CVW BeamLink-Lite User manual

Quick Start Guide
Version:1.1
BeamLink-Lite ONE AND A HALF YEAR LIMITED WARRANTY
Postal Code: 518102 Service Hotline: [phone]
Tel.: [phone] Fax: [phone]
E-mail：[e-mail] E-mail：[e-mail]
ADD:F12,F518 Idea Land,Baoyuan Road,Baoan Central Area,Shenzhen,China
BeamLink-Lite

BeamLink-L ite RX
H D M I
S D I H D M I
HDMI input
www.cv-hd.cn
Thank you for choosing professional-grade wireless
HD transmission products manufactured by CVW.
Please read through these instructions carefully
before using the product.
Please switch
the working
frequency in
case of
interference
sources.
After the receiver switches the working frequency, the receiver
OLED screen and the digital tube of the transmitter will display
the number of current frequency point.
Power adapter ( 12V/2A ) × 1
90
Battery
Transmitter
00:00:00
HD M IHD M I
4. Please install the transmitter or battery adapter with
the transmitter. (As shown in the following figure)
Power
--
BeamLink-L ite RX
HD M IHD M I SD I
SD I SD I
SD I
SD I SD I
PRODUCT FEATURES
Two transmitters and one receivers, supporting two channels
of high-definition video transmission at the same time,
one RF channel is required for two channels of videos.
Each channel has a bit rate of 10Mbps, two channels are
transmitted at the same time, the farthest transmission
distance is up to 200 meters, and the image transmission
delay is as low as 70 ms.
The receiver supports two-channel SDI and two-channel
HDMI output interfaces, which can seamlessly interface
with various types of cutting stations.
Simple product installation, convenient operation, flexible
application, eliminating the trouble of wiring for multiple
machines.
PACKING LIST
The following items are included in the product package:
Transmitter
* 2 pieces
Antenna
* 2 pieces
Double screw the
connector*2 pieces HDMI cable *2
Receiver* 1 piece Antenna * 2 pieces
*Note: The transmitter comes with a Sony NP-F battery holder that can
be directly powered by a battery.
Transmitter Installation
1. Please install the antenna to the antenna interface
of the transmitter as shown in the figure and fan it.
( As shown in the following figure)
2. Please fix the transmitter through the 1/4 nut hole at the
bottom or back of the machine body to the position of 1.5-2
meters from the ground. When multiple transmitters work
simultaneously, please ensure that the transmitters are at
least 1 meter apart. (As shown in the following figure)
Distance> 1 m
Transmitter at a height of
around 1.5 to2 meters above floor.
3. Please connect the HDMI video cable between the transmitter
and the camera. (As shown in the following figure)
4. Please install the transmitter or battery adapter with
the transmitter. (As shown in the following figure)
Receiver Installation
1. Please install the antenna to the antenna interface of
the receiver as shown in the figure and fan it.
(As shown in the following figure)
2. Place the receiver 1.5 to 2 meters above the ground.
( As shown in the following figure)
Place the receiver
1.5 to -2 meters
above the ground.
3. Connect the HD video cable between the
receiver and the control panel or monitor.
(As shown in the following figure)
HDMI
output
HDMI output
SDI output
SDI output
Power up and start to use
Please turn on the power switch of the transmitter, receiver and
other related devices in turn. After power-on, the transmitter
digital tube and the OLED screen of the receiver will light up.
When the transmitter and receiver are connected to Wi-Fi, the
transmitter indicator flashes in red. When the Wi-Fi is successfully
connected, the red light is constantly on and the real-time image
can be viewed at the display terminal connected to the receiver.
It is estimated to take 1 minute from powering up the product to
displaying live images.
The two video output ports of the two transmitters and receivers
are in one-to-one correspondence. The transmitter of device
number 1 is displayed on the OLED screen, and the decoded
video will be output through the video port at the Silkscreen
1 on the back of the receiver, and the like.
Description of buttons operation
Usage
Scenario Transmitter Receiver
Cycle through 11 working
frequency points by short
pressing the [CH] button
Cycle through 11 working
frequency points by short
pressing the [CH] button
Press and hold the [CH]
button for 3 seconds to
start the code matching.
Press and hold the [WPS]
button for 3 seconds to start
the code matching.
Please re-match
the codes after
replacing the
device.
The receiver
restarts a certain
decoder board
During the code process, the two-color lamp of
the transmitter will flash alternately, and the receiver
OLED screen will display the character of “WPS”.
Press the [RESET] button shortly to
cycle through the 1st and 2nd cycles
to select the decoder board to be
restarted, then press and hold the
[RESET] button for 3 seconds to
confirm the restart.
