D-Link DIR-505 User manual

DIR-505
All-in-one Mobile Companion
Transform any Internet connection
into aWi-Fi hotspot
Wirelessly access your media les
from any USB drive
Transform any Internet connection into
a Wi-Fi hotspot
Wirelessly access your media les from
any USB drive
Easily backup your iPad® and iPhone® les
Free iPad® and iPhone® apps
Product Highlights What this product does
Get the best of all worlds with the handy little Mobile Companion. Imagine being able
to share your videos, music and photos from any external hard drive or USB thumb drive
to any iPad® or iPhone® mobile devices in your home. What’s more, you can back up
your videos, music and photos easily. And, the Mobile Companion isn’t just for home. If
you want to take the Mobile Companion on the road with you, it works as a great travel
router/access point, so you can get instant wireless from any hotel or conference room
where a network already exists. While you’re out and about, the Mobile Companion can
also charge your iPhone®.
Great for
traveling

DIR-505 All-in-one Mobile Companion
Package Contents
• All-in-oneMobileCompanion
• EthernetCable
• QuickInstallGuide
Minimum System Requirements
Computer with:
• Window7®5,Windows Vista®5Windows® XP SP25
 orMacOSX(v10.7)
• InternetExplorer®v9orMozilla®Firefox®v9.0
 orGoogleChrome(16.0.912.75)orSafari5
• 20MBHardDiskSpace
• NetworkInterfaceCard
Power Input:
• 100-240VAC,50/60Hz
For Internet Access:
• CableorDSLModemforHighSpeedInternet
Connection
• SubscriptiontoanInternetServiceProvider(ISP)
• ForWirelessNPerformance,an802.11nadapter
is required
Features
• MultipleOperationModes,Router/AccessPoint,
 RepeaterandWi-FiHotSpotModestoCreate
 DierentUsages
• IEEE802.11nand802.11gCompliant1
• ModeSelectorSwitch
• One10/100LAN/WANPort2
• MACSupport
• SupportsPoweroverUSBforAddedConvenience
• SupportsSecureWirelessEncryptionUsingWPA
or WPA2
• Wi-FiProtectedSetup(WPS)PushButton
• DualActiveFirewalls-SPIandNAT
 (RouterModeonly)
• SharePort®WebFileAccessSupport
 (RouterandWi-FiHotspotModeOnly)
• SharePort®MobileAppforiPhone®andiPad®
 (RouterandWi-FiHotspotModeOnly)
• QRSMobileAppforiPhone®andiPad®
 (RouterModeOnly)
• Wall-plugDesignforMoreConvenientUse
• ElegantDesignandCompactSize-
 DoesNotBlockOtherOutlets
• D-LinkOne-TouchAPConguration
• GuestZoneSupport
• 24/7BasicInstallationSupport3
• 1-YearLimitedWarranty4
Internet Router / Access Point
Internet Router / Access Point
iPhone®
iPad®
Laptop
DIR-505
Mobile Companion
Internet
iPhone®
iPad®
Laptop
USB Drive
(for file sharing)
DIR-505
Mobile Companion
iPhone®
iPad®
Laptop
USB Drive
(for file sharing)
DIR-505
Mobile Companion
Modem
Router Mode
Repeater Mode
Wi-Fi Hotspot Mode
Wi-Fi-as-WAN:CreateaWi-FiHotspotfroma wireless
InternetconnectionandwithNATforitsownnetwork
Travel router
High-endrouterwith
USB sharing capability
OnlinesharingsiteorDropBoxsubscription
(ifover2GB)
Phone charger
Create aWi-Fi hotspot for all
your mobile devices
Watch videos from a USB drive
Share your videos and
pictures with friends
Charge your iPhone®
With this product What you needed before

Building Networks for People
DIR-505 All-in-one Mobile Companion
©2012D-LinkCorporation/D-LinkSystems,Inc.Allrightsreserved.D-Link,theD-Linklogo,mydlinkandtheD-LinkRoHSlogoaretrademarksorregisteredtrademarksofD-LinkCorporationoritssubsidiariesintheUnitedStatesand/orothercountries.
Other trademarks or registered trademarks are the property of their respective owners. Visit www.dlink.com for more details.
Updated3/7/12
U.S.A.|17595Mt.HerrmannStreet|FountainValley,CA92708|800.326.1688|dlink.comCanada|2525MeadowvaleBlvd|Mississauga,ONL5N5S2|800.361.5265|dlink.ca
For more information
DIR-505 QRS App
SharePort™
Mobile App
Technical Specications
Standards
• IEEE802.11n
• IEEE802.11g
• IEEE802.3
• IEEE802.3u
Wireless Modes
• Wi-FiHotspotMode
• Router/APMode
• RepeaterMode
 (USBsharingcapabilitydisabled)
Wireless Frequency Range
• 2.4GHzto2.4835GHz
Antennas
• InternalAntenna
Security
• Wi-FiProtectedAccess(WPA/WPA2)
• WPS™(PBC)
Advanced Features
• SharePort™MobileappforiOS
• QuickRouterSetupappforiOS
• VPNpassthrough
• GuestZoneSupport
• UPnP™Support
• WebFileAccessSupport
• Wi-FiWMMQualityofService
Advanced Firewall Features
• NetworkAddressTranslation(NAT)
• StatefulPacketInspection(SPI)
• MACAddressFiltering
• DMZSupport
Device Management
• WebUI
Diagnostic LEDs
• Power/WPS
Operating Temperature
• 32to104˚F(0to40˚C)
Operating Humidity
• 0%to90%non-condensing
Certications
• CE
• Wi-FiCertied
• FCC
• IC
Dimensions
• 2.68”x1.65”x2”
 (68x42x51mm)
Weight
• 0.23lb(104.3grams)
Warranty
• 1-YearLimitedWarranty4
1Actualdatathroughputwillvary.Networkconditionsandenvironmentalfactors,includingvolumeofnetworktracandnetworkoverhead,loweractualdatathroughputrate.
2The attached devices must have CAT5 or above Ethernet cable.
324/7BasicInstallationSupportisavailableonlyintheUSAfortherst30daysfromdateoforiginalpurchase.
41-YearLimitedWarrantyavailableonlyintheUSAandCanada.
5ComputermustadheretoMicrosoft’srecommendedSystemRequirements.
Allreferencestospeedandrangeareforcomparisonpurposesonly.Productspecications,sizeandshapearesubjecttochangewithoutnotice,andactualproductappearancemaydierfromthatdepictedherein.
Internet Port
Plug your Internet cable in here
ResetButton
Restoresettings
WPS Push Button
Securely connect to wireless network
USB Port
Connect a USB storage device
Mode Switch
Switch between
Router/AP,Repeaterand
Wi-FiHotspotMode
