1
BPSE240V82A
User’s Manual
K01-C000100-00
This manual contains important instructions. Please read and follow all
instructions carefully during installation and operation of the unit. Read
this manual thoroughly before attempting to unpack, install, or operate
the Battery modules.
CAUTION! The UPS unit must be connected to a grounded AC
SAFETY

2
power outlet with fuse or circuit breaker protection. The Battery
modules grounded are through the UPS.
CAUTION! The battery can power hazardous components
inside the unit, even when the AC input power is disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in
a temperature and humidity controlled indoor area, free of
conductive contaminants. (Please see specifications for
acceptable temperature and humidity range).
CAUTION! (No User Serviceable Parts): Risk of electric shock,
do not remove cover. No user serviceable parts inside. Refer
servicing to qualified service personnel.
CAUTION! (Non-Isolated Battery Supply): Risk of electric
shock, battery circuit is not isolated from AC power source;
hazardous voltage may exist between battery terminals and
ground. Test before touching.
CAUTION! Wiring must be done by qualified personnel.
CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS!
To reduce the risk of fire, do not use with or near aquariums.
Condensation from the aquarium can come in contact with
metal electrical contacts and cause the machine to short out.
CAUTION! Do not dispose of batteries in fire as the battery
may explode.
CAUTION! Do not open or mutilate the battery, released
electrolyte is harmful to the skin and eyes.
CAUTION! A battery can present a risk of electric shock and
high short circuit current. The following precaution should be
observed when working on batteries
1. Remove watches, rings or other metal objects.
2. Use tools with insulated handles.

3
CAUTION! Make sure everything is turned off and
disconnected completely before conducting any maintenance,
repairs or shipment.
CAUTION! Connect the Protection Earth (PE) safety conductor
before any other cables are connected.
DO NOT INSTALL THE UNIT WHERE IT WOULD BE EXPOSED
TO DIRECT SUNLIGHT OR NEAR A STRONG HEAT SOURCE!
SERVICING OF BATTERIES SHOULD BE PERFORMED OR
SUPERVISED BY PERSONNEL KNOWLEDGE OF BATTERIES
AND THE REQUIRED PRECAUTIONS. KEEP UNAUTHORIZED
PERSONNEL AWAY FROM BATTERIES!
The box should contain the following:
Battery Module
Battery Cable
User’s manual
UNPACKING

4
SCHEMATIC
FRONT/REAR PANEL DESCRIPTION
BAT OUTPUT+
BAT INPUT+
Breaker
Battery String1 Battery String2
BAT OUTPUT-
BAT INPUT-
Breaker
Terminal Block
Self-locking frame
BASIC OPERATION

5
CONNECTION#1：POWER MODULE (UPS) WITH ONE BATTERY
MODULE
Step 1: First turn off the Breaker, then loosen the screws to remove
the Terminal block Cover of Battery Module.
Step 2: Connect the Battery Cable to Terminal block and ensure the
polarity is right.

6
Step 3: Connect the Battery Cable to UPS and ensure the polarity is
right.
Step 4: Retighten the Terminal Block Cover of Battery Module and
UPS.

7
CONNECTION#2：PARALLEL CONNECTION OF THE BATTERY
MODULE
In order to meet the requirement of the user on longer back-up time,
a special parallel connection of the battery pack is provided below
and the quantity of the battery pack for parallel connection can be
added at will.
Model
BPSE240V82A
Battery
Sealed Maintenance Free Lead Acid Battery
12V / 9Ah x20pcs x2sets
Rated Battery Voltage
240Vdc
Overload Protection
Breaker (100A 125Vdc 3P)
Physical
Maximum Dimensions (HxWxD) (mm)
718x260x550
Weight (kg)
124
Environment
Operating Temperature
0C to 40C
Relative Humidity
0 to 90%(Non-condensing)
For more information, visit www.cpsww.com
All rights reserved. Reproduction without permission is prohibited.
BATTERY OUTPUT BATTERY INPUT BATTERY OUTPUT BATTERY INPUT
TO UPS Battery Module 1 Battery Module 2
-
+
TECHNICAL SPECIFICATION
