Automatic Voltage Regulator Models
V-Armor600E/1000E/1500E/2000E
User’s Manual K01-C000035-00
IMPORTANT SAFETY INSTRUCTIONS
(SAVE THESE INSTRUCTIONS)
This manual contains important safety instructions. Please read and follow all instructions carefully
during installation and operation of the unit. Read this manual thoroughly before attempting to unpack,
install, or operate your V-Armor.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled
indoor area free of conductive contaminants. (See the specifications for the acceptable temperature and
humidity range.)
CAUTION! To reduce the risk of overheating the V-Armor, do not cover the V-Armor’s cooling vents and
avoid exposing the unit to direct sunlight or installing the unit near heat emitting appliances such as
space heaters or furnaces.
CAUTION! Do not plug the V-Armor input into its own output.
CAUTION! Do not allow liquids or any foreign object to enter the V-Armor. Do not place beverages or
any other liquid-containing vessels on or near the unit.
CAUTION! In the event of an emergency, press the OFF button and disconnect the power cord from the
AC power supply to properly disable the V-Armor.
CAUTION! Unplug the V-Armor prior to cleaning and do not use liquid or spray detergent.
INSTALLING YOUR V-Armor SYSTEM
UNPACKING
The box should contain the following:
(1)V-Armor Unit1; (2) Power Cord1; (3) User Manual1;
Applications
The V-Armor automatically corrects brownouts (by boosting low voltage) and over voltages (by stepping
down high voltage) from the power utility service to levels that are safe for computers, as well as other
sensitive equipment. The V-Armor provides the highest degree of protection from line voltage sags and
swells.
The total power consumption of all equipment plugged into the V-Armor must not exceed the “Maximum
Output Power Capacity” rating listed in the Specifications table.
BASIC OPERATION
FRONT PANEL DESCRIPTION
1. Power Switch
Press the power switch to turn the ON / OFF V-Armor.
2. Normal Mode LED
The green LED will light when utility power is normal.
3. AVR Mode LED
The yellow LED will light when utility power is abnormal and the unit will work in AVR mode.
The yellow LED will flash every 3 seconds when input line voltage is not in acceptable range and the unit
will switch off the outputs.
4. Fault LED
The red LED will light when fault or over load occurs.
REAR PANEL DESCRIPTION
1. AC Inlet
Connect to utility power through the input power cord.
2. Input Circuit Breaker
The circuit breaker provides optimal overload protection.
3. AC outlet
The V-Armor provides outlets for connected equipment to insure temporary uninterrupted
operation during a power failure and against surges and spikes.
4. Fan
The V-Armor provides fan for heat dissipation (for V-Armor1000E/1500E/2000E).
TECHNICAL SPECIFICATIONS
Output Voltage
Regulation
Firmware & Circuit Breaker
Operating Relative
Humidity
Maximum Dimensions
(HxWxD) (mm)
