CyClone Micro 2+ User manual

CYCLONE Micro 2 +
USER MANUAL

Contents
BRIEF INTRODUCTION ................................................... 1
FEATURE............................................................. 1
BASIC PERFORMANCE ......................................... 1
PRODUCT DETAILS ........................................................ 2
PACKING LIST ..................................................... 2
FRONT VIEW ....................................................... 2
BACK VIEW ........................................................ 3
REMOTE CONTROL .............................................. 4
BASIC OPERATION ......................................................... 7
USAGE PREPARING.............................................. 7
OPERATION OF PRODUCT USAGE............................. 10
SETUP MENU .....................................................11
PICTURE VIEW MODE ........................................ 13
MUSIC PLAY MODE............................................ 15
MOVIE PLAY MODE ........................................... 16
SUBTITLE .......................................................... 17
MAINTENANCE NOTICE ............................................... 19
FAQ ................................................................................. 20
OTHERS ......................................................................... 22

1
Brief introduction
Feature
This product is a new type of family high-definition home
video player, which can play your favorite pictures,
audio/videos files from the built-in external storage device
and memory card including SD (Secure Digital) card,
MMC (Multi Media Card) to a connected audio/video
playback device. And it can decode a number of audio
and video file formats, including the popular online movie
RM/RMVB, digital photos and MP3. Meanwhile, the
product, which is facilitated with many ports and HDMI,
can show you pictures and videos with high definition. It is
really your desirable entertainment product.
Basic performance
Video Format- MKV, AVI, MP4, MPG,FLV, VOB, DAT,
RM/RMVB
Audio Format-MP3, WMA, AAC、APE、OGG、FALC
Image Format-JPG/BMP/PNG
USB HOST- Connection USB mass storage device
HDMI-High Definition Multimedia Interface, high definition
audio /video port
1080P output -Full HD 1080P (1920x1080) decoder
output

2
Product details
Packing list
Check the accessories after receive the product. If there
are some missing, please contact immediately with your
supplier to insure your consumer’s right.
Item Quantity
Media player 1
Power adaptor 1
Remote control 1
AV cable 1
Coaxial cable 1
User’s Manual 1
Front view
Element Definition
Element Remark
①USB supports multiple external USB

3
HOST storage devices
②LED Light LED light display
③IR Infrared sensor
④2-in-1card
reader Supports SD, MMC
How to use memory cards: The Product has an integrated
multimedia card reader supporting memory cards
including SD, and MMC. Gently insert the memory card
into the reader with the arrow side upward until there goes
a “click” sound
Back View
Element Definition
Element Remark
①AV
Outputs composite video
②HDMI Outputs digital signal via HDMI port
③Coaxial Output option "SPDIF”/"RAW”

4
audio coaxial port
④DC IN Inputs power
Remote control

5
BUTTON FUNCTION
POWER Turn on and off in the stand by mode
MUTE Turn on or shut audio output
HOME Switch to the main menu.
AUDIO Switch the audio format output
ZOOM Zoom in/out.
TV SYSTEM
Press to switch between NTSC, PAL,
480P, 576P, 720P 50HZ, 720P 60HZ,
1080I 50HZ and 1080I 60HZ, 1080P
24HZ 、1080P 50HZ,1080P 60HZ.
SUBTITLE
Press to set the type, color, the text
encoding format ,size of subtitle, when
playing the video
PLAY Press to play media file and to auto play
the picture
STOP End the playback of a media file
PAUSE/STEP Press to pause the playback. Press
continuously for step by step playback
RETURN Return to the previous menu
VOL- Press to decrease the volume
VOL+ Press to increase the volume
REPEAT Press to set repeat option: sequence,
random, only once, rotate one, rotate all.

6
Press to return to previous file
Press to go to next file
Press shortly to move cursor left
Press shortly to move cursor right
Press shortly to move cursor up
Press shortly to move cursor down
OK Press this button confirms a selection
and starts the playback of a media file.
Press to fast rewind from current play
and again to select the speed
Press to fast forward from current play
and again to select the speed
SETUP In any mode, press to enter to
corresponding setting menu
GOTO Jump to the appointed time/page when
playing video
DISPLAY Press to display time, title, information of
chapter when play video and photo
0-9 Press to input digital
ALL Press this button, the list of all
documents in storage media will display.
MUSIC Press this button, the list of music
documents in storage media will display.

7
PHOTO Press this button, the list of photo
documents in storage media will display.
MOVIES Press this button, the list of film
documents in storage media will display.
Basic operation
Usage preparing
1. Power connection
Take out power adapter from the package and connect
2.Connection of TV audio and video output
The product is designed with multi-output, including
composite (AV), Optical and HDMI. Individuals can select
different interface according various need. The product
can detect video output automatically, making the
operation friendly and convenient. Please refer to the
following instruction for connection to avoid any problem.
Composite output connection (AV)
Plug the yellow connector into the AV output of product
and AV input of TV, and plug the red and white

8
connector into the audio input of TV or HIFI. Turn on the
TV and select AV mode. Turn on the product and TV
displays the interface of initiation.
Note: You must select to the “PAL/NTSC” output, if
not there is no video output by AV.
Coaxial output connection
Coaxial output：Connect the Coaxial connector of the
media player with the coaxial connector of other video or
audio device by Coaxial cable. Then enter the product's
audio output format interface, select the Digital Output
option "RAW”. It is available to enjoy 5.1 high quality
sounds through a multi channel decoder/amplifier with
coaxial input.
Note: when select to the “normal” output format, there is
no audio output by coaxial output, and if select to the
“SPDIF”/“RAW”output format ,the HDMI and AV have
no audio output.

9
HDMI output mode
HDMI is an output with best audio and video effect which
outputs digital video and audio composite at the same
time. Connect HDMI cable to output of product and
display device with HDMI input. Select HDMI mode in TV
until it displays the interface of initiation.
Note: When select to the “HDMI” output, there is no
video output by AV. When select to the “PAL/NTSC”
output, there is no video output by HDMI.
The usage of USB HOST interface
Player with an ability to expand large-capacity. The USB
HOST port can read external mobile hard disk, U disk,
digital cameras, card readers and other data storage
devices.
You can connect external storage devices through the
USB HOST interface. To direct play a variety of
high-definition formats high-fidelity audio and video files
stored in external storage devices. To watch HD movies
and digital photos are more palatable, at the same time
the output digital audio signals to audio equipment can

10
feel the shock of high-fidelity sound effects.
Operation of product usage
When connecting the power supply for the first time, press
the “power” key on the remote control(you also can press
the button on the front face of product) and the device will
power on automatically and appear the main menu.
Please read the following instructions carefully to
understand the function of each option.
Main menu: There will be three function options on the
main menu.
You can enter this main menu by press “HOME” key on
the remote control. Under the main interface, you may
select the USB Device, Smart Card, Setup icon by press

11
and key on the remote control, then press “OK”
key to browse or play the corresponding files stored in the
external USB, card and the card reader. In addition to,
you can go to the setup menu directly and set up the
“Language”, “Video ”“Audio”, “Photo” and so on
according to your needs.
Setup Menu
Select “Setup” option to enter the setup menu. Then
select any option you want by pressing “up” and “down”
on the remote controller, and press OK to confirm or press
“Return” to exit.
System Setup
Language: Select to choose the OSD (On Screen Display)

12
language. Press and to select the language.
Press OK to confirm.
Screen :Turns the screen function on or off the function of
screen saver. Pressing the navigation keys to select.
Screen saver mode will automatically start after 2, 5 or 10
minutes of non activity.
AutoPlay: is set to on, in the root directory of external
storage device and memory card, creating a folder which
is named auto play or AUTOPLAY. Power on, the media
player auto repeat play the video within the folder, and it
can plug and auto play.
Restore Default: To restore the factory’s default settings
System Info: View software version information
Audio Setup
Select to choose the audio output:
Normal：Digital signal is directly outputted through product
SPDIF LPCM: The digital audio signal which is decoded
by the product outputs through coaxial
SPDIF RAW: The raw digital signal of multimedia data
directly outputs through coaxial ,at this time the remote
control has no function of adjusting the volume.
Video Setup
Video Output: Select to adjust TV
system:NTSC,PAL,480P,576P,720P 50HZ, 720P 60HZ,
1080i 50HZ, 1080i 60HZ, 1080P 24HZ、1080P 50HZ,

13
1080P 60HZ
Resume Play: On/Off. When a movie paused, the device
will record the time that the movie is paused and the next
user can choose "Resume Play" to continue from the last
pause point to resume playback.
Auto Detect: On/Off Turns the Auto Detect function on or
off.
Photo Setup
Slide Show Timing: Set time interval of slide show.
3/5/10/20s
Transition Effect: Select a picture transformation effects,
there are eight different effects to choose.
Background Music: There are two options to choose :
Folder and Play List . If you choose the option of Folder,
the music must be in the same folder , and you can
choose background music’s position by the navigation. If
you choose the Play List ,Every time you startup the
media player you must choose a folder as the background
folder, and play a song in it . When you play pictures the
music which in this folder will become background music.
Picture view mode
Enter a storage device, and the files under the current
directory will be set out. Press “ ” and “ ” to select the
folder containing your photo files. You also can press
green or red key on remote, if you press green key, all

14
folders and supported picture files will be displayed, if you
press red key, all folders and supported video, audio and
picture files will be displayed.（Note：If you press the other
two color of buttons on remote there will no photo files
display）
Enter the folder press “ ” and “ ” to select the photo
you want to view and press “OK”, the photo is displayed
full screen. When you browse the photo, press the UP
and DOWN key to view the previous or next photo. If you
want to playback some music during the slideshow,
simply make sure that you copy your music file(s) in the
same directory as the pictures. Then setting the
“Background Music” on and the music synchronously
when browsing the picture (Only for MP3 format).

15
Music play mode
Enter a storage device and the files under the current
directory will be set out. Press “ ” and “ ” to select the
folder containing your audio files. You also can press blue
or red key on remote, if you press blue key, all folders and
supported music files will be displayed, if you press red
key, all folders and supported video, audio and picture
files will be displayed.（Note：If you press the other two
color of buttons on remote there will no music files
display）
A thumbnail strip appears at the bottom of the screen,
along with song information. Press “ ” and “ ” to select

16
the file you want to play and press OK to play. This
browsing music function supports MP3, WMA, AAC
APE 、OGG、FALC format Playback.
Movie play mode
Enter a storage device, and the files under the current
directory will be set out. Press “ ” and “ ” to select the
folder containing your video files. You also can press
yellow or red key on remote, if you press yellow key, all
folders and supported movie files will be displayed, if you
press red key, all folders and supported video, audio and
picture files will be displayed.（Note：If you press the other
two color of buttons on remote there will no movie files
display）
Enter the folder press “ ” and “ ” to select the movie

17
you want to view and press OK the movie is played full
screen. The Product supports multiple video formats,
including RM, RMVB, AVI, MPG, VOB, DAT and so on.
In addition, the Product also supports breakpoint movie
play. Next time you play the movie, there will be a prompt:
“is play from the breakpoint”. If you choose to “YES”, the
movie will start from where it stops last time.
Subtitle
The media player supports subtitle file formats including
SSA, SUB, SRT. Make sure the subtitle file and the video
file are in the same folder and the same name .When
playing the file, press SUBTITLE button to show / hide the
subtitle setup menu and realize subtitles settings. If using
external subtitles in a movie, press the arrow keys on the
remote control to select the option to adjust and press OK
to confirm. Then we can set the encode format , font size,
font color of the subtitle and subtitle selection by pressing
UP/DOWN arrow key on remote control. For example, to
change the color of subtitle, firstly select the color option
by pressing right arrow keys, then press OK key to enter,
finally press up/down arrow key to select the option you
need and press OK key to confirm the setting.
Specification
USB host Support multiple USB storage

18
Video output Composite video /HDMI
Audio output Stereo/digital HDMI/ Coaxial
Audio MP3, WMA, AAC、APE、OGG、FALC
Video MKV, AVI, MP4, MPG, FLV, VOB,
DAT, RM/RMVB
Subtitle SSA，SRT，SUB
Picture JPG/BMP/PNG
Power AC input：100V～240V，50/60HZ
DC output：5V/2A
adapter
Dimension 76 x 65 x 15 mm
Weight 70g
Supported video, audio and picture formats as follows
DECODE FORMARTS RESOLUTION
VIDEO
MPEG-1 DAT 320×240
MPG 720×576
MPEG-2 VOB 720×576
MPG 1920×1080P
MPEG-4,
XVID
AVI 1920×1080P
MP4 1920×1080P
MKV 1920×1080P
RM/RMVB RM/RVMB 1920×1080P
H.264
AVI 1920×1080P
MP4 1920×1080P
MOV 1920×1080P
