EUROSTER 11E User manual

EUROSTER 11E USER MANUAL 1
EUROSTER 11E
CENTRAL HEATING/UTILITY HOT WATER SYSTEM PUMP CONTROLLER
MANUFACTURER: P.H.P.U. AS, Polanka 8a/3, 1-131 Poznań, POLAND
1 INTRODUCTION
Carefully study this user manual to learn how to correctly operate the EUROSTER 11E central
heating/utility hot water system pump controller.
2 FIELD OF APPLICATION
EUROSTER 11E is a modern microprocessor- ased controller used to control central heating
(CH) system pump or utility hot water (UHW) system pump.
The EUROSTER 11E controller features the ANTY STOP
function that prevents idle pump rotors against seizing. Once
the heating season is over, every 14 days the function
automatically turns ON the pumps for 30 seconds. To that
end the controller must e left powered up.
3 VISIBLE CONTROLLER ELEMENTS
1. 230 VAC~ mains input
2. 230 VAC~ power supply to pump
3. Input for temperature sensor ca le
4. Mains switch
5. LCD display
6. Kno
4 INSTALLATION
Hazardous voltages may be present inside the controller and on its cables.
Therefore it is expressly forbidden to install the device prior to disconnecting
its mains power supply. Only qualified technicians may install the controller.
Do not install any devices showing signs of any mechanical damage.
The procedure:
a) Mount the controller:
using a pair of supplied nylon nail-it fasteners (anchors) mount the controller ox on a

EUROSTER 11E USER MANUAL 2
wall (or any other suita le supporting structure)
using fasteners fix controller ca les to the wall.
b) Install temperature sensors:
do not immerse sensors in liquids nor install them within stream of flue gases
install oiler temperature sensor at the oiler point specially designed for that purpose
or else on an unshielded oiler outlet pipe (as close to the oiler as possi le) or install
UHW tank temperature sensor at the tank point specially designed for that purpose
using hose clips tighten the sensor to its pipe and cover it with thermal insulation.
c) Hook up pump power supply cable:
connect yellow (or yellow-green) PE wire with the terminal
connect lue wire with the N terminal
connect rown wire with the L terminal.
d) Verify the connections:
check up all ca le connections and tighten terminal ox lids.
e) Hook up the controller:
make sure controller cables are protected against incidental cut off
plug the controller power supply ca le into a 230V/50Hz mains socket equipped with a
grounding pin.
The controller must not be installed in a place where the ambient
temperature may exceed 40ºC.
5 CONTROLLER DISPLAY
Elements of the controller display:
1. Name of the controlled parameter (displayed while set point values are rowsed/set)
2. Heat source ( oiler) temperature sensor icon (CH system control mode)
3. Manual operation mode (icon lit while the temperature is manually controlled)
4. Alarm (icon links in case of an alarm)
5. State of the heat source ( oiler) furnace – animated icon, see description elow
6. UHW system pump icon lit while the pump is running (UHW system control mode)
7. CH system pump icon lit while the pump is running (CH system control mode)
8. Heat source ( oiler)/UHW tank temperature (CH system/UHW system control mode,
respectively) / other displayed parameter value
9. UHW tank temperature sensor icon (UHW system control mode)
10. Menu option num er (displayed while set point values are rowsed/set)
Animated icon that visually presents state of the heat source (boiler) furnace is for
information purposes only, it does not influence operation of the controller in any

EUROSTER 11E USER MANUAL 3
way.
Normal operation: <-> supply temperature etween 35ºC and 90ºC
Overheating: <-> supply temperature > 90ºC
Furnace put out: supply temperature < 35ºC
TURNING THE CONTROLLER ON
Turn the controller mains switch (4 in section 3) into the “I” position.
Device firmware version No. and compilation date are sequentially displayed for 2 s.
“AS” letters are linking on the display while the ANTY STOP function turns on the
pump.
State of the system is shown on the display.
If the controller is eing turned on for the first time: select the desired mode of
operation (see section 7 elow) and set the desired controller presets (see section 8
elow).
7 MODE OF OPERATION AND FACTORY (DEFAULT) PRESETS
The EUROSTER E11E controller may e operated in two modes: it may control CH system
pump or UHW system pump. In the former mode the CH system pump is engaged if sensor
temperature has exceeded the preset limit. In the latter mode the UHW system pump is kept
running until sensor temperature reaches the preset value.
Restore one of the factory default presets to change the mode:
Set 1 has een complied for layouts in which CH system pump is controlled
Set 2 has een complied for layouts in which UHW pump is controlled.
Proceed as follows to restore factory presets (e.g. in order to change the controller operational
mode):
Press the kno and while holding it depressed turn the controller off and on.
”Fd” (factory defaults) is displayed.
Release the kno . Digit 0 is displayed.
Select the desired set of defaults (1 or 2) and accept the selection.
Check and correct the presets if needed.
8 CONTROLLER PRESETS
Shortly after power supply of the controller is turned on, current state of the system is shown
on the display. Turn the kno to the right to enter the preset rowse/edit mode. General
procedure to edit a preset:
1. Turn the kno to select the desired preset (parameter). The controller displays current
value of the selected parameter (top) and its num er ( ottom).
2. Press the kno . The displayed parameter value starts to link.
3. Set the desired new value and press the kno to accept it
or
Wait 10 seconds until the displayed parameter value stops linking in order to a ort the
edit procedure (to leave the current value intact)
Configuration windows are num ered to facilitate manipulations. User may edit the following

EUROSTER 11E USER MANUAL 4
controller parameters (presets):
1. Controlled temperature
Threshold temperature at which controller will turn the respective pump ON/OFF.
2. Pump hysteresis
Difference etween the temperature at which the controller turns the pump ON and the
temperature at which the controller turns it OFF. See section 9 elow for details.
3. Temperature sensor correction
A constant added to/su tracted from all values measured y (external) temperature
sensor to compensate for difference in respect to water temperature inside the system.
4. Pump manual operation (test)
Display current pump status commanded y the controller (0/1 = pump
disengaged/engaged).
Press the kno and modify the parameter value to manually control the pump. Press
the kno once more or leave it inactive for 10 seconds to resume automatic mode of
control.
All presets are listed elow for two possi le modes of operation:
●CH central heating pump control mode
●UHW utility hot water pump control mode
Parameter Preset value
Unit
Name default min max
CH UHW CH UHW CH UHW
Controlled temperature 40 60 10 10 80 80 °C
Pump hysteresis 4 4 2 2 10 10 °C
Temperature sensor
correction 0 0 –5 –5 5 5 °C
Pump manual operation
(test)
as calculated y
the controller
as calculated y
the controller
0
(OFF)
0
(OFF)
1
(ON)
1
(ON) -
9 CONTROLLER OPERATION
Central heating pump control mode:
•The pump is engaged as soon as the oiler temperature T oiler has exceeded the preset
threshold Tpreset y more than half of the pump hysteresis Hpump:
Toiler > Tpreset + Hpump/2
•The pump is disengaged as soon as the oiler temperature has dropped elow the
threshold y more than half of the hysteresis:
Toiler < Tpreset – Hpump/2
Utility hot water pump control mode:
•The pump is engaged as soon as the UHW tank temperature Ttank has dropped elow the
threshold Tpreset y more than half of the pump hysteresis Hpump:
Ttank < Tpreset - Hpump/2
•The pump is disengaged as soon as the UHW tank temperature has exceeded the
threshold y more than half of the hysteresis:
Ttank > Tpreset + Hpump/2
10 THE ANTY-STOP FUNCTION
The ANTY-STOP function turns on the pump immediately after the controller is turned on, then
every 14 days. “AS” letters are linking on the controller display while the function is active.
Any alarm generated while the ANTY-STOP function is active (overheating or temperature
sensor failure) a orts the function execution.

EUROSTER 11E USER MANUAL 5
11 TROUBLESHOOTING
a) Device is dead
Burnt mains fuse or ROM failure. Replace the fuse or have the controller serviced.
b) Sensor icon on the display blinks, “Sh” or “OP” letters next to the icon
Sensor circuit shorted (Sh) or opened (OP). Check/replace the sensor ca le or ship the
controller (together with the sensor) to service.
c) Pump does not operate
Turn on the controller and make sure that pump icon is displayed. If not, check the presets or
restore factory ones (see section Błąd: Nie znaleziono źródła odwołania). Check pump
connection.
d) Controller knob operates erratically
Pulse generator failure. Have the controller serviced.
12 COMPATIBILITY WITH STANDARDS/CERTIFICATES
The EUROSTER 11E controller meets all requirements of the EMC and the LVD EU Directives.
The CE Conformity Declaration is availa le on the http://www.euroster.com.pl Internet
we page.
13 SPECIFICATIONS
a) Mains 230 V 50Hz
) Current consumption max. 7 mA (1.6 W)
c) Output rated load 3 A
d) Length of ca les 1,5 m
e) Dimensions (width x height x depth) 150 x 90 x 54 mm
14 KIT CONTENTS
a) controller ox with temperature sensor
) sensor hose clip
c) ox fasteners/anchors
d) this Installation & Operation Manual
e) template to drill holes for fasteners/anchors

EUROSTER 11E USER MANUAL 6
15 CONNECTION DIAGRAMS
Diagrams presented elow are simplified (not every element necessary to correctly operate the
system is shown).
Central heating pump control mode
1. EUROSTER 11E controller
2. CH oiler
3. Heat source temperature sensor
4. CH pump
5. Radiator (heat load)
Utility hot water pump control mode
1. EUROSTER 11E controller
2. UHW tank temperature sensor
3. UHW tank
4. UHW tank pump
5. CH (gas) oiler
6. CH pump
7. Radiator (heat load)

EUROSTER 11E USER MANUAL 7
Utility hot water re-circulation pump control mode (the so called “third pipe”)
1. Controller EUROSTER 11E
2. Re-circulated water temperature
sensor
3. Re-circulation pump
4. CH oiler with UHW tank
5. CH pump
6. Radiator (heat load)
1 ELECTRONIC WASTE MANAGEMENT INFORMATION
We made every effort to get as a long controller lifetime as possi le.
However, the device is su ject to natural tear and wear. We ask you to have
a controller that will not meet your requirements any more rought in to an
electronic waste management facility. Electronic waste is collected free of
charge y local distri utors of electronic equipment.
Inappropriate management of electronic waste may lead to an unnecessary
environment pollution.
Card oard oxes should e disposed of at a paper recycling facility.
