Operation Manual
Operation Manual
nT13AX06/CPLUS-V8E
1 by 8 6G HDMI Splitter

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer file, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufficient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 10/03/16 Preliminary release
31/05/16 Add texts.

CONTENTS
1. Introduction ............................................ 1
2. Applications ........................................... 1
3. Package Contents ................................ 1
4. System Requirements ............................ 1
5. Features .................................................. 2
6. Operation Controls and Functions ....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel .........................................4
7. Connection Diagram ............................ 5
8. Specications ........................................6
8.1 Technical Specifications .................6
8.2 Supported Resolutions .....................7

1
1. INTRODUCTION
The 1 by 8 HDMI Splitter with HDCP 2.2 is an advanced solution
for splitting a single HDMI input to 8 HDMI outputs. It provides high
performance audio and video output up to 4K2K@60Hz (YUV444)
resolution and is capable of provide high end of audio and video
performance. This unit also support HDR (High Dynamic Range
Imaging) function, which allows giving more luminance radiance
contrasting and colourful pictures for better experience. It supports
high resolution digital audio formats such as LPCM 7.1CH, Dolby
TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio,
audio sampling rate up to 192kHz. The System Reset function allows
the unit to set the TV to its default HDMI input automatically.
2. APPLICATIONS
• Lecture Room/Hall Presentation
• Show Room/Demo Room
• Public Commercial Display
3. PACKAGE CONTENTS
• 1 by 8 HDMI splitter
• 5V/3A DC Power Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as Blu-ray/DVD/PS3 player or Set-Top-
Box or any 6G with HDCP2.2 source.
And output with 6G HDMI TV/Display and or audio amplifier with
connection cables.
Note: To achieve 6G performance will need to collocation with
particular HDMI cable to get the better quality.

2
5. FEATURES
• HDMI 2.0 with 4Kx2K 6G supported, HDCP 2.2 and DVI compliant
(Excludes Deep color and Color space YCbCr 422/444)
• 1 HDMI input and 8 HDMI outputs
• System Reset function supported (CEC active source command)
• Simultaneous displays of a single Ultra High-Definition sources on up
to 8 UHDTV displays
• 3D pass-through with compatible 3D source and 3D TV
• Supports UHDTV resolutions up to 4Kx2K:3840x2160@24/25/30/50/60
Hz & 4096x2160 @24/25/30/50/60Hz
Note: When displaying HDMI 4Kx2K signal, equivalent source signal,
output display and HDMI cables are required in order to secure the
best image display.
• Supports pass-through of high definition audio: LPCM 2/5.1/7.1CH,
Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby TrueHD, Dolby Atmos
and DTS-HD Master Audio
• HDCP 2.2 and HDCP 1.4 compliant
• HDMI input supports ‘Standard’ mode and ‘TV’ mode EDID settings
• HDR Pass Through supported.
Note: To active HDR function, input source and output device
should also equip and support HDR function.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1 2 3 4 5
OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT
EDID
STD TV
SYS-RST
ON OFF
+
1 3
2
1 EDID: Switch the dip switch to choose EDID mode to Standard (STD)
or TV mode. When on TV mode, the unit will automatically detect
and store output 1 sink EDID data. Switch to STD mode, the unit will
set to standard at 1080p and audio standard at PCM 2 channel.
2 OUTPUT 1~5: Connect to 6G HDMI TV / display or HD amplifier for
output display.
3 SYS-RST: Switch the dip switch from off to on, the unit will trigger TV
to its HDMI input1 immediately, when stays in on, the unit will trigger
the system in every 8~10 minutes. (*The purpose of this function is
to guarantee all outputs are displaying the corresponding image.
For example, at the display side user may switch to different HDMI
input or select other sources and this reset function will force the
display to switch back to its HDMI input1. TV/displays shall support
CEC function in order to perform this function successfully.)

4
6.2 Rear Panel
6 7 81
OUTPUT OUTPUT INPUT OUTPUTSERVICE SYNC POWER
DC 5V
1 3 4 22 65
1 SERVICE: This is reserved for firmware update use only.
2 OUTPUT 6~8: Connect to HDMI 6G TV/display or HD amplifier for
output signal display.
3 SYNC: When input detected, the LED will illuminate, the LED will
flicker when detected abnormal, for example, when source signal
not stabled. When input is not connected, the LED light will be off.
4 INPUT: Connect with 6G HDMI source equipment such as Blue-ray/
PS4 players and or PC/Laptop devices.
5 Power: This LED will illuminate when the device is connected to an
active power supply.
6 DC 5V: Connect the adapter included in the package and
connect to AC wall outlet for power supply.

5
7. CONNECTION DIAGRAM
1 2 3 4 5
OUTPUT OUTPUT OUTPUT OUTPUT OUTPUT
EDID
STD TV
SYS-RST
ON OFF
+
6 7 81
OUTPUT OUTPUT INPUT OUTPUTSERVICE SYNC POWER
DC 5V
Simultaneous
HDMI OUT
6G HDMI TV/Display 6G HDMI TV/Display
6G HDMI TV/Display
6G HDMI TV/Display
Projector
Projector Projector
Blu-Ray/PS4Player
Projector
Power
Supply
Simultaneous
HDMI Outputs
HDMI
Input

6
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 600MHz/18Gbps
Input Ports 1 x HDMI
1 x USB(Service)
Output Ports 8 x HDMI
Supported Resolutions VGA~WUXGA
480i~1080p@24/50/60
4K2K@24/25/30/50/60(YUV444)
HDMI Cable I/O 5m@4K2K/60_YUV444
Distance 10m@1080p/12-bit
15m@1080p/8-bit
Power Supply 5VDC/3A (US/EU standards, CE/FCC/
UL certified)
ESD Protection Human Body model:
± 8kV (air-gap discharge)
± 4kV (contact discharge)
Chassis Material Metal
Silkscreen color Black
Dimensions 240mm (W) x 103mm (D) x 25mm (H)
(Jacks excluded)
240mm (W) x 110mm (D) x 30mm (H)
(Jacks included)
Weight 690g
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
Power Consumption 9.5w

7
8.2 Supported Resolutions
DVI and HDMI Supported Resolutions Input Output
640x480@60/72/75/85 √ √
800x600@56/60/72/75/85 √ √
1024x768@60/70/75/85 √ √
1280x1024@60 √ √
1366x768@60 √ √
1600x1200@60 √ √
1920x1080@60 √ √
1920x1200@60 √ √
1440x576i@50 √ √
[email protected]/60 √ √
[email protected]/60 √ √
720x576p@50 √ √
1280x720p@50/59.94/60 √ √
1920x1080i@50/59.94/60 √ √
[email protected]/24/25/29.97/30/50/59.94/60 √ √
3840x2160@24/25/30/50/60 √ √
4096x2160@24/25/30/50/60 √ √
