CyberView X5 User manual
ENGLISH
1
User’s Manual
CyberView X5
ENGLISH
ENGLISH
3
ENGLISH
2
TABLE OF CONTENTS
Getting Started 4
Quick Installation Guide (QIG) 6
Installing Software and Driver 8
Installing Hardware
Loading 120 Films into the Holder 10
Loading 120 Film Holder into the Scanner 13
Loading 135 Film into the Holder 14
Loading 135 Mounted Slides into the Holder 16
Loading 135 Film and Slide Holder into Scanner 16
How to Scan 17
STEP 1 - Powering On the Scanner 17
STEP 2 - Select Film Type 17
STEP 3 - Optional Prescan 18
STEP 4 - Set Scan Settings 18
STEP 5 - Set Scan Preferences 20
STEP 6 - Scan
STEP 7 - Exit 24
User Interface
Menu Commands
Scan 2
Preview 2
Image Adjustm
Window 3
Help 3
Function Bar Diagram / Toolbar Diagram
Active Frame Setting Area 3
Technical Support 3
FEDERAL COMMUNICATIONS COMMISSION
(FCC)STATEMENT
This Equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment oand on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
X Re-orient or relocate the receiving antenna.
X Increase the separation between the equipment and receiver.
X Connect the equipment into an outlet on a circuit dierent from which
the receiver is connected to.
X Consult the dealer or an experienced radio/TV technician for help.
Warning :
Use only shielded signal cables to connect I/O devices to this equipment.
You are cautioned that changes or modications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
2
ENGLISH
3
ENGLISH
2
TABLE OF CONTENTS
Getting Started 4
Quick Installation Guide (QIG) 6
Installing Software and Driver 8
Installing Hardware
Loading 120 Films into the Holder 10
Loading 120 Film Holder into the Scanner 13
Loading 135 Film into the Holder 14
Loading 135 Mounted Slides into the Holder 16
Loading 135 Film and Slide Holder into Scanner 16
How to Scan 17
STEP 1 - Powering On the Scanner 17
STEP 2 - Select Film Type 17
STEP 3 - Optional Prescan 18
STEP 4 - Set Scan Settings 18
STEP 5 - Set Scan Preferences 20
STEP 6 - Scan
STEP 7 - Exit 24
User Interface
Menu Commands
Scan 2
Preview 2
Image Adjustm
Window 3
Help 3
Function Bar Diagram / Toolbar Diagram
Active Frame Setting Area 3
Technical Support 3
FEDERAL COMMUNICATIONS COMMISSION
(FCC)STATEMENT
This Equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment oand on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
X Re-orient or relocate the receiving antenna.
X Increase the separation between the equipment and receiver.
X Connect the equipment into an outlet on a circuit dierent from which
the receiver is connected to.
X Consult the dealer or an experienced radio/TV technician for help.
Warning :
Use only shielded signal cables to connect I/O devices to this equipment.
You are cautioned that changes or modications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
3
ENGLISH
7
ENGLISH
6
Check the package content before getting started.
For Quick Installation please refer to Quick Installation Guide. (Pg. 9).
Important! Save the original box, receipt and packing material for future
shipping needs or to return for warranty issues.
Package Contents
X Scanner unit.
X Medium format lm holder for one or two frames (6 x 4.5 cm, 6 x 6 cm),
one frame (6 x 7 cm, 6 x 8 cm, 6 x 9 cm, 6 x 12 cm).
X 135 lm holder.
X 135 slide holder.
X Power Adapter.
Warning! Using any other power adapter may severely damage the scan-
ner and will void the product warranty.
X USB 2.0 Cable.
X CyberView Driver.
X Application software CD for scan editing.
X Printed User’s Manual.
NOTE:
X Application software means the imaging software such as Adobe®
Photoshop® Elements, this is subject to change without notice.
GETTING STARTED
GENERAL GUIDANCE:
X Only use the supplied USB-cable. Connect the scanner to the computer
directly using the USB 2.0 cable.
X Do not use a Hub or extension cable. Only use the USB ports on the back
of desktop computers.
X If there are any other devices (multifunction device, printers, scanners,
webcam) connected to the computer through USB disconnect them.
X A minimum of 1GB RAM (PC/Mac) is required.
Operating Ambient Temperature Range
50º to 104ºF (10º to 40ºC)
Note:Do not turn on the scanner unless it is within this range. If the
scanner has been stored or transported outside of this range,
allow it to return
to within this range before turning it on.
Operating Ambient Humidity Range 15% to 76% relative
humidity (non-condensing)
Note:If the scanner is stored or to be transported in cold temperature
and then brought into a warm / humid environment
condensation may occur.
This device is designed solely for private use and is not intended for commercial
use. The warranty is reduced from 2 years to 1 year if errors or defects arising from
inappropriate use, improper operation or stress occur. The guarantee period of the
device for private use is 2 years or 20,000 scans.
4
ENGLISH
7
ENGLISH
6
Check the package content before getting started.
For Quick Installation please refer to Quick Installation Guide. (Pg. 9).
Important! Save the original box, receipt and packing material for future
shipping needs or to return for warranty issues.
Package Contents
X Scanner unit.
X Medium format lm holder for one or two frames (6 x 4.5 cm, 6 x 6 cm),
one frame (6 x 7 cm, 6 x 8 cm, 6 x 9 cm, 6 x 12 cm).
X 135 lm holder.
X 135 slide holder.
X Power Adapter.
Warning! Using any other power adapter may severely damage the scan-
ner and will void the product warranty.
X USB 2.0 Cable.
X CyberView Driver.
X Application software CD for scan editing.
X Printed User’s Manual.
NOTE:
X Application software means the imaging software such as Adobe®
Photoshop® Elements, this is subject to change without notice.
GETTING STARTED
GENERAL GUIDANCE:
X Only use the supplied USB-cable. Connect the scanner to the computer
directly using the USB 2.0 cable.
X Do not use a Hub or extension cable. Only use the USB ports on the back
of desktop computers.
X If there are any other devices (multifunction device, printers, scanners,
webcam) connected to the computer through USB disconnect them.
X A minimum of 1GB RAM (PC/Mac) is required.
Operating Ambient Temperature Range
50º to 104ºF (10º to 40ºC)
Note:Do not turn on the scanner unless it is within this range. If the
scanner has been stored or transported outside of this range,
allow it to return
to within this range before turning it on.
Operating Ambient Humidity Range 15% to 76% relative
humidity (non-condensing)
Note:If the scanner is stored or to be transported in cold temperature
and then brought into a warm / humid environment
condensation may occur.
This device is designed solely for private use and is not intended for commercial
use. The warranty is reduced from 2 years to 1 year if errors or defects arising from
inappropriate use, improper operation or stress occur. The guarantee period of the
device for private use is 2 years or 20,000 scans.
5
ENGLISH
7
ENGLISH
6
Scanner - front view
Scanner - rear view
Power button
Scan button
LED light
Opening for 135 lm & slide holder
Opening for 120 lm
DC power
USB 2.0 port
QUICK INSTALLATION GUIDE (QIG)
Opening for 135 lm & slide holder
INSTALLING SOFTWARE AND DRIVER
for PC (Windows) User
WINDOWS SYSTEMS INSTALLATION: DURING DRIVER INSTALLATION A WARNING
DIALOGUE BOX MAY APPEAR, IF THIS IS THE CASE PLEASE SELECT “INSTALL THIS
DRIVER ANYWAY”.
Be sure to install the Application Software (ex: Adobe® Photoshop®
Elements) BEFORE installing the CyberView scanner driver software.
You may install the scanner driver directly if you have already installed TWAIN
compliant application software on your computer (i.e. photo editing
software). Mac users can use iPhoto for editing.
1. Place the application software DVD into the DVD drive. If you have CD
autoplay disabled, right click and select“Explore”. Select “AutoPlay.exe”
and follow the on-screen instructions to complete the installation.
2. Place the CyberView CD into the drive. If you have CD/DVD autoplay
disabled, right click and select “Explore” (ex.: D:\Install\Drivers\Pack-
age\CVX.exe), double click the le “CVX.EXE” and follow the on-screen
instructions to complete the installation.
3. Restart your computer.
4. Once the drivers have been installed, connect the scanner. Verify that
the scanner is switched OFF (light on the front is not lit) and connect
the scanner to a power source. Then connect the scanner to a live USB
port. When using desktop PC, connect the scanner to rear ports only,
hub extensions and long USB cables are not supported.
5. Switch on the power. The scanner is now ready to work.
Windows operating system should state “New hardware detected“, and should
begin installing or request to select an option - select “Locate and install driver
software”.
NOTE: Not all PC’s will display the found new hardware window, some will install
in the background.
6
ENGLISH
7
ENGLISH
6
Scanner - front view
Scanner - rear view
Power button
Scan button
LED light
Opening for 135 lm & slide holder
Opening for 120 lm
DC power
USB 2.0 port
QUICK INSTALLATION GUIDE (QIG)
Opening for 135 lm & slide holder
INSTALLING SOFTWARE AND DRIVER
for PC (Windows) User
WINDOWS SYSTEMS INSTALLATION: DURING DRIVER INSTALLATION A WARNING
DIALOGUE BOX MAY APPEAR, IF THIS IS THE CASE PLEASE SELECT “INSTALL THIS
DRIVER ANYWAY”.
Be sure to install the Application Software (ex: Adobe® Photoshop®
Elements) BEFORE installing the CyberView scanner driver software.
You may install the scanner driver directly if you have already installed TWAIN
compliant application software on your computer (i.e. photo editing
software). Mac users can use iPhoto for editing.
1. Place the application software DVD into the DVD drive. If you have CD
autoplay disabled, right click and select“Explore”. Select “AutoPlay.exe”
and follow the on-screen instructions to complete the installation.
2. Place the CyberView CD into the drive. If you have CD/DVD autoplay
disabled, right click and select “Explore” (ex.: D:\Install\Drivers\Pack-
age\CVX.exe), double click the le “CVX.EXE” and follow the on-screen
instructions to complete the installation.
3. Restart your computer.
4. Once the drivers have been installed, connect the scanner. Verify that
the scanner is switched OFF (light on the front is not lit) and connect
the scanner to a power source. Then connect the scanner to a live USB
port. When using desktop PC, connect the scanner to rear ports only,
hub extensions and long USB cables are not supported.
5. Switch on the power. The scanner is now ready to work.
Windows operating system should state “New hardware detected“, and should
begin installing or request to select an option - select “Locate and install driver
software”.
NOTE: Not all PC’s will display the found new hardware window, some will install
in the background.
7
ENGLISH
9
ENGLISH
8
Installing Scanner Driver
a. Insert driver CD into the computer CD/DVD drive and look at the contents
with “Finder”.
b. Double click the ”CyberView ” icon to begin the installation process.
Follow the onscreen prompts to complete the installation process.
NOTE: Make sure the scanner is NOT connected to the computer during the
CyberView driver installation.
c. Restart the computer once the installation process is complete.
INSTALLING HARDWARE
for PC (Windows) and Mac (OSX) Users
Connect the scanner to a power source:
1. Plug the AC adapter into an AC power source FIRST before plugging it
into the scanner.
2. Attach the USB cable to the computer using the standard USB adapter
end. Attach the USB adapter end of the cable to back panel of the
scanner.
3. Switch on the power on the front side of the scanner.
INSTALLING SOFTWARE AND DRIVER
for Mac (OSX) User
Before Installing the scanner driver...
If you choose to use the provided application for image editing, install the
application software (ex: Adobe® Photoshop® Elements) by inserting the
application CD into the computer’s CD/DVD drive. Follow the instructions that
will be displayed in a window that opens automatically. If you have the iPhoto
application (or other photo editing software) installed on your Mac, you can skip
this step.
For instructions on loading lm into holders continue on p. 11.
If you are familiar with loading lm into lm holders skip to p. 18.
TWAIN scanner plug-in Installation Guide for Adobe Photoshop Elements 9
and newer versions
The TWAIN scanner plug-in is no longer installed with Photoshop Elements 9.
In order to be able to import scanner device through Adobe Photoshop ele-
ments, please follow below instructions after installing Adobe Photoshop
Elements 9 to nd where and how to install the TWAIN component which was
previously installed with the application for versions earlier than Photoshop
Elements 9.
Important: Do not move plug-ins from previous versions of Photoshop Elements
into the Photoshop Elements 9 > Plug-Ins folder, or set the Photoshop Elements
8 (or earlier) > Plug-In folder as the Additional Plug-Ins Folder in Preferences.
Find complete information at ocial Adobe website:
http://kb2.adobe.com/cps/849/cpsid_84933.html
Macintosh
To install the legacy TWAIN plug-in for Macintosh, copy TWAIN.plugin folder
from: //Applications/Adobe Photoshop Elements 9/Optional Plug-Ins/Import-
Modules/
Into: //Applications/Adobe Photoshop Elements 9/Locales/<locale>/Plug-Ins/
Windows
To install the legacy TWAIN plug-in for Windows, copy twain_32.8ba from:
C:\Program Files\Adobe\Photoshop Elements 9\Optional Plug-Ins\Import-
Export\
Into: C:\Program Files\Adobe\Photoshop Elements 9\Locales\<locale>\Plug-Ins\
Import-Export\
64-bit Windows
Photoshop Elements 9 is a 32-bit application. When installed on a 64-bit version
of Windows the path is slightly modied.
To install the legacy TWAIN plug-in for Windows, copy twain_32.8ba from:
C:\Program Files (x86)\Adobe\Photoshop Elements 9\Optional Plug-Ins\Import-
Export\
Into: C:\Program Files (x86)\Adobe\Photoshop Elements 9\Locales\<locale>\
Plug-Ins\Import-Export\
8
ENGLISH
9
ENGLISH
8
Installing Scanner Driver
a. Insert driver CD into the computer CD/DVD drive and look at the contents
with “Finder”.
b. Double click the ”CyberView ” icon to begin the installation process.
Follow the onscreen prompts to complete the installation process.
NOTE: Make sure the scanner is NOT connected to the computer during the
CyberView driver installation.
c. Restart the computer once the installation process is complete.
INSTALLING HARDWARE
for PC (Windows) and Mac (OSX) Users
Connect the scanner to a power source:
1. Plug the AC adapter into an AC power source FIRST before plugging it
into the scanner.
2. Attach the USB cable to the computer using the standard USB adapter
end. Attach the USB adapter end of the cable to back panel of the
scanner.
3. Switch on the power on the front side of the scanner.
INSTALLING SOFTWARE AND DRIVER
for Mac (OSX) User
Before Installing the scanner driver...
If you choose to use the provided application for image editing, install the
application software (ex: Adobe® Photoshop® Elements) by inserting the
application CD into the computer’s CD/DVD drive. Follow the instructions that
will be displayed in a window that opens automatically. If you have the iPhoto
application (or other photo editing software) installed on your Mac, you can skip
this step.
For instructions on loading lm into holders continue on p. 11.
If you are familiar with loading lm into lm holders skip to p. 18.
TWAIN scanner plug-in Installation Guide for Adobe Photoshop Elements 9
and newer versions
The TWAIN scanner plug-in is no longer installed with Photoshop Elements 9.
In order to be able to import scanner device through Adobe Photoshop ele-
ments, please follow below instructions after installing Adobe Photoshop
Elements 9 to nd where and how to install the TWAIN component which was
previously installed with the application for versions earlier than Photoshop
Elements 9.
Important: Do not move plug-ins from previous versions of Photoshop Elements
into the Photoshop Elements 9 > Plug-Ins folder, or set the Photoshop Elements
8 (or earlier) > Plug-In folder as the Additional Plug-Ins Folder in Preferences.
Find complete information at ocial Adobe website:
http://kb2.adobe.com/cps/849/cpsid_84933.html
Macintosh
To install the legacy TWAIN plug-in for Macintosh, copy TWAIN.plugin folder
from: //Applications/Adobe Photoshop Elements 9/Optional Plug-Ins/Import-
Modules/
Into: //Applications/Adobe Photoshop Elements 9/Locales/<locale>/Plug-Ins/
Windows
To install the legacy TWAIN plug-in for Windows, copy twain_32.8ba from:
C:\Program Files\Adobe\Photoshop Elements 9\Optional Plug-Ins\Import-
Export\
Into: C:\Program Files\Adobe\Photoshop Elements 9\Locales\<locale>\Plug-Ins\
Import-Export\
64-bit Windows
Photoshop Elements 9 is a 32-bit application. When installed on a 64-bit version
of Windows the path is slightly modied.
To install the legacy TWAIN plug-in for Windows, copy twain_32.8ba from:
C:\Program Files (x86)\Adobe\Photoshop Elements 9\Optional Plug-Ins\Import-
Export\
Into: C:\Program Files (x86)\Adobe\Photoshop Elements 9\Locales\<locale>\
Plug-Ins\Import-Export\
9
ENGLISH
11
ENGLISH
10
120 lm holder
Loading 120 lm into the holder
Tabs
Lock
Tabs
Upper Magnetic
Film Guide
Lower Magnetic
Film Guide
Loading 120 lm into the holder (continued)
1. As illustrated above, turn the holder with the embossed arrow
facing towards the left, so that the lock on the holder is at the bot-
tom.
2. Open the two magnetic lm holder guides on the sides of the holder
by pulling on the tabs of the guides upwards.
Tabs
Lock
Tabs
Opened
guide
Closed
guide
Upper Magnetic
Film Guide
Lower Magnetic
Film Guide
Unlockedlocked
ABC
10
ENGLISH
11
ENGLISH
10
120 lm holder
Loading 120 lm into the holder
Tabs
Lock
Tabs
Upper Magnetic
Film Guide
Lower Magnetic
Film Guide
Loading 120 lm into the holder (continued)
1. As illustrated above, turn the holder with the embossed arrow
facing towards the left, so that the lock on the holder is at the bot-
tom.
2. Open the two magnetic lm holder guides on the sides of the holder
by pulling on the tabs of the guides upwards.
Tabs
Lock
Tabs
Opened
guide
Closed
guide
Upper Magnetic
Film Guide
Lower Magnetic
Film Guide
Unlockedlocked
ABC
11
ENGLISH
13
ENGLISH
12
3. To scan a 3rd frame in the strip you will need to remove the strip
and rotate it 180 degrees so the writing on the edges is now
inverted
NOTE: Make sure that the lm is as at as possible between the lm guide
holders (see below).
ABC
ex.: curved lm INCORRECT
ex.: attened lm CORRECT
4. Orient the lm as illustrated the text on the lm edges will read ABC.
Align the lm with the triangle mark in the upper left corner. Close
the upper lm guide rst.
Loading 120 lm into the holder (contin-
ued)
X Insert the holder into the front of the scanner, pushing it in as far as it will
go.
X To release the holder, gently pull it out.
Loading 120 lm holder into scanner
ex.: correctly positioned lm, lower left corner at the triangle
mark
ex.: incorrectly positioned lm, not aligned with triangle mark
ABC
ABC
Note: Orientation of scanner in the diagrams is from the front of the unit. Take
note of the curved edge of the 120 lm holder also facing towards the front of
the scanner for correct orientation when loading the scanner.
12
ENGLISH
13
ENGLISH
12
3. To scan a 3rd frame in the strip you will need to remove the strip
and rotate it 180 degrees so the writing on the edges is now
inverted
NOTE: Make sure that the lm is as at as possible between the lm guide
holders (see below).
ABC
ex.: curved lm INCORRECT
ex.: attened lm CORRECT
4. Orient the lm as illustrated the text on the lm edges will read ABC.
Align the lm with the triangle mark in the upper left corner. Close
the upper lm guide rst.
Loading 120 lm into the holder (contin-
ued)
X Insert the holder into the front of the scanner, pushing it in as far as it will
go.
X To release the holder, gently pull it out.
Loading 120 lm holder into scanner
ex.: correctly positioned lm, lower left corner at the triangle
mark
ex.: incorrectly positioned lm, not aligned with triangle mark
ABC
ABC
Note: Orientation of scanner in the diagrams is from the front of the unit. Take
note of the curved edge of the 120 lm holder also facing towards the front of
the scanner for correct orientation when loading the scanner.
13
ENGLISH
15
ENGLISH
14
b. Open the lm holder by pulling down on the tab
from the bottom center of the holder. Lift the front
part of the holder. The top side of the holder
is marked with white arrows.
Loading 135 lm into the holder
a. Orient lm strip based on
the example graphic“abc”
on the holder.
135 lm holder
abc
abc
abc
Pull
down
White arrows
Lift
open
e. Insert the lm holder into the scanner from the left or right side into the
small opening. Push the holder inside until you feel it hit a stop, then scan.
After the scan is done, push the holder farther into the scanner until it hits
another stop, and scan again. Repeat until the end of the holder.
Make sure that the orientation of white arrows on the holder correspond
with the triangle mark on the scanner.
c. lnsert the orientated lm negative into the holder between the
horizontal guides. Carefully line up the dividers on the lm negative with
the dividers on the holder.
Loading 135 lm into the holder (continued)
Horizontal
guides
Dividers
d. Close the holder and push the tab to the closed position.
abc
Push to closed
position
Insert the lm holder
14
ENGLISH
15
ENGLISH
14
b. Open the lm holder by pulling down on the tab
from the bottom center of the holder. Lift the front
part of the holder. The top side of the holder
is marked with white arrows.
Loading 135 lm into the holder
a. Orient lm strip based on
the example graphic“abc”
on the holder.
135 lm holder
abc
abc
abc
Pull
down
White arrows
Lift
open
e. Insert the lm holder into the scanner from the left or right side into the
small opening. Push the holder inside until you feel it hit a stop, then scan.
After the scan is done, push the holder farther into the scanner until it hits
another stop, and scan again. Repeat until the end of the holder.
Make sure that the orientation of white arrows on the holder correspond
with the triangle mark on the scanner.
c. lnsert the orientated lm negative into the holder between the
horizontal guides. Carefully line up the dividers on the lm negative with
the dividers on the holder.
Loading 135 lm into the holder (continued)
Horizontal
guides
Dividers
d. Close the holder and push the tab to the closed position.
abc
Push to closed
position
Insert the lm holder
15
ENGLISH
16
Loading 135 mounted slides into the holder
a. Orient slides based on the example graphic“abc” on the holder.
b. Insert mounted slides into the holder.
abc
a
b
c
INCORRECT CORRECT
Insert the lm holder into the scanner from the left or right side into the small
opening. Push the holder inside until you feel it hit a stop, then scan. After the
scan is done, push the holder farther into the scanner until it hits another stop,
and scan again. Repeat until the end of the holder.
Make sure that the orientation of white arrows on the holder correspond with
the triangle mark on the scanner. (see previous page for illustration).
135 slide holder
Loading 135 lm and slide holder into the scanner
16
ENGLISH
19
STEP 1 – Powering on the scanner
STEP 2 – Select lm type
a. Open the CyberView scanning interface.
b. Select the lm type to be scanned - Positive, Negative or B&W (Black and
White).
HOW TO SCAN
Status LED Scanner Status
Power on Cycle Unit will take approx. 40-50 sec. to callibrate. The power
LED will be solid blue (not blinking) to indicate that
the scanner is ready to use.
LED Status Flashing indicates the scanner is busy, do not insert/re-
move lm holders
Flashes several times,
then a pause,
then ashes again
Scanner is malfunctioning. Turn the unit o, close the
software, power on the scanner, wait for calibration, then
re-open CyberView.
c. Once you have selected a lm type you will have the option to select
the frame sizes for the various 120 format lms, after you have inserted
the lm holder into the unit.
NOTE: The 135 lm will be auto-detected, a frame selection is not necessary.
Scanning process step-by-step:
Powering on the scanner > Select lm type > Optional Prescan >
> Set scan settings > Scan
17
ENGLISH
21
ENGLISH
20
a. Resolution
The default scanning resolution is 1000dpi, additional resolution options are
listed below.
Notice: Higher scanning resolutions result in greater scanning time and hardisk space
requirements.
b. Color Depth
Choose between 8 and 16 bit. A higher color depth setting will result in
a larger range of colors in the nal scanned image.
Scan Mode – Normal mode produces a scan in jpeg format while Quality pro-
duces a non-compressed,“loss-less”TIFF image.
Set Scan Settings (Continued)
STEP 4 – Set Scan Settings
1. After clicking on the “Scan“ from the menu, then click on Prefernce select
the lm type “Scan setting“ setup dialog box will appear:
STEP 3 – Optional Prescan
Pre-Scanning should be used to manually adjust color/edit settings before doing
a nal scan.
1. In the CyberView interface click on the “Prescan”menu bar icon.
The scanner will initialize the prescanning process.
2. Once the prescan is complete, the image will appear in the CyberView
interface:
3. When the image appears on the screen, select the “Final scan icon“ to scan
the le into a folder on the hard drive.
3a. Editing of the prescanned image before saving can also be done
by clicking on the “Image Adjustment“ icon,
(for more see “Advanced scanning options“ Page 23).
18
ENGLISH
21
ENGLISH
20
a. Resolution
The default scanning resolution is 1000dpi, additional resolution options are
listed below.
Notice: Higher scanning resolutions result in greater scanning time and hardisk space
requirements.
b. Color Depth
Choose between 8 and 16 bit. A higher color depth setting will result in
a larger range of colors in the nal scanned image.
Scan Mode – Normal mode produces a scan in jpeg format while Quality pro-
duces a non-compressed,“loss-less”TIFF image.
Set Scan Settings (Continued)
STEP 4 – Set Scan Settings
1. After clicking on the “Scan“ from the menu, then click on Prefernce select
the lm type “Scan setting“ setup dialog box will appear:
STEP 3 – Optional Prescan
Pre-Scanning should be used to manually adjust color/edit settings before doing
a nal scan.
1. In the CyberView interface click on the “Prescan”menu bar icon.
The scanner will initialize the prescanning process.
2. Once the prescan is complete, the image will appear in the CyberView
interface:
3. When the image appears on the screen, select the “Final scan icon“ to scan
the le into a folder on the hard drive.
3a. Editing of the prescanned image before saving can also be done
by clicking on the “Image Adjustment“ icon,
(for more see “Advanced scanning options“ Page 23).
19
ENGLISH
23
ENGLISH
22
4. Options - Use Film Index: Use the number assigned to the slide based on it’s
position in the cartridge.
User Dened Start Number: Enter a specic start number
5. Choose the le type , “TIF” or “JPG”. (TIF uncompressed or JPG Compressed-
Choose image quality for JPEG. (20-100) 100 oers the least amount of compres-
sion
“Prescan Resolution“ - Default pre-scan resolution.
“Color Depth“ – Default color depth while scanning.
“Scan Mode“ – Default scan mode while scanning.
Conguring Scan settings
1. Select Browse and choose the designated folder to save the scanned
image to
2. Enter the le name.
3. Trailing Index after Base File Name Digits: Denes the length of the le
name and numbering sequence up to 6 digits Example image1 or im-
age000001.
Set Scan Preferences (Continued...)
STEP 5 – Set Scan Preferences
Set Scan Settings (continued...)
Default Scanning
Resolution
Color Depth
per RGB channel
Color Mode
(24-bit/48-bit)
Film Size
(mm)
Approx.
File Size*
1000dpi 8 bit 24-bit 35 3.93 MB
1000dpi 8 bit 24-bit 60 x 45 11.97 MB
1000dpi 8 bit 24-bit 60 x 60 15.96 MB
1000dpi 8 bit 24-bit 60 x 70 18.63 MB
1000dpi 8 bit 24-bit 60 x 90 23.94 MB
1000dpi 8 bit 24-bit 60 x 120 31.92 MB
1000dpi 16 bit 48-bit 35 7.87 MB
1000dpi 16 bit 48-bit 60 x 45 23.95 MB
1000dpi 16 bit 48-bit 60 x 60 31.92 MB
1000dpi 16 bit 48-bit 60 x 70 37.21 MB
1000dpi 16 bit 48-bit 60 x 90 47.89 MB
1000dpi 16 bit 48-bit 60 x 120 63.85 MB
* for TIFF =
uncompressed format, higher resolution will create larger le sizes.
NOTE: Make sure there is enough space available on the computer when changing
the Scanning Resolution. A high scanning resolution results in large les that
may prove dicult to save.
Select Scan - Preference - Film Type - Scan Setting
c. Note: Color image le size of dierent resolutions and color depths:
The Film Scanner color depth is 48 bit true color
The scanning software has the capability of selecting 8 bit color mode or 16 bit
color mode when scanning, This will produce 24 or 48 bit color images, 8 bits or 16
bits per Red, Green and Blue color channels
Example:
8 bit mode = 8 Red, 8 Green, and 8 Blue for a total of 24 bit color
16 bit mode = 16 Red, 16 Green, and 16 Blue for a total of 48 bit color
20
Table of contents
Other CyberView Scanner manuals
