Cypress SE-DVI-8-LC User manual

8-in 1-out
DVI Switcher
Operation Manual
CDVI-81

Introduction
Cypress CDVI-81 is a high performance DVI switcher
with remote control. It allows your various DVI sources to
share one DVI display.
Simply pressing one button to select your desired DVI source
for display on the HDTV.
Features
* HDMI 1.1, HDCP 1.1 and DVI 1.0 compliant.
* Signal enhancement feature allows you to improve signal quality
after long distance transmission.
* LED indicators.
* Ideal for home theater integration.
* Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, and UXGA (1600 x 1200)&
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, and 1080p
* Remote control.
* Easy to install and simple to operate.
Operation Controls and Functions
Front Panel
1245 1233
1. Remote control sensor.
2. DVI inputs: Connect your various DVI sources to each of the
DVI input of the unit using DVI cables.
3. Input select/Indicators: Press the " INPUT" button repeatedly to switch to your
desired input source and the LED will illuminate to indicate which
input source is being selected.
4. Signal Enhancement/Indicator: Press the " Signal Enhance" button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
5. Power LED Indicator: The LED will illuminate when the power is connected.
DVI IN 6DVI IN 5 DVI IN 7 DVI IN 8
INPUT3 421 POWER
SIGNAL
ENHANCE
87
65
CDVI-81 8x1 DVI Switcher

Operation Controls and Functions
Rear Panel
1 4 2 3
1. DVI output: Connect the DVI output to the DVI input of
your display using DVI cable.
2.DVI inputs: Connect your various DVI sources to each of the
DVI input of the unit using DVI cables.
3. Power: Plug the supplied 5VDC power supply into the unit.
4. RS232: 9-pin D-sub female connector for connecting to your other control
console for remote control.
Remote Control
CR-22
1
3
2
1. Power:
Press the button to turn on/off the unit.
2. Direct input selector:
Press numerical number button to select your desired
input source.
3. Void buttons (No function). If the button number is
greater than the total input number of the unit then
the button is of no function.
Specifications
* Frequency bandwidth: 1.65Gbps(single link)
* Inputs: 8 x DVI female ports (Type A connector)
* Output: 1 x DVI female port (single link)
* 5VDC universal power supply
* Weight: 1kgs
* Dimension: 280(W) x104(D) x 44(H)mm
DVI IN 1DVI IN 2DVI IN 3DVI IN 4DVI OUT
RS-232
DC 5V

LCD TV DVD 2
DVD 2
DVD 1 STB
