DSB-T100
USB TV Tuner
Quick Install Guide
Quick Install Guide
11 Remove the DSB-T100 from the boxRemove the DSB-T100 from the box
22 Insert the Driver CD into the CD-ROMInsert the Driver CD into the CD-ROM
Please make sure that the following items are included with the DSB-T100:
l DSB-T100
l CD with Drivers and Software
l User’s Manual
l Quick Install Guide
l Sound Cable
l Stand
The autorun screen will appear.
Click on the button labeled
“Install Drivers/Jukebox.”
dsb-t100.3.14.01
dsb-t100.2.21.01
For more detailed information, please see your User’s Manual.
Note: Please do not connect the DSB-T100 to the USB port
until instructed to do so.
11
APPENDIXAPPENDIX
If prompted for the Windows 98 CD, insert
the Windows 98 CD into the
CD-ROM Drive.
Click OK.
Providing Windows 98 FilesProviding Windows 98 Files
Specify the correct location in the “Copy files from:” box. If the CD-ROM
drive is the D: drive, then type D:\Win98 in the box.
(Some computers will have the Windows 98 files
available in the C:\Windows\options\cabs
directory).
After typing in the location,
Click OK.
Windows will copy the necessary system files.

33
44
55
Installing the TV Jukebox software.Installing the TV Jukebox software.
Connect the USB cableConnect the USB cable
Loading the necessary driversLoading the necessary drivers
66 The Ulead VideoStudio andThe Ulead VideoStudio and
Ulead Photo ExplorerUlead Photo Explorer
Follow the on-screen instructions to install
the TV Jukebox software. Once
installation of the TV Jukebox is finished,
the driver installation will begin.
Follow the on-screen instructions and
select:
“Yes, I want to restart my computer
now,” when prompted.
Click Finish.
If you wish to install the Ulead VideoStudio software, you may do so by
returning to the initial autorun screen on your installation CD.
Click on the “Install Video-Studio” button.
When the computer has finished rebooting, connect the USB cable of the DSB-T100
to an available USB port on your computer.
Windows will recognize the DSB-T100 and load the necessary drivers.
Note: If Windows prompts you for your Windows CD, follow the
instructions in Appendix 1 to locate the required files.
Note: Windows 2000 users may be prompted by a “Digital Signature” screen.
Click “Yes” on each screen to continue.
The DSB-T100 is now installed.
Ulead VideoStudio is a video editing program that can be used to create
home videos that have been captured using the DSB-T100.
D-Link Technical Support over the Telephone:
[phone]
6 a.m. to 6 p.m. Monday thru Friday
D-Link Technical Support over the Internet:
www.dlink.com
Please refer to the User’s Manual for advanced features and instructions.
D-Link Technical Support information is listed below if any problems arise during
installation.
You may also click the “Install Photo Explorer” button to install Ulead Photo Explorer.
Note: The sound cable is used to connect the DSB-T100 to your sound card.
Connect the sound cable to the “sound out” on the DSB-T100 and then connect the
other end to the “in/mic” input on your sound card.
Rev. dsb-T100.2.21.01 Rev. dsb-t100.2.21.01
