Contents of Package:
D-Link Express EtherNetwork
Broadband Router
Manual, Warranty and Print Server Software on CD
QuickInstallationGuide
Package Contents
If any of the above items are missing, please contact your reseller.
System Requirements for Configuration:
!
!
PowerAdapter - 5V DC
!
WARNING! Using apowersupplywitha different voltageratingthan
theoneincludedwiththeDI-704Pwillcausedamageandvoidthe
warrantyfor this product.
TM
Internet Explorer version 6.x or Netscape Navigator
version 6.x and above, with Javascript enabled
!
Computer with Windows, Macintosh, or Linux-based Operating
System with an installed Ethernet adapter
!
!
Ethernet (CAT5-UTP/Straight-Through) Cable
!
Ethernet-based Cable or DSL Modem
!
DI-704P

4
Introduction
Thank you for purchasing DI-704P 4-Port Ethernet Broadband Router. The DI-
704P is an Ethernet Broadband Router with a built-in 4-port switch. It also fea-
tures a parallel port to share a printer on the home or office network and in-
cludes a print server application for Windows1.As many as four computers can
beconnected directlyto therouter’sintegratedswitch,using itsfour10/100Mbps
AutoMDIXEthernetports. Morecomputerscan be addedtothe network bycon-
nectingadditionalswitches to the DI-704P.TheDI-704Ppackage even includes
an Ethernet cable to get you started.
The DI-704P is ideal if you’re creating your first home or small business net-
work, or if you’re a more advanced user looking for additional management
settings.
The DI-704P includes a new, easy-to-use D-Link web-based graphical user
interface (GUI) to configure the router. To prevent unwanted Internet intruders
from accessing your private network, the DI-704P also serves as a feature-rich
firewall.
So, whether you’re a college student who wants to network with friends and
roomates, an executive working at home or in a small office, or a concerned
parent who just wants to have more control over how your children access the
Internet,thenthe D-Link Express EtherNetwork DI-704Pisthe networking solu-
tion for you.
1Print Server software included is for Windows Operating Systems only. Postscript Level 1 and 2
printers can be connected to the DI-704P for Macintosh OS 9.x or X computers. The DI-704P does not
support non-Postscript printers with Macintosh OS.

5
Network Address Translation - NAT allows your private
network to share a single public IP address.All your computer
connected to the DI-704P will be on a private network shielded
from Internet intruders.
!
Features & Benefits
!Firewall Features
!Filtering - Easily applied filtering based on MediaAccess
Control (MAC) Addresses, IP Addresses, PortAddresses, and
time schedule allows or denies computer on the network
access to the Internet.
!Built-In 4-Port Switch -Allows you to quickly and easily share an
Internet connection with multiple computers and devices. Each 10/
100 Ethernet Port automatically senses and accepts the type of
Category (CAT) 5 cable you attach - whether straight through or
cross-over. Connect additional switches to allow more computer
to access the Internet.
!Built-In Print Server - Includes a parallel port to connect to a
centronic printer and includes a Windows-based print server software
application, so users on the network can share the printer1. The print
server is also capable of TCP/IP printing.
Ethernet Cable Included - One Ethernet cable is included with the
DI-704P to get you started.
!
Simple Setup Wizard for Easy Installation - The D-Link setup
wizard simplifies the installation process, getting you up and running
in just a few clicks.
!
1Print Server software included is for Windows Operating Systems only. Postscript Level 1 and 2
printers can be connected to the DI-704P for Macintosh OS 9.x or X computers. The DI-704P does not
support non-Postscript printers with Macintosh OS.

6
LEDs
LED LED Activity
Power A solid light indicates a proper connection to
thepowersupply.
M1LED
M2LED Solid light indicates that Internet connec-
tionhasbeenestablished.
WAN A Solid light indicates connection on the
WAN port. This LED blinks during data
transmission.
Flashes consistently to indicate that the
DI-704Pisworking properly.
LOCAL
NETWORK
LEDs
(Ports1-4)
A solid light indicates a connection to an
Ethernet-enabledcomputeronports 1-4. This
LEDblinks during data transmission
POWER LED
M1LED M2 LED WAN LED
LOCALNETWORKLEDs

7
Connections
WARNING!
Usingapowersupplywithadifferentvoltage rating than the one
includedwiththeDI-704P will cause damage and void thewarranty
forthisproduct.
Receptorfor
PowerAdapter
Reset button is to reset the device to its factory
defaultsettings.
ResetButton
PrinterPort
WAN port is the connection point for your DSL or
Cablemodem.
WAN Port
LAN port is where you would connect each
computertoyournetwork.
Connect totheprinterusingaparallel cable. This
featureis usedtoshare theprinteron thenetwork.
LanPorts
Connectthesuppliedpower adapter that came
withtheunit.Usingthewrongpower adapter will
damagetheunit.
Receptor for Power Adapter
Reset Button
Printer Port WAN Port
LANPorts

8
Introduction to Broadband
Router Technology
A router is a device that forwards data packets from a source to a destination.
Routers can work on Open System Interconnection (OSI) layer 3, which for-
wards data packets using an IP address and not a MAC address. A router will
forward data from the Internet to a particular computer on your LAN.
The information that makes up the Internet gets moved around using routers.
When you click on a link on a wed page, you send a request to a server to show
you the next page. The information that is sent and received from your com-
puter is moved from your computer to the server using routers. A router also
determines the best route that your information should follow to ensure that the
information is delivered properly.
A router controls the amount of data that is sent through your network by elimi-
nating information that shouldn’t be there. This provides security for the com-
puters behind your router because computers from the outside cannot access
or send information directly to any computer on your network. The router deter-
mines which computer the information should be forwarded to and sends it. If
the information is not intended for any computer on your network, the data is
discarded. This keeps any unwanted or harmful information from accessing or
damaging your network.
Introduction to Firewalls
A firewall is a device that sits between your computer and the Internet that pre-
vents unauthorized access to or from your network. A firewall can be a com-
puter using firewall software or a special piece of hardware built specifically to
act as a firewall. In most circumstances, a firewall is used to prevent unautho-
rized Internet users from accessing private networks suchs as corporate LANs
andIntranets.
A firewall watches all of the information moving to and from your network and
analyzes each piece of data. Each piece of data is checked against a set of
criteria that the administrator configures. If any data does not meet the criteria,
that data is blocked and discarded. If the data meets the criteria, the data is
paased through.. This method is called packet filtering.
A firewall can also run specific security functions based on the type of applica-
tion or type of port that is being used. For example, a firewall can be configured
to work with an FTP or Telnet server. Or a firewall can be configured to work
with specific UDP or TCP ports to allow certain applications or games to work
properlyoverthe Internet.

9
Introduction to Local Area Networking
Local Area Networking (LAN) is the term used when connecting several com-
puterstogetherover asmallarea such asabuilding or groupofbuildings. LAN’s
canbeconnected over large areas.AcollectionofLANs connected over a large
area is called a WideArea Network (WAN).
A LAN is consists of multiple computers connected to each other. There are
many types of media that can connect computers together. The most common
media is CAT5 cable; UTP or STP twisted pair wire. Each computer must have
a Network Interface Card (NIC), which communicates the data between com-
puters.ANIC is usually a 10Mbps network card or 10/100Mbps network cards.
Most networks use hardware devices such as hubs or switches that each cable
can be connected to in order to continue the connection between computers.A
hub simply takes any data arriving through each port and forwards the data to
all other ports. A switch is more sophisticated, in that a switch can determine
the port that each piece of data is supposed to be delivered to. A switch mini-
mizes network traffic and speeds up the communication over a network.
Networks take some time in order to plan and implement correctly. There are
many types of scenarios to consider which could affect the operability of a net-
work. Some of these issues are discussed in the manual under the
Networking Basics section.

10
1
5
3
2
4
6
Sample Scenario
You will need broadband Internet access (a Cable or DSLsubscription line into
yourhome or office)
Consultwithyour Cable or DSL provider for properinstallationofthemodem
ConnecttheCable or DSL modem to theDI-704Pwirelessbroadbandrouter
(see the Quick Installation Guide included with the DI-704P.)
If you are connecting a desktop computer to your network, you can install the
D-Link DFE-530TX+ Ethernetadapter into an available PCI slot. (See the
QuickInstallation Guide included withtheDWL-530TX+.)
Ifyou are connecting a laptop computer toyournetwork,install the drivers for
theEthernetCardbusadapter(e.g., D-Link DFE-690TXD)intoalaptop
computer.(SeetheQuickInstallation Guide included withtheDFE-690TXD.)
**Easily upgrade toawirelessnetworkby adding awirelessAccessPoint(D-Link DWL-900AP+) **
Connect your printer to the printer port on the DI-704P. Please refer to the
quickinstallationguidefor loading the print server software.
A typical network setup at home (as shown above) might contain the following de-
vices. For specific information on setting up your network with the DI-704P please see
theNetwork Setup section on the followingpage.

11
Network Setup
Turn everything off.
A. Power OFF your Cable or DSL modem. If you modem does
not have an on/off switch, disconnect the power cable.
B. Turn OFF your computer.
C. Do NOT connect the power adapter to your D-Link router.
Connect the D-Link Router Cables.
A. Connect the Ethernet (or networking) cable from the Cable or
DSL modem to the WAN port of the router.
B. Usethe D-LinksuppliedEthernet cableto connecttheEthernet
port (Network Card) of your computer to one of the LAN ports of
therouter.Thecomplete setupshouldlooklikeFig.1shownabove.
Power up the devices in sequence.
A. Power upthe Cable orDSLmodem. Wait until the modem has
made the connection to your Internet Service Prover’s (ISP’s)
network.
B. Power up the D-Link router by connecting the D-Link provided
power adapter to the router and to an available power outlet.
C. Turn on your computer.
D. Now, refer to either the Quick Installation Guide or continue
to follow this manual to complete the installation process.
Note: Please see the Manual included with your modem for an explanation of
themodem’sLEDs.

12
Using the Setup Wizard
Thelogonpop-upscreen will appear.
Open your Web browser and
type“http://192.168.0.1” into the
URLaddress box. Thenpressthe
Enter or Return key.
Type “admin” for the username and
leavethepasswordfieldblank.
ClickOK
Once you have logged in, the Home
screenwill appear.
Click Run Wizard

13
You will see the following screens
Click Next
Using the Setup Wizard (continued)
Set up your new password.
You have theoptionto
establisha password.
Click Next

14
Select your Internet
Connection. You will be
prompted to select the
typeof Internet connection
foryourrouter.
If you are unsure of which setting to select,
please contact your Internet Service Provider.
Click Next
Select Others only if you use PPTP in Europe or
BigPondCable inAustralia.
Using the Setup Wizard (continued)
Click Next
Set up your Time Zone.You
have the option to the set
standardtime for your router.
Tochangethedefault
selection, select the drop
downarrowandchosethe
correct time zone.

15
Using the Setup Wizard (continued)
If you selected Dynamic IP
Address,thisscreen will
appear: (Usedmainly for
CableInternet service.)
What is a MAC address? Each
network adapter has a discrete
Media Access Control (MAC)
address. Note that some computers
and peripherals may already
include built-in network adapters.
Click Next
Click the“Clone MAC Address”
button to automatically copy the
MAC address of the network
adapter in your computer.You can
also manually type in the MAC
address.
If your ISP requires a Static
IP Address, and this option
is selected, then this
screenwillappear:
Enterthe IPAddress informa-
tionoriginallyprovided to you
by your ISP. You will need to
completeall the required
fields.
Click Next

16
If your ISP uses PPPoE
(Point-to-PointProtocolover
Ethernet), and this option is
selected, then this screen will
appear: (Used mainlyfor DSL
Internetservice.)
Enter in the username and
passwordprovidedtoyou by
your ISP.
Click Next
Using the Setup Wizard (continued)
Please be sure to remove any
existing PPPoE client software
installed on your computers.
Click Restart

17
Using the Configuration Menu
Whenever you want to configure your network or the DI-704P, you can access the
ConfigurationMenubyopening theweb-browserandtypingin theIPAddressoftheDI-
704P. The DI-704Pdefault IPAddress is shown below:
Opentheweb browser
Type in the IPAddress of
theDI-704P
Home > Wizard
Note: if you have changed the default IP Address assigned to the DI-704P, make sure to
enter the correct IP Address.
The factory default User name is
“admin” and the default Password is
blank (empty). It is recommended that
you change the admin password for
security purposes. Please refer to
Tools>Admin to change the admin
password.

18
The Home>Wizard screen will appear. Please refer to the Quick Installation Guide
formoreinformation regarding theSetupWizard.
Using the Configuration Menu (continued)
Clicking Apply will save changes made to the page
Clicking Cancel will clear changes made to the page
ClickingHelp will bring up helpful informationregardingthepage
ClickingRestart willrestarttherouter. (Necessaryfor some changes.)
Home > Wizard (continued)

19
Using the Configuration Menu (continued)
Home > WAN (continued)
WAN is short for WideArea Network. The WAN settings can be referred to as the
Public settings.All IP information in the WAN settings are public IP addresses which
are accessible on the Internet. The WAN settings consist of four options: Dynamic IP
Address,Static IP
Address,PPPoE, and Others. Select theappropriate optionand fillin theinformation
needed to connect to your ISP.
Choose Dynamic IP Address to obtain IPaddressinformation automatically from
your ISP. Select this option if your ISP does not give you any IP numbers to use. This
option iscommonly used forCable modem services. Host Name: TheHostName field
is optional but may be required by some ISPs. The host name is the device name of
theBroadband Router.

20
MACAddress:
The default MAC address is set to the WAN’s physical interface MAC address on the
Broadband Router. You can use the “Clone MACAddress” button to copy the MAC
address of the Ethernet Card installed by your ISP and replace the WAN MAC
address with this MAC address. It is not recommended that you change the default
MAC address unless required by your ISP.
Primary/Secondary DNSAddress:
Enter a DNSAddress if you do not wish to use the one provided by your ISP.
MTU:
Only enter the MTU if it is required by your ISP. Otherwise, leave it
at the default setting of 1500.
Auto-reconnect:
Ifenabled, the Broadband Routerwill automatically connect toyour ISP after your
system is restarted or if the connection is dropped.
Using the Configuration Menu (continued)
Home > WAN (continued)
