CyberPower Paragon OL1000RMXL2U User manual

OL1000RMXL2U
OL1500RMXL2U
OL2000RMXL2U
OL3000RMXL2U
Paragon
Series
UserManual

Pr eface
About this Manual
Thank you for purchasing a CyberPower Systems product to protect
your electrical equipment.
The Paragon series has been designed with the utmost care. We
recommend that
you take the time to read this manual to take full
advantage
of your UPS’s many features.
The Paragon UPS and the optional battery packs that are covered in
this
manual are listed below:
- UPS OL1000RMXL2U (1000VA/700W).
- UPS OL1500RMXL2U (1500VA/1050W).
- UPS OL2000RMXL2U (2000VA/1400W).
- UPS OL3000RMXL2U (3000VA/2100W).
- ABP36VRM-2U (36Vdc, 7Ah, for OL1000RMXL2U and
OL1500RMXL2U).
- ABP72VRM-2U (72Vdc, 9Ah, for OL2000RMXL2U and
OL3000RMXL2U).
To learn more about our entire line of CyberPower Systems products
and
the options available for the Paragon series, visit our web site at
www.cyberpowersystems.com
or contact your local CyberPower
Systems representative.
FCC Notice
This equipment has been tested and found to comply with the limits
for a Class B digital
device, pursuant to part 15 of the FCC rules.
These limits are designed
to provide reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses,
and can radiate radio frequency energy and, if not
installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no
guarantee that interference
will not occur in a particular installation. If
Preface i

this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of
the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver
is connected
• Consult the dealer or an experience radio/TV technician for help
Environment
The Paragon UPS models OL1000RMXL2U, OL1500RMXL2U,
OL2000RMXL2U, and OL3000RMXL2U
are intended for installation
in an environment within 0ºC to
40ºC and free of conductive
contaminants.
CyberPower Systems pays great attention to the environmental
impact of
its products. Environmental protection measures for the
Paragon series include:
• The eco-design approach used in product development.
• Provisions for the recycling of the Paragon unit at the end of its ser-
vice life.
ii Preface

Icon Usage
Read the following section to familiarize yourself with the icons used
in this
manual:
Icon Description
Indicates a hazard to personnel or equipment. These
warnings must always be followed.
Indicates notes, useful tips, and helpful information.
Indicates essential information.
LED off.
LED on.
LED flashing.
Preface iii

Safety Instructions
Read before installing
SAVE THESE INSTRUCTIONS. This manual contains important
instructions that should be followed during
installation, operation,
and maintenance
of the UPS and batteries.
CAUTION: Personal Safety
❑ The UPS has its own internal power source (the battery).
Consequently, the
power outlets may be energized even if the
UPS is
disconnected from the AC power source.
❑ Dangerous voltage levels are present within the UPS. It should be
serviced only
by qualified service personnel.
❑ The UPS must be properly grounded. Measurements should be
taken
to ensure that the total leakage current of the UPS and the
protected equipment does not
exceed 3.5mA (maximum leakage
current of the UPS
= 2mA).
❑ The battery supplied with the UPS contains small amounts of toxic
materials. The
safety warnings below must be followed:
- Never burn the battery (risk of explosion).
- Do not attempt to open the battery (the electrolyte is dangerous
for the
eyes and skin).
- Comply with all applicable regulations for the disposal of a
battery.
- Batteries constitute a danger (electrical shock, burns). The
short-circuit current may be
very high. Precautions must be
taken when handling: remove watches, rings, bracelets and any
other metal objects; use tools with
insulated handles.
- Do not lay tools or metal parts on top of batteries.
iv Safety Instructions

CAUTION: Product Safety
❑ The UPS connection instructions and operation described in the
manual must
be followed in the order indicated.
❑ The UPS must be connected to a nearby wall outlet that is easily
accessible. The UPS can be
disconnected from the AC power
source by removing
the power cord.
❑ Ensure that the electrical specifications on the rating plate for your
AC powered system and the actual
electrical consumption of all
the equipment
to be connected to the UPS are compatible.
❑ Never install the UPS near liquids or in an excessively damp
environment.
❑ Never allow anything to penetrate the UPS.
❑ Never block the ventilation grates of the UPS.
❑ Never expose the UPS to direct sunlight or a source of heat.
❑ If the UPS must be stored prior to installation, storage must be in a
dry place.
❑ The acceptable storage temperature range is -25ºC to +55ºC.
Special Precautions
❑ At least two people are required to move or install the UPS safely.
❑ Once installed and connected to the AC power source for the first
time, the battery will
start to charge. A full charge requires at least
8 hours.
❑ If the UPS is inactive for an extended period, it must be charged
for a period of 24 hours, at least
once every 6 months. This avoids
possible damage.
During the replacement of the battery module, it
is imperative to use the same
type and number of batteries as the
original battery
module to maintain an identical level of
performance and safety. In case
of doubt, do not hesitate to
contact our sales department
or refer to our web site at
www.cyberpowersystems.com.
Safety Instructions v

Contents
Preface .............................................................................i
Safety Instructions
............................................................. iv
Device Overview
.............................................................… .. 1
System configurations ............................................................... .. 1
Rear panel ..............................................................................… 2
Control panel ............................................................................. … 5
Installation ........................................................................…..6
Unpacking ................................................................................. … 6
Installing the UPS in a rack .....................................................… . 7
Setting the UPS in the vertical position ..................................... 8
Connecting the RS232 or the USB communication port (optional)
................................................................................................... .. 9
Installing the optional communication card ............................. . 10
Connections ............................................................................ . 10
Operation .......................................................................… 12
Start-up ................................................................................... .. 12
LED indicators ......................................................................... . 13
Operation on battery power (following AC input power failure) 14
Personalization (option) .......................................................... 15
UPS Shutdown ........................................................................ 19
UPS Remote Power Off ........................................................... 19
Maintenance ................................................................... 21
Troubleshooting ...................................................................... 21
Replacement of the battery module ....................................... 23
Appendix ......................................................................... 25
Technical Characteristics ....................................................... 25
Technical Specifications ...................................................... 25
Limited Warranty and
Connected Equipment Guarantee ................................ 29
vi

1 Device Overview
1.1 System configurations
Rack setup
Model
Dimensions
(WxDxH)(inch)
Weight
(pound)
OL1000RMXL2U 17.24x18.66x3.41 43
OL1500RMXL2U 17.24x18.66x3.41 45.19
OL2000RMXL2U 17.24x25.69x3.41 70.11
OL3000RMXL2U 17.24x25.69x3.41 72.31
Tower setup
Device Overview 1

1.2 Rear panel
Paragon OL1000RMXL2U/OL1500RMXL2U
1 3 4 5 10 11
986 ２ ６ ７ ８ ９
Paragon ABP36VRM-2U (optional)
4 12
8 8
NO Description
1 USB communication port.
2 RS232 communication port.
3 Connector for remote power off (RPO).
4 Connector for automatic detection of an additional battery pack.
5 Expansion slot for optional communication card.
6 Button to test phase/neutral inversion of AC power source.
7 LED indicating Site Wiring Alarm enabled, with flashing and
periodic buzzer. Reset fault with rear panel button.
8 Connector for an additional battery pack.
9 NEMA 5-15P Input power plug for direct connection to AC
power source.
10 Six NEMA 5-15/20R receptacles for connection to AC power source.
11 Two programmable NEMA 5-15/20R receptacles.
12 Circuit breaker for battery ON/OFF and protection.
2 Device Overview

Paragon OL2000RMXL2U/OL3000RMXL2U
8 ８７
7
4 6 10 11 5
3 L5-20R/
L5-30R
L5-30P
(OL3000RMXL2U)
5-20P
(OL2000RMXL2U)
Paragon ABP72VRM-2U (optional)
4 12
8 8
NO
Description
1 USB communication port.
2 RS232 communication port.
3 Connector for remote power off (RPO).
4 Connector for automatic detection of an additional battery pack.
5 Expansion slot for optional communication card.
6 Button to test phase/neutral inversion of AC power source.
7 LED indicating Site Wiring Alarm enabled, with flashing and
periodic buzzer. Reset fault with rear panel button.
8 Connector for an additional battery pack.
9
Input/Output power cords for direct connection of protected equipment.
(5-20P/L5-20R for OL2000RMXL2U; L5-30P/L5-30R for OL3000RMXL2U).
10 Upper two NEMA 5-15/20R receptacles for connection to AC
power source.
11 Lower two NEMA 5-15/20R programmable receptacles.
12 Circuit breaker for battery ON/OFF and protection.
Device Overview 3
１
２
３
９
