DÖRR SNAPSHOT MINI 5.0 PRO User manual

doerr-outdoor.de
SNAPSHOT
MINI 5.0 PRO
SURVEILLANCE CAMERA
INSTRUCTION MANUAL
GB

doerr-outdoor.de2
INDEX PAGE
01 | SAFETY HINTS 3
02 | SAFETY HINTS FOR BATTERIES 4
03 | PRIVACY POLICY 4
04 | NOMENCLATURE 4
05 | ILLUSTRATION OF PARTS 5
06 | FIRST COMMISSIONING 6
06.1 Inserting the batteries 6
06.2 Alternative power supplies 6
06.3 Inserting the SD/SDHC/SDXC Memory Card 6
06.3.1 ⛔ IMPORTANT SDXC Memory Cards 64 GB & 128 GB 6
07 | OPERATION 7
07.1 Overview home screen 7
07.2 All basic factory settings 7
07.3 Main Menus 7
07.4 Menu navigation 7
08 | SETTINGS & FUNCTIONS 8
08.1 Main Menu CAM 8
08.2 Main Menu PIR 9 - 10
08.3 Main Menu SYS 11 - 12
08.4 Quick view of settings 12
09 | TEST RECORDINGS / VIEW RECORDINGS 13
10 | MOUNTING / DIRECTING / ACTIVATING 13
10.1 Mounting and directing the camera 13
10.2 Turn on camera and start surveillance 13
10.3 Notes for mounting the camera 13
10.3.1 PIR Sensor 13
10.3.2 Light conditions 13
10.3.3 Weather protection 14
11 | OPTIONAL ACCESSORIES 14
11.1 Optional mounting accessories 14
11.2 Optional anti-theft devices 14
12 | CLEANING AND STORAGE 14
13 | SCOPE OF DELIVERY 15
14 | TECHNICAL SPECIFIATIONS 14
15 | DISPOSAL, CE MARK 16
15.1 Disposal of batteries/accumulators 16
15.2 WEEE Information 16
15.3 Disposal of the packaging 16
15.4 RoHS Conformity 16
15.5 CE Mark 16

doerr-outdoor.de3
01 | SAFETY HINTS
• This device is not a toy! To prevent accidents and suffocation
keep the device, the accessories and the packing materials away
from children and pets.
• People with physical or cognitive disabilities should use the
camera with supervision.
• People with cardiac pacemakers, defibrillators or any other elec-
trical implants should maintain a minimum distance of 30 cm, as
the device generates magnetic fields.
• Your camera is fitted with a weatherproof housing according to
protection class IP66 (dust and jet waterproof) so that the camera
can be used outdoors. Nevertheless, protect the camera from
extreme weather conditions and direct sunlight.
• Caution! Make sure to use only fresh Mignon AA LR6 1.5V
Alkaline Manganese batteries or rechargeable NiMH batteries
of the same type and brand. Never combine Alkaline Man-
ganese batteries with NiMH batteries! When inserting the bat-
teries please respect the correct polarity (+/-). Please remove
batteries when device is not in use for a longer period.
• Only use SD/SDHC memory cards from 8GB to 32GB (SDXC
64GB to max. 128GB see instruction manual chapter 08.3).
Using a micro SD card in combination with an adapter may lead
to malfunctions.
• Do not drop the camera onto a hard surface. Do not use the
camera if it has been dropped. In this case a qualified electrician
should inspect the camera before you use it again.
• Do not attempt to repair the devise by yourself. Risk of electrical
shock! When service or repair is required, contact qualified service
personnel.
• Do not open the camera housing (except the housing lid and
the battery compartment) – the warranty will become void. The
housing may only be opened by qualified DÖRR GmbH staff.
• LED bulbs can only be replaced by qualified DÖRR GmbH staff.
• Do not use the camera nearby devices that generate strong elec-
tromagnetic fields.
• Avoid touching the camera lens with your fingers.
• Protect the camera against extensive dirt. Never use aggressive
cleansing agents or benzine to clean the camera. We recommend
a soft, slightly damp microfiber cloth to clean the outer parts of
the camera and the camera lens. Make sure to remove batteries
before cleaning.
• Store the camera in a dust-free, dry and cool place when not in
use.
• If the device is defective or without any further use, dispose of the
device according to the Waste Electrical and Electronic Equipment
Directive WEEE. For further information, please contact your local
authorities.
GB
THANK YOU very much for choosing a quality product by DÖRR.
Please read the instruction manual and the safety hints carefully
before using the device for the first time.
Keep the operating instructions together with the device for referen-
ce. If other people use this device, provide them with these instruc-
tions. If you sell the unit, this manual forms an integral part of the
device and must be supplied with it.
DÖRR is not liable for damage caused by improper use or failure to
observe the operating and safety instructions.
In the event of damage caused by improper handling or by external
influence, the guarantee or warranty claim becomes void. Any ma-
nipulation, structural modification of the product or opening of the
housing by the user or an unauthorised third party shall be considered
improper handling.

doerr-outdoor.de4
02 | SAFETY HINTS FOR BATTERIES/ACCUMULATORS
Only use high-quality batteries or accumulators of popular brands.
When inserting the batteries or accumulators, please respect the
correct polarity (+/-). Do not insert batteries of dierent types and
always replace all batteries at the same time. Never combine Alkali-
ne Manganese batteries with NiMH batteries! Do not combine used
batteries with fresh batteries. Please remove batteries/accumulators
when device is not in use for a long period of time. Do not throw the
batteries/accumulators into fire, do not short-circuit and do not
disassemble them! Never charge non-rechargeable batteries - risk
of explosion! Remove empty batteries immediately from the device
to avoid the leaking of battery acid. Remove leaking batteries from the
device immediately. Clean the contacts before inserting fresh batte-
ries. Risk of battery acid burn! In case of contact with battery acid,
rinse the aected area immediately with water and contact a doc-
tor. Batteries can be dangerous to life if swallowed. Keep batteries/
accumulators away from small children and pets. Do not dispose of
batteries in household waste (see also chapter „Disposal of Batteries/
Accumulators“).
03 | PRIVACY POLICY
In every country, legal data protection rules apply. As these rules may
vary per country, please contact the appropriate authorities to learn
about the latest privacy policy in your country. In any case kindly note:
• Do not observe public areas such as sidewalks, roads, parking
lots etc.
• Never observe your staff.
• Respect the general right of privacy.
• Do not publish pictures showing individuals without having
their permission. Do not publish pictures showing identifiable
automobile license plates.
• Make aware of the observed areas with a sign and inform your
neighbours and visitors if necessary.
04 |NOMENCLATURE
01 Infrared LEDs
02 LED indicator/light sensor
03 Motion detector (PIR sensor)
04 Camera lens
05 Tension lock
06 Microphone
07 Eyelet for U-lock (lock optional)
08 LCD camera display
09 MENU button
10 OK button
11 Slide control (OFF/SETUP/ON)
12 Navigation buttons
13 Battery compartment
14 USB-C port
15 DC 12V connection
16 ¼“ thread mount
17 Eyelets for mounting strap
18 Eyelets for cable lock (lock optional)
19 SD card slot
20 Mounting strap

doerr-outdoor.de5
05 |ILLUSTRATION OF PARTS
01
02 06
04 05
05
03
07
08
11
13
09
10
12
SD
19
20
14
15
17 17
18
16

doerr-outdoor.de6
06 |COMMISSIONING
CAUTION
To avoid camera damages, make sure that camera is switched o
(slide control 11 = OFF) for the following steps!
11
06.1 Inserting the batteries
CAUTION
Make sure to use only fresh Mignon AA LR6 1.5V Alkaline Mangane-
se batteries or rechargeable NiMH batteries of the same type and
brand. Never combine Alkaline Manganese batteries with NiMH
batteries! When inserting the batteries please respect the correct
polarity (+/-). Please remove batteries when device is not in use for a
longer period.
Open the camera releasing the lateral tension locks (05). Make sure
that the slide control (11) is on position OFF. Insert 8 pcs AA 1,5V bat-
teries (not included) into the battery compartment (13). Respect cor-
rect polarity (+/-).
▶ NOTICE
To ensure exact indication of battery status when operating the
camera with NiMH rechargeable batteries, please select NiMH in
the camera menu „Battery Type“ located in camera register „SYS“
(see chapter 08.3).
06.2 Alternative power supplies
Use the DÖRR solar panel with internal Lithium Ion battery 1500
mAh for a sustainable and extended runtime. Optionally available in
our DÖRR webshop:
DÖRR Solar Panel Li-1500 12V/6V
www.doerr-outdoor.de/204446 
Alternatively, the camera can be operated with an external 12V bat-
tery in conjunction with our DÖRR battery cable. All optionally avai-
lable in our DÖRR webshop:
Lead Battery 12V/12Ah
www.doerr-outdoor.de/204347
DÖRR Battery Cable 2m with flat plug
www.doerr-outdoor.de/204364 
Both the solar panel and an external battery need to be plugged-in to
the cameras DC 12V port (15). Any inserted batteries do not need to be
removed when using external power supplies. The camera automa-
tically reverts to the inserted batteries as soon as the external power
supply is disconnected.
06.3 Inserting the SD/SDHC/SDXC memory card
▶ NOTICE
Only use SD/SDHC/SDXC memory cards from 8GB to max. 128GB.
Using a micro SD card in combination with an adapter may lead to
malfunctions. Make sure that the SD card is formatted and unlo-
cked:
micro
SD
06.3.1 SDXC memory cards 64 GB & 128 GB
⛔ IMPORTANT
SDXC Speicherkarten 64 GB & 128 GB
Due to their standard formatting, SDXC memory cards with 64 GB
and 128 GB must be formatted with the camera before use. How to
format the SDXC card with the camera, please read chapter 08.3.
Insert the SD/SDHC/SDXC memory card (not included) with the label
facing upwards into the SD card slot (19) until it snaps into place.

doerr-outdoor.de7
07 |OPERATION
07.1 Overview home screen
Switch the slide control (11) to the middle position SETUP .
11
After the DÖRR Logo the LCD display (08) shows the basic factory
settings:
Camera is in single photo mode
Resolution 5 Megapixel
Battery level
Date/time
Used/Free space
(Example with 16GB SDHC card)
07.2 All basic factory settings
CAM Camera mode: Photo
Photo settings: Resolution: 5 M
Multi Shot: 1 photo
Flash Power: High
PIR Trigger mode: PIR Sensor ON
PIR Sensitivity: Level 7
PIR Delay: O
Time Lapse: O
Timer 1 + 2: O
SYS Language: German *
Password: O
Battery Type: Alkaline
Overwrite SD: On
* The camera menu language is factory set to GERMAN. To change
the menu language, please go to chapter 08.3.
07.3 Main Menus
To adjust the settings for your purposes, switch the slide control (11)
to the middle position SETUP and press the menu button (09) .
The 3 main menus appear in the top left of the LCD display (08). The
selected main menu is highlighted in yellow :
Main menu CAM
Here you can adjust the camera settings. You can see the dierent
settings in chapter 08.1.
Main menu PIR
Here you can adjust the trigger settings. You can see the dierent
settings in chapter 08.2.
Main menu SYS
Here you can set the date/time, language, password etc. You can
see the dierent settings in chapter 08.3.
07.4 Menu navigation
• Press the navigation buttons (12) or to select the desired
submenu. The selected submenu is highlighted in yellow:
CAM PIR SYS
Kamera Modus
‹Foto ›
MENU Exit Save OK
• Use the navigation buttons (12) or to select the desired setting.
• To save your settings press the OK button (10) .
• Press the menu button (09) to return to the home screen.

doerr-outdoor.de8
08 |SETTINGS & FUNCTIONS
08.1 Main Menu CAM
Cam Mode ‹Photo ›Selection ‹ Photo ›. The camera takes pictures according to your further, subsequent photo
settings.
Image Size Select the desired image resolution.‹5M ›5 MP (3072 x 1728)
‹3M ›3 MP (2304 x 1280)
Multi Shot Select the number of images to be taken upon
movement or triggering..
‹1 Photo ›
‹2 Photos ›
‹3 Photos ›
Flash Power Select the desired flash range.‹Low ›up to approx. 8 m
‹High ›up to approx. 20 m
Cam Mode ‹Video ›Selection ‹ Video ›.The camera makes videos according to your further, subsequent video
settings.
Video Size Select the desired video format.‹HD-720P ›HD (1280 x 720)
‹FHD-1080P ›Full HD (1920 x 1080)
Video Length Select the desired video length.‹Sec ›5 - 59 seconds
Flash Power Select the desired flash range.‹Low ›up to approx. 8 m
‹High ›up to approx. 20 m
Cam Mode ‹Photo+Video ›Selection ‹ Photo+Video ›. The camera first takes a photo (or photos) and then records a video
according to your other subsequent settings for photos and videos.
Image Size Select the desired image resolution.‹5M ›5 MP (3072 x 1728)
‹3M ›3 MP (2304 x 1280)
Multi Shot Select the number of images to be taken upon
movement or triggering..
‹1 Photo ›
‹2 Photos ›
‹3 Photos ›
Video Size Select the desired video format.‹HD-720P ›HD (1280 x 720)
‹FHD-1080P ›Full HD (1920 x 1080)
Video Length Select the desired video length.‹Sec ›5 - 59 seconds
Flash Power Select the desired flash range.‹Low ›up to approx. 8 m
‹High ›up to approx. 20 m

doerr-outdoor.de9
08.2 Main menu PIR
PIR Sensor ‹ON ›Selection ‹ ON › The Passive Infrared Sensor (PIR) triggers upon motion and temperature changes recog-
nised within the detection range.
‹OFF ›
PIR Sensitivity Adjust the sensitivity of the motion
detector.
‹Level 1 ›
Select when camera triggers too often
upon environment influences, e.g. fal-
ling branches or strong sunlight.
‹Level 2 ›
‹Level 3 ›
‹Level 4 ›
‹Level 5 ›
‹Level 6 ›
The camera recognises even smallest
motion and temperature changes.
‹Level 7 ›
‹Level 8 ›
‹Level 9 ›
PIR Delay Set a pause for the PIR Sensor. This set-
ting prevents the camera from taking too
many images/videos.
Example with setting 5 minutes:
After triggering, the camera sets the PIR
inactive for 5 minutes. After the time set
the PIR sensor will be active again.
Possible delay: min. 05 seconds to max.
24 hours (Input 23:59:59)
‹OFF ›
‹ON ›After selection ‹ ON ›and pressing the
OK button (10) another window opens
for entering the time duration:
MENU Exit Save OK
PIR Delay
Use the buttons (12) or to select
the hours. Use the button to enter the
next input field. Select the minutes and
seconds accordingly. Confirm your entry
with the OK button (10).
Time Lapse The camera triggers according to the spe-
cific time set, independently from the
PIR detector.
Example with setting 01:00:00:
The camera triggers every hour inde-
pendently from motion recognition.
Possible time interval: min. 05 seconds to
max. 24 hours (Input 23:59:59)
‹OFF ›
‹ON ›After selection ‹ ON ›and pressing the
OK button (10) another window opens
for entering the time interval:
MENU Exit Save OK
Time Lapse
Use the buttons (12) or to select
the hours. Use the button to enter the
next input field. Select the minutes and
seconds accordingly. Confirm your entry
with the OK button (10).

doerr-outdoor.de10
08.2 Main menu PIR
Timer 1 Set a fixed working time frame in which
the camera is active. Outside of this
time, no recordings are made or move-
ments are registered.
Example with setting 2:00 – 5:00:
Camera is only active between 2:00 and
5:00 a.m.
If you select the ‹ OFF › function in this
menu item, the camera works 24 hours a
day. You can set up to 2 working times
per day.
‹OFF ›Selection ‹ OFF › Camera works 24 h.
‹ON ›After selection ‹ ON ›and pressing the
OK button (10) another window opens
for entering the start and end time:
Start
End
Timer 1
Use the buttons (12) or to select
the hours. Use the button to enter the
next input field. Select the minutes. Con-
firm your entry with the OK button (10).
Timer 2 Set a fixed working time frame in which
the camera is active. Outside of this
time, no recordings are made or move-
ments are registered.
Example with setting 2:00 – 5:00:
Camera is only active between 2:00 and
5:00 a.m.
If you select the ‹ OFF › function in this
menu item, the camera works 24 hours a
day. You can set up to 2 working times
per day.
‹OFF ›Selection ‹ OFF › Camera works 24 h.
‹ON ›After selection ‹ ON ›and pressing the
OK button (10) another window opens
for entering the start and end time:
Start
End
Timer 2
Use the buttons (12) or to select
the hours. Use the button to enter the
next input field. Select the minutes. Con-
firm your entry with the OK button (10).

doerr-outdoor.de11
08.3 Main Menu SYS
Date & Time Set the date and time.
Date format: DD / MM / YYYY
TIme format: 24-hours
‹Enter ›After selection ‹ Enter ›and pressing the
OK button (10) another window opens for
entering the date and time:
Date & Time
DD/MM/YYYY
SS:MM:SS
Use the buttons (12) or to select the day.
Use the button to enter the next input field.
Select the month and year accordingly.
Use the button to access the time input
field. Use the buttons (12) or to select the
hour. Use the button to enter the next input
field. Set the minutes and seconds according-
ly. Confirm your entry with the OK button (10).
Language Select the desired language for the camera
menu.
‹Deutsch › * * pre-installed
‹English ›
‹Français ›
‹Italiano ›
‹Español ›
‹Čeština ›
‹Dansk ›
‹Suomi ›
‹Magyar ›
‹Nederlands ›
‹Svenska ›
Password The camera can be password protected against
unauthorized use. When the password function
is activated, the password will be requested im-
mediately after the camera is switched on.
Default password:
‹ 0 0 0 0 0 0 ›
▶ NOTICE
We recommend writing down the password in
a safe place, as the camera can no longer be
operated if the password is lost.
‹OFF ›No password request when switching on.
‹ON ›After selecting ‹ ON ›and pressing the OK
button (10), another window opens for ent-
ering a 6-digit numerical code:
Password
Use the buttons (12) or to select the
number. Use the button to enter the next
input field. Confirm your entry with the OK
button (10).

doerr-outdoor.de12
08.3 Main Menu SYS
Battery Type To ensure an accurate indication of the battery
status, please select whether you have inserted
alkaline batteries or Ni-MH batteries into the
camera.
‹Alkaline › * * pre-installed
‹Ni-MH ›
Overwrite SD When selecting ‹ OFF ›
If the SD card is full, the camera stops recor-
ding until the card is changed or formatted.
When selecting ‹ ON ›
If the SD card is full, the camera overwrites the
oldest files.
‹OFF ›Camera stops recording
‹ON ›Camera overwrites oldest files
FW Update Only for DÖRR service work! ‹YES › By pressing the menu button (09) you exit
this function and return to the start screen.
Format SD This function deletes all files from the SD
card and re-formats the memory card.
▶ NOTICE
Make sure that you do not need the files
on the SD card anymore, before you start
formatting!
‹YES › By pressing the menu button (09) you exit
this function and return to the start screen.
Reset Restoring of Factory Settings
This function restores all settings to initial facto-
ry settings (except date and time).
‹YES › By pressing the menu button (09) you exit
this function and return to the start screen.
08.4 Quick view of settings
To quickly view and check your settings, set the slide control (11) to
the SETUP position.
Then press the button (12) . An overview of your settings appears
in the LCD display:
PIR Sens. ON
Sensitiv. 7
Cam Info
Use the buttons (12) or to scroll through the overview.

doerr-outdoor.de13
09 |TEST RECORDINGS / VIEW RECORDINGS
In SETUP mode (slide control 11 on position SETUP), a test photo, test
video or test photo+video can be released according to your settings
made in the main menu CAM camera mode.
11
To trigger the test recording, press the OK button (10).
If the test recording was successful, the following appears in the dis-
play (depending on the camera mode set):
taken
Video
taken
Pic+Video
taken
The recordings can be viewed with the help of a laptop or PC. You
have 2 options for this:
1. Connect the camera directly to the computer using an optional
USB-C data cable. To do this, plug the USB-C data cable into the
USB-C socket (14) of the camera and connect it to the USB port
of your computer.
2. Remove the memory card from the camera and read it out with
an external card reader (optionally available).
10 |MOUNTING / DIRECTING / ACTIVATING
10.1 Mounting and directing the camera
Pull the supplied mounting strap (20) through the eyelet (17) on the
backside of the camera. Mount the camera to a tree, pole or any other
suitable object. Do not fix the belt finally at this stage.
We recommend placing the camera at a height of 0.75 m to 1.00 m.
The optimal distance to the subject is between 3 and 10 m. Larger
distances are possible as well, but then the reliability of the motion
sensor is no longer given. The camera lens (04) should now point to
where the object is expected to show-up.
To verify your camera is hung up in a correct angle, we recommend
taking a view test photos (see chapter 09). The camera should be di-
rected in a way that the object will appear in the centre of the picture.
You may have to re-adjust the camera and take another test shot.
▶ NOTICE
To change the camera angle you can use e.g. a small wooden wedge
between camera and trunk. Please also note chapter 11 with our ex-
tensive range of accessories for installation and anti-theft protec-
tion.
Once the camera position is correct, the mounting belt (20) can be
tightened to hold the camera firmly. After successful assembly and
test recording, switch the camera o (11 = OFF).
10.2 Turn on camera and start surveillance
In order to get the camera ready to work, move the slide control (11)
to the position ON and close the camera housing. After approx. 10
seconds, the camera will be active. In case of movements detected, it
takes pictures according to your settings.
11
10.3 Notes for mounting the camera
10.3.1 PIR sensor
The PIR sensor triggers only under specific circumstances within a
certain range. The capturing of objects strongly depends on tem-
perature, vegetal cover, reflecting surfaces etc. Under perfect con-
ditions the recognition range can be up to 20m. Usually, you may
expect a range of 15 m. It may take a few attempts to find a good
position for the camera. During photo test, be aware that animals
are usually remarkably smaller than human beings. Animals might
be below the PIR sensor detection range and not be captured.
10.3.2 Light conditions
Avoid direct backlight when mounting the camera. The lens should
not point directly into the sun and camera should not be placed in
shadow.
10.3.3 Weather protection
Although the camera is weatherproof and well-suited for outdoor
use (dust and jet water protected according to IP66 protection
class) we recommend mounting the camera in a secured place not
facing the weather exposed side. Prevent the camera from driving

doerr-outdoor.de14
rain and constant exposure to sunlight. After a long period of hu-
midity caused by rain or fog, the camera should be placed in a dry
area for a few days.
11 |OPTIONAL ACCESSORIES
11.1 Optional mounting accessories
Our optional accessories such as the patented DÖRR holding fixture
in combination with the DÖRR universal adapter are designed for
fast and easy mounting of the camera at a tree, wall or other objects.
The camera clicks into the holding fixture and is firmly held in pla-
ce. The camera can be removed easily for a quick change of place of
action. The ball head ensure a flexible direction of the camera. The
fixture is rotatable by 360° and swivels up to 30° in all directions:
DÖRR Holding Fixture Multi for SnapShot
www.doerr-outdoor.de/204490 
DÖRR UNI-1 Universal Adapter for Holding Fixture
www.doerr-outdoor.de/204495 
11.2 Optional anti-theft devices
Pull a padlock (available as accessory) through the eyelet (07) to lock
the camera housing:
DÖRR Combination Lock 3-digits small
www.doerr-outdoor.de/204454 
Use our DÖRR cable lock (available as accessory) and pull it through
the eyelet for cable lock (18) on the backside of the camera to secure
it against theft:
DÖRR Universal Cable Lock 1,80 m
www.doerr-outdoor.de/204452 
󰏦Visit our web shop www.doerr-outdoor.de
for a great variety of surveillance camera accessories and get more
information on our wide assortment of hunting and outdoor items!
12 |CLEANING AND STORAGE
Never use aggressive cleansing agents or benzine to clean the device.
We recommend a soft, slightly damp microfiber cloth to clean the ou-
ter parts of the device. Remove batteries before cleaning! Store the
device in a dust-free, dry and cool place. This device is not a toy -
keep it out of reach of children. Keep away from pets.
13 |SCOPE OF DELIVERY

doerr-outdoor.de15
14 |TECHNICAL SPECIFICATIONS
Recording capability Photo / Video with audio / Photo+Video with audio
Combined picture and video recording Yes
Number of LEDs / LED Type 60 invisible infrared LEDs, 940nm
Flash range max. approx. 20 m
Detection range motion sensor approx. 20 m / 60°
Picture angle approx. 60°
Trigger speed PIR sensor approx. 0,5 - 0,6 s
Image sensor 3MP colour CMOS sensor
Aspect ratio 16:9
Picture resolution 3MP (2304x1280) / 5MP (3072x1728)
Video resolution Full HD 1080P (1920x1080) / HD 720P (1280x720)
Video length 5 - 59 s
Digital picture format JPEG
Digital video format MP4
Mobile transmission no
Display 1,4" TFT colour display
Playback on display (only settings)
Lens F = 2.0 / 60°
Multiple shots (pictures per release) 1 - 3 Photos
Delay PIR Sensor 5 seconds to 24 hours
Sensitivity PIR sensor 1 - 9 levels
Time frames per day 2
Time lapse function Yes
Time stamp on image Camera name, battery status, temperature (°F/°C), moon phase, date, time
Menu language DE, GB, FR, ES, IT, CZ, DK, FI, HU, NL, SE
Password protection Yes
Memory card SD/SDHC from 8GB to 32GB (SDXC 64GB to max. 128GB see instruction manual)
memory card not included
Thread mount 1/4" Yes
Compatible with DÖRR Holding Fixture
(Item-No. 204490) Yes, with DÖRR Uni 1 adapter (Item No. 204495, optional)
Power supply 8x Mignon AA LR6 1.5V Alkaline batteries or equivalent NiMH rechargeable batteries
(not included)
Operating voltage DC 12V
Power consumption approx. in operation 38-321mA by day, 45-722mA by night / standby 0.16mA
Runtime in standby mode approx. up to 8 month with 8x AA batteries
Socket for external battery Yes
USB port USB-C
Ingress protection code IP66
Operating temperature approx. -20°C to +55°C
Storage temperature approx. -25°C to +60°C
Relative humidity approx. 5% - 90%
Colour camouflage/black
Dimensions approx. 9,3 x 12,5 x 7,5 cm
Weight without batteries approx. 256 g
DÖRR GmbH reserves the right to make technical changes without notice.

doerr-outdoor.de16
15 | DISPOSAL, CE MARKING
15.1 DISPOSAL OF BATTERY/ACCUMULATOR
Batteries and rechargeable batteries are marked with the symbol
of a crossed-out waste bin. This symbol indicates that empty bat-
teries or rechargeable batteries that can no longer be recharged
must not be disposed of in household waste. Old batteries may
contain harmful substances that can cause damage to health and
the environment. As the end user, you are legally obliged to return
used batteries (under German battery law, Section 11 Act Revising
the Law of Waste-Related Product Responsibility for Batteries and
Accumulators). You can return batteries free of charge after use
at the point of sale or in your immediate vicinity (e.g. at municipal
collection points or in shops). You can also return batteries to the
seller by post.
15.2 WEEE INFORMATION
The WEEE (Waste Electrical and Electronic Equipment) Directive,
which came into force as European law on 13 February 2003, led
to comprehensive changes in the disposal of discarded electrical
equipment. The primary purpose of this directive is to prevent e-
waste while promoting reuse, recycling and other forms of repro-
cessing in order to reduce waste. The WEEE logo (dustbin) shown
on the product and on the packaging indicates that the product
must not be disposed of in normal household waste. You are
responsible for delivering all discarded electrical and electronic
equipment to appropriate collection points. Sorting waste for se-
parate collection and sensible recycling of packaging waste helps
to use natural resources more sparingly. Furthermore, e-waste re-
cycling is a contribution to preserving our environment and thus
also people‘s health. Further information on the disposal of elec-
trical and electronic equipment, recycling and collection points
can be obtained from local authorities, waste disposal companies,
specialist retailers and the manufacturer of the device.
15.3 DISPOSAL OF THE PACKAGING
Dispose of the packaging by type. Give cardboard to the waste
paper, foils to the collection of recyclables.
15.4 CONFORMITY WITH ROHS
This product complies with the European RoHS Directive on the
restriction of the use of certain hazardous substances in electrical
and electronic equipment and variations thereof.
15.5 CE MARK
The imprinted CE mark complies with the applicable EU standards
and indicates that the device meets the requirements of all EU directi-
ves applicable to this product.
DÖRR Surveillance Camera
SnapShot Mini 5.0 Pro
Item-No. 204501
Made in China
DÖRR GmbH
Messerschmittstr. 1
D-89231 Neu-Ulm
Fon: [phone]
[e-mail]
https://doerr-outdoor.de
