Modular Media Converter Center System
KC-1300
Operation Manual
DOC.101202
-1-

(C) 2010 KTI Networks Inc. All rights reserved. No part of this documentation may be
reproduced in any form or by any means or used to make any directive work (such as translation
or transformation) without permission from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in
content from time to time without obligation on the part of KTI Networks Inc. to provide
notification of such revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/
-2-

The information contained in this document is subject to change without prior notice.Copyright
(C) All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
-3-

Table of Contents
1. Introduction...................................................................................................................................6
1.1 Features................................................................................................................7
1.2 Technical Specifications........................................................................................8
2. Installation...................................................................................................................................13
2.1 Unpacking ...........................................................................................................13
2.2 System Units.......................................................................................................13
2.2.1 Management Module .......................................................................................14
2.2.2 Power Chassis Modules...................................................................................16
2.2.3 Media Converter Slots......................................................................................19
2.4 Rack Mounting ....................................................................................................20
3. Network Management ................................................................................................................21
3.1 Management Functions.......................................................................................21
3.2 Protocols Supported............................................................................................22
3.3 Setup for Out-of-band (Console) Management...................................................22
3.4 Setup for In-band Management...........................................................................23
4. Console and Telnet Operation ..................................................................................................24
4.1 IP Menu...............................................................................................................28
4.2 SNMP Menu........................................................................................................29
4.3 View System Status ............................................................................................30
4.4 Slot Menu............................................................................................................31
4.4.1 View Converter Slots Status.............................................................................31
4.4.2 Set Slot Name..................................................................................................33
4.5 Restore Default Values .......................................................................................33
4.6 Security Manager................................................................................................34
4.7 Update Firmware.................................................................................................35
4.8 Reboot System....................................................................................................36
5. SNMP Management ....................................................................................................................37
5.1 Configuring SNMP Settings via Console Operation............................................37
5.2 SNMP Private MIB ..............................................................................................38
5.3 SNMP Traps........................................................................................................39
-4-

6. Web Management.......................................................................................................................40
6.1 Start Browser Software and Making Connection.................................................40
6.2 Login to the System Unit.....................................................................................40
6.3 Converter Status .................................................................................................42
6.4 System Status.....................................................................................................43
6.5 Administrator Menu.............................................................................................44
6.5.1 Basic ................................................................................................................45
6.5.2 Console Port Information .................................................................................50
6.5.3 Slot Information................................................................................................50
6.5.4 Security Manager.............................................................................................51
6.5.5 Image Refresh Time.........................................................................................51
6.5.6 Update Firmware..............................................................................................52
6.5.7 Reboot System.................................................................................................53
6.6 Slot Icon Operations............................................................................................54
-5-

1. Introduction
The Modular Converter System NC-1300 is a managed media converter rack that provides 16
slots and hosts 16 of NC-300D or NC-300DM 10/100 Ethernet network Media Converter
(MC). A wide range of media converters are available depending on your variety of network
cabling environment. These optional media converters include 10/100 UTP to multimode or
single mode fiber cable.
The rack unit provides a centered power supply to the converter modules and serves as a
converter center and wiring concentrator.
For specifications of media converter NC-300D and NC-300DM, refer to the associated
installation guides respectively.
-6-

1.1 Features
Some of the key features include:
zManaged Media Converter Center Rack
z19-inch rack-mountable 2U chassis
zManaged system accommodates up to 16 media converters
zHighly modularized chassis design with
- modular media converters
- modular management module
- two system power modules for power redundancy
zProvides high availability and maintainability
zPower backup feature with two power chassis
zVisible system status indication
zSupports in-band Telnet, SNMP and web-based management
zSupports out-of-band direct console management
zManagement from anywhere and any platform using a web browser
zEasy-to-use point and click user interface
zPhotographic quality interface to configure and monitor the system
zSupports in-band event SNMP trap report
zPhotographic quality interface to configure and monitor the system
zTFTP Software Upgrade
-7-

1.2 Technical Specifications
System Model NC-1300L/1A NC-1300L/2A NC-1300/1A NC-1300/2A
Management support Unmanaged Unmanaged Managed Managed
Plug-in power modules 1 AC 2 AC 1 AC 2 AC
Input voltage 90~264V 90~264V 90~264V 90~264V
Power supply rating 60W 60W 60W 60W
Weight (noMCinstalled) 5.5Kg 6.2Kg 5.5Kg 6.2Kg
System Model NC-1300L/1D NC-1300L/2D NC-1300/1D NC-1300/2D
Management support Unmanaged Unmanaged Managed Managed
Plug-in power modules 1 DC 2 DC 1 DC 2 DC
Input voltage -48VDC -48VDC -48VDC -48VDC
Power supply rating 60W 60W 60W 60W
Weight (noMCinstalled) 5.5Kg 6.2Kg 5.5Kg 6.2Kg
Common Specifications
19-inch rack mount Yes
Number of MC slots 16 slots
Number of power slots 2
Cooling 1 DC Fan
Dimensions H 88mm (2U) x W 443mm x D 328mm
Environmental
Operating temperature -5~40oC
Storage temperature -20~75oC
Operating humidity 10~90%RH
Emission standard
Conducted emission EN55022, CISPR 22
Radiated emission EN55022, CISPR 22
Voltage harmonics EN61000-3-2
Voltage fluctuation & flicker EN61000-3-3
Susceptibility
Electrostatic discharge immunity EN61000-4-2, IEC61000-4-2
Radiated immunity EN61000-4-3, IEC61000-4-3
EFT/Burst immunity EN61000-4-4, IEC61000-4-4
Surge immunity EN61000-4-5, IEC61000-4-5
Continuous wave voltage immunity EN61000-4-6, IEC61000-4-6
PFMF immunity EN61000-4-8, IEC61000-4-8
Voltage DIP/Interrupt immunity EN61000-4-11, IEC61000-4-11
-8-

Certifications
FCC Part 15, Class A
CE EMC Class A, EN50081-1, EN50082-1
AC Power Chassis Module Specifications
Dimensions 194mm x 156mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Power status indication Green LED
Electric
Input voltage rating 100 ~ 240VAC
Input voltage range 90 ~ 264VAC
Input frequency 47 ~ 63Hz
Input surge current 20A max. @115VAC
Efficiency 75% @115VAC full load
Output power 60W
Overcurrentprotection All output with short circuit protection
Safety UL/cUL, TUV EN60950
Insulation Resistance >10M Ohm @DC500V
Dielectric withstands 1500VAC 10mA 1min.
DC Power Chassis Module Specifications
Dimensions 194mm x 156.6mm x 40.3mm
Installation method Plug in from system rear panel
Maintenance Modular design for easy maintenance
DC power switch System power on/off switch
DC power receptacle Screw type terminal block
Power status indicator Green LED
Electric
Input voltage rating -48VDC
Input voltage range -48VDC +/-10%
Efficiency 73% typ. at full load
Output power 60W
Protection Over voltage, over power, short circuit
Safety Meet UL1950
-9-

Management Module Specifications
Dimensions 107mm x 24mm x 86.4mm
Slot position Slot 0
CPU RISC-based ARM7
RAM size 1M bytes
Flash size 512K bytes
System interface
Connector FutureBus connector
Console interface
Interface RS-232 DTE
Connector 9-pin male D-SUB connector
Baud rate 38400, N, 8, 1, 0
Flow control Disabled
In-band interface
Interface 10/100M LAN port
Connector Shielded RJ-45 MDI
Standard IEEE 802.3 10BASE-T/100BASE-TX
Auto-negotiation Support
LED Indicators
P1, P2 Green LED, power module status
DIAG Green LED, CPU initialization
FAN Green LED, Fan failure indication
CONSOLE Green LED, Console RS-232 Rx activities
LNK/ACT. Green LED, LAN port link and activities status
-10-

Management Specifications
Management interface
Telnet Via direct RS-232 console connection
Telnet Via TCP/IP Telnet software
SNMP agent Via TCP/IP SNMP manager software
HTTP server Via web browser software
Protocols
IPv4 IP version4 RFC791
TCP Transmission Control Protocol RFC793
UDP User Datagram Protocol RFC768
ICMP Internet Control Message Protocol RFC792
SNMP SNMP agent v1 RFC1157
MIB-II Standard MIB RFC1213
TFTP Trivial File Transfer Protocol RFC1350
TELNET Telnet protocol RFC854
HTTP HTTP server for web management RFC1945
Management Objects
Password for access control Set and monitor
System status : CPU, memory, flash, software Monitor
System power 1&2 status Monitor
System fan status Monitor
IP address of the system Set and monitor
Subnet mask of the system Set and monitor
Default gateway IP address Set and monitor
SNMP name information Set and monitor
SNMP location information Set and monitor
SNMP contact information Set and monitor
SNMP community names (up to 4) Set and monitor
SNMP community access right (up to 4) Set and monitor
SNMP trap host IP address (up to 3) Set and monitor
Slot status : MC installed or not Monitor
MC status : media type, speed, duplex Monitor
MC link status of two ports Monitor
Remote MC link status (two NC-300DMs link only) Monitor
SNMP Traps
Cold Start System is powered on and completes initialization
Authentication failure SNMP community authentication failure
Power status The system power 1&2 failure and recovery
-11-

Fan failure System fan failure and recovery
Slot # Port A link Slot # MC Port A link down or up
Slot # Port B link Slot # MC Port B link down or up
Slot # PTP link Slot # Remote MC TP Port link change
Update Firmware Via TFTP protocol
Remote boot system
-12-

2. Installation
2.1 Unpacking
The product package contains:
zThe system unit
zOne power cord
zOne 19-inch rack mounting kit
zOperation Manual
2.2 System Units
The figure below illustrates the front view of the NC-1300 system:
Depending on the model purchased, the type and numbers of the pre-installed media converters
may be different. The figure shows a system which is fully installed with media converters.
The following figures show the rear view of the NC-1300 system. The main chassis provides
two power chassis slots on the rear panel. Each power chassis slot can be installed with one AC
power chassis. Two power slots design features the system a power redundant function.
The following figure shows the model equipped with two AC power chassis.
-13-

Main Chassis : provides insertion slots on front panel for CPU management module and
optional add-on media converters. It also provides two chassis slots on rear for mounting power
chassis modules.
Management Module : serves as a management agent to monitor system status and add-on
converter modules for in-band and out-of-band management requests.
Power Chassis : provides full centered power supply for whole system unit. It can receive
commercial AC power with AC power chassis and -48VDC power with DC power chassis.
System Cooling Fan : provides forced air to cool down the temperature for the system unit.
2.2.1 Management Module
The system unit comes with one pre-installed Management module. The module facilitates the
following functions:
zDirect out-of-band management via RS-232 console port
zSNMP agent to serve in-band management via SNMP protocol
zTelnet console in-band management via TCP/IP protocol
zHTTP host to serve web-based in-band management
zMonitoring all MCs status installed in the system
zMonitoring system power and fan status
See figure below for major components on the panel:
-14-

Console Port
This port is a 9-pin male D-sub connector. It serves as an RS-232 DTE port. Refer to Chapter xx
for the console operation. The pin definitions are:
Pin2 RXD
Pin3TXD
Pin 4 DTR
Pin5GND
Pin6DSR
UTP Port
This is an auto-negotiation 10/100BASE-TX LAN port and provides a shielded RJ-45 jack with
MDI definition. This port must connect to your TCP/IP network for all in-band management
operations.
LED Indicators ColorStates Interpretation
P1 GreenOn Power 1 module is ON
P2 GreenOn Power 2 module is ON
DIAG GreenOn CPU initialization
Off Initialization complete
FAN Green On Fan failure detected
Off Fan in normal operation
CONSOLE Green On Rx activities of console port
LNK/ACT Green On LAN port link is active
Green Blink Tx/Rx activities of UTP port
-15-

2.2.2 Power Chassis Modules
The system power supply is assembled in a plug-in chassis module as shown below:
Each single power module is capable to supply full power for system operation with media
converters fully installed.
AC Power Chassis Specifications (NC1300-AC)
AC power switch System power on/off switch
AC power receptacle IEC320 type receptacle
Input voltage range 90 ~ 264VAC
Input frequency 47 ~ 63Hz
Output power 60W
AC power cord IEC320 type power cord
Power status display Green LED
-16-

DC Power Chassis Specifications (NC1300-DC)
Input power switch System power on/off switch
Input power receptacle Terminal connector (screw type)
Input voltage rating -48VDC
Input voltage range -48VDC +/-10%
Output power 60W
Power status display Green LED
-17-

Removal of System Power Chassis
The system power chassis is pre-installed in the system unit when system unit is shipped from
factory. The chassis is designed for easy un-installation from system unit in case of any
inspection purpose. However, note that this removal only can be performed by a well-trained
technical person.
For safety reason before removing the power chassis, make sure:
zThe power switch is turned off.
zThe power cord is disconnected from the power chassis.
To remove the chassis, unscrew two chassis screws until they are released from system chassis,
hold the handle and pull the chassis out from the system chassis smoothly. See the following
example figure:
Insertion of System Power Chassis
Before inserting the power chassis into system unit, make sure:
zThe system power switch is turned off.
zThe power cord is disconnected from the power chassis.
To insert the power chassis, hold the handle and push it into system unit until it is seated in
system chassis properly. Screw the chassis securely in the system unit. See figure below:
The power chassis is designed to be hot plugged into or unplugged from the system even when
another power chassis is installed in another power slot and in operation.
-18-

2.2.3 Media Converter Slots
The system chassis provides sixteen slots for installing optional slide-in MCs. A media
converter can be inserted into an available slot or removed from a slot anytime even when
system unit is powered on. This hot-plug design keeps all exiting connections on the other slots
running with no influence.
To insert an MC into a slot, the steps are:
1. Install a bracket, which is provided in the rack chassis package onto the MC unit as shown
below:
2. Remove slot cover first and insert the MC into slot slowly until it is seated in slot properly.
3. Screw the bracket onto system chassis securely before making any cable connection.
To remove an MC from slot, the steps are:
1. disconnect all cable connections on the MC first.
2. Unscrew the MC bracket from system chassis.
3. Hold the bracket and pull it slowly out from the slot.
The media converters are designed with hot-plug feature, which allows insertion and removal of
the converters can be performed even when the system is in operation.
-19-

2.4 Rack Mounting
One rack mounting kit is supplied in the product package. It includes two rack mounting
brackets and screws for installing the system unit into a 19-inch rack.
Mount both brackets onto the system unit as shown below:
Install the system unit into a 19-inch rack as shown below:
-20-
