Daewoo HL510S User manual

Model : HL510S
HL710S
S/M No : OSHL510S01
MAR. 2005
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So,
LCD Monitor

HL510S/HL710S Service Manual
-2-
Contents
HL510S/HL710S..................................................................................................................... 4
PRECAUTIONS................................................................................................. 4
ITEMS ............................................................................................................ 6
HOW TO CONNECT THE SEVERAL CABLES TO THE LCD MONITOR.......................... 7
▶HL510S/HL710S Cable Connections............................................................... 7
ADJUSTING THE MONITOR................................................................................ 8
▶HL510S/HL710S The Function Control Buttons ................................................. 8
▶How to use the function Key. ........................................................................ 8
HL510S/HL710S SPECIRICATIONS........................................................................ 9
▶HL510S Specirications ............................................................................... 9
▶HL710S Specirications ............................................................................. 10
DISPLAY MODES ............................................................................................ 11
DPMS POWER SAVING MODE........................................................................... 11
OSD MENU.................................................................................................... 12
▶Menu Tree............................................................................................ 12
FACTORY SET ................................................................................................ 13
BURN-IN MODE ............................................................................................. 13
INVERTER & POWER ...................................................................................... 14
▶Inverter & POWER(HL510S) ..................................................................... 14
▶Specification ......................................................................................... 14
▶Electrical Characteristics ........................................................................... 14
▶Pin Connection ...................................................................................... 15
▶Inverter & POWER(HL510S) ..................................................................... 15
▶Specification ......................................................................................... 15
▶Electrical Characteristics ........................................................................... 16
▶Pin Connection ...................................................................................... 16
▶Inverter & POWER(HL710S) ..................................................................... 17
▶Specification ......................................................................................... 17
▶Electrical Characteristics ........................................................................... 17
▶Pin Connection ...................................................................................... 18
TROUBLESHOOTING ...................................................................................... 19
▶No operating at all................................................................................... 19
▶Doesn’t display on LCD............................................................................ 20
EXPLODE VIEW ............................................................................................. 22
▶HL510S............................................................................................... 22
▶HL710S............................................................................................... 23

HL510S/HL710S Service Manual
-3-
PART LIST ..................................................................................................... 24
▶HL510S Mechanical Part List ..................................................................... 24
▶HL710S Mechanical Part List ..................................................................... 25
▶HL510S AD B/D Part List ......................................................................... 26
▶HL510S FUNCTION B/D Part List .............................................................. 29
▶HL710S AD B/D Part List ......................................................................... 30
▶HL710S FUNCTION B/D Part List .............................................................. 33
▶Inverter & POWER BD Part List(SHI1520WY)................................................ 34
▶Inverter & POWER BD Part List(FLF1521-04A) .............................................. 37
▶Inverter & POWER BD Part List(FLF1742-04A) .............................................. 39
CIRCUIT DIAGRAM ........................................................................................ 41
▶AD B/D(HL510S)................................................................................... 41
▶FUNCTION B/D(HL510S) ........................................................................ 46
▶AD B/D(HL710S)................................................................................... 47
▶FUNCTION B/D(HL710S) ........................................................................ 51
▶Inverter & POWER B/D(SHI1520WY).......................................................... 52
▶Inverter & POWER B/D(FLF1521-04A) ........................................................ 54
▶Inverter & POWER B/D(FLF1742-04A) ........................................................ 56
PCB Layout .................................................................................................... 58
▶AD B/D TOP SILK (HL510S) .................................................................... 58
▶AD B/D TOP PATTERN (HL510S) .............................................................. 59
▶AD B/D BOTTOM SILK (HL510S) ............................................................. 60
▶AD B/D MASK TOP (HL510S)................................................................... 61
▶AD B/D MASK BOTTOM (HL510S) ........................................................... 62
▶FUNC B/D TOP SILK (HL510S) ................................................................. 63
▶FUNC B/D BOTTOM PATTERN (HL510S).................................................... 63
▶AD B/D TOP SILK (HL710S) .................................................................... 64
▶AD B/D TOP PATTERN (HL710S) .............................................................. 65
▶AD B/D BOTTOM SILK (HL710S) ............................................................. 66
▶AD B/D MASK TOP (HL710S)................................................................... 67
▶AD B/D MASK BOTTOM (HL710S) ........................................................... 68
▶FUNC B/D TOP SILK (HL710S) ................................................................. 69
▶FUNC B/D BOTTOM PATTERN (HL710S).................................................... 69

HL510S/HL710S Service Manual
-4-
HL510S/HL710S
PRECAUTIONS
zPlug the power cord into a properly grounded outlet.
There is the risk of electric shock.
zIf you hear a noise or smell smoke from the computer or adaptor, unplug the power cord
immediately, and call the service center.
There is the risk of electric shock or fire.
zDo not overload an electrical outlet with too many devices.
There is the risk of fire.
zDo not unplug from the outlet by pulling the power cord or when your hands are wet.
There is the risk of electric shock or fire.
zDo not bend the power cord excessively or place heavy objects on it. Keep children and pets
away from the power cord as they may damage the power cord. There is the risk of electric
shock or fire.
zDo not use a damaged power cord or plug. Make sure the plug fits snugly into the outlet.
There is the risk of electric shock or fire.
zDo not expose the monitor to the direct sun light.
zDo not block the fan louvers.
There is the risk of fire or damage to the monitor.
zDo not attempt to disassemble, fix, or modify the monitor.
There is the risk of electric shock or fire.
zKeep the monitor away from high temperature, humidity, and dust.
Operating environment = 0 ~ 40 Degrees Celsius
Operating environment = 30 ~ 80 Relative Humidity
zDo not allow any object or liquid to enter inside the monitor.
There is the risk of electric shock, fire, or damage to the monitor.

HL510S/HL710S Service Manual
-5-
zUse a proper voltage/current level indicated.
zDo not clean the LCD with abrasive chemicals.
There is the risk of damage to the LCD.
zDo not scratch and damage the LCD with sharp objects.
zKeep the monitor away from objects and electrical appliances that may generate
electromagnetic fields.
zPlace the monitor on a flat, stable surface.
The monitor may fall and there is the risk of damage or injury.
zUnplug the power cord when the monitor is not in use for a prolonged period of time.
zMake sure the power cord is unplugged.
zDo not spill or pour liquid on the monitor.
zCleaning the LCD panel
1. Use a clean, soft cloth to wipe off dust from the LCD.
2. If still not clean, wipe the LCD with a clean soft cloth with a small amount of glass cleaner
without alcohol or ammonia.
zCaution
Do not use alcohol or ammonia based cleaning products. Abrasive chemicals, such as alcohol or
ammonia, may damage the monitor. The company is not responsible for the damages to the monitor
caused by the use of alcohol or ammonia based cleaning products.

HL510S/HL710S Service Manual
-6-
ITEMS

HL510S/HL710S Service Manual
-7-
HOW TO CONNECT THE SEVERAL CABLES TO THE LCD
MONITOR
▶HL510S/HL710S Cable Connections
POWER PC
Name Cable connections
1 POWERCORD
2 15-PIN D-SUB SIGNAL CABLE

HL510S/HL710S Service Manual
-8-
ADJUSTING THE MONITOR
▶HL510S/HL710S The Function Control Buttons
▶How to use the function Key.
Button Function
1. First click : The OSD main menu appears.
2. Second click : The OSD main menu disappears.
1. Select a command function.
2. When you push Auto button,this will optimize quality automati-
cally..
Down : 1. Automatic adjust color(white level) for various input source’s
white level.
2. Move the on-screen highlighted command item to the next one.
3. Decrease the current value.
UP : 1.Move the on-screen highlighted command item to the Previous one.
2.Increase the current option value.
Power On/Off toggle button.

HL510S/HL710S Service Manual
-9-
HL510S/HL710S SPECIRICATIONS
▶HL510S Specirications
Panel Specification
Panel Type HSD150SX84 or other
Panel Dimension 321.0 (H) x 249.0 (V) x 9.9(D) mm
Panel Weight 950g (max)
Screen diagonal 15.0 inches [304.1 (H) x 228.1 (V)mm]
Pixel pitch 0.297mm x 0.297mm
Pixel format 1024(horizontal) x 768 (Vertical) Pixels
RGB stripe arrangement
Color depth 8bit (16,777,216 colors)
Right 65(Typ.)
H
Left 65(Typ.)
Up 45(Typ.)
Viewing angle (Deg)
V
Down 55(Typ.)
Response Time 25 ms
Contrast ratio 400 : 1(typ.)
Average brightness 250 cd/m2(typ.)
Cross talk Hori.:1.3%(Max.), Vert.:1.3%(Max.)
Vertical Sync (Frame
rate)
60Hz(typ.), 75Hz(Max)
Horizontal Sync 31.5 ~ 60KHz
Dclk 32.5MHz(Odd/Even)
Electrical Interface TTL
Monitor’s specification
Resolution Recommend: 1024x768@60Hz
Max. : 1024x768@75Hz
Frequency Horizontal: 31.5 ~ 60 KHz
Vertical : 56 ~ 75 Hz
Sync. Signal TTL, P. or N.
OSD Control Power,Menu,Select/Auto,Down,Up

HL510S/HL710S Service Manual
-10-
▶HL710S Specirications
Panel Specification
Panel Type HT17E13-100 or other
Panel Dimension 358.5 (H) x 296.5 (V) x 17.0(D) mm typ.
Screen diagonal 17.0 inches [337.92 (H) x 270.336 (V)mm
Pixel pitch 0.264mm x 0.264mm
Pixel format 1280(horizontal) x 1024 (Vertical) Pixels
RGB stripe arrangement
Color depth 8bit (16,777,216 colors)
Right 80(Typ.)
H
Left 80(Typ.)
Up 65(Typ.)
Viewing angle (Deg)
V
Down 65(Typ.)
Response Time 16 ms
Contrast ratio 500 : 1(typ.)
Average brightness 300 cd/m2(typ.)
Cross talk Horizontal:2.0%(Max.), Vertical:2.0%(Max.)
Vertical Sync (Frame
rate)
60Hz(typ.), 75Hz(Max)
Horizontal Sync 31 ~ 80KHz
Dclk 54MHz(Typ.),68MHz(Max.)
Electrical Interface LVDS
Monitor’s specification
Resolution Recommend: 1280x1024@60Hz
Max. : 1280x1024@75Hz
Frequency Horizontal: 31.5 ~ 80 KHz
Vertical : 56 ~ 75 Hz
Sync. Signal TTL, P. or N.
OSD Control Power,Menu,Select/Auto,Down,Up
