IMPORTANT
1. Before beginning installation, please thoroughly read and become familiar with these instructions.
2. Installation and service must be completed by a qualified installer or service agency.
3. Installer: Please leave these Installation Instructions with the owner.
4. Owner: Please keep these instructions for local electrical inspectorʼs use and for future reference.
5. Read the accompanying Use & Care Manual prior to operating this appliance.
TABLE OF STEPS
STEP 1 Verifying the package contents Page 2
STEP 2 Planning the installation Page 2-3
STEP 3 Gas and electrical supply requirements Page 4-5
STEP 4 Installing the cooktop Page 5
STEP 5 Gas connection Page 5-6
STEP 6 Installing the burner components Page 6
STEP 7 Electrical connection Page 6
STEP 8 Verifying cooktop operation Page 7
Part No. 65141-B Rev. 011504
TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI Z21.1 STANDARD FOR
HOUSEHOLD GAS COOKING APPLIANCES.
NOTES:
Contain helpful hints and tips to facilitate the installation.
CONVENTIONS USED IN THESE INSTRUCTIONS
IMPORTANT:
Must be followed carefully to avoid damage.
WARNINGS:
Must be followed carefully to avoid personal injury.
SAVE AND READ THESE INSTRUCTIONS
Installation Instructions
Preference™ Cooktops

INSIDE FRONT COVER
THIS PAGE IS BLANK INTENSIONALLY
Page 1

INSIDE FRONT COVER
THIS PAGE IS BLANK INTENSIONALLY
Page 1
WARNINGS:
1. Read all instructions before using the appliance.
2. Improper installation, adjustment, alteration, service, or maintenance can cause personal injury
or property damage. Refer to these instructions and the accompanying Use & Care Manual. For
assistance or additional information, consult a qualified installer, service agency, manufacturer
(dealer), or the gas supplier.
3. For your safety:
• Do not obstruct the flow of combustion and ventilation air to the unit.
• Keep appliance area clear and free from combustible material, gasoline and other flammable
vapors and liquids.
• Do not use or attempt to use this appliance in the event of a power failure.
4. This unit is designed as a cooking appliance. Never use it for warming or heating a room.
5. This appliance must not be used in combination with surface (countertop) ventilation systems.
The use of an overhead hood is recommended for ventilation.
6. This appliance must be installed with the gas pressure regulator supplied with it.
7. Disconnect the electrical supply before installing or servicing the appliance.
8. This appliance must be grounded. Connect only to a properly grounded electrical supply. Refer
to “Electrical Requirements”.
9. Install or locate this appliance only in accordance with these installation instructions.
10. Use this appliance only for its intended use as described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of appliance is not designed for industrial or
laboratory use.
11. As with any appliance, close supervision is necessary when used by children.
12. Do not operate this appliance if it has a damaged electrical cord, plug, conduit or wires, if it is not
working properly, or if it has been damaged or dropped.
13. This appliance should be serviced only by qualified service personnel. Contact the nearest
DACOR Authorized Servicer at [phone], or at www.dacor.com for examination, repair or
adjustment.
Some products, such as whole eggs, and sealed containers, such as closed glass jars, may
explode and should not be heated on this cooktop.
Based on safety considerations, the top burner flame should be adjusted so it does not extend
beyond the edge of the cooking utensil.
Cooking utensils should not be used on the open top broiler section.
WARNINGS:
1. If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or death.
2. What to do if you smell gas:
• Do not try to light any appliance.
• Do not touch any electrical switch, do not use any phone in your building.
• Immediately call the gas supplier from a neighborʼs phone.
• Follow the gas supplierʼs instructions.
• If you cannot reach your gas supplier, call the fire department.
3. For your safety:
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
4. Installation of this appliance must be performed by a qualified installer, service agency or the
gas supplier.

Page 2
Page 3
NOTES:
1. If cabinet storage space is to be provided directly above the cooktop, the risk of personal injury
may be reduced by installing a ventilating hood that projects horizontally a minimum of 5 inches
beyond the face of the cabinets.
2. Allow a minimum 1/4 inch clearance between the bottom of the any cooktop chassis and all
combustible surfaces, including the upper edge of a drawer installed below the cooktop.
3. Access to the underside of the cooktop and the junction box must be provided for inspection
and service.
4. A fixed shelf should not be installed below the cooktop.
5. Clearance inside the cabinet must allow for proper side mounting bracket installation.
6. All models are designed for 24” (610mm) minimum base cabinet depth.
7. The maximum depth of cabinets installed above cooking tops is 13 inches (330mm)
STEP 1
Verifying the Package Contents
• Use & Care Manual • Hold Down Bracket Kit
• Cleaning Kit • Simmer Plate (SGM Only)
• Grate/Burner Cap Pack • Burner Set
• Gas Pressure Regulator • Grill Drip Pan (SGM464GG Model Only)
• Grill U-burner (SGM464GG Model Only) • Grill Heat Control Channels (SGM464GG Model Only)
• Grill (SGM464GG Model Only) • Grease Control Box (SGM464GG Model Only)
STEP 2
Planning the Installation
Cabinet and Countertop Preparation
The installation of this built-in appliance must be completed by a qualified appliance technician or contractor. Proper installation is the
ownerʼs responsibility.
Carefully check the location where the cooktop is to be installed. The cooktop should be placed for convenient access, but away from drafts
that may be caused by open doors and windows or by HVAC duct outlets. Make certain that gas and electrical power can be provided
in the selected locations. Plan the installation so that all minimum clearances are met or exceeded. Dimensions shown provide minimum
clearances, unless otherwise noted.
WARNINGS:
1. To reduce the risk of personal injury caused by reaching over a hot appliance, cabinet storage
space located directly above the cooktop should be avoided.
2. Keep appliance area clear and free from combustible materials, gasoline and other flammable
vapors and liquids.
3. Failure to provide proper clearances may result in a fire hazard!
4. Do not store combustible materials or items adversely affected by heat immediately below the
cooktop.
5. The back edge of the cooktop must remain a minimum of 2 1/4" (57mm) from any combustible
backsplash material. This will require special cabinet and countertop dimensions.
IMPORTANT:
When installing the cooktop into a laminated (Formica, etc.) or synthetic (Corian, etc.) countertop,
radius the corners of the cutout to prevent cracking of the countertop. Follow the countertop
manufacturerʼs instructions regarding the minimum corner radius, use of heat reflective tape,
reinforcement of corners, etc.

Page 2
Page 3
13"
(330mm)
Maximum
A
3 1/8"
(79mm)
18"
(457mm)
Minimum
30"
(762mm)
Minimum
"A" "A"
Model Minimum Recommended
SGM304 30" (762mm) 36" (914mm)
SGM364 36" (914mm) 42" (1067mm)
SGM365 36" (914mm) 42" (1067mm)
PGM365 36" (914mm) 42" (1067mm)
SGM466 48" (1219mm) 54" (1372mm)
SGM464GG 48" (1219mm) 54" (1372mm)
30"
(762mm)
21"
(533mm)
4" (102mm)
Chassis height
1/4" (6mm) Min.
to combustibles
below chassis
27 1/2"
(699mm)
19 7/8" (505mm)
3 1/8"
(79mm)
7 1/2" (191mm) Min.
to combustible
side wall above
the cooktop
(both sides)
2 1/4"
(57mm) Min.
Vertical
combustible
surface
Rear
wall
2"
(51mm) Min.
25" (635mm)
Minimum
36"
(914mm)
21"
(533mm)
19 7/8"
(505mm)
33 3/4"
(857mm)
4" (102mm)
Chassis height
3 1/8"
(79mm)
1/4" (6mm) Min.
to combustibles
below chassis
7 1/2" (191mm) Min.
to combustible
side wall above
the cooktop
(both sides)
2 1/4"
(57mm) Min.
Vertical
combustible
surface
Rear
wall
2"
(51mm) Min.
25" (635mm)
Minimum
21"
(533mm)
4" (102mm)
46"
(1168mm)
44 1/2"
(1130mm)
19 7/8" (505mm)
3 1/8"
(79mm)
1/4" (6mm) Min.
to combustibles
below chassis
7 1/2" (191mm) Min.
to combustible
side wall above
the cooktop
(both sides)
Vertical
combustible
surface
Rear
wall
2 1/4"
(57mm) Min.
2"
(51mm) Min.
25" (635mm)
Minimum
6 1/2"
(165mm)
30 1/2"
(775mm)
14"
(356mm)
STEP 2
Planning the Installation
Cabinet and Countertop Preparation
Clearance to Combustibles
Cutout Dimensions for the
SGM304
Plan the installation so that the electrical connection, gas shut-off valve, and pressure regulator are accessible from the front of the cabinet.
1/4” (6mm) Minimum
clearance to combustible
surfaces
B
"B"
Model Minimum
SGM304 29" (737mm)
SGM364 35 1/4" (895mm)
SGM365 35 1/4" (895mm)
PGM365 35 1/4" (895mm)
SGM466 46" (1168mm)
SGM464GG 46" (1168mm)
Under Cabinet Clearances
Cutout Dimensions for the
SGM364, SGM365, and PGM365
(SGM365 shown)
Cutout Dimensions for the
SGM466 and SGM464GG
(SGM464GG shown)
NOTES:
1.The only downdraft approved for use with the SGM464GG is the Dacor ERV/PRV. Dacor
recommends a 54 inch wide hood with a minimum 1100 CFM blower.
2.The SGM464GG cooktop is approved for 2” (51mm) min. clearance to combustibles below the
chassis.
3.For the SGM464GG, a noncombustible material is to be installed on the underside of a cabinet
located above the grill section in accordance with local codes, or in the absence of local codes,
with the National Fuel Gas Code, ANSI Z223.1/NFPA 54.

Page 4
Page 5
STEP 3
Gas and Electrical Supply Requirements
NOTES:
1. All gas cooktops have the gas and electrical located in the back right corner as you face the
front of the appliance.
2. Each cooktop ships with a factory regulator in the box. All 30, 36, and the SGM464 models
utilize 1/2” regulators. The SGM 466 uses a 3/4” regulator, which is approved for connection to
a 1/2” house gas supply.
WARNINGS:
1. If the gas or electric service provided does not meet the product specifications, do not proceed
with the installation. Call the selling dealer, the gas supplier, or a licensed electrical or plumbing
contractor.
2. The grounding plug must not, under any circumstances, be cut or removed.
3. This appliance must be installed by a licensed plumber or gas fitter when installed within the
Commonwealth of Massachusetts.
Gas Supply Requirements
Check your local building codes for the proper method of installation. In the absence of local codes, this appliance should be installed in
accordance with the National Fuel Gas Code ANSI Z223.1/NFPA 54. Be certain that the appliance being installed is correct for the gas service
being provided. Refer to the data plate located on the rear of the cooktop chassis.
NOTES:
1. No adjustment of burner settings is required. All valves and air mixture shutters found in this
appliance have been factory preset.
2. Liquid propane (LP) cooktops should be special-ordered from the factory. Liquid propane units
are identified by the “LP” designation at the end of the model number.
3. Under extenuating circumstances, some cooktops may be field converted to operate on LP
gas or at elevations in excess of 5,000 feet above sea level. However, field conversion must be
completed by a qualified service agency and authorization must be granted by the factory prior
to any field conversion.
Electrical Requirements
The SGM304, SGM364, SGM365, SGM466 and SGM464GG cooktops are supplied with a factory installed three-prong, grounding plug.
It is the owner's responsibility to ensure that the electrical connection of this appliance is performed by a qualified electrician. The electrical
installation, including minimum supply wire size and grounding, must be done in accordance with National Electric Code ANSI/ NFPA 70-1993*,
(or the latest revision) and local codes and ordinances.
*A copy of this standard may be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02269-9101
Model No.
Electrical circuit
required
Total connected
load Gas type Manifold pressure
Minimum gas
supply pressure
SGM304
SGM304LP
SGM364
SGM364LP
SGM365
SGM365LP
SGM466
SGM466LP
SGM464GG
SGM464GGLP
Liquid Propane
Liquid Propane
Liquid Propane
Liquid Propane
Liquid Propane
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz,15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
Natural
Natural
Natural
Natural
Natural
4" Water Column 5" Water Column
10" Water Column
4" Water Column
10" Water Column
4" Water Column
10" Water Column
4" Water Column
10" Water Column
4" Water Column
10" Water Column
11" Water Column
5" Water Column
11" Water Column
5" Water Column
11" Water Column
PGM365
PGM365LP Liquid Propane
120VAC, 60Hz, 15A
120VAC, 60Hz, 15A
0.25 Amps (0.03 Kw)
0.25 Amps (0.03 Kw)
Natural 5" Water Column
10" Water Column
6" Water Column
11" Water Column
5" Water Column
11" Water Column
5" Water Column
11" Water Column
Gas and Electrical Requirements

Page 4
Page 5
STEP 3
Gas and Electrical Supply Requirements
The correct voltage, frequency and amperage must be supplied to the appliance from an isolated, grounded circuit which is protected by a
properly sized circuit breaker or time-delay fuse.
The cooktop must be connected to the power supply with copper wire only. The use of aluminum wire may result in unsatisfactory connections.
Flexible armored or non-metallic, sheathed copper cable (with a grounding wire) should be used to supply electrical power to the junction
box or receptacle.
For the SGM304, SGM364, SGM365, SGM466 and SGM464GG the factory-equipped, three-prong grounding plug must be inserted into a
mating grounding-type receptacle in accordance with National Electric Code and applicable state, municipal and local codes.
Be certain to locate the junction box or electrical outlet so the electrical supply may be easily disconnected in the event that service becomes
necessary. Also, provide extra slack in the cable to allow the cooktop to be removed for servicing.
IMPORTANT:
1. If the electrical supply circuit does not have a grounding-type receptacle, it is the responsibility
of the customer to have the existing receptacle changed by an electrician to a properly grounded
receptacle.
2. The power supply must be properly polarized. Reverse polarity will result in continuous sparking
of the electrodes, even after flame ignition. If the power supply is not properly polarized, it is the
responsibility of the customer to have the polarity corrected.
3. If there is any doubt as to whether the wall receptacle is properly grounded or polarized, have it
checked by a qualified electrician prior to installing the cooktop.
4. Do not plug the cooktop into Ground Fault Circuit Interrupter (GFCI) receptacles. The cooktop
spark ignition module can cause a GFCI to trip.
STEP 4
Installing the Cooktop
Place and center the cooktop within the cutout. Secure the cooktop to the countertop utilizing the two (2) hold-down brackets provided. Do
not over-tighten the screws.
IMPORTANT:
Do not use a hardening compound or caulking to permanently seal the cooktop into place, as the
unit must be readily removable for service. If such a hardening compound is used, removal of the
unit will be at the customerʼs expense.
STEP 5
Connecting the Gas
WARNINGS:
1. The maximum gas supply pressure to the regulator must not exceed 1/2 pound per square inch.
2. Verify that the proper gas supply has been provided according to Step 3.
3. Do not apply excessive pressure when tightening connections and fittings.
4. Do not use plumber's putty or Teflon tape on gas compression connections. It can defeat the
proper sealing of these fittings. Use plumber's putty or Teflon tape only on pipe thread fittings.
5. Turn all cooktop control valves to the “OFF” position, then turn on the gas supply. Check all
supply lines and connections for leaks using a soap and water solution. Do not use a flame
to check for leaks. After verifying that there are no gas leaks, turn off the gas supply to the
cooktop by turning the gas shut-off valve to the off position. Leak testing of the appliance shall
be conducted according to the manufacturerʼs instructions.
6. For LP gas installations, the LP gas tank must have its own high-pressure regulator. This is in
addition to the pressure regulator supplied with the cooktop.

Page 6
Page 7
STEP 5
Connecting the Gas
Attach the gas pressure regulator (included with the cooktop) to cooktop pipe nipple inlet. For tight installations, the regulator may be installed
upstream from the pipe nipple, anywhere between the shut-off valve and the cooktop.
Install a gas shut-off valve (not included with the cooktop) in the main gas supply line in an accessible location near the cooktop. Complete
connection of the gas supply to the cooktop by installing 1/2 inch flexible gas line (not included with the cooktop) between the pressure
regulator and the shut-off valve.
IMPORTANT:
To prevent damage to the gas pressure regulator, install the regulator only after the cooktop is
mounted in its permanent position. Ensure that the arrow on the regulator points in the direction
of the gas flow towards the cooktop.
STEP 6
Installing the Burner and Grill Components
Grate
Burner Cap
Burner Ring
Top Frame
Burner Head (Fixed)
SGM Burner Components
Remove the brass burner rings, porcelain burner caps, and porcelain grates from their shipping packages. Place each burner ring onto its
corresponding burner base, being certain that the five alignment tabs slide into the matching notches in the base. Set each porcelain burner
cap on top of its corresponding burner ring. Place each grate onto the cooktop, being certain that the rubber feet are positioned in the locating
dimples.
PGM Burner Components
Remove the brass burner heads, burner caps, and porcelain grates from their shipping packages. Place each burner head onto its
corresponding burner base, being certain that the alignment tabs slide into the matching notches in the base. Set each burner cap on top of its
corresponding burner ring. Place each grate onto the cooktop, being certain that the rubber feet are positioned in the locating dimples.
Grill Components
Remove the grill components from inside the main carton. Remove all of the packing materials from the Grill, U-burner, Heat Control Channels,
Grease Control Box and the Drip Pans.
Begin your set up by placing the Drip Pans inside on the bottom of the open grill burner box area, using the dimples to locate the Drip Pan.
Next, slip the open end of the U-burner onto the gas stub located in the front inside of the grill burner box, and insert the bracket on to opposite
end of the U-burner into the slot located on the Grease Control Box.
Proceed to install the Heat Control Channels, which sit on top of four pins at the inside front and back of the grease control box. Finally,
set the grill in place on the top of the cooktop.
WARNING:
Never attempt to operate the cooktop with any of the burner rings, burner caps, grates, or grill
components removed.
SGM Burner Components
NOTE:
The U-burner is adjusted at the factory and does not require any field adjustment for proper
function.
Grate
Dual Burner Cap
Dual Burner Head
Dual Burner
Cross Ring
Single Burner Base
Single Burner Head
PGM Burner Components

Page 6
Page 7
STEP 7
Electrical Connection
WARNINGS:
1. Ensure that the power supply is disconnected before proceeding.
2. Verify that the power supply matches the ratings found on the appliance data plate before
proceeding.
3. The complete appliance must be properly grounded at all times when electrical power is
applied.
4. Do not ground the appliance with the neutral (white) house supply wire. A separate ground
wire must be utilized.
5. If aluminum house supply wiring is utilized, splice the appliance copper wires to the aluminum
house wiring using special connectors designed and agency-certified for joining copper and
aluminum.
6. Follow the connector manufacturerʼs recommended procedure carefully. Improper connection
can result in a fire hazard!
SGM304, SGM364, SGM365, SGM466 and SGM464GG: Plug the three-prong plug from the appliance into the properly grounded and
polarized wall receptacle.
WARNINGS:
1. If the cooktop fails to operate properly, ensure that the electrical power supply and gas supply
are turned on and that all installation steps have been carefully followed. Call a qualified service
technician if the cooktop still does not operate properly.
2. The cooktop and shut-off valve must be disconnected from the gas supply piping during any
pressure testing exceeding 1/2 pound per square inch (3.5 kPA).
3. The cooktop must be isolated from the gas supply piping by closing the shut-off valve during any
pressure testing at or below 1/2 pound per square inch (3.5 kPA).
Before beginning the test procedure, ensure that the gas supply is turned off at the
shut-off valve, all cooktop control valves are in the “OFF” position, and all burner
rings, burner caps, and grates are properly positioned on the cooktop.
SGM Models
Rotate one knob at a time counterclockwise to the “HIGH” position. Verify that all
ignitors spark continuously, then return the knob to the “OFF” position. Repeat for all
knobs.
PGM Model
Rotate one knob at a time counterclockwise to the “HIGH” position. Verify that
associated burner igniter sparks, then return the knob to the “OFF” position. Repeat
for all knobs.
Turn on the main gas supply to the cooktop by opening the gas shut-off valve.
Test each burner separately by pressing and turning one control knob at a time
counterclockwise to the “HIGH” position. On the SGM models, all ignitors will spark
simultaneously, but only the burner with gas flowing to it will ignite. On the PGM model, only the selected burner will spark. (It will take
approximately four seconds for ignition to occur, at which time all ignitors will stop sparking. If ignition does not occur within four seconds, turn
off the knob, wait for at least two minutes to allow any gas to dissipate, then repeat this ignition test.) The control knob can then be rotated
counterclockwise from “HIGH” to “LOW” to adjust the flame height progressively. Repeat the ignition test for all burners.
When installed properly, the flame will be steady and quiet. It will also have a sharp, blue inner cone that will vary in length proportional to
the burner size. Flame adjustment will not be necessary.
Read and understand the accompanying Use & Care Manual prior to cooking with this appliance. The Use & Care Manual contains additional
important safety, service and warranty information.
STEP 8
Verifying Proper Operation
Light & high position Off position
Low position
Burner indicator light
Gas Control Knob

Page 8
INSIDE BACK COVER
THIS PAGE IS BLANK INTENSIONALLY

Page 8
INSIDE BACK COVER
THIS PAGE IS BLANK INTENSIONALLY

  
    
   
     
