegato all'input negativo (unità 48v isolato ± 100V).
Funzioni soltanto l'unità a partire da una batteria. Non colleghi l'unità a qualunque altra fonte di energia.
All'interno di uso soltanto. Non esponga ad umidità. Non copra. L'unità farà funzionare il carico elevato di sotto caldo.
Stacchi la batteria prima di cambiare il fusibile. Non funzioni l'unità con la copertura fuori.
Spenga quando non in uso evitare lo scolo della batteria. Non essere usato per il supporto di vita.
Non usi in un veicolo commovente senza il consenso del fornitore del veicolo.
Non usi per il fante di marina o le applicazioni di aeronautica senza nostro accordo scritto.
Questa apparecchiatura è fornita in base all'utente che determinal'idoneità di uso.
Riserviamo il diritto di cambiare la specifica senza avviso.
Le informazioni [phone] Web: http://www.custompsudesign.com.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
FRANÇAIS.
Configuration: Le rendement est isolé et limité pour permettre le remplissage commandé de batterie.
RACCORDEMENT:
Entrée 12V et 24V: Branchez l'unité à la douille d'allumeur de la cigarette, à l'aide de la prise fournie. Le contact de
centre est positif.
Entrée 48V: Le câble d'entrée a un marqueur JAUNE. Le fil rouge est le raccordement positif. Le fil noir est le
raccordement négatif. Fusible 3,15A T.
Connecteur de Débit: Le rendement 15V ou moins: Cavo ultimazione. Le rendement 18V ou plus grands, des
connecteurs de ' baril ' de 2.5mm, centrent le positif. Le fil rouge ou la ligne blanche est le raccordement positif. Le fil
noir est le raccordement négatif. La garantie n'est pas affectée si l'acheteur adapte un connecteur différent.
SPÉCIFICATIONS:
Rendement:
Tension (charge 10%): ± 0,1V du ± 1,7% de tension nominale.
Règlement de charge (10-90%): 0,5% + chutex de tension en câble de rendement.
Règlement, le changement de l'entrée 2V: Maximum 50mV.
Courant de chargement complet: Voir le tableau au haut de la première page.
Limite de courant: 120% du courant de chargement complet, ± 17%.
Ondulation de basse fréquence: Maximum200mV.
Entrée: 12v Batterie. 24v Batterie. 48v Batterie.
Chaîne d'entrée, continue: 10,6V à 15V. 21,2V à 30V. 43,2V à 56V.
Courant d'entrée par charge 10W: 1A typique. 0,5A typique. 0,25A typique.
Courant D'Entrée, Aucune Charge: 0,1A typique. 0,07A typique. 0,05A typique.
Fusible Interne: 10A T. 5A T. EXTERNE.
Général:
Isolement, entrée au rendement: Minimum 500K au maximum ± 100V.
Protection: Fusible d'entrée. Limite de courant de sortie.
Taille: 111mm long, 60mm larges, 30mm hauts.
Poids: 380 grammes.
Température ambiante: -40C à +30C fonctionnant, -40 à +70C au stockage.
Longueur de câble d'entrée: 0,6 mètres de typique.
Longueur de câble de rendement: 0,6 mètres de typique.
Fabricant: SMET Ltd., Reading, Berkshire, RG7 3BL, RU.
AVERTISSEMENT DE SÛRETÉ.
Assurez-vous que la tension de batterie est correcte pour le modèle. Ne renversez pas la polarité de la tension d'entrée.
Employez au moins un fil 2mm2pour relier à la batterie. Un fil mince causera le risque d'incendie. Fusible la batterie
près de la source. Il caso è collegato all'input negativo (unités 48v d'isolement ± 100V). Actionnez seulement l'unité à
partir d'une batterie. Ne reliez l'unité à aucune autre source d'énergie. L'unité courra chaud quand sous la charge élevée.
Ne couvrez pas. Débranchez la batterie avant de changer le fusible. N'actionnez pas l'unité avec la couverture au loin.
Utilisez à l'intérieur seulement. N'exposez pas à l'humidité. Éteignez quand pas en service pour éviter de vider la
batterie. Ne pas être employé pour l'appui de la vie. N'employez pas dans un véhicule mobile sans consentement du
fabricant de véhicule. N'employez pas pour le soldat de marine ou les applications d'aviation sans notre accord écrit.
Cet équipement est fourni sur la base de l'utilisateur déterminant la convenance de l'utilisation. Nous nous réservons le
droit de changer les spécifications sans communication préalable.
L'information: [phone] Web: http://www.custompsudesign.com.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
DEUTSCH.
Konfiguration: Der Ausgang wird und gegenwärtiges begrenztes lokalisiert, um der kontrollierten Batterieaufladung
zu ermöglichen.
ANSCHLUSS:
Eingang 12V und 24V: Verstopfen Sie die Maßeinheit in die Zigarette-Feuerzeugeinfaßung des Autos mit dem
bereitgestellten Stecker. Der Mittekontakt ist positiv.
Eingang 48V: Das Eingangskabel hat eine GELBE Markierung. Rote Leitung ist der positive Anschluß. Schwarze
Leitung ist der negative Anschluß. Schmelzsicherung 3.15A T.
AusgangsStecker: Ausgang 15V oder kleiner: Nicht bendet. Ausgang 18V oder grössere, 2.5mm-' Faß' Stecker,
zentrieren Positiv. Rote Leitung oder weiße Linie ist der positive Anschluß. Schwarze Leitung ist der negative
Anschluß. Die Garantie wird nicht beeinflußt, wenn der Käufer einen anderen Stecker paßt.
SPEZIFIKATION:
Ausgang:
Spannung (Last 10%): ± 0.1V des Nennspannungs ± 1,7%.
Regelung, für Änderung der Last 10-90%: 0,5% Plusspannungsabfall des Ausgangskabels.
Regelung für Änderung des Einganges 2V: Maximum 50mV.
Vollaststrom: Sehen Sie Tabelle oben der ersten Seite.
Gegenwärtige Begrenzung: 120% des Vollaststroms, ± 17%.
Niederfrequenzkräuselung: Maximum 200mV.
Eingang: 12V Batterie 24V Batterie 48V Batterie
Eingangsstrecke, ununterbrochen: 10.6V zu 15V. 21.2V zu 30V. 43.2V zu 56V.
Eingangsstrom pro Last 10W: 1A typisch. 0.5A typisch. 0.25A typisch.
EingangsStrom, Keine Last: 0.1A typisch. 0.07A typisch. 0.05A
typisch.Interne Sicherung: 10A T. 5A T. EXTERN.
Allgemein:
Lokalisierung, Eingang zum Ausgang: Minimum 500K am maximum ± 100V.
Schutz: Eingangssicherung. Ausgangsstrombegrenzung.
Größe: 111mm lang, 60mm breit, 30mm hoch.
Gewicht: 380 Gramm.
Umgebende Temperaturspanne: -40 zu +30C funktionierendem, -40 zu +70C Speicher.
Eingangskabellänge: 0,6 Meter, typisch.
Ausgangskabellänge: 0,6 Meter, typisch.
Hersteller: SMET Ltd., Reading, Berkshire, RG7 3BL, Großbr.
SICHERHEITS-WARNING.
Stellen Sie sicher, daß die Batteriespannung für das Modell korrekt ist. Heben Sie nicht die Polarität der
Eingangsspannung auf. Benutzen Sie mindestens Leitung 2mm2, um an die Batterie anzuschließen. Dünne Leitung
verursacht Brandgefährdung. Schmelzsicherung Sie die Batterie nahe der Quelle. Der Fall wird an den negativen
Eingang angeschlossen (modelle 48V werden lokalisiert ± 100V). Lassen Sie nur die Maßeinheit von einer Batterie
laufen. Schließen Sie die Maßeinheit nicht an irgendeine andere nergiequelle an. Innerhalb nur des Gebrauches.
Stellen Sie nicht Feuchtigkeit heraus. Die Maßeinheit läßt heißes wenn unter erhöhter Last laufen. Bedecken Sie nicht.
Trennen Sie die Batterie, bevor Sie die Sicherung ändern. Lassen Sie nicht die Maßeinheit mit der Abdeckung weg
laufen. Drehen Sie sich weg wenn nicht in Gebrauch, Batterieabfluß zu vermeiden. Nicht für Lebenunterstützung
verwendet werden. Verwenden Sie nicht in einem beweglichen Wagen ohne die Vereinbarung des Wagenherstellers.
Verwenden Sie nicht für Marine oder Luftfahrtanwendungen ohne unsere schriftliche Vereinbarung. Diese Ausrüstung
wird auf der Grundlage von den Benutzer geliefert, der die Eignung des Gebrauches feststellt. Wir behalten uns das
Recht vor, die Spezifikation ohne Nachricht zu ändern.
Informationen [phone] Web: http://www.custompsudesign.com.

_________________________________________________________________________________________________________________________________________________________
Registered in England & Wales, Number 2218478. Registered .Office: Bell House, Ashford Hill Road, Ashford Hill, Berks. RG19 8BB. VAT No. (GB) 944 0645 24
ESPAÑOL.
Configuración: La salida se aísla y limitado actual para permitir la carga controlada de la batería.
CONEXIÓN:
Entrada 12V y 24V: Tape la unidad en el zócalo del alumbrador del cigarrillo del coche, usando el enchufe
proporcionado. El contacto del centro es positivo.
Entrada 48V: El cable de la entrada tiene un marcador AMARILLO. El alambre rojo es la conexión positiva. El
alambre negro es la conexión negativa. Fusible 3,15A T.
Conectador De Salida: Salida 15V o menos: No terminado cable. La salida 18V o mayores, los conectadores del '
barril ' de 2.5m m, centra el positivo. El alambre rojo o la línea blanca es la conexión positiva. El alambre negro es la
conexión negativa. La garantía no se afecta si el comprador cabe un diverso conectador.
ESPECIFICACIÓN:
Salida:
Voltaje (carga 10%): ± 0.1V del ± 1,7% del voltaje nominal.
Regulación de la carga (10-90%): 0,5% caídas de voltaje más en cable de la salida.
Regulación, 2V cambio de la entrada: Máximo 50mV.
Corriente de carga completa: Vea la tabla en la parte superior de la primera página.
Límite de la corriente: 120% de la corriente de carga completa, ± 17%.
Ondulación de la frecuencia baja: Máximo 200mV.
Entrada: 12V Batería. 24V Batería 48V Batería
Gama de la entrada, continua: 10,6V a 15V. 21,2V a 30V. 43,2V a 56V.
Corriente de la entrada por la carga 10W: 1A típico. 0,5A típico. 0,25A típico.
Corriente De la Entrada, Ninguna Carga: 0,1A típico. 0,07A típico. 0,05A típico.
Fusible Interno: 10A T. 5A T. EXTERIOR.
General:
Aislamiento, entrada a la salida: Mínimo 500K en el máximo ± 100V.
Protección: Fusible de la entrada. Límite de la corriente de salida.
Tamaño: 111mm largo, 60mm anchos, 30mm altos.
Peso: 380 gramos.
Gama De temperaturas Ambiente: -40 a +30C que funciona, -40 +70C almacenaje.
Longitud de cable de la entrada: 0,6 metros, típico.
Longitud de cable de la salida: 0,6 metros, típico.
Fabricante: SMET Ltd., Reading, Berkshire, RG7 3BL. GB.
ADVERTENCIA DE SEGURIDAD.
Asegúrese de que el voltaje de la batería esté correcto para el modelo. No invierta la polaridad del voltaje de entrada.
Utilice por lo menos el alambre 2mm2para conectar con la batería. El alambre fino causará riesgo de incendios.
Fusible la batería cerca de la fuente. El caso está conectado con la entrada negativa (se aíslan las 48V unidades ±
100V). Funcione solamente la unidad desde una batería. No conecte la unidad con ninguna otra fuente de energía.
Utilice solamente el interior. No exponga a la humedad. La unidad funcionará caliente cuando bajo carga elevada.
No cubra. Desconecte la batería antes de cambiar el fusible. No funcione la unidad con la cubierta apagado.
Dé vuelta apagado cuando no en uso de evitar el dren de la batería. No ser utilizado para la ayuda de la vida.
No utilice en un vehículo sin el consentimiento del fabricante del vehículo.
Este equipo se provee en base del usuario que determina la conveniencia del uso.
Reservamos la derecha de cambiar la especificación sin el aviso.
Información [phone] Web: http://www.custompsudesign.com.
