Daewoo Cyclone Lyte User manual

1
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
•Read and familiarise yourself with all operating instructions before
using this Vacuum Cleaner.
•Before plugging your unit into the mains, visually check that the unit is
intact and has not suffered any transit damage.
•Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
•This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Keep the appliance and its cord out of reach of children less than 8
years when it is energised or cooling down.
•Do not immerse the appliance or its cord in water or any otherliquids.
•Do not leave the appliance unattended during use.
•Do not leave the appliance unattended whilst connected to the mains
supply.
•Do not use this appliance outdoors.
•It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
•Repairs to electrical appliances should only be performed by a qualified
electrician. Improper repairs may place user at serious risk.
•Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
•Regular, periodic checks should be carried out on the mains cable to
•ensure no damage is evident. Should there be any signs of damage the
appliance should not be used.
•If the power cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in order to
avoid a hazard
•Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
•Allow the unit to cool before storage.
•Before cleaning, disconnect the appliance from the mains supply and

3
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
allow to cool.
•This appliance is intended for household use only and should not be
used for industrial purposes.
•Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
•Do not use this appliance for anything other than its intended use.
•Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
•Unplug after each use. Grasp the plug, not the cord.
•Do not pull or carry the Vacuum Cleaner by the electrical cord, use the
handle provided.
•Ensure fingers and other objects are never placed in any part of the
vacuum cleaner. Clothing or hair may become trapped if thevacuum is
used improperly.
•Keep hair, loose clothing, jewellery, fingers and all parts of the body
away from openings and moving parts.
•Keep all air vents clear and free of dust, lint, hair and anything else that
may reduce airflow.
•Avoid directing the appliance towards naked flames as the air
discharged may extinguish gas fires or pilot lights and may disturb
ashes in open fires.
•Do not Vacuum water or any other liquids with this vacuum.
•Do not Vacuum hot ashes or lit cigarettes, etc.
Description of Parts
1. Air/Dust Inlet
2. Filters
3. Dust Release Catch
4. Dust Compartment
5. Handle
6. On/Off Trigger Switch
7. Filter Compartment Release Catch
8. Filter Compartment
1
2
3
4
5
6
7
8

4
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Accessories
Attaching the Accessories
CAUTION Ensure that the vacuum cleaner is not connected to the mains supply before using
the attachments.
The Floor Attachment
1. Push the Telescopic Tube (12) onto the Air/Dust Inlet (1) as shown below:
2. Push the Floor Tool (9) onto the other end of the Telescopic Tube (12)
NB Adjust the lever on the Floor Tool (9) according to the type of floor being cleaned. Push
the lever down for use on hard floors (i.e. non carpeted), pull the lever up for vacuum
cleaning carpets:
9
10
11
12
9. Floor Tool
10.2 in 1 Crevice Tool
11.Upholstery Tool
12.Telescopic Tube
Left: Adjust the lever on the
Floor Tool for carpeted or
hard floors:
Up for carpets
Down for hard floors

5
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3. Set the required height of the cleaner by pressing the button on the Telescopic Tube (12)
and adjusting the tube to the required height:
The Crevice Tool
1. Attach the 2 in 1 Crevice Tool (10) onto the Telescopic Tube (12) to clean carpet edges
and hard to get at areas:
2. If the Telescopic Tube (12) is not required, attach the crevice tool directly to the cleaner,
this useful whilst cleaning soft furnishings, stairs, etc.:
NB Rotate the brush on the end of the 2 in 1 Crevice tool to brush dust out of hard
to get at areas.
The Upholstery Tool
1. Attach the Upholstery Tool (11) to the cleaner to clean soft furnishings such as sofas
armchairs etc. Attach the Upholstery Tool (11) to Telescopic Tube (12) to give better reach
to clean curtains, etc.:

6
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Once the dust level reaches the ‘MAX’
mark on the Dust compartment (4) it
will need emptying and the filters
cleaned.
2. To empty the cleaner, hold the Dust
Compartment (4) over a dust bin and
press the Dust Release Catch (3) and
the base of the dust compartment will
swing open and allow the collected
dust to fall out into the dust bin.
3. Hold the Filter Compartment (8) and
press the Filter Compartment Release
Catch (7) and remove the Filter
Compartment.
4. Twist the top off the Filter
Compartment (8) anticlockwise and
remove.
5. Pull out the filter assemblies.
6. Wash the Micro, Sponge and cyclonic
filters in warm running water until the
water runs clear. Allow the filters to
dry thoroughly for 24 hours before
reuse.
Using Your Corded Stick Vacuum Cleaner
Emptying and Cleaning Your Corded Stick Vacuum Cleaner
WARNING Always disconnect the cleaner from the mains power supply before cleaning.
WARNING do not continue to use your vacuum cleaner once the ‘MAX’ mark has been
reached as permanent damage may occur to the appliance.
1. Once you have assembled
your vacuum cleaner as
desired above, Insert the
mains plug into the nearest
socket.
2. To operate the vacuum cleaner,
grip the vacuum by the Handle
(5) and press the On/Off Trigger
Switch (6) at the top of the
handle –arrowed right.
1
2
3
1
2

7
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of your Cyclone Lyte Vacuum Cleaner
•Always disconnect the cleaner from the mains power supply before cleaning.
•Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
•Do not submerge the cleaner in water or any other liquids.
•Empty the Dust Compartment (4) as soon as the ‘MAX’ mark has been reached.*
•Wash the Micro, Sponge and Cyclonic Filters (6) regularly –see table below.
•Allow the filters to thoroughly dry out for 24 hours before reassembly and use.
*WARNING do not continue to use your vacuum cleaner once the ‘MAX’ mark has been
reached as permanent damage may occur to the appliance.
Recommended filter cleaning intervals
Filter Type
Recommended cleaning period
WARNING Ensure the filters are cleaned periodically according to the table above, failure to
clean the filters regularly will severely impair the performance and permanent damage may
occur to the appliance and may invalidate your warranty.
Micro filter (top)
Sponge Filter
(underside)
Cyclonic Filter
4
5
•Shake out debris when you empty the dust
container
• Rinse under war m water once a month
•Allow to dry thoroughly for 24 hours before reuse.
• Occasionally r emove any dust/debris as necessary .
•The filter should also be rinsed under warm water
once a month.
•Allow to dry thoroughly for 24 hours before reuse.
•Shake out debris once a month
• Rinse under war m water once a month.
•Allow to dry thoroughly for 24 hours before reuse.
Round Micro Filter
Round Sponge Filter
Cyclonic Filter
6

8
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Electrical Connections
This appliance is fitted with a fused three-pin plug to BS 1363. If the plug has to be removed, it
should be cut off and carefully disposed of immediately. To avoid a possible shock hazard, do
not insert the discarded plug into a mains socket.
Fitting a new plug
The mains lead must be connected as shown below. The wires are coloured with the following
code - Brown wire = Live (L), Blue wire = Neutral (N).
NB no connection must be made to the Earth (E) terminal.
•The Blue wire must be connected to the terminal marked N or coloured Black.
•The Brown wire must be connected to the terminal marked L or coloured Red.
•Check that there are no cut or stray strands of wire inside the plug.
•Use a 13 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.
•If you are in any way unsure which plug or fuse to use, always refer to a qualified
electrician.
•After replacing or changing a fuse on a moulded plug, the cover must be refitted to the
plug; the appliance must not be used without a fuse cover.
Technical Specification
Model Number
FLR00039
Supply Voltage
AC 220-240V ~ 50/60Hz
Rated Power
600W
Protection Class
II
Unpacked Weight (approx.)
1.8 Kgs
Dimensions (approx.)
315mm (l) x 115mm (w) x 215mm (h)
Vacuum (max)
17kpa
Noise Level (approx.)
75dB
Dust Compartment Capacity
0.6L
Connect
Brown to
Live (L)
Connect
Blue to
Neutral (N)
Ensure the outer sheath of the mains lead
is securely held by the cable clamp

9
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Solution
Unit fails to turn on.
The unit may not be
properly plugged in.
The fuse may have
tripped.
Ensure the plug is fully
inserted into the socket and
the socket is switched on.
Check the fuse on the mains
board, if it has tripped, reset
it.
Low suction or poor pick-up.
Cylinder is full.
Filters are clogged.
Blockage in the hose.
Empty the cylinder. Check
and clean the filters.
Check the Telescopic Tube
and clear if necessary.
The vacuum is making a “hissing”
sound.
The airflow is
restricted
Empty the cylinder. Check
and clean the filters.
Check the Telescopic Tube
and clear any blockages if
necessary.

10
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.

11
Cyclone Lyte 600W Corded Vacuum Cleaner
FLR00039
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
