Cypress CPA-1 User manual

1. Introduction
CPA-1/CPA-2 is a PC or HDTV test pattern generator you can test display CRT, LCD Monitor,
LCD TV, PDP, Projector, HDTV. CPA-1 is analog output. CPA-2 is DVI digital output .
2. Features
1. Simple and easy use.
2. Built in all PC / HDTV output format.
3. Many kinds of pattern such as color bar, staircase, crosshatch, character, multiburst and so on.
3. Connector Block Diagram
5. Specifications
Front and Real Panel:
OUTPUT
MODE
PC/HD OUT PATTERN
-
+
CPA-1
DC 5V
DC 5V
CPA-2
CPA-1
CPA-2
DVI OUT
-
+
PATTERN
OUTPUT
MODE
Front Panel Rear Panel
Front Panel Rear Panel
XGA 480p
XGA
480p
CPA -1 CPA-2
Output Format
RGBHV, YPbPr RGBHV
Output Connector
HD 15 Female 29-pin D- shell connector
Output Singnal
Weight
Dimensions - HxWxD
Power Source 5VDC @ 2A
4. Operation Controls and Functions
Mode: Select the output resolution.
+ or - : Select the test pattern signal such as color bar, staiscase, multiburst.
Press " mode, - " : Reset the output resolution to 480p / color bar.
Press " - , + " : Reset the output to XGA / color bar.
PC display Monitor
Plasma TV
or
PC output
HDTV
output
146 x 77 x 30 mm 161 x 77 x 30 mm
240 grams 270 grams
RGB @ 0.7Vp-p, H&V Sync @ 3Vp-p,
Y @ 1Vp-p, Pb,Pr @ 0.7Vp-p 75 ohm
Digital

6. What's Included
The following items are included in the standard shipping package.
1. PC/HDTV pattern generator.
2. 15 PIN D-sub to D-sub cable x 1 /CPA-1.
3. 15 PIN D-sub to YPbPr 3 RCA Cable x 1 / CPA-1 / Option.
4. DVII to DVII digital cable x1 / CPA-2.
5. AC power adaptor DC 5V 2A.
Output pattern
5. Specifications
NO Signal Content
NO
Signal Content
1 Color bar
15
Crosshatch 1
2 Color bar and Multiburst
16
Circle 1
3 8-setup Greyscale
17
Crosshatch 2
4 8-setup Greyscale(mirror)
18
English characters H
5 Checkerboard
19
English characters E
6 Dynamic Purity
20
Chinese 鷹
7 White
21
Chinese 慧
8 Yellow
22
Chinese
9 Cyan
23
Burst 1
10 Green
24
Burst 2
11 Magenta
25
Burst 3
12 Red
26
Burst 4
13 Blue
27
Multiburst
14 Black
28
PC Resolutions Vert Rate
Vert Rate
Format
Format
Scan Type
Scan Type
VGA
SVGA
XGA
WXGA
SXGA
640 X 480
800 X600
1024X768
1280X768
1280X1024
HDTV Resolutions
480p
576p
720p
1080i
720 x 480
720 x 576
1280 x 720
1920x1080
50,60,72,75,85 Hz
50,56,60,72, 75, 85 Hz
50,60, 70, 75, 85 Hz
50,60 Hz
50,60 Hz
50,60 Hz
50,60 Hz
50,60 Hz
50,60 Hz
RGBHV
RGBHV
RGBHV
RGBHV
Progressive
progressive
Progressive
Progressive
Progressive
Progressive
Progressive
Pseudo Interlance
YPbPr, RGBHV
YPbPr, RGBHV
YPbPr, RGBHV
YPbPr, RGBHV
Output Signal Specifications
* CPA-2 DVI is digital RGBHV output without digital YPbPr output.
