D-Link DCS-1000 User manual

Web Based RemoteWeb Based Remote
Web Based RemoteWeb Based Remote
Web Based Remote
Access Using Any JavaAccess Using Any Java
Access Using Any JavaAccess Using Any Java
Access Using Any Java
Enabled Web BrowserEnabled Web Browser
Enabled Web BrowserEnabled Web Browser
Enabled Web Browser
The DCS-1000 ensures compatibility with
your computer and operating system by
utilizing a web management interface,
accessible using any Java-enabled web
browser.
Integrated Web ServerIntegrated Web Server
Integrated Web ServerIntegrated Web Server
Integrated Web Server The DCS-1000 eliminates the need to
connect the camera directly to your
computer by using an integrated web
server. Once installed, you use the built-in
IP address to gain access to the camera,
view live streaming video, and make
necessary changes to camera settings.
10/100Mbps Fast10/100Mbps Fast
10/100Mbps Fast10/100Mbps Fast
10/100Mbps Fast
Ethernet ConnectionEthernet Connection
Ethernet ConnectionEthernet Connection
Ethernet Connection The DCS-1000 utilizes the speed and
convenience of 10/100Mbps Fast
Ethernet. Using a standard RJ-45 Fast
Ethernet jack, the DCS-1000 easily
connects to your existing Fast Ethernet
network using the included CAT5 Fast
Ethernet networking cable.
Archive Streaming VideoArchive Streaming Video
Archive Streaming VideoArchive Streaming Video
Archive Streaming Video
to your Hard Driveto your Hard Drive
to your Hard Driveto your Hard Drive
to your Hard Drive The DCS-1000 includes IPView, a
Windows based monitoring application.
IPView allows you to control all of the
DCS-1000 or DCS-1000W cameras on
your LAN from one location. IPView also
lets you view as many as 16 cameras on
one screen and also supports manual and
scheduled recording to anAVI movie file
on your hard drive.
Streaming Video at upStreaming Video at up
Streaming Video at upStreaming Video at up
Streaming Video at up
to 30 Frames Per Secondto 30 Frames Per Second
to 30 Frames Per Secondto 30 Frames Per Second
to 30 Frames Per Second The DCS-1000 uses Motion-JPEG to
stream live video at up to 30fps using
Motion-JPEG technology. The camera
supports resolutions up to 640x480 and
five levels of JPEG compression to
customize image size and quality to ensure
a steady stream to any viewer.
D-LinkD-Link
D-LinkD-Link
D-Link
DCS-1000DCS-1000
DCS-1000DCS-1000
DCS-1000
ExpressExpress
ExpressExpress
Express
EtherNetworkEtherNetwork
EtherNetworkEtherNetwork
EtherNetwork
Internet CameraInternet Camera
Internet CameraInternet Camera
Internet Camera

DCS-1000DCS-1000
DCS-1000DCS-1000
DCS-1000
D-LinkSystems,Inc. 53 Discovery DriveIrvine CA 92618 www.dlink.com
©CopyrightD-Link Systems, Inc.2002.All rights reserved.D-Link® is a registeredtrademark of D-LinkSystems, Inc.
Othertrademarks orregistered trademarksare theproperty oftheir respectivemanufacturers orowners. Priceand
specificationsaresubjecttochanges withoutnotice. See insidepackage forwarrantydetails.
* 24/7 Tech Support is available only in USA.
Product InformationProduct Information
Product InformationProduct Information
Product Information
Part No: DCS-1000
Description: Express
EtherNetwork Internet Camera
UPC: 790069-241420
D-Link Systems, Inc.
TEL: [phone]
www.dlink.com
ReplaceableReplaceable
ReplaceableReplaceable
Replaceable
C/CS Lens MountC/CS Lens Mount
C/CS Lens MountC/CS Lens Mount
C/CS Lens Mount
Power LEDPower LED
Power LEDPower LED
Power LED
RJ-45RJ-45
RJ-45RJ-45
RJ-45
JackJack
JackJack
Jack
Package ContentsPackage Contents
Package ContentsPackage Contents
Package Contents
• DCS-1000
• Software & Documentation on
CD-ROM1
• Stand & Mounting Brackets
• AC Power Adapter
• Installation Guide
• Manual
• CAT5 Cable
1: Latest Software and Documentation are
Available at http://support.dlink.com
LAN/WANLAN/WAN
LAN/WANLAN/WAN
LAN/WAN
LEDLED
LEDLED
LED
ResetReset
ResetReset
Reset
SwitchSwitch
SwitchSwitch
Switch
5 Volt I/O5 Volt I/O
5 Volt I/O5 Volt I/O
5 Volt I/O
ConnectorsConnectors
ConnectorsConnectors
Connectors
DC 5V/2.4ADC 5V/2.4A
DC 5V/2.4ADC 5V/2.4A
DC 5V/2.4A
Power SupplyPower Supply
Power SupplyPower Supply
Power Supply
