CyberPower UP1200 User manual

User’s Manual
Utility Series UPS
UP1200
ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT:
www.cyberpowersystems.com/support.htm

2
TABLE OF CONTENTS
IMPORTANT SAFETY WARNINGS…………….……………………………………….………1
INSTALLING YOUR UPS SYSTEM…………………….………………………………….……2
-UNPACKING…… ………………………………………………………………..2
- HARDWARE INSTALLATION GUIDE…………………………………….……2
BASIC OPERATION…………………………………………...................................................2
- FRONT PANELAND REAR PANEL DESCRIPTION....................................2
BATTERY REPLACEMENT AND STORAGE………………………………………….…...….4
- BATTERY REPLACEMENT PROCEDURE……………………………...……4
TROUBLESHOOTING……………………………………………………….........................….6
TECHNICAL SPECIFICATIONS…………………………………………………….………..….7
DEFINITION FOR ILLUMINATED LED INDICATORS……………………………………..…8
LIMITED WARRANTY AND POWER CONTROL GUARANTEE……………………………9
Thank you for purchasing a CyberPower Systems Product. To enjoy all the features and
benefits of this Uninterruptible Power System (UPS), please read and follow all installation
and operation instructions completely. This UPS is designed to provide guaranteed power
protection for connected electronic equipment. The accompanying PowerPanel Plus™
software saves data, closes open applications and automatically shuts down your
computer system in an intelligent and orderly manner.

UP1200
Guaranteed Uninterruptible Power
System
3
IMPORTANT SAFETY WARNINGS
(SAVE THESE INSTRUCTIONS)
This manual contains important instructions that should be followed during installation and
maintenance of the UPS and batteries. Please read and follow all instructions carefully
during installation and operation of the unit. Read this manual thoroughly before attempting
to unpack, install, or operate.
CAUTION! Live parts inside can be energized by the battery, even when plugged into
an AC outlet with fuse or circuit breaker protection. DO NOT plug unit into an outlet that is
not grounded.
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT
EQUIPMENT! CyberPower Systems does not sell products for life support or medical
applications. DO NOT use in any circumstance that would affect operation or safety of any
life support equipment, with any medical applications, or patient care.
CAUTION! The battery can energize hazardous live parts inside even when AC power
is disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and
humidity controlled indoor area, free of conductive contaminants. (Please see
specifications for acceptable temperature and humidity range).
CAUTION! To reduce the risk of electric shock, do not remove the cover, except to
service the battery. No user serviceable parts inside, except for the battery.
CAUTION! To avoid electric shock, turn off the unit and unplug it from the AC power
source before servicing the battery or installing a computer component.
CAUTION! DO NOT USE WITH OR NEARAQUARIUMS! To reduce the risk of fire, do
not use with or near aquariums. Condensation from the aquarium can cause the unit to
short out.

4
INSTALLING YOUR UPS SYSTEM
UNPACKING
Inspect the UPS upon receipt. The box should contain the following:
(1) UPS Unit; (1) User’s Manual for UPS; (1) Warranty Registration Card;
(1) PowerPanelTM Software Disk; (1) User’s Manual for PowerPanelTM;
(1) Serial Interface Cable (DB-9); (1) Serial-to-USB cable; (1) Telephone Cable
HARDWARE INSTALLATION GUIDE
1. Connect the equipment to your UPS outlets. Items such as copiers, laser printers,
vacuums, space heaters, paper shredders, or other large electrical devices should not
be connected to the UPS. Please assure that the total loads of your equipments must be
less than the maximum total power load of your UPS.
2. Connect your UPS power cord into a two-pole, three-wire
grounding receptacle only. Please avoid using extension
cords and adapter plugs. (To maintain optimal battery
charge, leave the UPS plugged in at all times.)
3. Press the UPS power button to turn it on. The “Power On” indicator will be illuminated in
“Green”.
4. Install your optional software and accessories. To use the software, simply connect the
enclosed serial interface cable to the serial port on the UPS and an open serial port on
the computer.
BASIC OPERATION
FRONT PANEL AND REAR PANEL DESCRIPTION

UP1200
Guaranteed Uninterruptible Power
System
5
◆ Power Switch
Press the power button to turn the UPS ON or OFF
◆ Power On Indicator
This LED is illuminated when the utility condition is normal and the UPS
outlets are providing “clean power”, free of surges and spikes
◆ Using Battery Indicator
This illuminates during utility failure, indicating that the battery is
supplying power to the battery-power supplied outlets.
◆ Battery Backup and Surge Protection Outlets
Provides three battery powered and surge protected outlets for
connected equipment to insure temporary uninterrupted operation
during a power failure and against surges and spikes.
◆ Surge Protection Outlets
Provides three surge protected only outlets for connected equipment
against surges and spikes
◆ Wiring Fault Indicator
This LED indicator will illuminate to warn the user that a wiring problem
exits with theAC outlet, such as bad ground, miss ground or reversed
wiring. If this is illuminated, the user is advised to disconnect all electrical
equipment from the outlet and have an electrician check the
outlet to insure proper wiring.
◆ Circuit Breaker Reset for Overload Protection
Circuit breakers provide optimal overload protection. When overload
occurs, the circuit breaker will switch to battery mode. You will need to
reset the circuit breaker so UPS will provide the power from utility.
◆ Serial Port to PC
This port allows connection and communication from the DB-9 serial or
USB port on the computer to the UPS unit. The UPS communicates its
status to the PowerPanel Plus™ software. This interface is also
compatible with the UPS service provided by Windows NT, Windows
2000, and Windows XP.
◆ Ethernet/Phone (RJ-45/RJ-11) Protection Ports
These ports are the protection for your computer network cable,
modem or telephone.

6
BATTERY REPLACEMENT AND STORAGE
Contact your dealer or call the number in this manual for information on battery
replacement. The order numbers for the battery are as follows:
BA-UP1200 for UP1200
CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing
the battery. Service the battery under the supervision of personnel knowledgeable of
batteries and their precautions. Keep unauthorized personnel away from batteries.
CAUTION! Use only the specified type of battery. See your dealer for replacement
batteries.
CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries
in a fire, as it may explode. Follow all local ordinances regarding proper disposal of
batteries.
CAUTION! Do not open or mutilate the batteries. Release electrolyte is harmful to the skin
and eyes and may be toxic.
CAUTION! A battery can present a high risk of short circuit current and electric shock. Take
the following precautions before replacing the battery:
1. Remove all watches, rings or other metal objects.
2. Only use tools with insulated handles.
3. DO NOT lay tools or other metal parts on top of battery or any battery terminals.
4. Wear rubber gloves and boots.
5. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove
source of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN
ELECTRICAL SHOCK! The likelihood of such shock will be reduced if such grounds
are removed during installation and maintenance (applicable to a UPS and a remote
battery supply not having a grounded circuit).
BATTERY REPLACEMENT PROCEDURE:
1. Turn off and unplug all connected equipment.
2. Turn the UPS off and unplug it from the AC power source.
3. Turn the UPS upside down.
4. Remove the 4 retaining screws.
5. Push the battery cover backward and remove the cover.
6. Rotate the UPS from vertical to horizontal.
7. Remove the battery from the compartment.
8. Disconnect the battery wires from the battery.

UP1200
Guaranteed Uninterruptible Power
System
7
8. Install the replacement battery by connecting the red wire to
the positive (+) terminal of the battery and connecting the black
wire to the negative (-) terminal of the battery.
9. Slide the battery back into the compartment.
10. Replace the cover and the 4 retaining screws.
11. Recharge the unit for 4 – 8 hours to ensure the UPS
performs expected runtime.
REMINDER: Batteries are consider HAZARDOUS WASTE and must be disposed of
properly. Contact your local government for more information about proper disposal and
recycling of batteries.
STORAGE:
First turn off your UPS and disconnect its power cord from the wall outlet. Disconnect all
cables connected to the UPS to avoid battery drain. To store your UPS for an extended
period, cover it and store with the battery fully charged. Recharge the battery every three
months to insure battery life. If the battery remains uncharged for an extended period of
time, it may suffer permanent loss of capacity.

8
TROUBLESHOOTING
Problem Possible Cause Solution
Batteries are not fully charged. Recharge the battery by leaving the
UPS plugged in.
The UPS does not
perform expected
runtime. Battery is slightly worn out. Contact CyberPower Systems at
[e-mail]
The on/off switch is designed to
prevent damage by rapidly turning
it off and on.
Turn the UPS off. Wait 10 seconds
and then turn the UPS on.
The unit is not connected to an
AC outlet. The unit must be connected to a 110/120v 60Hz outlet.
The battery is worn out. Contact CyberPower Systems at
[e-mail]
The UPS will not
turn on.
Mechanical problem. Contact CyberPower Systems at
[e-mail]
Circuit breaker is tripped due to
overload Turn the UPS off and unplug at least one piece of equipment. Wait 10
seconds, reset the circuit breaker
and then turn the UPS on.
Batteries are discharged Allow the unit to recharge for at least
4 hours.
Outlets do not
provide power to
equipment
Unit has been damaged by a
surge or spike. Contact CyberPower Systems at [e-mail]
The serial cable is not connected. Connect the serial cable to the
UPS unit and an open serial
port on the back of the
computer. You must use the
cable that came with the unit.
The serial cable is connected to
the wrong port. Check the back of the computer for an additional
serial port. Move the cable to
this port.
The unit is not providing battery
power. Shutdown your computer and turn the UPS off. Wait 10
seconds and turn the UPS
back on. This should reset the
unit.
PowerPanel™ is
inactive (all icons
are gray).
The serial cable is not the cable
that was provided with the unit. You must use the cable that was included with the unit for
the software and the unit to be
able to communicate.

UP1200
Guaranteed Uninterruptible Power
System
9
TECHNICAL SPECIFICATIONS
Model UP1200
Capacity (VA) 1200VA
Capacity (Watts) 670W
Input
Input Voltage Range 100Vac – 140Vac
Frequency Range 57 – 63 Hz
Output
On Battery Output Voltage Simulated Sine Wave at 120Vac +/- 5%
On Battery Output Frequency 60 Hz +/- 1%
Transfer Time (Typical) 4ms
Overload Protection On Utility: Circuit Breaker, On Battery: Internal Current Limiting
Surge Protection and Filtering
Lightning / Surge Protection Yes
Internet Ready (DSL / Phone /
FAX / Modem Protection) RJ11/RJ45 (One In/One Out)
Physical
Total # of UPS Receptacles 4 for UPS, 4 for Surge
Maximum Dimensions 31.0cm*14.1cm*18.1cm
Weight 12.3kg
Battery
Sealed Maintenance Free Lead
Acid Battery 12V / 7.2AHx2
Replaceable Yes
Typical Recharge Time 8 Hours
Warning Diagnostics
Indicators Power On, Using Battery, Wiring Fault
Audible Alarms On Battery, Low Battery, Overload
Environmental
Operating Temperature +32°F to 95°F ( 0°C to 35°C )
Operating Relative Humidity 25% to 85% Non Condensing
Communication
PowerPanelTM Software Windows 95/98/ME/NT/2000/XP
Management
Self-Test Yes
Auto-Charger Yes
Auto-Restart Yes
USB Yes

10
DEFINITIONS FOR ILLUMINATED LED INDICATORS
Power
On
Using
Battery
Wiring
Fault
Circuit
Breaker
Alarm
Condition
On Off Off Set Off
Normal
Off On On/Off Set Two
Beeps Utility Failure- The UPS is providing battery power
to the Battery-Power Supplied outlets.
Off On On/Off Set
Rapid
Beeps Utility Failure- The UPS is providing battery
power. The rapid beeps indicate the battery will
run out of charge within a few minutes.
Off On Off Up
Two
beeps
or
rapid
beeps
Overload- Occurs in the Full-time Surge
Protection Outlets. Turn the UPS off and unplug
at least one piece of equipment from the UPS.
Wait 5 seconds, reset the circuit breaker and turn
the UPS on.
Off
On/Off On/Off Set Long
Beep
Overload- Occurs in the Battery-power Supplied
Outlets. Turn the UPS off and unplug at least one
piece of equipment from the UPS. Wait 5
seconds, reset the circuit breaker and turn the
UPS on.
On/Off On/Off On Set/Up None
Electrical Wiring Fault- This indicates a wiring a
problem such as a bad ground, missed ground or
reversed wiring within the AC outlet. User is
advised to disconnect all electrical equipment
from the outlet and have the outlet checked by an
electrician.
