CYP CLUX-M2SDI User manual

CLUX-M2SDI
3G-SDI/HDMI Scaler Box
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 10/02/12 Preliminary Release
VS0 16/07/12 SDI standards updated
VR1 12/04/13 Support timing change from
WUXGA to SXGA
VR1.1 04/06/13 RS-232 Pin Assignments
VR1.2 14/11/13 TV Wall Function Option

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 OSD Menu.........................................6
6.4. Remote Control...............................8
6.5 RS-232 Pin Assignments....................9
6.6 RS-232 Commands.........................10
7. Connection Diagram .......................... 11
8. Specications ...................................... 13
9. Acronyms ............................................. 14

1
1. INTRODUCTION
The HDMI/PC/Component/CV to SDI/HDMI Scaler allows you to
upscale HDMI/PC/Component/Composite signals to high denition
video of HDMI formats (720p@50/60 Hz or 1080p@50/60 Hz) and SDI
formats (HD-SDI SMPTE 292M or 3G-SDI 424M/425M), then output to
both ports at the same time. Besides scaling features, the device also
carries an optional functionalities for it to serve as control center of
video wall up to 15×15 total of 225 displays showing one single picture
together.
2. APPLICATIONS
• Simultaneous output on HDMI and SDI display
• Up-scales video resolution to HD output display
• TV/Video/Display/Gaming/Movie wall display (Optional)
• Combination advertising wall
3. PACKAGE CONTENTS
• 3G-SDI/HDMI Scaler Box
• 1×Remote Control (CR-115)
• 1×IR Receiver
• 1×5V DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
HDMI/PC/Component/Composite input source signal and connection
cables, output display HDMI & SDI monitors with connection cables.
Or HDMI/SDI splitter with connection and RS-232 cables, output display
TV wall with connection cables. (Optional)

2
5. FEATURES
• Supports HDMI, PC, Component and Composite Video input signals
• Supports SDI and HDMI output simultaneously
• Supports SDI output distance up to 100 meters (3G-SDI), or 200
meters (HD-SDI) and 300 meters (SD-SDI)
• Scales any input signal to the following output signals:
1. HDMI: 720p@50/60 Hz or HD-SDI: SMPTE 292M (1.485 Gbit/s)
2. HDMI: 1080p@50/60 Hz or 3G-SDI: SMPTE 424M/425M
(2.970 Gbit/s)
• Supports HDMI input timings: VGA@60 ~ SXGA@75 & 480p/576p ~
1080p@50/60 Hz
• Supports VGA input timings: VGA@60 ~ SXGA@60 Hz &
1920×1080@60 Hz
• Supports Component input timings: 480i/576i ~ 1080i/p@50/60 Hz
• Supports Composite Video input timings NTSC, PAL
• Supports video wall controlling (Optional)
Note: Tested with Belden 1694A cable. Results may vary with cables
that have a different specication.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
MENU －
POWER ENTER INPUT
＋
CLUX-M2SDI SDI/HDMI SCALER
1 3 4 5 6 72
1POWER
Press this button to switch on the device(s). All the connected
Video wall system control device(s) will be switch to ON.
2IR Remote Control Sensor
3MENU
a. Press this button to enter into the OSD main menu.
b. Under Picture & Setup Menu, press this button to move down
the selection.
4DOWN
a. Press the DOWN button to move down the selection in the
OSD main menu.
b. When in Picture & Setup Menu, press DOWN button to show
the individual setup slide bar and continue press the button to
reduce the value.
5UP
a. Press the UP button to move up the selection in the OSD
main menu.
b. When in Picture & Setup Menu, press UP button to show the
individual setup slide bar and continue press the button to
increase the value.
6ENTER
a. Press ENTER to conrm the selection.
7INPUT
a. Press to select the input sources.

4
b. When enter the OSD menu, press INPUT button to exit the
setup.
Note: Points a/b denes multiple usage of the key button.
6.2 Rear Panel
SDI HDMI HDMI PC
AUDIO
PC
OUTPUT
RL
Pr/Cr Pb/CbY RLVIDEO RS232 IN
IR IN DC 5V
RS232 OUT
INPUT
1 2 3 4 5 6 8 97
1SDI/HDMI OUT
These slots are where you connect the SDI/HDMI display. Both slots
are output simultaneously.
2HDMI IN
Connect the HDMI input port to the HDMI/DVI output ports of your
source equipment such as DVD/Blu-ray player or set-top-box.
3PC with PC AUDIO IN
Connect the PC/audio input port to the PC/audio output port of
your source equipment such as Laptop or PC.
4Component with R/L IN
Connect Component and R/L input port to the component and
R/L output port of your source equipments such as DVD/Blu-ray
player or set-top-box.
5Video with R/L IN
Connect Video and R/L input port to the Video and R/L output
port of your source equipments such as DVD player or set-top-box.
6RS-232 IN
This slot is to connect with PC/NB equipment for RS-232 control. For
detail RS-232 commands please refers to section 8.
7RS-232 OUT
This slot is to connect to the next RS-232 IN.

5
8IR IN
This slot is to connect with IR receiver included in the package for
receiving the IR signal of the device’ remote controller.
9Power
Plug the DC 5V power supply into the system and connect the
adaptor to AC wall outlet.

6
6.3 OSD Menu
Main Menu 2nd Layer
MAIN MENU PICTURE MENU*1 STANDARD ON/OFF
R OFFSET 0~255 (118)
G OFFSET 0~255 (116)
B OFFSET 0~255 (118)
R GAIN 0~255 (098)
G GAIN 0~255 (098)
B GAIN 0~255 (098)
CONTRAST 0~63 (50)
BRIGHTNESS 0~63 (40)
SETUP MENU*1 LANGUAGE ENG / T.CHINESE
(ENG)
HDMI SOUND ON/OFF (ON)
STANDARD*3 ON/OFF (ON)
H POSITION
START*4 000~385 (*2)
V POSITION
START*4 000~53 (*2)
H Blanking Edit*4 0~255 (20)
V Blanking Edit*4 0~255 (20)
TV Option Width*4 1~15 (1)
TV Option
Height*4 1~15 (1)
*Note:
1. The Picture Menu allows users to adjust single monitor’s setting
while the Setup Menu will only needs to be adjust once and all
monitors will be automatically adjusted.
2. Suggest to set the SETUP MENU's STANDARD to ON after a change
of the timings to obtain the best position under TV wall function.

7
3. The SETUP MENU's STANDARD can only be adjust under PC mode.
4. Optional TV wall functions.
Picture Standard: Set it to ON will allow system to set the picture
menu into the default value as indicated in the ( ).
Picture R/G/B Offset: These functions are to set the single picture's
R/G/B brightness.
Picture R/G/B Gain: These functions are to increase or decrease
the color of single picture's R/G/B.
Picture Contrast: This function is to set the single picture's color
contrast.
Picture Brightness: This function is to set the single picutre's
brightness.
Setup Language: There are two language available in the OSD
and they are English and Traditional Chinese.
Setup HDMI Sound: This function is to set the HDMI output audio
sound to be ON or OFF.
Setup Standard: Set it to ON will allow system to set the setup menu
into the default value as indicated in the ( ).
Setup H/V Position Start: These functions are to set the total value
of the vertical and horizontal value of the TV wall.
Setup H/V Zoom Size: These functions are to set the total value of
the vertical and horizontal zoom in and zoom out size of the TV
wall.
Setup H/V Blanking Edit: These functions are to set the total value
of the vertical and horizontal value of the blanking area of the TV
wall.
Setup TV Option Width: This function is to set the numbers of the TV/
display that is to be on a horizontal line of the TV wall.
Setup TV Option Height: This function is to set the numbers of the
TV/display that is to be on a vertical line of the TV wall.

8
6.4. Remote Control
1POWER*
Press this button to switch on the
device(s). All the connected
Video wall system control
device(s) will be switch to ON.
2POWER OFF*
Press this button to switch off the
device. All the connected Video
wall system control device(s) will
be switch to OFF.
3SINGLE*
Press this button to set the image
to be displayed on each and
every connected TV/monitor
identically. (Optional Function)
4FULL*
There are 6 options of setting an image to be displayed on TV/
monitor and they are 2x2, 3x3, 4x4, 3x2, 4x3 and 5x5. (Optional
Function)
5 ▲▼◄►& OK
Press the arrow buttons to select and adjust the selection in the
OSD menu and value or to select the display. Press OK to conrm
the selection and all the displays will be adjusted in once. If OK is
not pressed only the rst display will be adjusted to the selected
value
6RETURN
Press this button to return to the last layer of OSD selection or to exit
the OSD.
7MENU
Press this button to enter into the OSD menu. When the setting is
selected and conrmed all the output display will automatically
changed to the selected settings.
8HDMI/VGA/COMP/CV*
2
7
10
1
3
4
5
6
8
9
POWER
2X2 3X3
3X2 4x3 5x5
RETURN MENU
POWER OFF
CR-115
FULL
OK
CV
4X4
SINGLE
720P 1080P
60 60 U/OVER
50 50
HDMI VGACOMP

9
Press the hot key to select the input sources.
9720p/1080p@50/60*
Press the hot key to select 720p@50 Hz, 720p@60 Hz, 1080p@50 Hz
and1080p@60 Hz timings for HDMI output, the SDI output timings
will be automatically converted to SMPTE 292M (1.485 Gbit/s) and
SMPTE 424M/425M (2.970 Gbit/s)
10 U/OVER
Press this key to change the output image to be overscan or
underscan.
*Function that automatically adjusts all monitors in once.
6.5 RS-232 Pin Assignments
RS-232 IN RS-232 OUT
PIN Assignment PIN Assignment
1 NC 1 NC
2TxD 2RxD
3RxD 3TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200 bps
Data bit: 8-bit
Parity: None
Stop Bit: 1
Flow Control: None

10
6.6 RS-232 Commands
COMMAND ACTION
0×23 0×53 0×30 0×30 0×31 0×23 POWER ON
0×23 0×53 0×30 0×30 0×30 0×23 POWER OFF
0×23 0×43 0×30 0×30 0×30 0×23 *UNDER SCAN
0×23 0×43 0×30 0×30 0×31 0×23 *OVER SCAN
0×23 0×43 0×52 0×WH 0×00 0×23 *Note
0×EF 0×05 0×D7 0×C0 0×22 0×0F 0×EE CHANGE TO HDMI
0×EF 0×05 0×D7 0×C0 0×22 0×0E 0×EE CHANGE TO PC
0×EF 0×05 0×D7 0×C0 0×22 0×02 0×EE CHANGE TO COMPOSITE
0×EF 0×05 0×D7 0×C0 0×22 0×0A 0×EE CHANGE TO COMPONET
*Note: Optional TV Wall function.
WH are the TV Option’s Width and Height. W&H can be indicated
from 1~9 & A~F where 11 means single panel’s TV wall, 22 means 2x2’s
TV wall and so on up to FF is 15x15’s TV wall setting.

11
7. CONNECTION DIAGRAM
SDI HDMI HDMIPC
AUDIO
PC
OUTPUT
RL
Pr/CrPb/Cb YRLVIDEO RS232 IN
IR IN DC 5V
RS232 OUT
INPUT
OR
OR
OR
PC
Blu-ray
SDI Monitor TV
NB
DVD
Set-top Box
DVD
Set-top Box

12
FULL SINGLE
HDMI Splitter
HDMI
䡾
HDMI
䡿
HDMI
䢀
HDMI
䢁
HDMI
HDMI HDMI HDMI
DVD
or
PS3
HDMI
IR!Cable
30° 30°
3M 3M
7M
䡾
䢁
䡿
䢀
䡿
䢀
䡾
䢁
SDI HDMI HDMIPC
AUDIO
PC
OUTPUT
RL
Pr/Cr Pb/Cb YRL VIDEORS232 IN
IR IN DC5V
RS232 OUT
INPUT
SDI HDMI HDMIPC
AUDIO
PC
OUTPUT
RL
Pr/Cr Pb/CbY RLVIDEO
IR IN DC5V
INPUT
SDI HDMI HDMIPC
AUDIO
PC
OUTPUT
RL
Pr/CrPb/Cb YRL VIDEO
IR IN DC5V
INPUT
SDI HDMI HDMIPC
AUDIO
PC
OUTPUT
RL
Pr/CrPb/CbY RLVIDEO
IR IN DC5V
INPUT
RS232 IN
RS232 OUT
RS232 IN
RS232 OUT
RS232 IN
RS232 OUT
Optional TV Wall Function

13
8. SPECIFICATIONS
SDI Transmission Rates 2.970 Gbps, 2.971/1.001 Gbps, 1.485 Gbps
and 1.485/1.001 Gbps
Video Bandwidth 148 MHz
Input Ports 1×HDMI (Type A connector), 1×PC
with Audio, 1×Component with R/L,
1×Composite with R/L
Output port 1×SDI (SD/HD/3G-SDI), 1×HDMI
SDI Cable Distance 3G/HD/SD up to 100/200/300 meters with
BELDEN 1694A cable
HDMI Cable Distance Input: 10 m, 8/12-bit
Output: 10 m, 8/12-bit
Input HDMI Timing Support VGA@60/72/75, SVGA@56/60/72/75,
XGA@60/70/75, SXGA@60/75, WXGA@60,
480p@60, 576p@50, 720p@50/60,
1080i@50/60, 1080p@50/60
Input VGA Timing Support VGA@60/72/75, SVGA@56/60/72/75,
XGA@60/70/75, SXGA@60, WXGA@60,
1920×1080@60
Input Component
Support
480i/p@60, 576i/p@50, 720p@50/60,
1080i/p@50/60
Input Composite
Support
NTSC, PAL
Output Timing Support HDMI: 720p@50/60, 1080p@50/60
SDI: SMPTE 292M (1.485 Gbit/s) & SMPTE
424M/425M (2.970 Gbit/s)
ESD Protection Human-body Model:
±8 kV (air-gap discharge)
±4kV (contact discharge)
Dimensions 320 mm (W)×201mm (D)×49 mm (H)
Weight 1630 g
Chassis Material Metal

14
Silkscreen Color Black
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
Power Consumption 20.2W
9. ACRONYMS
ACRONYM COMPLETE TERM
3G Bandwidth 2.97Gbit/s ≈3G
COMP Component
CV Composite Video
HDMI High-Denition Multimedia Interface
SDI Serial Digital Interface
VGA Video Graphics Array

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
MPM-CLUXM2SDI
