CYALKIT-E03 QUICK START GUIDE
1
• Place the Solar BLE Sensor under an indoor light
source.
• Download the Cypress BLE-Beacon Apps from
either App Store or Google play. Note that
supported mobile devices are following. iOS 8
or newer / Android 4.4 or newer
1
+
2Kit Contents:
1 Solar-Powered BLE Sensor Beacon
(Solar BLE Sensor) x 5 pcs
2 Quick Start Guide (this document)
SOLAR-POWERED BLE SENSOR BEACON 5 PACK
x 5 pcs
Cypress BLE-Beacon Cypress BLE-Beacon
2
http://www.cypress.com/CYALKIT-E03
3
• Turn ON Bluetooth setting on your device, and
then run the Cypress BLE-Beacon Apps.
• The Cypress BLE-Beacon window appears, and
change the view mode to “Graph”. You can check
the sensor data on Graph window.
4
• If the sensor data does not appear on iOS,
please conrm that “Location” settings is set to
“While Using the App”.
(iOS: Home screen > Settings > BLE-Beacon
> Location)

© 2016 - 2017 Cypress Semiconductor Corporation. All rights reserved.
All trademarks or registered trademarks referenced herein are the properties of their respective owners.
Doc.#: 002-11705 Rev.*D
CYALKIT-E03 QUICK START GUIDE
SOLAR-POWERED BLE SENSOR BEACON 5 PACKSOLAR-POWERED BLE SENSOR BEACON 5 PACK
• To program, debug and set the parameters on
Solar BLE Sensor, you need at least one Debug
Board (Not included in the package) that is
including in CYALKIT-E02 Solar-Powered BLE
Sensor Beacon RDK
Solar BLE Sensor Board Details
6
• Download the documents from
www.cypress.com/CYALKIT-E03
• The CYALKIT-E03 is Expansion pack of CYALKIT-E02
Solar-Powered BLE Sensor Beacon RDK.
Download the CYALKIT-E02 example projects,
documents, and hardware design les from
www.cypress.com/CYALKIT-E02
15 x 15 mm
Solar Cell
EZ-BLE™PRoC™
Module
400 μF
Storage Capacitor
Energy Harvesting Power
Management IC
S6AE103A
0.2 F Super
Capacitor
5
Connector for Power,
SWD, UART, GPIO
Temperature and
Humidity Sensor
Slide Switch for
S6AE103A mode select
