DNC 60 PS
User Guide
CYBELEC SA Tel. ++ 41 24 447 02 00
RUE DES UTTINS 27 Fax ++ 41 24 447 02 01
CH - 1400 YVERDON-LES-BAINS E-Mail: [email protected]
SWITZERLAND
V-DOC-60PS-EN
CYBELEC SA Tel. ++ 41 24 447 02 00
RUE DES UTTINS 27 Fax ++ 41 24 447 02 01
CH - 1400 YVERDON-LES-BAINS E-Mail: [email protected]
SWITZERLAND
V-DOC-60PS-EN

Information in this document is subject to change without notice, and does not represent
a commitment on the part of CYBELEC SA.
The software described in this document is furnished under a licence or nondisclosure agreement. The
software may be used or copied only in accordance with the terms of the agreement. It is against the law
to copy the software on any medium except as specifically allowed in the licence or nondisclosure
agreement.
Copyright CYBELEC SA. 1991
All rights reserved.
Important:
This notice explains normal and standard programming operations for the numerical control.
In view of the fact that numerical controls can be equipped with configurable functions by the press
manufacturer for his own specific purposes, please refer to the manufacturer-supplied complementary
instructions regarding the programming of these functions.
Autocad is a registered trade mark of Autodesk Inc..
CYBELEC is a registered trademark of CYBELEC SA.
Ethernet is a registered trade mark of Xerox Corporation.
IBM , PC/AT , PC Network , Token Ring Network
are registered trade marks of the International Business Machines Corporation.
MS-DOS is a registered trade mark of Microsoft Corporation.
MS-Windows is a registered trade mark of Microsoft Corporation.
Novell Netware is a registered trade mark of Novell, Incorporated.
Windows NT is a registered trade mark of Microsoft Corporation.

SAFETY AND MAINTENANCE INSTRUCTIONS PAGE I
SAFETY AND MAINTENANCE INSTRUCTIONS
The operator must be trained for working with the
machine on which the numerical control is installed.
Improper use of the numerical control can cause
heavy damage on equipment and/or injuries to peo-
ple.
Modification of machine parameters can cause im-
portant material damage or lead to irregular product
quality.
The rear panel may only be removed by a qualified
technician (danger of electrocution).
Do not expose the numerical control to excessive
humidity so as to avoid any risk of electrocution and
any deterioration of the equipment.
Make sure the numerical control is disconnected
from the mains power before carrying out any clean-
ing. Do not use liquids based on alcohol or ammo-
niac.
In case of malfunction of the numerical control, call a
technician.
Do not expose the numerical control to direct sun
rays or any other heat source.
Do not place the numerical control in the neighbour-
hood of magnetic equipment such as transformers,
motors or devices which generate interference (weld-
ing machines, etc.)
Replace fan filters at regular intervals so as to avoid
overheating.

PAGE II USER GUIDE DNC 60 PS
This page has been left blank intentionally.

LICENSE AGREEMENT PAGE III
LICENCE AGREEMENT FOR CYBELEC
SOFTWARE
GENERAL COPYRIGHT
The CYBELEC software is protected by Copyright, and all the copying rights are reserved.
The CYBELEC software may only be installed and used in authorized equipments (PC or DNC).
The user manuals are also covered by copyright, and all rights to use and to copy are reserved.
This document may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced
without prior consent, in writing, from CYBELEC.
SPECIAL DISKETTE COPYRIGHT
The legal users of this software product are authorized only to copy the contents of the diskette into the
memory of the computer to run the program, and to make one backup copy of the original diskette for
safety purposes in case of loss of the original program.
Unauthorized copying, duplicating, selling or otherwise distributing this product is a violation of the law.
SPECIAL EPROM COPYRIGHT
The CYBELEC DNC and CNC units in which the original software made by CYBELEC has been re-
placed by a copy not made by CYBELEC, and without written authorization of CYBELEC, will immedi-
ately lose their warranty.
WARRANTY
CYBELEC does not warrant that its software products will function properly in every computer and
programming environment.
The limitations of use of a software product and its technical specifications are decided by CYBELEC
only; CYBELEC solely is entitled to decide upon conformity and performance of a given software.
The CYBELEC software does not compensate for incompatibilities in operating system revisions or ver-
sions.
Running the CYBELEC software under various revisions or versions, or switching between different
versions or revisions may result in loss or alteration of data.

PAGE IV LICENCE AGREEMENT
SOFTWARE UPDATE SERVICE
Purchase of the CYBELEC software entitles the user, during one year, to delivery of software updates of
the "correction" type.
During the use of a revised or corrected version of the software it may occur that data (program, parame-
ters, etc.) is lost, or that the equipment or its connections need to be modified; these effects are not always
foreseeable and do not engage CYBELEC's responsibility.
TERMINATION
This agreement shall automatically terminate upon any act of bankruptcy by or against licensee, upon any
assignment for the benefit of creditors of the licensee, upon any attachment execution of judgement or
process against licensee or its assets that substantially inhibits its ability to do business, or upon dissolu-
tion of licensee.
CYBELEC has the right to terminate this agreement immediately, should the licensee violate the afore-
mentioned conditions.
Within 30 days of termination of this agreement for any reason, licensee shall at his option, either:
return to CYBELEC or authorized dealer all existent copies of such software and related materials, or
furnish to CYBELEC evidence satisfactory that the original and all copies of the software, in whole
and in any form, have been destroyed.
LIMITATION OF LIABILITY
The foregoing warranty is instead of all other warranties, expressed or implied.
Licensee further agrees that CYBELEC shall not be liable for any lost profits, lost savings, loss of use, or
other incidental or consequential damages arising from the use or inability to use the software, or for any
claim or demand against licensee by any other party.
In no event shall CYBELEC be liable for consequential damages, even if CYBELEC has been advised of
the possibility of such damages.
CYBELEC does not warrant that the functions contained in the software will meet the licensee's require-
ment or that the operation of the software will be totally error free.
Should the software prove defective, the licensee (and not CYBELEC or an authorized dealer or repre-
sentative) will assume the entire cost of all necessary service, repair or correction.
CYBELEC warrants the diskettes, EPROMS or other magnetic support or cassettes on which the pro-
grams are supplied to be free of defects in material and workmanship under normal use for a period of 90
days from the date of shipment to the licensee as evidenced by a copy of the packing slip.

LICENSE AGREEMENT PAGE V
LIMITATION OF REMEDIES
CYBELEC's entire liability and the licensee's exclusive remedy shall be as follows:
The replacement of any diskettes or EPROMS or magnetic support media or cassettes not meeting CY-
BELEC's limited warranty and which materials are returned to CYBELEC or an authorized CYBELEC
representative with a copy of the packing slip, or
If CYBELEC or its representative is unable to deliver replacement diskettes, magnetic support media,
EPROM or cassettes which are free of defects in materials or workmanship, the licensee may terminate
this agreement under the terms and conditions herein mentioned, and the purchaser's money will be re-
funded.
GENERAL
The licensee acknowledges that he has read this agreement, understands it and agrees to be bound by its
terms and conditions.
The licensee agrees to hold CYBELEC harmless on all liability associated with licensee's breach of this
agreement including, but not limited to, all reasonable attorney's fees and court costs, if any.
This licence agreement shall be governed by Swiss law; place of jurisdiction is Lausanne, Switzerland.
MAINTENANCE
CYBELEC will provide one year of software maintenance. The extent of maintenance, and response
time for furnishing same, shall be at the sole discretion of CYBELEC. Maintenance shall normally in-
clude correction of errors in code, correction of errors in supporting documentation, update versions of
the covered software which may be released by CYBELEC during the maintenance period.
In no event shall CYBELEC be obliged to provide technical support in attempting to resolve problems or
difficulties resulting from licensee's modification of the licensed software; any such modification by
licensee is entirely at licensee's own risk.

PAGE VI LICENCE AGREEMENT
This page has been left blank intentionally.

29.09.2006 V. 1.3
N60PS_EN.DOC CONTENTS PAGE 1
CONTENTS
SAFETY AND MAINTENANCE INSTRUCTIONS...........................................................................I
LICENCE AGREEMENT FOR CYBELEC SOFTWARE..................................................................III
Safety, Copyright & Licence agreement..............................................................................3
EASY BEND PAGE..........................................................................................................................5
CREATING A PRODUCT ................................................................................................................7
The sequence page.............................................................................................................7
Programming on the sequence page..................................................................................11
PRODUCT MANAGEMENT.............................................................................................................17
List of products....................................................................................................................17
ANNEX A: CONVENTIONS.............................................................................................................21
Typographical conventions .................................................................................................21
Abbreviations / glossary......................................................................................................21
ANNEX B: THE USER INTERFACE................................................................................................23
The screen...........................................................................................................................23
The keyboard ......................................................................................................................23
ANNEX C: THE MAIN MENU ..........................................................................................................29
Choice of main menu ..........................................................................................................30
ANNEX D: THE MACHINE WORKING MODES .............................................................................31
Adjustment mode ................................................................................................................31
Sensitive mode....................................................................................................................32
Automatic mode ..................................................................................................................32
ANNEX E: TOOL PROGRAMMING.................................................................................................33
Punch / Die programming....................................................................................................34
ANNEX F: PROGRAMMING WITH L-ALPHA.................................................................................37
Programming on the L-alpha page......................................................................................38
L-alpha method ...................................................................................................................43
Definition of the bending order............................................................................................46
ANNEX G: MAINTENANCE AND MISCELANEOUS ......................................................................53
The initialization page..........................................................................................................53
In case of failure..................................................................................................................55

PAGE 2 USER GUIDE DNC 60 PS
The tool reference ..............................................................................................................58
The contact point (CP) or Pinch point ................................................................................ 61
The gauge axes..................................................................................................................62
Programming the axes datum ............................................................................................66
Calibration........................................................................................................................... 66
Ideal curve..........................................................................................................................68
Cycle without bend .............................................................................................................70
Punching.............................................................................................................................70
Bottoming............................................................................................................................71
Angle correction..................................................................................................................71
Alphanumerical characters.................................................................................................73
Messages / Errors ..............................................................................................................73
The interactive messages................................................................................................... 74
ANNEX H: TRANSFER...................................................................................................................76
Tests of the serial ports ......................................................................................................77
CYBACK............................................................................................................................. 78
Internal backup (save)........................................................................................................ 79
Internal restoration of PMs and tools..................................................................................81
ANNEX I: PRINT OF THE CURRENT SCREEN............................................................................84
To print from the DNC ........................................................................................................ 84
HyperTerminal....................................................................................................................85
ANNEX J: PROTECTION OF THE ACCESS LEVELS................................................................... 92
General Information............................................................................................................92
The users............................................................................................................................93
Access by password...........................................................................................................94
Access to levels superior to 3.............................................................................................95
Change password...............................................................................................................96
Management of the access levels by external key.............................................................97
ACCESSORIES...............................................................................................................................98
INDEX..............................................................................................................................................101

FOREWORD PAGE 3
SAFETY,COPYRIGHT &LICENCE AGREEMENT
Please consult the safety instructions, copyright and licence agreement on the
first pages of the manual.
ABOUT THIS MANUAL
This manual is designed to help the user to familiarize with the numerical
control DNC 60 and to use it with a maximum of efficiency.
To reach a maximum of comfort and productivity of the numerical control, it
is recommended to read attentively the whole manual.
A table of contents and a well organized index enable you to find rapidly the
searched subject.
Remark: In this User Guide it is assumed that the DNC has an opera-
tional configuration (i.e. machine parameters and tools are programmed).
This manual is in constant development. You, the user, can help us to give
you better assistance. If you have any remarks on this document, please write
to us at:
CYBELEC S.A.
Dpt Communication
Rue des Uttins 27
CH-1400 Yverdon-les-Bains
Fax ++ 41 24 447 02 01
E-mail: [e-mail]

PAGE 4 USER GUIDE DNC 60 PS
This page has been left blank intentionally.

EASY BEND PAGE PAGE 5
EASY BEND PAGE
The EASY BEND page is accessible by hitting the key twice..
Easy Bend
Th: 2.00 σ45.00 Kg/mm2 Ac_Al_In_
p/d 1/1 CR __/ri 2.78
--MEM-- --POS--
90.0° mes __._°
Y1 293.11 350.92
Y2 293.11 351.05
L 136.0
X1 133.9 51.8
Lp 5000 Fp 78
Rx ___ Start Ext _
Vy __% __% ΔTp _._s
PCV ___
This page makes it possible to quickly programme a bend, and/or briefly stop
production to perform a single bend without modifying or losing data in the
production programme.
PROGRAMMING A BEND
Enter the thickness and the tools if they differ from the product in the
course of production.
To speed up programming, the p/m fields as well as the material are
taken over from sequence 1 of the product currently in hand. The
modification of these data does not affect the programme that is running.
Enter the angle of the bend in the field
Enter the height Lof the wing (external measurement) and the position of
the X gauge will be calculated automatically.
or
directly enter the distance at which the X
gauge is to be positioned.
Enter the length of the bend.
The system automatically calculates the pressure and bending.
Possibly also enter,
ohow long the pressure is to be maintained (if not pro-
grammed, the default is = 0.5 s),
othe retraction of the gauge,
othe reduction in bending speed,
oslow lifting, etc.
L

PAGE 6 USER GUIDE DNC 60 PS
Press the START button or the pedal and the axes will position to the de-
sired values. The numerical command will automatically go into semi-
automatic mode.
Actuate the pedal to bend.
When the beam returns, the DNC switches to programming mode.
You can now enter new data or actuate the pedal for a new bend.
Hit the key to return to production mode.
EXPLANATION OF THE FIELDS
See Explanation of the fields page 8.

CREATING A PRODUCT PAGE 7
CREATING A PRODUCT
This paragraph explains how to programme a product as well as the method
for correcting and recording it.
THE SEQUENCE PAGE
This page displays all the bending information for the current sequence.
That is the requested position of the Y and X (R, etc.) axes, the pressure, the
gauge retraction, the crowning, the dwell time, etc.
Important This page displays the result of the calculations made when programming a
product in the L-alpha page with definition of the bending order.
The operator can modify these values if necessary (especially the retraction,
the dwell time, the top dead centre).
However he must avoid directly modifying the Y and X values calculated by
the DNC.
If modifications should be necessary for these axes, the correction page has
to be used.
Hint An operator can directly programme a product in this page, without "pass-
ing" through the L-alpha page and definition of the bending order.
This simplifies the manipulations a great deal, since all the information re-
quired for the bending are on this page.
To reach the sequence page, press the key.
The first press displays the dimensions page in large characters.
A second press displays all the dimensions and functions of the current se-
quence in small characters.
This page is displayed during the powering-on of the DNC.
To change from one sequence to another, press the or key.
When the last sequence of the program is reached, the small LED of the
key lights up. At this moment, when pressing the key, a new se-
quence is created with the same contents as the last sequence. A message
COPIED is displayed.
On this page, the key is used to move the cursor from one significant
field to another.
The key is used to move the cursor across all the fields. This function
can be deactivated in the machine parameters.
If a product is removed, the data contained in the tool fields, the thickness
field and the material information fields continue to be displayed. This saves
the operator from having to reprogramme unchanged data.

PAGE 8 USER GUIDE DNC 60 PS
P 1 N 1 / 4 CY __
Th: 2.00 45.00 Kg/mm²
p/d 1/ 1 CR __/ri 2.78
--MEM-- --POS-- --COR--
90.0° mes____.__
Y1 293.11 350.92 ____.__
Y2 293.11 351.05 ____.__
L 136.0
X1 133.91 51.85 ____.__
Q ____ ____
Lp 5000 TON 78
Rx _ ___ Ext start _
Vy __% __% ΔT _._s
TDC ___ SP ___
F1:___ F2:___ F3:___ F4:__ F5:__ Cr: 41
EXPLANATION OF THE FIELDS
PNumber of the product in the working memory.
P+ Number of the following product when there is a
sequence of programmes.
NBending order (sequence) number to be made
and the total number of bends for the product.
CY Number of sequence repetitions.
(programmed 0, the sequence is jumped)
Th Material thickness.
The Greek symbol "Sigma" indicates the tensile
and rupture strength.
This field, as well as those showing the type of
material, can be hidden (see the preferences page
in the machine parameters).
If this field is hidden, the default value is steel 45
kg/mm2, but other values can be defined in the ad
hoc field in the machine parameters.
p/d Number of the punch/die pair associated with the
bend to be made.
In the P or D field press to display the list
of tools.
Select the tool in the list then press again to
return.
CR/ri Number of bends requested when working with
ideal curve (min. 4), and internal bending radius.

CREATING A PRODUCT PAGE 9
--MEM-- This column contains either the values calculated
by the system when simulating, or the values
programmed by the operator.
--POS-- This column indicates the real axes' positions.
--COR-- This column contains all the sequence and prod-
uct corrections introduced on the
CORRECTION page.
#The , Y1, Y2,etc. fields are dependant on the axes programmed in
the numerical control.
L Height of the wing after bending. The DNC will
automatically calculate the position of the back
gauge of axis X.
QNumber of product sequence repetitions. Quan-
tity of products to be produced. The Q field is
displayed only if the parameter in the
PREFERENCES page is activated.
Lmat Bending length.
TON Bending force.
Rx Back gauge retraction. The operator indicates in
mm the retraction distance. If nothing is pro-
grammed, the beam doesn't stop at the CP. No
retraction.
If value 0 is introduced, the beam stops at the
CP, then executes immediately the bend without
carrying out a retraction.
The field between the Rx and the retraction
value serves to define the retraction mode.
_ = the beam stops at the CP and waits till the
retraction is made, in order to carry out the
bend.
1 = the beam stops at the CP, then continues
immediately, at the same time as the retrac-
tion is carrying out.
Ext start If nothing is programmed in this field, the axes
start automatically from the BDC, from the CP
or from the TDC, depending on the choice made
in the machine parameters.
If 1is programmed, the start will be made as a
function of the configuration made by the con-
structor.
- In most of the configurations, it will be suffi-
cient to give a down command. At this com-
mand, the axes take position, then a second
down command has to be given, in order to
move the beam.
L

PAGE 10 USER GUIDE DNC 60 PS
- In other configurations, the provided start
button must be pressed.
- When the message TOL ZONE appears, that
means that a down command has been given
and that the axes are not positioned in the
current sequence. Give a start with the pro-
vided button or on the front panel of the
DNC.
Vy Beam bending speed.
Programmed at 0, the speed is 1 mm/s.
Programmed at 9, the speed is 10 mm/s.
(If the machine is capable of reaching this speed)
Vy Rising speed from BDC to CP.
Programmable from 0 (slow) to 9 (fast).
Allows to vary the speed at which the beam rises
to the CP. (Function depending on the machine's
hydraulics).
ΔTDwell time.
TDC Distance from top dead centre.
SP Distance from the beam speed changing point.
(Switch Point).
F1 - F5, Cr Value of the auxiliary functions F1 to F5 and
crowning.
The auxiliary functions are displayed only if the
function is configured.
These fields can also be re-programmed by the user.
However, certain fields are related, that is modifying one provokes a
modification of the other.
