Operation Manual
Operation Manual
UHD+HDMI over Copper Receiver
VEX-X1102R-B0C

DISCLAIMERS
The information in this manual has been carefully checked and is believed
to be accurate. Cypress Technology assumes no responsibility for any
infringements of patents or other rights of third parties which may result from
its use.
Cypress Technology assumes no responsibility for any inaccuracies that
may be contained in this document. Cypress also makes no commitment to
update or to keep current the information contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express written
permission and consent from Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document are trademarks of
the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture
or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings
or empty slots in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it
is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to
be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings
in the unit housing that provide ventilation and allow for su󰀩cient space
for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use to
avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2021/07/09 Preliminary release

CONTENTS
1. Introduction...................................................... 1
2. Applications ..................................................... 1
3. Package Contents ........................................... 1
4. System Requirements..................................... 1
5. Features............................................................ 2
6. Operation Controls and Functions ................ 3
6.1 Front Panel.................................................. 3
6.2 Rear Panel................................................... 4
7. Connection Diagram ....................................... 5
8. Specications .................................................. 6
8.1 Technical Specications .............................. 6
8.2 Video Specications .................................... 7
8.3 Audio Specications .................................... 9
8.3.1 Digital Audio ....................................... 9
8.4 Cable Specications.................................... 9
9. Acronyms ....................................................... 10

1
1. INTRODUCTION
This 4K UHD+HDMI over Copper Receiver is designed for high-quality
AV extension with minimum latency. By using a sophisticated ultra-light
compression scheme (lossless for most content) it’s a great solution for
extending 4K@60Hz (4:4:4) HDMI audio/video streams. Advanced HDMI
content such as HDR (High Dynamic Range), 10-bit color and multi-
channel HD Bitstream audio can be easily received. The use of 10 Gigabit
Ethernet allows for extension distances of up to 100m when using Cat.6A/7.
Additionally, this unit’s compact form factor makes it ideal for installation in
tight spaces, or inclusion in A/V travel kits.
2. APPLICATIONS
• High quality, low latency, video extension
• Household entertainment
• Lecture halls, meeting rooms, and classrooms
• Point-to-Point secure video conferencing
3. PACKAGE CONTENTS
• 1× UHD+HDMI over Copper Receiver
• 1× 5V/2.6A DC Power Adapter
• 1× Shockproof Feet (Set of 4)
• 1× Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI receiving equipment such as an HDTV, monitor, or audio amplier
• Compatible copper-based transmitter
• The use of Premium High Speed HDMI cables, and industry standard
Cat.6A, or Cat.7 Ethernet cable is highly recommended.

2
5. FEATURES
• HDMI 2.0 and DVI 1.0 compatible
• HDCP 2.2 and HDCP 1.x compliant
• 1 10GbE input
• 1 HDMI output
• Ultra-light compression, lossless for most content
• Extension up to 100m when using at.6A/7
• Supports up to 4K UHD+ (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input
and output
• Supports pass-through of 10/12-bit HDR sources
• Supports pass-through of audio formats including LPCM (up to 8
channels), Bitstream and HD Bitstream
• Simple, hassle free, point-to-point connection

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
CAT6A/7VIDEO
HDMI OUT
SYS
1 3
2
4 5
1Power ( ) LED: This LED will illuminate to indicate the unit is on and
receiving power.
 Note:ThisLEDwillblinkduringthermwareupdateprocess.
2System ( ) LED: This LED will illuminate to indicate that the system is
stable and ready to process audio/video streams.
 Note:ThisLEDwillblinkduringthermwareupdateprocess.
3VIDEO LED: This LED will illuminate to indicate that the video source is
stable, and streaming is in process.
4HDMI OUT Port: Connect to an HDMI TV, monitor, or amplier for digital
video and audio output.
5CAT6A/7 Port: Connect directly to a compatible transmitter for audio and
video extension.

4
6.2 Rear Panel
DC 5V
SERVICE
1 2
1SERVICE (USB Mini-B) Port: This port is for rmware update only.
2DC 5V Port: Plug the 5V DC power adapter into this port and connect it
to an AC wall outlet for power.

5
7. CONNECTION DIAGRAM
TX
RX
DC 5V
SERVICE
DC 5V
SERVICE
CAT6A/7VIDEO
HDMI OUT
SYS
CAT6A/7VIDEO
HDMI IN
SYS
Media Player
Smart TV
Power
Supply
Power
Supply
HDMI
Input
HDMI
Output

6
8. SPECIFICATIONS
8.1 Technical Specications
HDMI Bandwidth 18Gbps
Ethernet Bandwidth 10Gbps
Input Ports 1×10GbE (RJ-45)
Output Ports 1×HDMI (Type-A)
Service Port 1×USB 2.0 (Mini-B)
Power Supply 5V/2.6A DC
(US/EU standards, CE/FCC/UL certied)
ESD Protection (HBM) ±8kV (Air Discharge)
±4kV (Contact Discharge)
Dimensions (W×H×D) 57mm×20.6mm×87mm [Case Only]
60mm×20.6mm×87mm [All Inclusive]
Weight 139g
Chassis Material Metal (Steel)
Chassis Color Black
Operating Temperature 0˚C – 50˚C/32˚F – 122˚F
Storage Temperature -20˚C – 60˚C/-4˚F – 140˚F
Relative Humidity 20 – 90% RH (Non-condensing)
Power Consumption 4.62W

7
8.2 Video Specications
Supported Resolutions (Hz)
Input Output
10GbE HDMI
720×400p@70/85  
640×480p@60/72/75/85  
720×480i@60  
720×480p@60  
720×576i@50  
720×576p@50  
800×600p@56/60/72/75/85  
848×480p@60  
1024×768p@60/70/75/85  
1152×864p@75  
1280×720p@50/60  
1280×768p@60/75/85  
1280×800p@60/75/85  
1280×960p@60/85  
1280×1024p@60/75/85  
1360×768p@60  
1366×768p@60  
1400×1050p@60  
1440×900p@60/75  
1600×900p@60RB  
1600×1200p@60  
1680×1050p@60  
1920×1080i@50/60  
1920×1080p@24/25/30  
1920×1080p@50/60  
1920×1200p@60RB  

8
Supported Resolutions (Hz)
Input Output
10GbE HDMI
2560×1440p@60RB  
2560×1600p@60RB  
2048×1080p@24/25/30  
2048×1080p@50/60  
3840×2160p@24/25/30  
3840×2160p@50/60 (4:2:0)  
3840×2160p@24, HDR10  
3840×2160p@50/60 (4:2:0), HDR10  
3840×2160p@50/60  
4096×2160p@24/25/30  
4096×2160p@50/60 (4:2:0)  
4096×2160p@24, HDR10  
4096×2160p@50/60 (4:2:0), HDR10  
4096×2160p@50/60  

9
8.3 Audio Specications
8.3.1 Digital Audio
10GbE Input / HDMI Output
LPCM
Max Channels 8 Channels
Sampling Rate (kHz) 32, 44.1, 48
Bitstream
Supported Formats Standard & High-Denition
8.4 Cable Specications
Cable Length
1080p 4K30 4K60
8-bit 12-bit
(4:4:4)
8-bit
(4:4:4)
8-bit
High Speed HDMI Cable
HDMI Output 15m 10m 5m 3m
Ethernet Cable
Cat.5e/6 70m
Cat.6A/7 100m
Bandwidth Category Examples:
• 1080p (FHD Video)
- Up to 1080p@60Hz, 12-bit color
- Data rates lower than 5.3Gbps or below 225MHz TMDS clock
• 4K30 (4K UHD Video)
- 4K@24/25/30Hz & 4K@50/60Hz (4:2:0), 8-bit color
- Data rates higher than 5.3Gbps or above 225MHz TMDS clock but
below 10.2Gbps
• 4K60 (4K UHD+Video)
- 4K@50/60Hz (4:4:4, 8-bit)
- 4K@50/60Hz (4:2:0, 10-bit HDR)
- Data rates higher than 10.2Gbps

10
9. ACRONYMS
ACRONYM COMPLETE TERM
10GbE 10 Gigabit Ethernet
4K UHD 4K Ultra-High-Denition (10.2Gbps max)
4K UHD+4K Ultra-High-Denition (18Gbps max)
AV Audio/Video
AVoIP Audio/Video over IP
Cat.5e Enhanced Category 5 cable
Cat.6 Category 6 cable
Cat.6A Augmented Category 6 cable
Cat.7 Category 7 cable
CEC Consumer Electronics Control
DVI Digital Visual Interface
EDID Extended Display Identication Data
Gbps Gigabits per second
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
HDR High Dynamic Range
kHz Kilohertz
LAN Local Area Network
LED Light-Emitting Diode
LPCM Linear Pulse-Code Modulation
MHz Megahertz
TMDS Transition-Minimized Di󰀨erential Signaling
USB Universal Serial Bus
