Daewoo Bus BS Series User manual

IMPORTANT SERVICE ACTIVITIES
Items Maintenance Schedule Remarks
Engine oil & Filter
Fuel Filter
DE08TIS
DE12TIS
DV15TIS
DL06
DL08
DV11
GE08TI
GE12TI
ISM
DE08TIS
DE12TIS
DV15TIS
DL06
DL08
DV11
ISM
Change : At end of first 1,000km,
long distance : every 30,000km
shot distance : every 20,000km
The initial change is at 5,000 km.
Replace it every 40,000 km (Driving in downtown/short-haul)
Replace it every 60,000 km (Driving at high speed/long-haul)
The initial change is at 1,000 km.
Replace it every 20,000 km (Driving in downtown/short-haul)
Replace it every 30,000 km (Driving at high speed/long-haul)
The initial change is at 1,000 km.
Replace it every 24,000km.
Replace it every 20,000 km.
Replace it every 40,000 km (Driving in downtown/short-haul)
Replace it every 60,000 km (Driving at high speed/long-haul)
Replace it every 24,000 km.
※Please refer to
‘‘Regular Check-up List and Periodic Table’’
(6-3 page) for more details.
※It is recommended to
replace this part at least twice
a year even if the vehicle is
not regularly operated.

Items Maintenance Schedule Remarks
Gas Filter
Spark Plug
Air Cleaner Filter
Manual Transmission Oil
Rear Axle Oil
Power Steering Oil & Filter
APU (Air dryer) Cartridge
APU Oil Separator
BX212Fan Clutch Oil
Clutch Oil
Hub Grease
Antifreezing Solution
GE08TI
GE12TI
GE08TI
GE12TI
Inspect it every 5,000 km and replace every 20,000 km.
Replace it every 80,000 km.
Clean it every 12,000 km or 300 hour.
Replace : After 3 cleaning
Replacement : Eevery 24,000km after the initial change at 5,000km.
Inspection & Refill : Every 4,000km after the initial one at 1,000km.
Replacement : Every 24,000km after the initial change at 5,000km.
Inspection & refill : Every 4,000km after the initial one at 1,000km.
Replace it every 40,000km after the initial change at 5,000km.
Replace it every 100,000km or one year.
Clean every 30,000km (O-Ring replacement)
Replace it every 80,000 ~ 100,000km or one year.
Replace it every 60,000km or one year.
Replace this part when attaching and detaching it.
Concentration check & refill : Every month.
Replacement : Every year.
Periodic check
※Please refer to
‘‘Regular Check-up List and Periodic Table’’
(6-3 page) for more details.

FOREWORD
Thank you very much for choosing a DAEWOO BUS.
This manual contains explanations in easy way about correct driving method and general inspection operation for your
vehicle that could have maximum performance in optimal condition.
Contents of this manual describe all the possible options which are fixable for a vehicle, therefore it can be different
from you vehicle depending on your chosen options and design change.
All written contents in this book can be changed without any notice for improvement of the product and we will be
grateful if you understand that our company has no obligation to apply it for delivered vehicles about changed contents.
Please read and familiarize this manual before driving a vehicle. You can gain maximum efficiency and optimal
economic result if you follow the constructions.
DAEWOO BUS has expert service manpower and modern facilities in order to be ready to take care of you vehicle.
We promise to provide continuous support that you can be satisfied and enjoy driving a DAEWOO BUS. Thank you
very much for using our vehicles.
It is recommended to use always DAEWOO BUS standard parts with
indicated label shown right side to keep your vehicle in optimal
condition.
OM-B520E

WARRANTY INFORMATION
We are pleased that you have purchased
a Daewoo Bus.
This is the warranty and maintenance
record of your Daewoo Bus.
This booklet should always be kept as a
permanent part of the vehicle, and remain
with your Daewoo Bus at time of resale.
When service is due according to the time
period or mileage indicated in the Owner󰿼s
Manual, present this Warranty to any
authorized Daewoo Bus dealer and
request that the appropriate service be
performed.
We sincerely hope that you will be
delighted with your Daewoo Bus and that
it brings you much enjoyment over the
years to come.
OWNER󰿼󰿼 S IDENTIFICATION
Owner Service No. (O.S. NO.) :
Model :
Vehicle Ident. No.(VIN) :
Engine No. : Body Color :
Date of Delivery :
Mileage at Delivery
Issued by
Dealer󰿼s Name :
Dealer󰿼s Address :
Dealer representative󰿼s
Signature :
1. Owner󰿼s Name :
Address :
Phone :
License No :
2. Owner󰿼s Name :
Address :
Phone :
License No :
Dealer󰿼s
Stamp

NEW VEHICLE WARRANTY
Daewoo Bus Corp., hereinafter called the manufacturer, warrants to the owner of each Daewoo Bus that the
Daewoo Bus shall be free, under normal use and maintenance, from any defects in material and workmanship,
subject to the following terms and conditions.
1. Warranty period
This warranty shall exist for a period 12 months from the date of either delivery to the first retail purchaser or
first use to the vehicle as a company vehicle by distributor or dealer, or until the vehicle has been driven for a
distance of 100,000 km ( -- miles), whichever comes first.
2. What is covered
Except as provided in paragraphs 3 hereof, an authorized Daewoo dealer or distributor shall either repair or
replace, at its option, any Daewoo genuine part that is defective in material or workmanship within the warranty
period set forth in paragraph 1 hereof, without charge to the owner of the Daewoo Bus.
3. What is not covered
This warranty shall not apply to or include any of the following.
(a) Repair or replacement required not as a result in material or workmanship of manufacturer but as a result of
(i) accident, (ii) misuse, (iii) lack of proper maintenance, (iv) repairs improperly performed or replacements
improperty installed by any person other than an authorized Daewoo dealer, (v) a replacement part or
accessory not conforming to the Manufacturer’s specifications, (vi) usage of any fuel other than that
specified for the Daewoo Bus, (vii) alterations by changing or adding to the vehicle, or (viii) damage grom
environmental conditions such as airborne fallout, salt, hail, windstorm, lightning, flood and the like, (ix)
transportation damage, (x) storage damage, (xi) diagnosis time.
(b) Any Daewoo Bus equipment subject to normal wear and tear, including, without limitation, filters, drive
belt(s), fuses, clutch facing, brake linings, wiper blades, and the like.

(c) Normal maintenance service, including, without limitation, cleaning and polishing, lubrication, adding
coolant, replacement of consumable parts, adjustment of necessary parts and engine tune-up.
(d) Any Daewoo Bus on which the odometer mileage has been altered or on which the actual mileage of the
Daewoo Bus cannot be readily determined.
(e) Extra expenses including, without limitation, payment for loss of the use of the vehicle, lodging bills, towing,
vehicle rentals, other travel costs and loss of pay.
(f) The further details are subject to the Daewoo Bus warranty policy and procedure manual.
Tire Warranty
Tires installed as original equipment on Daewoo Bus are warranted by their respective manufacturers and not
warranted by Manufacturer.
Owner’’ s Responsibility
1. Maintenance service are the owner’s responsibility
You should retain evidence that proper maintenance has been performed on your Daewoo Bus. Claims made
during the warranty period will not quality under the warranty if resulting from lack of mainrenance rather than
from defective material or workmanship. We recommend that such services be performed by an authorized
Daewoo dealer using genuine parts. Please note that the maintenance services described in the Owner󰿼s Manual
should be performed even more frequently if your Daewoo Bus is subject to severe conditions such as
operation in extremely dusty or extreme (high or low) temperature areas. Under such severe conditions, we
recommend that your engine oil level should be checked each time your purchase fuel for your Daewoo Bus
and that your engine coolant and cooling fan belt should be inspected frequently. Refer to the Owner’s
Manual for applicable specifications.
2. You must deliver your Daewoo Bus to an authorized Daewoo dealer or distributor to obtain warranty service.

SUGGESTIONS DAEWOO PRODUCTS
Please write down any suggestions concerning Daewoo products that help Manufacturee to develop Daewoo products.

DAEWOO BUS
OWNERSHIP REGISTRATION CARD/The copy for Manufacturer, Dealer and Owner
This card should be sent to Manufacturer by Dealer.
Owner Service No.
(O.S No.) Model
Street
City
Date of Delivery
Shipping Date
Owner󰿼s Phone No.
Country
Vehicle Ident. No.
(VIN)
Engine No.
Mileage at Delivery
Owner󰿼s Name
Owner󰿼s Address
Dealer󰿼s Signature Dealer󰿼s Name
Dealer󰿼s Signature
cut here

DAEWOO BUS
OWNER INFORMATION
Please read this owner information carefully to familiarize yourself with the type of service which you are entitled
under each of the warranties applicable to your new Daewoo Bus.
1. Pre-Delivery Inspection
To insure your satisfaction and long term enjoyment of your new Daewoo Bus, your Daewoo dealer inspects whether
the vehicle is complete or not in accordance with the standard factory instruction before delivery to you. If, after
delivery, an unexpected defect is found, please come to see selling dealer󰿼s service manager or authorized service
man immediately. On this defect, your selling dealer will be willing to perform the service as requested.
2. Parts Repair and Replacement by Warranty
Should any defects in material or workmanship occur within the period, said part will be repaired or replaced without
cost to you after certification of the Daewoo dealer.
3. Change of Residence Privileges
Although you have changed your residence within the warranty period, you are entitled, on presentation of this Service
Guide/Warranty Information booklet which will be signed and stamped by the selling dealer, to erceive the services at
any Daewoo dealer󰿼s service shop, regardless of where the vehicle may have been purchased.
4. Periodic Inspection and Service
Regular inspection and maintenance by skilled technicians is the key to more efficient operation of the vehicle. Should
the safety inspection and lubrication service be performed as described in owner󰿼s manual, your vehicle will always
maintain trouble-free operation and optimum performance.

Dealer󰿼s
Stamp
PRE-DELIVERY INSPECTION
Pre-Delivery
Inspection
I hereby certifty that the vehicle has been delivered in an
orderly and proper operating condition, including a tool-kit,
keys, an owner󰿼s manual and service guide booklet. I also took
notice of the warranty terms as presented in this booklet. The
warranty commencess as of the date of delivery.
Date Owner󰿼s Signature
cut here
O.S. NO.
We hereby certify to have delivered
the vehicle in proper operating
condition.
Performed at
Dealer󰿼s Name :
Signature of Dealer Representative :
Date :
km
Owner󰿼s Name :
Address :
City :
Telephone Number :
License Plate No. :
Model :
Engine Number :
Vehicle Ident. Number :

Record oil brand used
※※Where applicable, adjust if necessary
ENGINE COMPARTMENT
□1. Idling speed-check
□2. Fuel system-check
□3. Drive belt-check
□4. Engine oil levels-check
□5. Power steering fluid levels-check
□6. Brake fluid level & leakage-check
□7. Clutch fluid level & leakage-check
□8. Coolant level & leakage-check
□9. Battery electrolyte level-leakage,
terminal-check
□10. Hose connections-check
□11. Air cleaner-check. Clean
□12. Fuel filter check and water drain
CHASSIS, UNDERBODY
□1. Front suspension-check
□2. Manual transmission leakage-check
□3. Rear axle oil-check
□4. Brake line connection-check
□5. Tire condition, inflation pressure and
wheel nut-check
□6. Brake system-check
BODY, INTERIOR
□1. Lights and signaling device-check
□2. Windshield wipe system-check
□3. Seat mechanism-check
□4. Parking brake-check
□5. Door looks and hinges-check
□6. Power window system-check

DEALER IMPRINT

INTRODUCTION
◆This manual contains the signs like , and when it is related in safety.
Please read and follow these instructions all the time.
This sign describes potentially dangerous situations and if you are not following this instruction, you
can get serious injury and could cause a death.
This sign shows potentially dangerous situations and if you are not following this instruction, it can
cause considerable damages for your vehicle and other properties.
This is an information sign to help for instruction contents or maintenance that is related with
customer’s vehicle.
•We will appreciate for your understanding about the fact that all the information in this manual could be changed
without notice and we would not offer a note or apply this changed situation for delivered vehicle.
•The parts and accessories which are not originated from our company, cannot receive a repair and inspection
services. Safety and suitability are not attested to the none-original parts and accessories, therefore we are not
responsible for damages and injuries from those causes.
•It is recommended that all the customer′s should read and be aware of this manual before using the vehicle.
•This manual is prepared based on LHD(Left Hand Drive) Vehicles. The description pictures may differ with
RHD(Right Hand Drive) Vehicles since their installation Iocations of certain accessories are the opposite of
LHD vehicles, but operation techniques are equal.
REFERENCE
CAUTION
WARNING
REFERENCECAUTIONWARNING

CONTENTS
INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
SAFETY CAUTIONS
DEVICE CONTROL TIPS
START-UP & DRIVING
EMERGENCY AID
VEHICLE INSPECTION AND MAINTENANCE
FAULTY DIAGNOSIS

INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
1
1. VEHICLE SPECIFICATIONS AND SERVICE DATA
Vehicle Specifications (VIN) ⋯⋯⋯⋯⋯⋯⋯⋯ 1-2
Engine Number ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-2
2. INTERIOR & EXTERIOR VIEW OF VEHICLE
Exterior View of Vehilce ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-3
3. SPECIFICATIONS
Vehicle ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-7
Engine⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-9
Chassis Number ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-2
Interior View of Vehicle ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-5
Tire and Wheel ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1-11

INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
The vehicle specifications plate located
at the front of a front door shows the
name and type of the DAEWOO BUS.
As for the vehicle of non step, The
vehicle specifications plate is placed
on the control panel to the left side of a
driver.
The engine number is stamped on the
right side of an engine block.
The chassis number is stamped on the
upper right rear of the chassis frame.
1 - 2
1. VEHICLE SPECIFICATIONS AND SERVICE DATA
Vehicle Specifications (VIN)
OM-F001E
OM-F002
Engine Number Chassis Number
TYPE A
OM-B521
TYPE B
OM-B522

INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
1. Air Conditioner
2. Manual Ventilator
3. Engine Air Intake
4. Side Lamps
5. Luggage Door
6. Entrance Door
7. Outside rearview Mirrors
8. Wiper
9. Side Turn Signal
10. Fog Lamps
11. Headlamps
12. Side Window
13. Engine Room Air Rotation Hole
14. Back Lamp
15. Towing Hook
16. Fuel Inlet
17. Entrance Door lock
18. Door Opening and Shutting Switch
19. Marker Lamps
20. Auto Ventilator
21. Antenna
22. Rear combination Lamps
23. Back Eye Camera
24. Spare Tire Carrier Hole
25. Coolant Injection Door
26. Exhaust Pipe
27. Rear Engine Door
1 - 3
Exterior View of Vehicle
2. INTERIOR & EXTERIOR VIEW OF VEHICLE
※Specs may vary depeding on the type and options.
OM-H206

INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
1 - 4
1. Air Conditioner
2. Manual Ventilator
3. Engine Air Intake
4. Side Lamps
5. Side Door
6. Entrance Door
7. Outside rearview Mirrors
8. Wiper
9. Side Turn Signal
10. Fog Lamps
11. Front Combination Lamps
12. Side Window
13. Engine Room Air Rotation Hole
14. Back Lamp
15. Towing Hook
16. Entrance Door lock
17. Door Opening and Shutting Switch
18. Marker Lamps
19. TV Antenna
20. Radio Antenna
21. Rear combination Lamps
22. Middle Entrance Door
23. Destination Plate
24. Spare Tire Carrier Hole
25. Coolant Injection Door
26. Exhaust Pipe
27. Rear Engine Door
OM-S108

INTERIOR & EXTERIOR VIEW AND SPECIFICATIONS
1 - 5
Interior View of Vehicle
※Specs and locations may vary depeding on the type and options.
OM-H250E
1. Instrument Panel
2. Speedometer
3. Back Eye Camera Monitor / Navigation
4. Mike Holder
5. Audio
6. Switches
7. Tachograph
8. Defroster Control Panel
9. Idle Speed Actuator and Cruise Switch
10. Gearshift
11. Wiper & Exhaust Brake Controls
12. Horn
13. Steering Wheel
14. Turn Signal & Headlamp Controls
15. Parking Brake
16. Clutch Oil Reserve
17. Engine Self-Diagnosis Swicth (Diesel Vehicle)
18. Outside Rearview Mirrors Adjustment
19. Control Panels
20. Power Window /
Luggage Door Lock Switch (BX212)
21. Voltmeter
22. Retarder Brake Lever
23. Power Supply (12V)
24. Engine Diagnostic Switch (Self-Diagnosis)
25. Idle Speed Actuator (CNG Vehicle)
