Service Manual
Color Television
CHASSIS :
Model :
CM-500/500F
DTU-29M5ME/MP/MT/MZ
DTU-29M6ME/MP/MT/MZ
DTU-29M7ME/MP/MT/MZ
DTU-29U1ME/MP/MT/MZ
DTU-29U5ME/MP/MT/MZ
DTU-29U8ME/MP/MT/MZ
DTU-29F1ME/MP/MT/MZ
DTU-29F2ME/MP/MT/MZ
DTU-29F3ME/MP/MT/MZ
S/G No.:TCM500FEF0
JULY. 2005
MODEL OPTION LIST
MODEL TEXT PIP
ME O O
MP X O
MT O X
MZ X X

-1-
1. SPECIFICATIONS 2
2. SAFETY INSTRUCTION 3
3. CIRCUIT BLOCK DIAGRAM 4
4. ALIGNMENT INSTRUCTIONS 5
5. CM-500/F TYPICAL SERVICE DATA 15
6. ELECTRICAL PARTS LIST 16
7. EACH MODEL PARTS LIST 24
8. SCHEMATIC DIAGRAM 25
9. PRINTED CIRCUIT BOARD 26
10. MECHANICAL EXPLODED VIEW AND PARTS LIST 29
11. IC DESCRIPTION 38
12. TROUBLE SHOOTING GUIDE 68
TABLE OF CONTENTS
APPENDIX(Appendix is provide only by internet[http://svc.dwe.co.kr])

-2-
1. SPECIFICATIONS
Items Model DTU-29M5ME/MP/MT/MZ
DTU-29M6ME/MP/MT/MZ
DTU-29M7ME/MP/MT/MZ
DTU-29U1ME/MP/MT/MZ
DTU-29U5ME/MP/MT/MZ
DTU-29U8ME/MP/MT/MZ
DTU-29F1ME/MP/MT/MZ
DTU-29F2ME/MP/MT/MZ
DTU-29F3ME/MP/MT/MZ
TV Standard Color system PAL/SECAM, NTSC-4.43(AV)
Sound system B/G, D/K, I, H
Rated Voltage AC 110-250V, 50/60Hz
Power consumption 73W(FLAT:110W)
Sound Output Power 7W+7W (FLAT:7.5W + 7.5W at EQUILIZER CENTER)
Channel Conerage VHF BAND I : CH 02 ~ CH04(48.25MHz ~ 62.25MHz)
BAND II : CH05 ~ CH12(175.25MHz ~ 224.25MHz)
CABLE BAND : S01 ~ S03, (69.25MHz ~ 83.25MHz)
S01~S20,(105,25MHz~294.25MHz)
HYPER BAND : S21~S41(303.25 ~ 463.25MHz)
UHF BAND IV, V : CH21 ~ CH69(471.25MHz ~ 855.25MHz)
Tuning System FS Tuning System
Program No. Indication ON-Screen Display
Program Selection 200 Programs
Aux. Terminal AV1 input <RCA : input, Scart(Option): input, Output>
AV2 input <SIDE> (Model for 29U8 Seriese: FRONT)
DVD1, DVD2
OUTPUT<OPTION:TV OUT or Monitor OUT>
Remote Control Unit R-49C07
Screen size 67.6Cm

-3-
2 SAFETY INSTRUCTION
2 SAFETY INSTRUCTION
NOTE : BEFORE SERVICING THIS CHASSIS READ THE “X-RAY RADIATION PRECAUTIONS”,
“SAFETY PRECAUTIONS” AND “PRODUCT SAFETY NOTICE” BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid
such hazards, the high voltage must not exceed the specified limit. The nominal value of the
high voltage of this receiver is 25.6KV [Normal Type](27.9KV [Flat Type]) at max beam
current. The high voltage must not, under any circumstances, exceed 28.6KV [Normal Type]
(30.9KV [Flat Type]). Each time a receiver requires servicing, the high voltage should be
checked. It is important to use an accurate and reliable high voltage meter.
2. The only source of X-RAY Radiation in this TV receiver is the picture tube. For continued X-
RAY RADIATION protection, the replacement tube must be exactly the same type tube as
specified in the parts list.
SAFETY PRECAUTION
1. Potentials of high voltage are present when this receiver is operating. Operation of the
receiver outside the cabinet or with the back cover removed involves a shock hazard from
the receiver.
1) Servicing should not be attempted by anyone who is not thoroughly familiar with the
precautions necessary when working on high voltage equipment.
2) Always discharge the picture tube to avoid the shock harzard before removing the anode
cap.
3) Discharge the high potential of the picture tube before handling the tube. The picture tube is
highly evacuated and if broken, glass fragments will be violently expelled.
2. If any Fuse in this TV receiver is blown, replace it with the FUSE specified in the
Replacement Parts List.
3. When replacing a high wattage resistor (metal oxide film resistor) in the circuit board, keep
the resistor 10 mm away from circuit board.
4. Keep wires away from high voltage or high temperature components.
5. This receiver must operate between AC 110-250 volts, 50/60Hz. NEVER connect to DC
supply or any other power or frequency.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this equipment have special safety-related
characteristics. These characteristics are often passed unnoticed by a visual inspection and the
X-RAY RADIATION protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have
these special safety characteristics are identified in this manual and its supplements, electrical
components having such features are identified by designated symbol ‘ ’ on the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use
of substitutes replacement parts which do not have the same safety characteristics as specified
in the parts list may create X-RAY Radiation.
1

-4-
3.CIRCUIT BLOCK DIAGRAM

-5-
4. ALIGNMENT INSTRUCTIONS
DOCUMENT HISTORY
VERSION DATE COMMENTS
V0.00 26/10/04 Document imported from project Cp520(Author J.D.Santos)
V1.00 12/11/04 Major revision after visit in Gunpo RND
V1.01 25/11/04 Tuner option revision(Byte1, bite2,1,0)
V1.02 29/11/04 Curtain beep option added(Byte3, bits1)
Curtain ON/OFF bit setting corrected
V1.03 02/12/04 Local key option bit changed.
Digital eye levels added
V1.04 17/12/04 Local keyboard option 01 changed
V1.05 20/01/05 AV stereo and Koran options added
V1.06 16/02/05 Default setting in case of virgin EEPROM changed

-6-
ALIGNMENT INSTRUCTIONS
4.1MICROCONTROLLER CONFIGURATION : SERVICE MODE
To switch the TV set into service mode please see instruction below.
1 - Select PR. number 91
2 - Adjust sharpness to minimum and exit all menus.
3 - Within 2 seconds press the key sequence : RED - GREEN - menu
The software version is displayed beside the word Service, e.g. “SERVICE V1.00”.
To exit SERVICE menu press menu key or Stand By key.
4.2 SERVICE MODE NAVIGATION
Pr Up/Down remote keys : cycle through the service items available.
Vol -/+ remote keys : Dec./Increment the values within range - Cycle trough option bits.
OK key : Toggle bits in option byte
Order Item Default setting
1 HOR CEN
2 RED GAIN
3 GRN GAIN
4 BLUE GAIN
5 RED BIAS
6 GRN BIAS
7 AGC LEVEL
8 G2 - SCREEN
9 OPTION1
10 OPTION2
11 OPTION3
12 V. LINEAR
13 V. SLOPE
14 S. CORRECT
15 VERT CENT
16 VERT SIZE
17 BRIGHINESS
18 SHIPPING

-7-
ALIGNMENT INSTRUCTIONS
4.3.1 OPTION1
B7 B6 B5 B4 B3 B2 B1 B0
1
0
TOP
Teletext
OFF
FASTEXT
(FLOF)
OFF TUBE
4:3 Dolby
Virtual
OFF
Teletext
ON TUNER OPTIONS
(see table below)
TOP
Teletext
ON
FASTEXT
(FLOF)
ON TUBE
16:9 Dolby
Virtual
ON
Teletext
OFF
4.3.2 OPTION2
B7 B6 B5 B4 B3 B2 B1 B0
1
0
NEC
remote
control AV out:
monitor
AV out:
Tuner
Koran
functions
enabled
Digital
eye
disabled
Digital
eye
enabled
PARS
logo
OFF
ON
Daewoo
Remote
control
Koran
functions
enabled
1 CONTROL BITS
There are two option bytes available (16 bits in all). These option bits are available from
FACTORY and SERVICE mode. First find the OPTION1, OPTION2 or OPTION3 control, and
then use the UP/DOWN and PLUS/MINUS keys on the relevant remote keypad to control the
bits.
The table below shows the three option bytes available.
Default setting in case of virgin EEPROM are shown in light grey.
Fixed to
‘0’Local key option
(see table below)
4.3.3 OPTION3
B7 B6 B5 B4 B3 B2 B1 B0
1
0
Beep at
curtain
opening:
OFF
PIP
OFF
PIP
ON
Chassis
with E/W
correction
circuit
Chassis
with out
E/W
correction
circuit
Beep at
curtain
opening:
ON
Full
stereo
AV
Stereo
only
Curtain
OFF
Curtain
On
Teletext language table

-8-
ALIGNMENT INSTRUCTIONS
4.4 USER GUIDE
4.4.1 ENTERING FACTORY MODE
To switch the TV set into FACTORY mode, use the factory remote control, and press on “SVC”.
The factory menu will appear on the screen, showing “FACTORY Vx,xx”(where x.xx is the
software version).
4.4.2 ENTERING OPTION BITS MENU
To find the option bits, push the button “OPT”once. To find OPTION2 press the button “OPT”a
second time.
4.4.3 SELECTING OPTION BITS
From left to right, bits 7 to 0 are shown. Navigation is done from the with FACTORY remocon
with the VOL MIN and VOL MAX buttons(otherwise known as EAST, WEST). The selected bit is
highlighted.
4.4.4 TOGGLING OPTION BITS
This is done by using the PR UP and PR DOWN button (otherwise known as NORTH,
SOUTH).
4.4.5 EXTING OPTION BITS MENU
Push the button “OPT”a third time. The full sequence enter to exit is;
FACTORY -> OPTION1 -> OPTION2 -> OPTION3 -> FACTORY
4.4.6 AFTER SETTING OPTION BITS
Before pushing on the shipping key, “BRI.”, it is necessary to push the “NORMAL”key to obtain
NORMAL I. This will reset all the sound and brightness settings to a factory defined level, as
well as some other settings such as sound PRESET and WAKE TIME/PROG.
Then, on pushing the shipping key, thess levels are memorised in the television, ready for
packing and delivery.
4.4.7 VERIFICATION
On pushing the shipping “BRI.”key, a four digit hexadecimal number is displayed in addition to
“SHIPPING”. This number is there to verify the option bits setting that has been entered. For
example the binary code 1001 1111(OPTION3) 0000 0111(OPTION2) 1100 0010(OPTION1)
will give 9F 07 C2 hex. The order of display is therefore OPTION3, OPTION2 then OPTION1
when reading from left to right.

-9-
ALIGNMENT INSTRUCTIONS
4.5 CONTROL DESCRIPTION
4.5.1 OPTION 1 BITS
- TOP Teletext(Bit 7)
Enables/disables the TV from displaying TOP row 24 link titles, and the dedicated TOP menu
table. A FLOF (if available) or SIMPLE / PAGETRACE presentation will be used.
- FLOF/Fastext (Bit 6)
Enables/disables the TV from displaying FLOF row 24 link titles. A TOP(if available) or
SIMPLE/PAGETRACE presentation will be used.
- Tube(Bit 5)
Define as 4:3 or16:9 tube. This will permit the ZOOM function to understand the formats that
should be available.
- Teletext ON/OFF(Bit 4)
Enables/disables the Teletext on TV. If Teletext is disabled, user can not select clock prog and
zoom selection in features menu. WSS is also disabled.
- Dolby Virtual(Bit 3)
Allows Doby Virtual (trademark) 3D effect to be available from the user control(button “3D”).
Note : Dolby Virtual is only available with some UOC reference.
- Tuner(Bits 2,1 & 0)
Configures the software to communicate with the tuner via i2c bus. Incorrect configuration may
not be immediately obvious, but will result in loss of functionality (e.g. unable to tune UHF
channels, unable to tune some hyperband channels).
See also NVM mapping to configure parameters for automatic AGC adjustment when external
AGC is used. When internal AGC is used, the TOP is stored in NVM.
Bit2 Bit1 Bit0 LAN Tuner
0 0 0 No Philips (external AGC)
0 0 1 No Philips (internal AGC)
0 1 0 No Alps
0 1 1 No Partsnic or Samsung
1 0 0 Yes Philips UV1356A MK3 (external AGC)
1 0 1 Yes Philips UV1356A MK3 (internal AGC)

-10-
ALIGNMENT INSTRUCTIONS
4.5.2 OPTION 2 BITS
- Remote control(Bit 7)
This is not intended to be changed by use of the FACTORY remote control.
- NEC/Daewoo Remocon(Bit 6)
User remote control configuration, the choise being between the following;
- NEC remocon(‘1’)
- Daewoo R-49C07(‘0’)
The R-30SVC7 “FACTORY”remote control will never be affected by this setting.
- Local keyboard option (Bit 3 & 2)
- Digital eye ON/OFF(Bit 1)
Enables/disables the digital eye function.
When enabled and selected, the microcontroller measures DC level on IC pin 15, and adjusts
picture setting according to the table below.
- PARS Logo ON/OFF(Bit 0)
Enables/disables the display of PARS logo at power on.
4.5.3 OPTION 3 BITS
- Curtain function at power ON(Bit 7)
Enables/disables the curtain function at power ON. The frequency and volume of associated
beep sound is controlled by NVM data.
11 10 01 00
0 mV ~ 220 mV Not used Menu Menu
22 mV ~ 620 mV (TV/AV) Menu TV/AV Prog. Up
620 mV ~ 1.06 V Vol. Up Vol. Dwn Prog. Dwn Not used
1.06 V ~ 1.48 V Vol. Dwn Vol. Up Vol. Up
1.48 V ~ 1.79 V Prog.Up Prog. Dwn Vol. Dwn
1.79 V ~ 2.07 V Prog.Dwn Prog. Up TV/AV
Brightness Contast Colour Sharpness
0 mV ~ 450 mV 18 30 28 27
450 mV ~ 900 mV 28 46 28 29
900 mV ~ 1.35 V 30 50 29 30
1.35 V ~ 1.80 V 32 55 30 31
1.80 V ~ 2.25 V 34 60 31 32
2.25 V ~ 2.70 V 36 63 32 33

Teletext table C12 C13 C14 Basic Char.Set Twist Char.Set NOT EW
Latin West 0 0 0 Latin Latin English West
0 0 1 Latin Latin German West
0 1 0 Latin Latin Swedish/Fin West
0 1 1 Latin Latin Italian West
1 0 0 Latin Latin French West
1 0 0 Latin Latin Spanish/Portuguese West
1 1 0 Latin Latin Turkish West
1 1 1 Latin Latin English West
Latin East 0 0 0 Latin Latin Polish East
0 0 1 Latin Latin German East
0 1 0 Latin Latin Estontan East
0 1 1 Latin Latin German East
1 0 0 Latin Latin German East
1 0 1 Latin Latin Slovenian East
1 1 0 Latin Latin Czech/Slovak East
1 1 1 Latin Latin Rumanian East
Russian 0 0 0 Latin Latin English West
0 0 1 Latin Latin German West
0 1 0 Latin Latin Estonian East
0 1 1 Latin Latin German East
1 0 0 Cyrillic Latin Russia East
1 0 1 Cyrillic Latin Ukrainian East
1 1 0 Latin Latin Czech/Slovak East
1 1 1 Latin Latin Rumanian East
Arabic/ 0 0 0 Latin Latin English West
Persian 0 0 1 Latin Latin German West
0 1 0 Latin Latin Swedish/Fin West
0 1 1 Latin Latin Italian West
1 0 0 Latin Latin French West
1 0 1 Latin Latin Spanish/Portuguese West
1 1 0 Latin Latin Turkish West
1 1 1 Arabic Latin Arabic West
-11-
ALIGNMENT INSTRUCTIONS
- Teletext language option(Bit 6, 5&4)
Teletext National Option table for each language option:
Bit6, 5&4
Latin West 000
Latin East 001
Russia 010
Persia 011
Arabic 100
Not used 101
..
Not used 111
- East/West correction (Bit 3)
You must enable this bit for large screen CRT which need EAST WEST correction circuitry.
- PIP(Bit 2)
Enable disable PIP function. Make sure PIP board is inserted in the main board.
- Beep at curtain opening(Bit 1)
Enable/disable beep sound at power ON.

-12-
ALIGNMENT INSTRUCTIONS
4.5.4 TV SET ALIGNMENT
(1) G2 ALIGNMENT
- Tune a colour bar pattern.
- Fine the “G2-SCREEN”item in service mode.
- Adjust screen volume(on FBT) to make the horizontal line just before disappeared.
(2) WHITE BALANCE
- Select a dark picture and adjust RED BIAS and GRN BIAS to the desired colour temperature.
- Select a bright picture and adjust RED, GRN and BLUE GAIN to the desired colour temperature.
(3) FOCUS
Adjust the Focus volume ( on FBT ) to have the best resolution on screen.
(4) VERTICAL GEOMETRY
Adjust V. LINEAR (linearity), S CORRECT (S. Correction), VERT SIZE (Vertical amplitude), VERT CENT (vertical
centring) to compensate for vertical distortion.
(5) HORIZONTAL PICTURE CENTRING
Adjust HOR CEN (Horizontal centre) to have the picture in the centre of the screen.
(6) EAST / WEST CORRECTION
Adjust the PARABOLA, HOR WIDTH, CORNER, HOR PARAL, EW TRAPEZ, to compensate for geometrical
distortion.
HOR PARAL

-13-
ALIGNMENT INSTRUCTIONS
HOR WIDTH
adjust for 90% overscan.
PARABOLA
CORNER B & CORNER T
EW TRAPEZ
3.7.7 AGC
- Make sure option bits are correct for the tuner fitted on the chassis (See above how to change option bits).
- Adjust the antenna signal level at 62 dB V± 2
- Tune a colour bar pattern.
- Find the “ AGC LEVEL ” item in service mode.
- Press the key “ OK ” on the remote keypad and wait until AGC level stabilise to the optimum value.
- Alternatively, use “ Vol Up/Dwn ” keys to adjust manually to the desired Tuner Take Over Point (TOP).

-14-
ALIGNMENT INSTRUCTIONS
Remote control
TV MODE
POWER
SOUND MUTE
NUMBER 0..9
TV / AV
NORMAL
RECALL
MENU
PROGRAM UP (CURSOR UP)
VOLUME DOWN (CURSOR LEFT)
VOLUME UP (CURSOR RIGHT)
PROGRAM DOWN (CURSOR
DOWN)
MODE
OK / PRESET
PIP ON
PIP PICTURE SWAP
PIP POSITION
PIP PICTURE SOURCE
TV TELETEXT
PIP PICTURE SIZE
SLEEP
ZOOM
3D (SOUND EFFECT)
TELETEXT MODE
POWER
SOUND MUTE
NUMBER 0..9
VOL/BRIGHT MENU SELECTION
PAGE UP
VOL / BRIGHT DOWN
VOL / BRIGHT UP
PAGE DOWN
INDEX
RED
GREEN
YELLOW
CYAN
CANCEL
PAGE HOLD
TELETEXT TV
REVEAL
SUBPAGE
HEIGHT

-15-
5. CM-500/F TYPICAL SERVICE DATA

-16-
6. ELECTRICAL PARTS LIST
ZZ100 48B5849C07 TRANSMITTER REMOCON R-49C07 (AAA)
ZZ110 PTACPWE135 ACCESSORY AS DTU-29M5ME
30 4850Q00910 BATTERY R03/NN
200 48586054K1 MANUAL INSTRUCTION DTM-2082CW
M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20)
ZZ120 PTBCSHE135 COVER BACK AS DTU-29M5ME
M211 4852161121 COVER BACK HIPS GY
M781 4857817630 CLOTH BLACK FELT 400X20X0.7
ZZ130 PTPKCPE135 PACKING AS DTU-29M5ME
10 6520010100 STAPLE PIN AUTO W65
M801 4858057600 BOX CARTON DW-3
M811 4858199100 PAD EPS 29M5
M821 4858215601 BAG P.E PE FOAM t0.5x1600x1270
ZZ131 48519A7810 CRT GROUND NET 2903S-1015-1P
ZZ132 58G0000182 COIL DEGAUSSING DC-29SF AL
ZZ140 PTCACAE135 CABINET AS DTU-29M5ME
M201A 4856017350 SCREW CRT FIX 6X27 L120 BK
M201B 4856215402 WASHER RUBBER CR T2.0
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211B 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M211C 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M231A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
M541 4855419800 SPEC PLATE ART 150
M682 4856816300 CLAMP WIRE NYLON 6 (V0)
M683 4856812001 TIE CABLE NYLON66 DA100
SP01A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
SP02A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
V901 4859646261 CRT A68KTB359X001(P) P38
ZZ200 PTFMSJE135 MASK FRONT AS DTU-29M5ME
M201 4852079701 MASK FRONT HIPS GY
M231A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M561 48556293SD MARK BRAND SILVER DIA-CUTTING
M781 4857821102 CLOTH BLACK FELT 340X10X1.5
ZZ205 PTPCSWJ912 PANEL CONTROL AS DTQ-29M5
M191 4851945700 BUTTON CTRL 4951401+5545800
M191A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M231 4852328201 PANEL DECO ABS GY
M481 4854861401 BUTTON POWER ABS GY
M481A 4856716000 SPRING SWPA PIE0.5
M591 4855933401 DECO EYE ABS BLUE
M591A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
ZZ210 PTSPPWD703 SPEAKER AS DTC-29M5ME
P601A 4850704S32 CONNECTOR YH025-04+YRT205+ULW=900
SP01 4858311110 SPEAKER 12W 8 OHM SP-58126F
SP02 4858311110 SPEAKER 12W 8 OHM SP-58126F
ZZ290 PTMPMSE135 PCB MAIN MANUAL AS DTU-29M5ME
C310 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
C405 CMYH3C103J C MYLAR 1.6KV BUP 0.01MF J
C406 CMYH3C912J C MYLAR 1.6KV BUP 9100PF J
C408 CMYE2D624J C MYLAR 200V PU 0.62MF J
C424 CEYF2A471V C ELECTRO 100V RSS 470MF (16X31.5)
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C811 CH1BFE222M C CERA AC U/C/V AC400V 2200PF
C817 CEYF2C221V C ELECTRO 160V RSS 220MF (18X35.5)
C821 CEYF1E222V C ELECTRO 25V RSS 2200MF (16X25)
C850 CEYD2G221D C ELECTRO 400V FHS 220MF (25X40)
D402 DRGP30J—- DIODE RGP30J DO-201AD 600V 3A
D403 DDGP30L—- DIODE DGP30L
D812 DRGP30J—- DIODE RGP30J DO-201AD 600V 3A
D814 DSR306E20- DIODE SR306E20
DF01 DLH2PR—— LED BLOCK LH-2P-R
F801 5F3GB6322L FUSE GLASS TUBE V/S TL 6.3A 250V MF51
H01 485A101880 WIRE 1007AWG26=100
H02 485A101980 WIRE 1007AWG26=180
I301 PTC2SW8227 HEAT SINK ASS`Y 1TDA8358J- + 7174301011
11TDA8358J-IC VERTICAL TDA8358J
0000A 4857028227 HEAT SINK AL EX BK
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
LOC PART CODE PART NAME DESCRIPTION REMARK
I601 PTA2SW8232 HEAT SINK ASS`Y 1LA42152-E + 7174301011
11LA42152-EIC AUDIO AMP LA42152-E
0000A 4857028232 HEAT SINK AL EX BK
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I701 1DA12072PQ IC TDA12072PQ/N1D
I702 124LC16B1B IC MEMORY 24LC16B1B
I801 PTA2SW7924 HEAT SINK ASS`Y 1STRW6756- + 7174300811
11STRW6756- IC POWER STR-W6756
0000A 4857027924 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I802 1LTV817C—IC PHOTO COUPLER LTV-817C
I804 PTT2SW6902 HEAT SINK ASS`Y 1LD1117V33 + 7174300811
11LD1117V33 IC REGULATOR LD1117AV33 3.3V 2% TO-220
0000A 4857026902 HEAT SINK AL EX BK
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I805 PTJ2SW7802 HEAT SINK ASS`Y 1K78R05—- + 7174300811
11K78R05—-IC REGULATOR KIA78R05API
0000A 4857027802 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
IF01 1346VF6—- IC PREAMP 346VF6
JPA01 4859110950 JACK PIN BOARD YS01-0001
JPA02 4859111750 JACK PIN BOARD PH-JB-9515
L301 58C7070085 COIL CHOKE TLN-3062A
L401 58H0000066 COIL H-LINEARITY TRL-230D
LF801 5PLF28A1—FILTER LINE LF-28A1
M687 4853747800 RETA PCB NYLON 66
PW801 4859903110 CORD POWER AS KKP-419J-H03VVH2+H0U=2200
A000 4859903511 CORD POWER CW4232 H03VVH2-F=2250
Q401 PTG2SW7609 HEAT SINK ASS`Y TST2009DH1 + 7174300811
1TST2009DH1 TR HORI ST2009DHI
0000A 4857027609 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q402 TKTC3229—TR KTC3229
R801 DDC7R0M290 POSISTOR ECPCD7R0M290
R803 RX10T339JS R CEMENT 10W 3.3 OHM J TRIPOD SMALL
SW801 5S40101143 SW POWER PUSH PS3-22SP (P.C.B)
T401 50H0000294 FBT LTC-432
T402 5TD0000018 TRANS DRIVE THD-120
T801 50M4445B9- TRANS SMPS TSM-4445B9
TU01 4859724930 TUNER VARACTOR UV1316/A I-4
X701 5XJ24R576E CRYSTAL QUARTZ HC-49/S 24.576MHZ 30PPM
Z701 5PK3953M—FILTER SAW K3953M
Z702 5PK9650M—FILTER SAW K9650M
ZZ200 PTMPJ0E135 PCB MAIN (RHU) AS DTU-29M5ME
C407 CMXE2G273J C MYLAR 400V PU 0.027MF J (TP)
C409 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C421 CCXB3D681K C CERA 2KV B 680PF K (TAPPING)
C422 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C423 CMXE2J472J C MYLAR 630V PU 4700PF J (TP)
C427 CEXF1E471V C ELECTRO 25V 470MF 10X12.5
C613 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C803 CCXB3A472K C CERA 1KV B 4700PF K (TAPPING)
C804 CCXB3A472K C CERA 1KV B 4700PF K (TAPPING)
C806 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C813 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C818 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C820 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP
C824 CMXB2G122J C MYLAR 400V EU 1200PF J
C835 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C838 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
ZZ200 PTMPJBE135 PCB MAIN M-10 AS DTU-29M5ME
10 2TM18006BE TAPE MASKING 6.2X500
E001 4856310300 EYE LET BSR T0.2 (R1.6)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310300 EYE LET BSR T0.2 (R1.6)
E004 4856310300 EYE LET BSR T0.2 (R1.6)
E005 4856310600 EYE LET BSR T0.2 (R2.3)
E006 4856310600 EYE LET BSR T0.2 (R2.3)
LOC PART CODE PART NAME DESCRIPTION REMARK

-17-
ELECTRICAL PARTS LIST
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E008 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310300 EYE LET BSR T0.2 (R1.6)
E011 4856310600 EYE LET BSR T0.2 (R2.3)
E012 4856310600 EYE LET BSR T0.2 (R2.3)
E013 4856310600 EYE LET BSR T0.2 (R2.3)
E014 4856310600 EYE LET BSR T0.2 (R2.3)
E018 4856310300 EYE LET BSR T0.2 (R1.6)
E019 4856310300 EYE LET BSR T0.2 (R1.6)
E020 4856310300 EYE LET BSR T0.2 (R1.6)
E021 4856310300 EYE LET BSR T0.2 (R1.6)
E022 4856310600 EYE LET BSR T0.2 (R2.3)
E023 4856310600 EYE LET BSR T0.2 (R2.3)
E024 4856310600 EYE LET BSR T0.2 (R2.3)
E025 4856310600 EYE LET BSR T0.2 (R2.3)
E026 4856310300 EYE LET BSR T0.2 (R1.6)
E027 4856310300 EYE LET BSR T0.2 (R1.6)
E028 4856310300 EYE LET BSR T0.2 (R1.6)
E029 4856310300 EYE LET BSR T0.2 (R1.6)
E030 4856310300 EYE LET BSR T0.2 (R1.6)
E031 4856310600 EYE LET BSR T0.2 (R2.3)
E032 4856310600 EYE LET BSR T0.2 (R2.3)
E033 4856310300 EYE LET BSR T0.2 (R1.6)
E034 4856310300 EYE LET BSR T0.2 (R1.6)
E035 4856310300 EYE LET BSR T0.2 (R1.6)
E036 4856310600 EYE LET BSR T0.2 (R2.3)
E037 4856310600 EYE LET BSR T0.2 (R2.3)
E038 4856310600 EYE LET BSR T0.2 (R2.3)
E039 4856310600 EYE LET BSR T0.2 (R2.3)
E040 4856310300 EYE LET BSR T0.2 (R1.6)
E042 4856310300 EYE LET BSR T0.2 (R1.6)
E043 4856310600 EYE LET BSR T0.2 (R2.3)
E044 4856310600 EYE LET BSR T0.2 (R2.3)
E045 4856310600 EYE LET BSR T0.2 (R2.3)
E046 4856310600 EYE LET BSR T0.2 (R2.3)
E047 4856310600 EYE LET BSR T0.2 (R2.3)
E048 4856310300 EYE LET BSR T0.2 (R1.6)
E049 4856310300 EYE LET BSR T0.2 (R1.6)
E050 4856310600 EYE LET BSR T0.2 (R2.3)
E051 4856310600 EYE LET BSR T0.2 (R2.3)
E059 4856310600 EYE LET BSR T0.2 (R2.3)
E060 4856310600 EYE LET BSR T0.2 (R2.3)
E065 4856310600 EYE LET BSR T0.2 (R2.3)
E066 4856310600 EYE LET BSR T0.2 (R2.3)
E067 4856310600 EYE LET BSR T0.2 (R2.3)
E068 4856310600 EYE LET BSR T0.2 (R2.3)
E069 4856310600 EYE LET BSR T0.2 (R2.3)
E070 4856310600 EYE LET BSR T0.2 (R2.3)
E080 4856310600 EYE LET BSR T0.2 (R2.3)
E081 4856310600 EYE LET BSR T0.2 (R2.3)
N0010 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N0011 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N0012 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N0013 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N005 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N006 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N007 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N008 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P402 485923182S CONN WAFER YW025-05 (STICK)
P501 485923202S CONN WAFER YW025-07 (STICK)
P601 485923172S CONN WAFER YW025-04 (STICK)
P602 485923182S CONN WAFER YW025-05 (STICK)
P603 485923192S CONN WAFER YW025-06 (STICK)
P701 485923172S CONN WAFER YW025-04 (STICK)
PD01 485923162S CONN WAFER YW025-03 (STICK)
R310 RS02Z129JS R M-OXIDE FILM 2W 1.2 OHM J SMALL
R317 RS02Z100JS R M-OXIDE FILM 2W 10 OHM J SMALL
LOC PART CODE PART NAME DESCRIPTION REMARK
R403 RS01Z272J- R M-OXIDE FILM 1W 2.7K OHM J (TAPPING)
R404 RS02Z101JS R M-OXIDE FILM 2W 100 OHM J SMALL
R406 RS02Z203JS R M-OXIDE FILM 2W 20K OHM J SMALL
R407 RS02Z102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R408 RF01Z100J- R FUSIBLE 1W 10 OHM J (TAPPING)
R409 RS01Z103J- R M-OXIDE FILM 1W 10K OHM J (TAPPING)
R414 RS02Z203JS R M-OXIDE FILM 2W 20K OHM J SMALL
R419 RS02Z201JS R M-OXIDE FILM 2W 200 OHM J SMALL
R422 85801060GY WIRE COPPER 1/0.6 TIN COATING
R807 RF02Z188K- R FUSIBLE 2W 0.18 OHM K (TAPPING)
R813 RF02Z688K- R FUSIBLE 2W 0.68 OHM K (TAPPING)
R830 RS02Z104JS R M-OXIDE FILM 2W 100K OHM J SMALL
ZZ200 PTMPJRE135 PCB MAIN RADIAL AS DTU-29M5ME
C102 CEXF1C100V C ELECTRO RSS 16V 10MF 4X7
C104 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C106 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C128 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C130 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C301 CMXM2A393J C MYLAR 100V 0.039MF J (TP)
C305 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C306 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C313 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C314 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C402 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C403 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C410 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C411 CEXF2E229V C ELECTRO 250V RSS 2.2MF (8X11.5)TP
C412 CCXB2H221K C CERA 500V B 220PF K (TAPPING)
C413 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C414 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C416 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C425 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C601 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5.0 TA
C602 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C603 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C604 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C605 CCXB1H682K C CERA 50V B 6800PF K (TAPPING)
C606 CCXB1H682K C CERA 50V B 6800PF K (TAPPING)
C607 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C608 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C609 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C610 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C614 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C701 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C704 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5.0 TA
C707 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C713 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C716 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C721 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C722 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C723 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C726 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C727 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C730 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C731 CEXF1E470V C ELECTRO RSS 25V 47MF 5X11 P5.0 TA
C732 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C734 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C735 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C740 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C749 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C751 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C752 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C753 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C754 CMXL1J154J C MYLAR 63V MEU 0.15MF J
C755 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C756 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C758 CMXL1J224J C MYLAR 63V MEU 0.22MF J (TP)
C759 CMXM2A682J C MYLAR 100V 6800PF J (TP)
LOC PART CODE PART NAME DESCRIPTION REMARK

-18-
ELECTRICAL PARTS LIST
C761 CCXB1H101K C CERA 50V B 100PF K (TAPPING)
C765 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C766 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C767 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C768 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C770 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C771 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C772 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C780 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C781 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C783 CEXF1C100V C ELECTRO RSS 16V 10MF 4X7
C784 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C790 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C805 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C807 CCXB1H821K C CERA 50V B 820PF K (TAPPING)
C808 CCXB1H471K C CERA 50V B 470PF K (TAPPING)
C810 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C812 CCXR3A102K C CERA HIKR 1KV 1000PF K 125C
C814 CCXB3A271K C CERA 1KV B 270PF K (TAPPING)
C819 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C822 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C825 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C828 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C836 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C840 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C860 CEXF1H330V C ELECTRO 50V RSS 33MF (6.3X11) TP
C870 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
CD01 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CD03 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
CV01 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
CV02 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
CV03 CMXL1J104J C MYLAR 63V MEU 0.1MF J
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I803 1K1A431B—IC REGULATOR(SHUNT) KIA431B 2.495V 0.5% TO-92
L302 58C0000142 COIL CHOKE ELC 0809 940K
L303 58C0000142 COIL CHOKE ELC 0809 940K
L601 58C0000142 COIL CHOKE ELC 0809 940K
L812 58C0000142 COIL CHOKE ELC 0809 940K
Q101 TKTC3198Y- TR KTC3198Y
Q403 TKTA1266Y- TR KTA1266Y (TP)
Q602 TKTA1266Y- TR KTA1266Y (TP)
Q701 TKTA1266Y- TR KTA1266Y (TP)
Q704 TKTC3198Y- TR KTC3198Y
Q705 TKTA1270Y- TR KTA1270Y (TP)
Q706 TKTC3198Y- TR KTC3198Y
Q707 TKTA1270Y- TR KTA1270Y (TP)
Q708 TKTC3198Y- TR KTC3198Y
Q721 TH2N7000—FET H2N7000
Q722 TH2N7000—FET H2N7000
Q810 TKSA1013Y- TR KSA1013Y (TP)
Q852 TKTC3198Y- TR KTC3198Y
Q853 TKTC3198Y- TR KTC3198Y
QF01 TKTC3198Y- TR KTC3198Y
R319 RN02B181JS R METAL FILM 2W 180 OHM J SMALL
R426 RN02B222JS R METAL FILM 2W 2.2K OHM J SMALL
R613 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R614 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R615 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
R616 RN01B229JS R METAL FILM 1W 2.2 OHM J SMALL
SW701 5S50101090 SW TACT THVH472GCA
SW702 5S50101090 SW TACT THVH472GCA
SW703 5S50101090 SW TACT THVH472GCA
SW704 5S50101090 SW TACT THVH472GCA
SW705 5S50101090 SW TACT THVH472GCA
SW706 5S50101090 SW TACT THVH472GCA
ZZ200 PTMPJAE135 PCB MAIN AXIAL AS DTU-29M5ME
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
LOC PART CODE PART NAME DESCRIPTION REMARK
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859810993 PCB MAIN 330X246 D1B
C101 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C105 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C107 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C129 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C415 CCZB1H561K C CERA 50V B 560PF K
C612 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C702 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C703 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C705 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C706 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C712 CCZB1H561K C CERA 50V B 560PF K
C714 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C715 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C717 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C719 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C720 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C728 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C729 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C733 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C736 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C739 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C741 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C750 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C757 CCZB1H223K C CERA HIBK 50V 0.022MF K AXL 52
C760 CCZB1H222K C CERA 50V B 2200PF K AXIAL
C764 CBZR1C392M C CERA 16V Y5R 3900PF M (AXIAL)
C769 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C782 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C785 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C798 CZCH1H100J C CERA 50V CH 10PF J
C799 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C823 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
C830 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
CA02 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA03 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA07 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA08 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA09 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA10 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA19 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA20 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA30 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA31 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA35 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA36 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA39 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA40 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CD02 CCZB1H103K C CERA HIKB 50V 0.01MF K AXIAL
CV16 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CV17 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CV18 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CV30 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
CV31 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
CV32 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
D102 DUZ33B—— DIODE ZENER UZ-33B
D301 D1N4937G—DIODE 1N4937G (TAPPING)
D401 D1N4937G—DIODE 1N4937G (TAPPING)
D404 D1N4937G—DIODE 1N4937G (TAPPING)
D405 D1N4004S—DIODE 1N4004S
D406 DRGP15J—- DIODE RGP15J DO-204AC 600V 1.5A
D410 D1N4937G—DIODE 1N4937G (TAPPING)
D602 D1N4148—- DIODE 1N4148 (TAPPING)
D701 DUZ3R9B—- DIODE ZENER UZ-3.9B
D702 D1N4148—- DIODE 1N4148 (TAPPING)
D703 D1N4148—- DIODE 1N4148 (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK

-19-
ELECTRICAL PARTS LIST
D704 DUZ3R9B—- DIODE ZENER UZ-3.9B
D710 D1N4148—- DIODE 1N4148 (TAPPING)
D750 DUZ9R1BM—DIODE ZENER UZ-9.1BM
D802 DLT2A05G—DIODE LT2A05G (TP)
D803 DLT2A05G—DIODE LT2A05G (TP)
D804 DLT2A05G—DIODE LT2A05G (TP)
D805 DLT2A05G—DIODE LT2A05G (TP)
D807 D1N4937G—DIODE 1N4937G (TAPPING)
D808 D1N4937G—DIODE 1N4937G (TAPPING)
D811 D1N4148—- DIODE 1N4148 (TAPPING)
D813 D1N4937G—DIODE 1N4937G (TAPPING)
D815 DRGP15J—- DIODE RGP15J DO-204AC 600V 1.5A
D816 DRGP15J—- DIODE RGP15J DO-204AC 600V 1.5A
D822 DMTZJ6R2C- DIODE ZENER MTZJ 6.2C
D899 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DA01 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DA04 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DA05 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DA09 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DA10 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DF02 DUZ3R9B—- DIODE ZENER UZ-3.9B
DV01 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
DV02 DMTZJ5R6B- DIODE ZENER MTZJ 5.6B
J101 85801060GY WIRE COPPER 1/0.6 TIN COATING
J102 85801060GY WIRE COPPER 1/0.6 TIN COATING
J103 85801060GY WIRE COPPER 1/0.6 TIN COATING
J104 85801060GY WIRE COPPER 1/0.6 TIN COATING
J105 85801060GY WIRE COPPER 1/0.6 TIN COATING
J106 85801060GY WIRE COPPER 1/0.6 TIN COATING
J108 85801060GY WIRE COPPER 1/0.6 TIN COATING
J109 85801060GY WIRE COPPER 1/0.6 TIN COATING
J110 85801060GY WIRE COPPER 1/0.6 TIN COATING
J111 85801060GY WIRE COPPER 1/0.6 TIN COATING
J112 85801060GY WIRE COPPER 1/0.6 TIN COATING
J113 85801060GY WIRE COPPER 1/0.6 TIN COATING
J114 85801060GY WIRE COPPER 1/0.6 TIN COATING
J117 85801060GY WIRE COPPER 1/0.6 TIN COATING
J119 85801060GY WIRE COPPER 1/0.6 TIN COATING
J121 85801060GY WIRE COPPER 1/0.6 TIN COATING
J122 85801060GY WIRE COPPER 1/0.6 TIN COATING
J123 85801060GY WIRE COPPER 1/0.6 TIN COATING
J125 85801060GY WIRE COPPER 1/0.6 TIN COATING
J130 85801060GY WIRE COPPER 1/0.6 TIN COATING
J131 85801060GY WIRE COPPER 1/0.6 TIN COATING
J132 85801060GY WIRE COPPER 1/0.6 TIN COATING
J140 85801060GY WIRE COPPER 1/0.6 TIN COATING
J145 85801060GY WIRE COPPER 1/0.6 TIN COATING
J149 85801060GY WIRE COPPER 1/0.6 TIN COATING
J150 85801060GY WIRE COPPER 1/0.6 TIN COATING
J160 85801060GY WIRE COPPER 1/0.6 TIN COATING
J170 85801060GY WIRE COPPER 1/0.6 TIN COATING
J171 85801060GY WIRE COPPER 1/0.6 TIN COATING
J180 85801060GY WIRE COPPER 1/0.6 TIN COATING
J182 85801060GY WIRE COPPER 1/0.6 TIN COATING
J183 85801060GY WIRE COPPER 1/0.6 TIN COATING
J190 85801060GY WIRE COPPER 1/0.6 TIN COATING
J191 85801060GY WIRE COPPER 1/0.6 TIN COATING
J199 85801060GY WIRE COPPER 1/0.6 TIN COATING
J235 85801060GY WIRE COPPER 1/0.6 TIN COATING
J236 85801060GY WIRE COPPER 1/0.6 TIN COATING
J239 85801060GY WIRE COPPER 1/0.6 TIN COATING
J303 85801060GY WIRE COPPER 1/0.6 TIN COATING
J304 85801060GY WIRE COPPER 1/0.6 TIN COATING
J305 85801060GY WIRE COPPER 1/0.6 TIN COATING
J308 85801060GY WIRE COPPER 1/0.6 TIN COATING
J309 85801060GY WIRE COPPER 1/0.6 TIN COATING
J310 85801060GY WIRE COPPER 1/0.6 TIN COATING
J319 85801060GY WIRE COPPER 1/0.6 TIN COATING
LOC PART CODE PART NAME DESCRIPTION REMARK
J320 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
J321 85801060GY WIRE COPPER 1/0.6 TIN COATING
J405 85801060GY WIRE COPPER 1/0.6 TIN COATING
J406 85801060GY WIRE COPPER 1/0.6 TIN COATING
J407 85801060GY WIRE COPPER 1/0.6 TIN COATING
J408 85801060GY WIRE COPPER 1/0.6 TIN COATING
J410 85801060GY WIRE COPPER 1/0.6 TIN COATING
J411 85801060GY WIRE COPPER 1/0.6 TIN COATING
J413 85801060GY WIRE COPPER 1/0.6 TIN COATING
J418 85801060GY WIRE COPPER 1/0.6 TIN COATING
J420 85801060GY WIRE COPPER 1/0.6 TIN COATING
J421 85801060GY WIRE COPPER 1/0.6 TIN COATING
J427 85801060GY WIRE COPPER 1/0.6 TIN COATING
J428 85801060GY WIRE COPPER 1/0.6 TIN COATING
J501 85801060GY WIRE COPPER 1/0.6 TIN COATING
J502 85801060GY WIRE COPPER 1/0.6 TIN COATING
J503 85801060GY WIRE COPPER 1/0.6 TIN COATING
J505 85801060GY WIRE COPPER 1/0.6 TIN COATING
J506 85801060GY WIRE COPPER 1/0.6 TIN COATING
J507 85801060GY WIRE COPPER 1/0.6 TIN COATING
J601 85801060GY WIRE COPPER 1/0.6 TIN COATING
J602 85801060GY WIRE COPPER 1/0.6 TIN COATING
J603 85801060GY WIRE COPPER 1/0.6 TIN COATING
J604 85801060GY WIRE COPPER 1/0.6 TIN COATING
J605 85801060GY WIRE COPPER 1/0.6 TIN COATING
J608 85801060GY WIRE COPPER 1/0.6 TIN COATING
J610 85801060GY WIRE COPPER 1/0.6 TIN COATING
J611 85801060GY WIRE COPPER 1/0.6 TIN COATING
J614 85801060GY WIRE COPPER 1/0.6 TIN COATING
J615 85801060GY WIRE COPPER 1/0.6 TIN COATING
J630 85801060GY WIRE COPPER 1/0.6 TIN COATING
J631 85801060GY WIRE COPPER 1/0.6 TIN COATING
J700 85801060GY WIRE COPPER 1/0.6 TIN COATING
J701 85801060GY WIRE COPPER 1/0.6 TIN COATING
J702 85801060GY WIRE COPPER 1/0.6 TIN COATING
J703 85801060GY WIRE COPPER 1/0.6 TIN COATING
J704 85801060GY WIRE COPPER 1/0.6 TIN COATING
J705 85801060GY WIRE COPPER 1/0.6 TIN COATING
J706 85801060GY WIRE COPPER 1/0.6 TIN COATING
J707 85801060GY WIRE COPPER 1/0.6 TIN COATING
J708 85801060GY WIRE COPPER 1/0.6 TIN COATING
J709 85801060GY WIRE COPPER 1/0.6 TIN COATING
J710 85801060GY WIRE COPPER 1/0.6 TIN COATING
J711 85801060GY WIRE COPPER 1/0.6 TIN COATING
J712 85801060GY WIRE COPPER 1/0.6 TIN COATING
J713 85801060GY WIRE COPPER 1/0.6 TIN COATING
J714 85801060GY WIRE COPPER 1/0.6 TIN COATING
J715 85801060GY WIRE COPPER 1/0.6 TIN COATING
J716 85801060GY WIRE COPPER 1/0.6 TIN COATING
J717 85801060GY WIRE COPPER 1/0.6 TIN COATING
J718 85801060GY WIRE COPPER 1/0.6 TIN COATING
J719 85801060GY WIRE COPPER 1/0.6 TIN COATING
J722 85801060GY WIRE COPPER 1/0.6 TIN COATING
J723 85801060GY WIRE COPPER 1/0.6 TIN COATING
J724 85801060GY WIRE COPPER 1/0.6 TIN COATING
J725 85801060GY WIRE COPPER 1/0.6 TIN COATING
J726 85801060GY WIRE COPPER 1/0.6 TIN COATING
J727 85801060GY WIRE COPPER 1/0.6 TIN COATING
J732 85801060GY WIRE COPPER 1/0.6 TIN COATING
J733 85801060GY WIRE COPPER 1/0.6 TIN COATING
J734 85801060GY WIRE COPPER 1/0.6 TIN COATING
J735 85801060GY WIRE COPPER 1/0.6 TIN COATING
J736 85801060GY WIRE COPPER 1/0.6 TIN COATING
J737 85801060GY WIRE COPPER 1/0.6 TIN COATING
J738 85801060GY WIRE COPPER 1/0.6 TIN COATING
J739 85801060GY WIRE COPPER 1/0.6 TIN COATING
J740 85801060GY WIRE COPPER 1/0.6 TIN COATING
J743 85801060GY WIRE COPPER 1/0.6 TIN COATING
LOC PART CODE PART NAME DESCRIPTION REMARK
