Cyclades AlterPath KVM/netPlus KVM Switch User manual

Benefits:
•Global access anytime (KVM over IP)
•Simplified management
•Reduced IT operational costs and risks
•Advanced security features with centralized
authentication and 128-bit private key encryption
•Simple and inexpensive CAT5-based cabling
•Enterprise-level scalability with centralized management
•Future investment protection
AlterPathTM KVM/netPlus
Enterprise KVM over IP Solutions
The AlterPath™ KVM/netPlus family of
enterprise-class KVM over IP switches is
designed for local and remote server
administration with centralized management and
advanced security features. The AlterPath
KVM/netPlus is the industry's first KVM solution
to offer Cyclades AdaptiveKVMTM technology
(patent pending) that combines Microsoft®
Remote Desktop Protocol (RDP) functionality
with KVM over IP access in a single device.
The AdaptiveKVM feature allows users to
manage most administrative tasks using the
efficient RDP protocol, delivering seamless
performance, even over low-bandwidth
connections. The AlterPath KVM/netPlus can
easily switch from RDP sessions to KVM over IP
sessions when Windows-based servers are down
or become disconnected from the IT production
network. The AlterPath KVM/netPlus provides a
cost-effective and simplified management
solution over low-bandwidth connections.
Fully integrated security features include server-
based authentication and support for RADIUS,
TACACS+, LDAP, Kerberos, NTLM, NIS and
Active Directory. In addition, the AlterPath
KVM/netPlus supports user access control lists
(ACLs) per port and user access logging. This
allows IT managers and administrators to manage
their servers with greater control and peace of
mind.
The AlterPath KVM/netPlus can also be
combined with the AlterPath Manager, Cyclades
out-of-band infrastructure (OOBI) manager, to
provide users with a consolidated view of all
KVM ports, centralized security and data logging.
This reduces network maintenance costs and
provides easier and faster provisioning of the
OOBI.
Available in 6 models, providing 1, 2 or 4 digital
channel access to 16 or 32 servers in 1U of rack
space, the AlterPath KVM/netPlus helps
streamline remote access to servers throughout
the IT infrastructure and includes the scalability
and security features to accomplish this objective.
The AlterPath KVM/netPlus reduces operational
costs and risks while increasing IT personnel
efficiency and productivity.
Application Example
Applications:
•KVM switching and control
•Local and remote server administration
•RDP sessions to provide enhanced remote
performance – even over low-bandwidth connections
•Simultaneous local and remote access to servers and
workstations for multiple users
•Power and temperature management

AlterPath KVM/netPlus Specifications
Hardware
CPU: MPC859P (Power PC) @133 MHz
Memory: 128 MB DIMM SDRAM/256 MB compact flash
Interfaces: 1 Ethernet 10/100 BT on RJ-45
1 RS-232 console on RJ-45
2 RS-232 auxiliary ports on RJ-45
16 or 32 RJ-45 KVM ports (CAT5-based)
1 VGA HD15 female and 2 MiniDIN6
(PS/2) user interface
1 RJ-45 user interface (CAT5-based)
2 PCMCIA slots (16-bit PC Card)
Power: 100 V/240 V, 50/60 Hz, 0.78 A/0.46 A
Form Factor: 1U rack mountable (rack mount kits included)
Operating
Temperature: 32°F to 122°F (0°C to 50°C)
Storage
Temperature: –40°F to 185°F (–40°C to 85°C)
Humidity: 5% to 90% noncondensing
Dimensions:
(WxDxH) KVM/netPlus
17 x 15 x 1.75 in
(43.18 x 38.1x 4.45 cm)
KVM Expander
12 x 2.5 x 1.53 in
(30.48 x 6.35 x 3.87 cm)
KVM Terminator
1.24 x 2.60 x 0.85 in
(3.15 x 6.60 x 2.16 cm)
KVM RP
9 x 9 x 1.75 in
(22.86 x 22.86 x 4.45 cm)
Certification: CSA, FCC, CE, EN60950, VCCI, C-Tick
Features
Accessibility
•16 or 32 server ports
•2 local users and 1, or 2 or 4 remote users over
IP network simultaneously
Security
•Local, RADIUS, TACACS+, LDAP, NTLM, NIS,
Active Directory and Kerberos authentication
•Token-based strong authentication (RSA SecurID)
•Local backup user authentication
•3DES and RC4 encryption (KVM over IP viewer only)
•User ACLs per port
•User access logging
•System event syslog
Server Management
•Access through Web management interface (WMI)
or on-screen display (OSD)
•Port name assignment
•Simultaneous access on the same port (port sharing
for local and remote users)
•Cascading with centralized port management
(access and configuration)
•Programmable cycling of screens
•Maximum resolution 1,600 x 1,200 @ 60 Hz (local
stations only); 1,280 x 1,024 @ 60 Hz (KVM over IP)
•Temperature monitoring
•Optional integrated power management with the AlterPath PM
•Optional 8- and 16-port expander modules
System Management
•WMI for configuration
Cabling
•CAT5-based terminators
•Compatible with PC PS/2, PC USB and Sun USB
keyboard/mouse interfaces
•CAT5, CAT5e, CAT6 and CAT7 UTP cabling
•Cable length up to 500 ft (152.4 m) distance
between terminator and KVM switch
Upgrades
•Upgrades available on FTP site
•Flash upgradeable
•TFTP support for network boot
Part Number Model Description
ATP1601 AlterPath KVM/netPlus 1601 16-port KVM over IP switch, 3 users,
2 local and 1 remote user over the network
ATP1602 AlterPath KVM/netPlus 1602 16-port KVM over IP switch, 4 users,
2 local and 2 remote user over the network
ATP1604 AlterPath KVM/netPlus 1604 16-port KVM over IP switch, 6 users,
2 local and 4 remote user over the network
ATP3201 AlterPath KVM/netPlus 3201 32-port KVM over IP switch, 3 users,
2 local and 1 remote user over the network
ATP3202 AlterPath KVM/netPlus 3202 32-port KVM over IP switch, 4 users,
2 local and 2 remote user over the network
ATP3204 AlterPath KVM/netPlus 3204 32-port KVM over IP switch, 6 users,
2 local and 4 remote user over the network
ATP4610 AlterPath KVM Terminator PC PS/2 Server-side unit, PC PS/2
ATP4630 AlterPath KVM Terminator PC USB Server-side unit, PC USB
ATP4620 AlterPath KVM Terminator Sun USB Server-side unit, Sun USB
ATP4710 AlterPath KVM RP Remote user interface unit
ATP4208 AlterPath KVM Expander 8 8-port KVM expander module
ATP4216 AlterPath KVM Expander 16 16-port KVM expander module
