Cytrix PCCast W7 User manual

Cytrix PCCast W7 Wi-Fi TV Box
USER MANUAL

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
WELCOME
Thank you for purchasing this device. It brings you wonderful user experience.
Before beginning, please refer to this user manual carefully. In case of any doubts
regarding CYTRIX TECHNOLOGY W7, you are welcomed to visit the CYTRIX
TECHNOLOGY official Facebook website: www.facebook.com/cytrixtech, for raising
your questions and sharing your experience.
Product features:
Wi-Fi connection, achieve displaying synchronization easily;
Based on Intel Baytrail 3736F architecture, processor frequency is 2.16GHz;

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
CHAPTER ONE A Glance on W7
I. W7 Appearance

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
KEYS
1: Power Switch key,
2: USB port, for connecting peripherals
3: Earphone jack
4: Micro USB for connecting to PC, when W7 is running Android OS
5: TF card slot: for TF card, maximum to 64GB
7: HDMI port
8: LAN RJ45 for internet cable
9: DC 12V power supply jack

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
II. Product Specifications
Items
Function description
1
Processor
Baytrail 3736F ,frequency is 1.83GHz,up to 2.16
2
LCD
7”1280*800
3
RAM
2GB
4
Storage
32GB OR 64GB
5
OS
Windows 8.1 with Bing + Android 4.4
4
Wi-Fi
2.4GHz , Wi-Fi signal;
6
Connection
ports
HDMI 1.4; MicroUSB for power supply and upgrading, and
USB2.0 for peripherals;
7
Switch key
Mode switching、reset 、upgrading key;
8
Bluetooth
4.0

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
III. W7 Accessories:
Name
quantity
Power charger
pc
1
User manual
pc
1

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
CHAPTER TWO Operations
I. OS operation
1. Connect 12V 2.4A Charger to the W7 DC jack for power supplying;
2. Press power button for a few seconds to turn it on;
3. Select Android or Windows, press Android icon to go to regular Android OS, and
press Windows icon to go to Windows system

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
4. OS Switch
When you are in Windows system press the Win to And Icon for switching into
Android

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m

Cytrix Technology www.cytrixtech.com
548 Donald St. Ste. 3, Bedford NH 03110
[phone] [email protected]m
When you are in Android system, slide the top right corner, and press the OS switch
icon to set up into Windows
5. HDMI output
Go to “Device”-“project”, and connect W7 to TV set (any display) via HDMI cable
