D-Link DI-1162M User manual

DI-1162/DI-1162M
RemoteAccessRouter
User’sGuide
First Edition (August 2000)
6DI1162M..01
Printed In Taiwan
RECYCLABLE

Limited Warranty
Hardware:
D-Link warrants each of its hardware products to be free from defects in workmanship and materials under normal use and service for a
period commencing on the date of purchase from D-Link or its Authorized Reseller and extending for the length of time stipulated by the
Authorized Reseller or D-Link Branch Office nearest to the place of purchase.
This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety (90) days
of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card.
If the product proves defective within the applicable warranty period, D-Link will provide repair or replacement of the product. D-Link shall
have the sole discretion whether to repair or replace, and replacement product may be new or reconditioned. Replacement product shall be of
equivalent or better specifications, relative to the defective product, but need not be identical. Any product or part repaired by D-Link
pursuant to this warranty shall have a warranty period of not less than 90 days, from date of such repair, irrespective of any earlier expiration
of original warranty period. When D-Link provides replacement, then the defective product becomes the property of D-Link.
Warranty service may be obtained by contacting a D-Link office within the applicable warranty period, and requesting a Return Material
Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D-Link, then a proof of purchase
(such as a copy of the dated purchase invoice) must be provided. If Purchaser's circumstances require special handling of warranty correction,
then at the time of requesting RMA number, Purchaser may also propose special procedure as may be suitable to the case.
After an RMA number is issued, the defective product must be packaged securely in the original or other suitable shipping package to ensure
that it will not be damaged in transit, and the RMA number must be prominently marked on the outside of the package. The package must be
mailed or otherwise shipped to D-Link with all costs of mailing/shipping/insurance prepaid. D-Link shall never be responsible for any software,
firmware, information, or memory data of Purchaser contained in, stored on, or integrated with any product returned to D-Link pursuant to
this warranty.
Any package returned to D-Link without an RMA number will be rejected and shipped back to Purchaser at Purchaser's expense, and D-Link
reserves the right in such a case to levy a reasonable handling charge in addition mailing or shipping costs.
Software:
Warranty service for software products may be obtained by contacting a D-Link office within the applicable warranty period. A list of D-Link
offices is provided at the back of this manual, together with a copy of the Registration Card. If a Registration Card for the product in question
has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when
requesting warranty service. The term "purchase" in this software warranty refers to the purchase transaction and resulting license to use
such software.
D-Link warrants that its software products will perform in substantial conformance with the applicable product documentation provided by
D-Link with such software product, for a period of ninety (90) days from the date of purchase from D-Link or its Authorized Reseller. D-Link
warrants the magnetic media, on which D-Link provides its software product, against failure during the same warranty period. This warranty
applies to purchased software, and to replacement software provided by D-Link pursuant to this warranty, but shall not apply to any update or
replacement which may be provided for download via the Internet, or to any update which may otherwise be provided free of charge.
D-Link's sole obligation under this software warranty shall be to replace any defective software product with product which substantially
conforms to D-Link's applicable product documentation. Purchaser assumes responsibility for the selection of appropriate application and
system/platform software and associated reference materials. D-Link makes no warranty that its software products will work in combination
with any hardware, or any application or system/platform software product provided by any third party, excepting only such products as are
expressly represented, in D-Link's applicable product documentation as being compatible. D-Link's obligation under this warranty shall be a
reasonable effort to provide compatibility, but D-Link shall have no obligation to provide compatibility when there is fault in the third-party
hardware or software. D-Link makes no warranty that operation of its software products will be uninterrupted or absolutely error-free, and no
warranty that all defects in the software product, within or without the scope of D-Link's applicable product documentation, will be corrected.
D-Link Offices for Registration and Warranty Service
The product's Registration Card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty
service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest you. An address/
telephone/fax/e-mail/Web site list of D-Link offices is provided in the back of this manual.

Trademarks
Copyright 2000 D-Link Corporation.
Contents subject to change without prior notice.
D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective
proprietors.
Copyright Statement
No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation,
transformation, or adaptation without permission from D-Link Corporation/D-Link Systems Inc., as stipulated by the United
States Copyright Act of 1976.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with this user’s guide, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be
required to take adequate measures.
Warnung!
Dies ist in Produkt der Klasse A. Im Wohnbereich kann dieses Produkt Funkstoerungen verursachen. In
diesem Fall kann vom Benutzer verlangt werden, angemessene Massnahmen zu ergreifen.
Precaución!
Este es un producto de Clase A. En un entorno doméstico, puede causar interferencias de radio, en cuyo case,
puede requerirse al usuario para que adopte las medidas adecuadas.
Attention!
Ceci est un produit de classe A. Dans un environnement domestique, ce produit pourrait causer des
interférences radio, auquel cas l`utilisateur devrait prendre les mesures adéquates.
Attenzione!
Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente domestico il prodotto può causare
interferenze radio, nel cui caso è possibile che l`utente debba assumere provvedimenti adeguati.
BSMI Warning

Table of Contents
INTRODUCTION...................................................................................................................................................1
Ease of Installation .............................................................................................................................................1
Networking Compatibility ...................................................................................................................................1
PRODUCT FEATURES ...............................................................................................................................................1
LAN Port ............................................................................................................................................................. 1
Multiple WAN Ports ............................................................................................................................................1
Expansion Slot/Modules......................................................................................................................................1
Dial on Demand..................................................................................................................................................2
Full Network Management..................................................................................................................................2
Security................................................................................................................................................................ 2
RIP-1/ RIP-2 Routing Protocols .........................................................................................................................2
DHCP Support.................................................................................................................................................... 2
Data Compression............................................................................................................................................... 2
Network Address Translation (NAT/NAPT)........................................................................................................2
APPLICATIONS FOR THE DI-1162/DI-1162M........................................................................................................... 2
Internet Access....................................................................................................................................................3
Internet Security..................................................................................................................................................3
Link Branch Offices.............................................................................................................................................3
Local Routing......................................................................................................................................................3
Telecommuting....................................................................................................................................................3
WHAT THIS MANUAL DOESN’T COVER...................................................................................................................3
ADDITIONAL INSTALLATION REQUIREMENTS .......................................................................................................... 3
INSTALLATION..................................................................................................................................................... 4
OVERVIEW ..............................................................................................................................................................4
OTHER RESOURCES................................................................................................................................................. 4
PACKING LIST..........................................................................................................................................................4
IDENTIFYING EXTERNAL COMPONENTS...................................................................................................................5
SITE INSTALLATION.................................................................................................................................................7
Rack Mounting.................................................................................................................................................... 7
INSTALLATION AND INITIAL CONFIGURATION OF THE ROUTER ................................................................................7
Step 1 - Setting up the Console ...........................................................................................................................8
Step 2 - Connecting the Console to the Router ...................................................................................................8
Step 3 - Initial Configuration of the Router ........................................................................................................8
Step 3a - Configuring the LAN Port..................................................................................................................10
Step 3b - Configuring the WAN Ports for Dial-in, Dial-out and Leased Lines.................................................10
Step 4 - Connecting the Router to a LAN.......................................................................................................... 13
Step 5 - Connecting the Router to WAN Devices ..............................................................................................13
Step 6 – Plugging in All Devices.......................................................................................................................13
Step 7 - Powering Up the DI-1162/DI-1162M..................................................................................................14
CONFIGURATION AND MANAGEMENT......................................................................................................15
CONSOLE PROGRAM MAIN MENU.........................................................................................................................15
SYSTEM INFORMATION..........................................................................................................................................16
INTERFACE CONFIGURATION.................................................................................................................................17
LAN ...................................................................................................................................................................18
WAN ..................................................................................................................................................................19
NETWORK CONFIGURATION .................................................................................................................................. 22
IP Configuration ...............................................................................................................................................23
IP Static Route ..................................................................................................................................................27
OSPF Configuration .........................................................................................................................................28
Bridge Configuration ........................................................................................................................................34

IPX Configuration.............................................................................................................................................36
SNMP AGENT CONFIGURATION............................................................................................................................41
SNMP Community Configuration .....................................................................................................................42
SNMP Trap Manager........................................................................................................................................ 42
ADVANCED FUNCTIONS.........................................................................................................................................43
Remote Access Configuration ...........................................................................................................................44
Script File Configuration..................................................................................................................................54
DHCP Configuration ........................................................................................................................................56
Filter Configuration..........................................................................................................................................60
Multiple Home Configuration........................................................................................................................... 68
Static ARP.........................................................................................................................................................70
NAT Configuration............................................................................................................................................72
NAPT for Special Aps........................................................................................................................................79
Telnet/Discovery Enable...................................................................................................................................81
DNS Configuration............................................................................................................................................82
RADIUS Configuration.....................................................................................................................................83
Multi-Link PPP Configuration..........................................................................................................................84
ADMIN CONFIGURATION........................................................................................................................................86
SYSTEM MAINTENANCE ........................................................................................................................................86
System Status.....................................................................................................................................................87
Counter..............................................................................................................................................................87
Runtime Tables..................................................................................................................................................91
Log and Trace...................................................................................................................................................96
Diagnostic.......................................................................................................................................................101
Software Update Menu.................................................................................................................................... 105
System Restart................................................................................................................................................. 106
Factory Reset .................................................................................................................................................. 107
System Settings Backup/Restore......................................................................................................................108
PROM SYSTEM CONFIGURATION..............................................................................................................111
PROM System Menu........................................................................................................................................111
System Configuration Menu............................................................................................................................112
TCP/IP Parameters Configuration Menu ....................................................................................................... 113
System Reset....................................................................................................................................................113
Software Update Menu.................................................................................................................................... 114
Factory Reset .................................................................................................................................................. 116
Execute Bootload ............................................................................................................................................116
USING TELNET .................................................................................................................................................117
TELNET CONFIGURATION ....................................................................................................................................117
Using Telnet via LAN......................................................................................................................................117
Using Telnet via WAN..................................................................................................................................... 117
System Timeout................................................................................................................................................117
USING RADIUS AUTHENTICATION ............................................................................................................117
INSTALLING A RADIUS SERVER......................................................................................................................... 118
CONFIGURING THE DI-1162/DI-1162M FOR RADIUS AUTHENTICATION...........................................................118
ADDING USERS TO THE RADIUS DATABASE...................................................................................................... 119
APPENDIX A – CABLES AND CONNECTORS............................................................................................120
RS-232 (EIA-574) for Diagnostic Port............................................................................................................120
RS-232 (EIA-530) Cable for WAN Port..........................................................................................................120
RS-449 Cable for WAN Port ........................................................................................................................... 121
V.35 Cable for WAN Port................................................................................................................................122
APPENDIX B – SPECIFICATIONS................................................................................................................. 123
APPENDIX C - IP CONCEPTS.........................................................................................................................124

IP ADDRESSES ....................................................................................................................................................124
IP Network Classes .........................................................................................................................................124
SUBNET MASK ....................................................................................................................................................125
APPENDIX D – IP PROTOCOL AND PORT NUMBERS.............................................................................126
IP PROTOCOL NUMBERS .....................................................................................................................................126
IP PORT NUMBERS..............................................................................................................................................126
APPENDIX E – CONFIGURATION FILE......................................................................................................127
CONFIGURATION FILE EXAMPLE..........................................................................................................................127
INDEX..................................................................................................................................................................129

DI-1162/DI-1162M Remote Access Router
1
Introduction
Congratulations on your purchase of a D-Link DI-1162/DI-1162M Remote Access Router. Your new router offers
inexpensive yet complete telecommunications and internetworking solutions for your corporate office, school or
business. It is ideal for everything from Internet browsing to receiving calls from Remote Dial-in Users. It
incorporates the most recent technologies to make fast, secure and stable connections to remote stations via LAN
to WAN and vice versa.
Distinguishing features of the DI-1162/DI-1162M include support for a full range of networking protocols such as
TCP/IP (Transmission Control Protocol/Internet Protocol), Ethernet, Fast Ethernet as well as various other
networking protocols.
Each DI-1162 /DI-1162M router is packed with features that give it the flexibility to provide a complete
networking solution for almost any site. The router fulfills the need for Internet access, IP-based intranetworks and
LAN to multiple WAN communications.
Ease of Installation
The DI-1162/DI-1162M is a self-contained unit that is quick and easy to install. It is designed to be a standalone
unit or it may be mounted on a standard 19-inch networking equipment rack. It uses standard Ethernet wiring to
connect (route) a local area network (LAN) to up to 4 separate wide area networks (WANs) through dial-up or
dedicated, leased lines.
Also included with the router is the DI-1162/DI-1162M Router Configuration Utility, a Windows-based
application that makes configuring the router a snap.
Networking Compatibility
The DI-1162/DI-1162M is compatible with remote access products from other companies such as Ascend, Cisco,
and 3Com. Furthermore, it supports Microsoft Windows 95, Windows 98, and Windows NT remote access
capability.
Product Features
LAN Port
The DI-1162/DI-1162M is equipped with an auto-negotiated 10/100 (Ethernet and Fast Ethernet) RJ-45 jack for
connecting the router to the LAN.
Multiple WAN Ports
The DI-1162/DI-1162M has two EIA-530 WAN ports, each of which can be connected to a dial-up (dial in or out)
line or a dedicated leased line by multiplexing with a modem or CSU/DSU (Channel Service Unit/ Data Service
Unit) respectively. We recommend connecting only one WAN port to the Internet.
Expansion Slot/Modules
The DI-1162/DI-1162M contains an expansion slot able to house any one of the following slide-in expansion
modules:
♦An RJ-45 10/100 Fast Ethernet port, giving the router another LAN connection.

DI-1162/DI-1162M Remote Access Router
2
♦Two high-speed serial (async/sync) ports for two additional WAN connections.
♦A BRI ISDN module (S/T interface only).
These modules allow you to expand the functionality of the DI-1162/DI-1162M to fulfill all your internetworking
needs.
Dial on Demand
The Dial-On-Demand feature allows the DI-1162/DI-1162M to automatically place a call to a remote node, via a
WAN, whenever there is traffic coming from any workstation on the LAN to that remote site.
Full Network Management
The DI-1162/DI-1162M incorporates SNMP (Simple Network Management Protocol) agents and a menu-driven
Network Management System accessible via an RS-232 (console) or Telnet connection.
Security
The DI-1162/DI-1162M supports PAP (Password Authentication Protocol), CHAP (Challenge Handshake
Authentication Protocol), Layer 2 and IP Filtering, and the creation of firewalls.
RIP-1/ RIP-2 Routing Protocols
The DI-1162/DI-1162M supports both RIP-1 and RIP-2 (Routing Information Protocol versions 1 and 2)
exchanges with adjacent routers. These exchanges allow the DI-1162/DI-1162M to send and/or receive routing
tables to adjacent routers in order to streamline WAN communications.
DHCP Support
DHCP (Dynamic Host Configuration Protocol) allows the DI-1162/DI-1162M router to automatically assign IP
addresses to computers as they enter the network. This feature frees the network administrator from assigning and
managing IP addresses for each individual machine on the LAN.
Data Compression
The DI-1162/DI-1162M incorporates the hardware-based Stac LZS Data Compression for CCP (Compression
Control Protocol).
Network Address Translation (NAT/NAPT)
This feature allows multiple users on the LAN to access the Internet (through an Internet Service Provider)
concurrently through a single IP address. This is especially useful for corporate office environments, where a large
number of users need access to the internet, but only a few internet addresses are available.
Applications for the DI-1162/DI-1162M
Some applications for the DI-1162/DI-1162M include:

DI-1162/DI-1162M Remote Access Router
3
Internet Access
The DI-1162/DI-1162M supports the TCP/IP (a.k.a. IP) protocol, which is the protocol language used for the
Internet. This router allows everyone connected to the LAN to access the Internet.
Internet Security
The DI-1162/DI-1162M can act as a firewall between your office network and the Internet, and can hide the size
of your office network and the host addresses of your office computers from prying Internet users. It can also filter
traffic to and from the Internet allowing only certain types of communications to or from certain locations to pass
through.
Link Branch Offices
The DI-1162/DI-1162M routes communications through its two (upgradeable to four) WAN ports allowing direct
communications to a branch office via phone lines, the internet or both.
Local Routing
The DI-1162/DI-1162M can route traffic between up to eight local IP networks.
Telecommuting
The DI-1162/DI-1162M allows remote users to dial in and obtain remote access to the LAN. This feature enables
users that have workstations with remote access capability, e.g. Windows 95, to dial in using a modem and access
the network resources without physically being in the office.
What This Manual Doesn’t Cover
This manual assumes that you are familiar with network management and networking devices, especially routing
protocols.
Additional Installation Requirements
In addition to the contents of your package, there are other hardware and software requirements needed before the
installation and use of your router. These requirements include:
♦Ethernet connection(s) to your computer(s) to form a LAN.
♦A computer equipped with an RS-232 serial port (standard on most PC’s) and serial line communications
software (i.e. Microsoft HyperTerminal included with Windows).
♦At least one modem or CSU/DSU for connecting the WAN port(s) to a telephone line.
♦At least one Internet IP Address per port on the router.
♦An Internet Service Provider (ISP).

DI-1162/DI-1162M Remote Access Router
4
Installation
This chapter details installation procedures for the DI-1162/DI-1162M router.
Overview
The DI-1162/DI-1162M can be configured in two ways; through a direct serial connection (a console), or
remotely, through the included Router Configuration Utility, Telnet, etc. Please note that if you wish to remotely
configure the router, you must still use a console to initially configure the LAN or WAN port for a remote
connection.
In general, the installation procedures are as follows:
1. Physically install the router into an equipment rack or onto a desktop.
2. Configure the router through a console.
3. Power off the router and console.
4. Plug in all cables and connectors (LAN, WAN, etc.).
5. Power on all devices.
Each of the above items is discussed in detail below.
Note: Your LAN does not need to be powered down when making a LAN connection to the router via the RJ-45
port. However, when connecting devices to the WAN or Diagnostic (console) ports please make sure the router
and the other devices are turned off before making the connection.
Other Resources
For more information about your DI-1162/DI-1162M please check the following sources:
♦Quick Installation Guide.
♦Support disk containing RouteView, a Windows-based configuration program used to set up and configure
the router.
♦Frequently Asked Questions (FAQ) and application notes for this router can be found on the D-Link Web
site at http://tsd.dlink.com.tw/.
Packing List
Before you proceed further, please check all items you received with your DI-1162/DI-1162M Router with this list
to make sure the package is complete. The complete package should include:
♦One DI-1162 or DI-1162M Router.
♦One 100~240V AC power cord (the plug type depends on the region the router is shipped in).
♦One RS-232 (DB-9 to DB-9) cable for console connection.
♦One 6 ft. (1.83m) Category 5 UTP cable for LAN connection.
♦One EIA-530 (DB-25 to DB-25) cable for WAN connection.
♦Four rubber feet with adhesive backing.

DI-1162/DI-1162M Remote Access Router
5
♦Rack mount kit including six screws and two mounting brackets.
♦One CD-ROM disc or floppy diskette containing the Windows-based Router Configuration Utility.
♦This User’s Guide.
If any item is found missing or damaged, please contact your local D-Link Reseller for replacement.
Identifying External Components
The following section illustrates the different components on the router’s front and rear panels. Before using the
router it is highly recommended to familiarize yourself with these components to ensure effective use of the
device.
♦LED Indicators The front panel consists of the LED indicators of the router. The LED indicators are used to
facilitate monitoring and troubleshooting. Please refer to the following chart for detailed descriptions of these
indicators.

DI-1162/DI-1162M Remote Access Router
6
LED STATUS/ FUNCTION
Power Lights whenever the router is plugged in, turned on, and thus
receiving power.
Diag Lights during the startup Power-On Self-Test (POST) test.
Boot Lights briefly during startup after the PROM program has
executed. Indicates a successful boot up.
Run Should be slowly blinking if the router is functioning properly.
10/100 This LED is ON for a 100Mbps link, and OFF for a 10Mbps
link.
LAN
Link/Act This LED is ON to show a good link to the LAN, and quickly
flashes to show communication activity on the line.
Full/Half This LED is ON for a full-duplex connection, and OFF for
half-duplex.
Col The LED flashes to show transmission collisions on the line.
WANs
1 & 2
Ready This LED is ON to show a good modem or CSU/DSU link to
the WAN port.
Act This LED flashes to show communication activity on the line.
Module
Ready This LED is ON to show a good modem or CSU/DSU link to
the WAN module, or a good link to the LAN port module.
Act This LED flashes to show communication activity on the line.
♦Diagnostics RS-232 Serial Port A DB-9 female connector used to connect a console to the router for initial
setup and out-of-band management.
♦Wan Ports (1 and 2) Two DB-25 male connectors each of which can be connected to a dial-up (dial in or out)
line or a dedicated leased line by multiplexing with a modem or CSU/DSU (Channel Service Unit/ Data
Service Unit), respectively.
♦Slot for Add-in Module This slot is able to house any one of the following slide-in expansion modules:
◊A single RJ-45 10/100 Ethernet port
◊Two high-speed serial (async/sync) ports
◊A BRI ISDN module (S/T interface only).
♦LAN Port This jack is a full featured RJ-45 10/100 Ethernet/Fast Ethernet port. This feature allows this port
to automatically configure itself to match the settings used by the port it is being connected to. If it is connected

DI-1162/DI-1162M Remote Access Router
7
to another 10/100M auto-negotiation capable port, the two ports will configure themselves to attain the best
connection possible.
♦Fan Provides ventilation inside the router. Please ensure to leave adequate space at the rear and sides of the
unit for proper ventilation.
♦Power Socket A standard 100~240V socket for the power cord.
♦Power Switch A rocker switch that turns the router off and on.
Site Installation
The site where you install the DI-1162/DI-1162M Router may greatly affect its performance. Please follow these
guidelines for setting up the router.
♦Install the router on a sturdy, level surface that can support at least 2 kg of weight. Do not place heavy
objects on the router.
♦The power outlet should be within 1.82 meters (6 feet) of the router.
♦Visually inspect the power adapter cord and see that it is fully secured to the power socket.
♦Make sure that there is proper heat dissipation from and adequate ventilation around the router. Leave at
least 10 cm of space at the side and rear of the router for ventilation.
♦Install the router in a fairly cool and dry place. See Appendix B for the acceptable temperature and
humidity operating ranges.
♦Install the router in a site free from strong electromagnetic field generators (such as motors), vibration, dust,
and direct exposure to sunlight.
♦When installing the router on a level surface, attach the rubber feet to the bottom of the device. The rubber
feet cushion the router, protect the casing from scratches and prevent it from scratching other surfaces.
Rack Mounting
The DI-1162/DI-1162M may stand alone or be mounted on a standard 19-inch equipment rack. Rack mounting
produces an orderly installation when you have a number of related network devices. Use the six supplied screws
to fasten the supplied mounting brackets to either end of the router, then fasten the router into the rack.
Installation and Initial Configuration of the Router
This section discusses the different connections that can be made to the router when setting it up.
Initially, you will only wish to connect the console to the router in order to configure the other ports. Once that is
complete, you will need to turn off the power to the router and plug in the connection cables to the other devices.
Next, power on the other devices. When they have finished powering up, power on the router. Each of these steps
is described in detail in the sections below. Please skip any setting adjustments that do not apply to your
configuration needs.
A Warning about Connecting Cables
It is important that correct cables are used for each connection; otherwise, the router could be damaged.
Before connecting or disconnecting an RS-232 cable between the DI-1162/DI-1162M and the console and
modems, please make sure all devices are off to avoid any chance of damage.

DI-1162/DI-1162M Remote Access Router
8
Step 1 - Setting up the Console
The initial setup of the DI-1162/DI-1162M requires connecting a console to the 9-pin RS-232 Diagnostic port
on the router’s front panel. A serial cable is supplied with the router in order to make this connection. A
console can be a terminal, such as a VT-100, or a normal PC running terminal emulation software (such as
Microsoft HyperTerminal, included with Windows). The terminal emulation software needs to be configured to
the following parameters:
◊VT100 terminal emulation
◊9600 baud
◊No parity, 8 data bits, 1 start bit, 1 stop bit
◊No flow control
Step 2 - Connecting the Console to the Router
A serial cable is included in the DI-1162/DI-1162M package. To connect this cable, plug its nine-pin connector
into the 9-pin RS-232 Diagnostic port on the router’s front panel, then connect the other end to the serial port on
the rear of your computer or data terminal.
Please make sure both machines are turned off before making this connection.
After the connection is made, first power on the console. If you are using a PC, run the terminal emulation
software at this time. After the PC and the terminal emulation software are up and running, power on the router.
Using the Console
The Console Program is the interface that you will be using to configure your DI-1162/DI-1162M. Several
operations that you should be familiar with before you attempt to modify the configuration of your router are listed
below:
♦Moving Forward to Another Menu To move forward to a submenu below the current one, use Tab or
arrow keys to position the cursor on the submenu item and press Enter to view the selected submenu.
♦Moving the Cursor Within a menu, use Tab and arrow keys to navigate through different information
fields.
♦Entering Information There are two types of fields that you will need to fill in. The first requires you to
type in the appropriate information. The second gives you choices to choose from. In the second case, press
the space bar to cycle through the available choices. Upon configuring all fields the submenu, position the
cursor on SAVE and press Enter to save, or position the cursor on EXIT to cancel.
♦Refreshing the Screen Console screens are notorious for becoming garbled. When this happens, simply
press <Ctrl> + <R> to refresh the contents of the screen.
Step 3 - Initial Configuration of the Router
After the console is properly connected and both devices are powered on as described in the preceding sections,
you should see the router run through the power on self test (POST). Finally, it will arrive at the logon screen
shown below:

DI-1162/DI-1162M Remote Access Router
9
To log on to the router, use the factory set username and password ‘Admin’ (without the quotes). Please note that
the user name and password are case-sensitive.
Upon entering the username and password (using the <Tab> key to jump to the next field), position the cursor on
OK and press <Enter>. You will then see the following Main Menu:

DI-1162/DI-1162M Remote Access Router
10
Step 3a - Configuring the LAN Port
Preparing the router for connection to a LAN only requires enabling the LAN port, enabling IP networking ,and
assigning the LAN port an IP address. After the LAN port is configured, all other features on the router can be
configured remotely through the LAN by using the included Windows-based Router Configuration Utility or
Telnet.
To configure the LAN:
1. The LAN port must be enabled in the Interface Configuration submenu.
♦Choose Interface Configuration!LAN 1.
♦Position the cursor over the State item and press <space bar>. The State will change from Disable to
Enable.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
♦Choose Exit in the submenus to return to the Main Menu.
2. Enable IP Networking
♦Choose Network Configuration!IP Configuration.
♦Position the cursor on the IP Networking line and press <space bar> to Enable it.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
3. Assign an IP address to the LAN port in the Network Configuration submenu of the Main Menu.
♦Still in Network Configuration!IP Configuration submenu from Step 2 above, choose IP Stack
Configuration!LAN 1.
♦Enter a valid IP address for the LAN in the first item. You may also enter a Netmask if you wish. For more
information about IP Addresses and Subnet masks, please refer to “Appendix C – IP Concepts.”
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
♦Choose Exit in the submenus to return to the Main Menu.
The router can now be accessed via the LAN by Telnet, the Windows-based DI-1162/DI-1162M Router
Configuration Utility (included with the router) and other SNMP management applications.
If you have any questions regarding the settings you made or other settings in the submenus, please refer to the
next chapter, “Configuration and Management.”
At this point, please proceed to the next initial configuration step.
Step 3b - Configuring the WAN Ports for Dial-in, Dial-out and Leased Lines
Please configure LAN port as described above to familiarize yourself with the configuration program (the LAN
port must be configured in any case). Some settings that were made configuring the LAN will be repeated below.
Please disregard the instructions below if the setting has already been changed.

DI-1162/DI-1162M Remote Access Router
11
Each WAN port can be configured to either receive dial-in calls (act as a Remote Access Server), dial out to other
routers (at branch offices or the Internet, for instance), or both (but not at the same time). The WAN ports can also
be configured for a leased line (synchronous) connection. Please note however that we recommend only one single
WAN connection to the Internet since a second connection will not significantly enhance the performance of the
connection.
Enabling a WAN Port
In this section, we will use WAN1 as an example. Other WAN ports however, will follow the same procedures.
1. The WAN port must be enabled in the Interface Configuration submenu.
♦Choose Interface Configuration!WAN 1.
♦Configure the Protocol setting. This is a very important setting as it determines what type of device can be
connected to the WAN port.
◊SLIP Asynchronous mode used for modems.
◊PPP_ASYN Asynchronous mode used for modems.
◊CISCO_HDLC Synchronous mode used for CSU/DSU’s or synchronous modems
using a leased line.
◊PPP_SYN Synchronous mode used for CSU/DSU’s or synchronous modems using a
leased line.
◊FRAME_RELAY A high-speed protocol available from many ISPs for switched lines.
The current version of this router only supports IP over frame relay and PVC. OSPF,
IPX, and bridge are not supported.
♦Position the cursor over the State item and press <space bar>. The State will change from Disable to
Enable.
♦Other items in this screen also need to be configured such as the Phone Number, Baud Rate, and additional
Frame Delay Config settings, which appear on a series of screens accessed from the bottom of this window
if FRAME_RELAY is selected. Please refer to the manual for the device being connected to the WAN port
for the proper settings. For more information regarding these settings, please refer to the appropriate section
in the “Configuration and Management” chapter of this manual.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
♦Choose Exit in the submenus to return to the Main Menu.
2. Enable IP Networking.
♦Choose Network Configuration!IP Configuration.
♦Position the cursor on the IP Networking line and press <space bar> to Enable it.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
3. Assign an IP address to the WAN port in the Network Configuration submenu of the Main Menu.
♦Still in Network Configuration!IP Configuration submenu from Step 2 above, choose IP Stack
Configuration!WAN 1.
♦Enter a valid IP address for the WAN in the first item. You may also enter a Netmask if you wish. For more
information about IP Addresses and Subnet masks, please refer to “Appendix C – IP Concepts.”

DI-1162/DI-1162M Remote Access Router
12
♦Other items in this screen may also need to be configured such as the State, Routing and Multicast settings.
Please refer to the appropriate section in the “Configuration and Management” chapter of this manual for
detailed explanations concerning the nature and use of these items.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
♦Choose Exit in the submenus to return to the Main Menu.
Configuring for Dial-in, Dial-out or Leased Line
At this point, you need to decide if the WAN port will be used for dialing in, dialing out, both or a leased line
connection. The settings you make in next few steps depend on how you wish to use the WAN port. Remember,
only one WAN port should be setup to connect to the Internet.
4. Configure the Dial settings in the Advanced Functions submenu.
♦Choose Advanced Functions!Dial Configuration.
♦Choose WAN1.
♦Please refer to the “Configuration and Management” chapter of this manual for more detailed information
regarding the items in this screen.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
5. Define and configure dial-in users who may access the router and the LAN it is connected to (if applicable).
♦From the Main Menu choose Advanced Functions!Remote Access Configuration!Dial-In User
Profile and press <Enter> in the first empty field.
♦Enter the dial-in user’s Username (this might not be their real name) and Password.
♦Change the State to Enable.
♦Please refer to the “Configuration and Management” chapter of this manual for more detailed information
regarding the items in this screen.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
The WAN port is now setup to receive calls from that user. At this point, you may wish to define other users
who will dial-in to the router. Please note that User Profiles for dial-in users are valid for any WAN port
configured to receive calls.
6. Define a WAN port for dialing out.
♦From the Main Menu choose Advanced Functions!Remote Access Configuration !Remote Network
Profile and press <Enter> in the first empty field.
♦Set the Direction to In, Out, or Both.
♦Enter a Name and Password used to establish Incoming and/or Outgoing connections (if the remote site
uses PAP or CHAP).
♦Configure the other settings shown in this window.

DI-1162/DI-1162M Remote Access Router
13
♦Change the State to Enable.
♦Please refer to the “Configuration and Management” chapter of this manual for more detailed information
regarding the items in this screen.
♦Position the cursor on the Save option at the bottom of the screen and press <Enter> to save the new
setting.
♦Choose Exit in the submenus to return to the Main Menu.
7. Define a WAN port for a leased line connection.
♦There are only three steps that need to be done to configure a WAN port for using a leased line and they
have already been done. They are numbers 1, 2 and 3; enabling the WAN port in the Interface
Configuration submenu, configuring the Protocol setting to a synchronous mode, and assigning an IP
Address to the WAN port in the Network Configuration submenu. Remember to save any submenu
screens in which you have made changes.
Choose LOGOFF from the Main Menu.
Your WAN ports are now configured and should operate normally. Please note that many of the settings
configured here depend on the type and capabilities of the device being connected.
At this point in the installation process, you need to turn off the router. Don’t worry. As long as you saved each
screen in the configuration process, your settings will have been saved in the EEPROM and will not be lost.
Step 4 - Connecting the Router to a LAN
Your DI-1162/DI-1162M has a single LAN port for connecting to an Ethernet or Fast Ethernet switch or hub.
The jack for the router’s Ethernet port is of the type known as EIA RJ-45. The cabling used should be Category 3,
4 or 5 UTP or STP depending on the connection speed, fitted with an RJ-45 connector.
The 10/100M auto-negotiation feature allows this port to automatically configure itself to match the settings used
by the port it is being connected to. If it is connected to another 10/100 Fast Ethernet capable port, the two ports
will configure themselves to attain the best connection possible.
Full duplex mode will only be enabled if this port is connected to a full-duplex capable switched port.
At this point, please connect the router to the LAN.
Step 5 - Connecting the Router to WAN Devices
The DI-1162/DI-1162M has two DB-25 ports corresponding to WANs 1 & 2. These two WAN ports are both
synchronous/asynchronous ports, and can connect to a modem or CSU/DSU using a standard serial cable with a
DB-25 connector at one end.
Make sure both the WAN device(s) and the router are turned OFF when making these connections.
Step 6 – Plugging in All Devices
Plug the 100 ~ 240V AC/DC power cord into the power jack on the router’s rear panel and into a power strip or
grounded wall outlet.
At this point in the installation, you may plug in and power on all other devices. Do not power on the router yet.

DI-1162/DI-1162M Remote Access Router
14
Step 7 - Powering Up the DI-1162/DI-1162M
After all the devices are powered up, the DI-1162/DI-1162M can be turned ON. The router will perform a POST
(Power-On Self-Test). It is during this POST procedure that the PROM Configuration Menu can be accessed.
The router is now able to use the LAN and WAN ports.
The router must be further configured for managing your network. This can now be done by using the console, the
included Windows-based Configuration Utility, or Telnet.
For more information about configuring or managing the router, please refer to the next chapter, “Configuration
and Management.”
