Daewoo DWC-LU1011 User manual

zGtG
Drum Washing Machine
Model: DWD-L100 Series
vUGYWW`
GGGGGGfGj
a pGGtSGGGGGGGSGG
GGGGGGUGzSGGGGG
GGSGGGGwwsOwGwGsPGG
zGpGjGOaVVUUUPU
zVtGuUGaGk~kskX[WWXG

DRUM WASHING MACHINE
SERVICE MANUAL
1. WHAT IS DRUM WASHING MACHINE?......................................1
2. WASHER SPECIFICATION ..........................................................2
3. PARTS LIST BY ASS'Y.................................................................4
4. CONTROL PART FUNCTION SPECIFICATION ........................23
5. ELECTRONIC FIELD PARTS LIST AND SPECIFICATION .......38
6. WIRING DIAGRAM .....................................................................39

1
Water consumption is reduced by using the power of the laundry falling (free-fall) created when rotating
the drum. With temperature control system, this drum washing machine saves energy and improves
washing performance at the same time.
1. WHAT IS DRUM WASHING MACHINE?
1. Drum Washing Machine
俕Waist Care
Designed by the waist, and the most comfortable
angle eject into the laundry is convenient and easy to
manipulate.
䯥Star Drum
Using Star Drum is able to show users higher
Washing Performance and Minimal damage of
laundry, water consumption.
䯥Luxury Audio Dial
Using the advanced Audio Dial is luxury design of
exterior.
俕DD inverter motor
The direct-drive type of which motor is directly
connected to drum without an interim clutch,
significantly reduces noise and vibration.
俕Self-Cleaning Course of Drum.
Enables the machine to do Self-Cleaning of Drum.
俕Digital Condensing Dry System.
Condensing Dry System with saveing energy.
2. Key Features

2
Ŗ&&%QPVTQN&KTGEVFTKXGV[RGQHFKTGEVEQPPGEVKQPDGVYGGPFTWOCPFOQVQT
Ŗ4QVCVKQPD[RQYGTHWNJKIJRGTHQTOCPEG$.&%OQVQT
2QYGT5[UVGO
Sxps#Gudlqdjh EOGF
ODXQGU\

33
2. WASHER SPECIFICATION
2TQFWEV5RGEKHKECVKQP
O1st Model O2st Model
MODEL DWC-LU1011/1211 DWD-LU1011/1211 DWC-LD1411/1611 DWD-LD1411/1611
Dimension (mm) 600 X 645 X 850
Maximum mass of textile (kg) 9 Kg
Unit Weight (net/gross) 78/82 71/75 76/80 69/73
Standard Water Consumption Ɛ
Spin Speed (RPM) DWC(DWD)-LU10XX : MAX 1000
DWC(DWD)-LU12XX : MAX 1200
DWC(DWD)-LD14XX : MAX 1400
DWC(DWD)-LD16XX : MAX 1600
Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm2~ 8kgf/cm2)

4
1. PANEL AS
3. PARTS LIST BY ASS'Y
A03
A02
A22
A21
A19
A20
A15
A14
A11
A09
A16
A18
A17
A01
A04
A05
A06
A07
A08
A10
A12
A13
OUV/QFGN

5
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL *F 36142T2000 ABS 1
A02 DECORATOR WINDOW COURSE 3611696000 ABS 1
A03 WINDOW COURSE 3615509200 %.7 1
A04 DECORATOR WINDOW DISPLAY 3611696100 ABS 1
A05 BUTTON FUNCTION 3616644000 ABS 1
A06 BUTTON PS 3616644100 ABS 1
A07 WINDOW DISPLAY 3615509300 %.7 1
A08 BUTTON LED 3616644200 %.7 1
A09 PCB BOARD 3614347000 L SERIES FRONT PCB BOARD 1
A10 CUSTOM LED 3613058300 %.7 1
A11 LED LAMP &592 9MM FORMING TYPE , D=3MM 36
A12 SW TACT 5S50101402 2PIN, 6*6*5 9
A13 HOLDER LED OPTION 3613058000 HIPS 1
A14 HOLDER LED FUNCTION 3613058100 HIPS 1
A15 HOLDER LED COURSE 3613058200 HIPS 1
A16 CASE PCB F 36111T1N00 HIPS 1
A17 BUTTON DIAL OUTER 3616643800 ABS 1
A18 BUTTON DIAL INNER 3616643900 ABS 1
A19 CASE DETERGENT 36111T1J00 PP 1
A20 CAP SOFTENER 3610916600 PP 1
A21 CASE HANDLE 3611149200 ABS 1
A22 DECORATOR CASE HANDLE 3611696200 ABS 1

6
2. PANEL F AS
A01
A02
A03
A04
A09
A10
A11
A12
A13
A07
A06
A14
A18 A17 A16 A15
A08
A05
OUV/QFGN

7
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL FRONT 36142T2100 ABS 2 4x16 SUS 430
A02 BUTTON FUNCTION 3616644400 ABS 1
A03 BUTTON OPTION 3616644700 ABS 1
A04 HOLDER LED FUNCTION 3613058500 HIPS 1
A05 PCB F AS PRPSSWL050 LD10/LU10,STANDBY 1W 1
PCB F AS PRPSSWL051 LD12/LU12,STANDBY 1W 1
PCB F AS PRPSSWL052 LD14,STANDBY 1W 1
PCB F AS PRPSSWL053 LD16,STANDBY 1W 1
PCB F AS PRPSSWL060 LD10/LU10,EC 1
PCB F AS PRPSSWL061 LD12/LU12,EC 1
PCB F AS PRPSSWL062 LD14,EC 1
PCB F AS PRPSSWL063 LD16,EC 1
A06 HOLDER LED DISPLAY 3613058600 ABS 1
A07 CASE PCB F 36111T1R00 HIPS 1
A08 SCREW TAPPING 7122401611 T2S TRS 1 4x16 MFZN
A09 PCB BOARD F 3614348500 (4 1
A10 HOLDER LED COURSE 3613058400 HIPS 1
A11 BUTTON DIAL 3616644300 ABS 1
A12 DECORATOR BUTTON DIAL 3611696400 ABS 1 CHROMIUM CILDING
A13 BUTTON START 3616644600 ABS 1
A14 BUTTON POWER 3616644500 ABS 1
A15 DECORATOR FILM 3611696500 P.C FILM 1
A16 WINDOW COURSE 3615509400 64#$5 1
A17 SCREW TAPPING 7122401608 T2S TRS 1
A18 CASE DETERGENT AS 36111T1P10 PP 1

8
B01
B02
B03
B05
B04
B08
B07
B06
B10
B09
B11
B12
B13
B14
3. INLET BOX AS

9
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
B01 NOZZLE *T 3618111100 PP 1
B02 NOZZLE *U 3618111000 PP 1
B03 BOX INLET 3610526500 PP 1
B04 HOSE INLET 3613274600 EPDM 1
B05 CLAMP AS 3611203200 ID=60, WIRE+GUIDE+BOLT+NUT 1
B06 VALVE INLET 3615416821 88&'$+6410 1
B07 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, WASHING 1
B08 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, PRE.WASH 2
B09 CLAMP HOSE 3611205800 100H, ID=13.8 W=10.0 0.9T 10
B10 VALVE INLET 3615414820 89#;*1622 1
B11 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, HOT 1
B12 HOSE WATER SUPPLY 3613270900 EPDM ID9.5 OD14.5, STEAM 1
B13 PIPE JOINT I 3614426000 PP 1
B14 Unit Steam AS 36189M2U00 .5'4+'556'#/70+69 1QRVKQP

10
4. CABINET F ASSY
C12
C01
C02
C03
C14
C15
C06
C07
C04
C05
C11
C08
C09
C10
C13
OUV/QFGN

11
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 CABINET *F 3610814000 SECD 0.8T 1
C02 SWITCH DOOR LOCK 3619047200 &.58#$+6410 1
C03 PLATE HINGE SUPPORT 3614539800 52)6&9&64 1
C04 FRAME DOOR *O 36122UD800 ABS 1
C05 PROTECTOR GLASS 3618345500 ABS 1
C06 DECORATOR DOOR *O 3611695900 ABS 1
C07 HOOK DOOR 3613100900 ZNDC 1
C08 SPRING HOOK 3615115400 SUS304, 1
C09 HOOK SHAFT 3613101000 SUS, D=3.0 1
C10 FRAME DOOR *I 36122UD600 PP 1
C11 HINGE DOOR 3612903800 #.&9&64 1
C12 CAP HINGE DOOR 3610916500 POM 4
C13 DOOR GLASS 361A113300 GLASS 1
C14 CASE PUMP 36111T1K00 PP 1
C15 COVER PUMP 3611431500 ABS 1

12
5. DOOR AS
C11
C01
C02
C03
C12
C10
C09
C04
C07
C05
C06
C08
OUV/QFGN

13
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 FRAME DOOR 0 36122UDC00 ABS 1
C02 PROTECTOR GLASS 3618345600 64#$5 1
C03 DOOR GLASS 361A113300 GLASS 1
C04 FRAME DOOR 1 36122UDD00 PP 1
C05 HINGE DOOR 3612903800 ALDC 1
C06 CAP HINGE DOOR 3610916500 POM 4
C07 SCREW TAPPING 7115402029 T1S FLT 14 4*20 STS430 NATURE
C08 HOOK DOOR 3613100900 ZNDC 1
C09 SPRING HOOK 3615115400 SUS 1
C10 KOOK SHAFT 36131101000 SUS 1
C11 CASE SPRING DOOR 3611149300 ABS 1
C12 SCREW TAPPING 7122401611 T2STRS 2 4*6 MFZN

14
6. TUB ASSY(UNIVERSAL)
D26
D23
D22
D25
D24
D20
D18
D17
D19
D16
D15
D10
D21
D11
D04
D07
D05
D06
D08
D03
D01
D02 D43
D32
D46
D38
D45
D50
D47
D48
D49
D36
D35
D37
D40
D28
D30
D27
D29 D31
D34
D09
D13
D14
D12
D44
D42
D41
D33
D39

15
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
D01 BALANCER WEIGHT L 3616110600 22&.7-) 1
D02 SPECIAL SCREW 3616029400 SWCH 8.5X30 8
D03 BALANCER WEIGHT R 3616110500 22&.7-) 1
D04 CLAMP GASKET AS 3611207000 %.7 1
D05 GASKET 3612325300 '2&/9#5*&.7 1
FOR WASH
D06 GASKET 3612325400 '2&/&4;%.7 1 FOR DRY
D07 NOZZLE SHOWER 3618111200 PP 1
D08 CLAMP GASKET BUSHING 3611206800
GI 1.2T 1 FOR DRY
D09 SPECIAL SCREW 3616029810 SWCH 6.5X45 4
D10 DUCT B AS 3610DUTL00 %.' 1 FOR DRY
D11 HOSE DRAIN *I 3613275200 '2&/&.7 1
D12 CLAMP AS 3611203210 ID=61, WIRE+GUIDE+BOLT, GS 1
D13 CLAMP HOSE 3611204700 D26 1
D14 CLAMP HOSE 3611201401 HSW3,YW,D2.6,ID36,W44.5 1
D15 AIR TRAP 361A500101 PP 1
D16 HOSE AIR(PRESSURE) 3613266930 +&1&.//.5'4+'5 1
D17 DAMPER FRICTION 361A700110
0#-556&..1901+5' 2
D18 DAMPER PIN 361A700200 AKS D=14.5 2
D19 TUB FRONT 3618830000 (422%.7 1
D20 SPRING SUSPENSION 3615116800 KGF 2
D21 SPECIAL SCREW 3616029800 SWCH 6.5X30 14
D22 SPECIAL SCREW 3616029500 SUS430 8*25 3
D23 LIFTER WASH 361A401300 PP,1PIECE,TWIST 3
D24 SCREW TAPPING 7122401408 T2S TRS 4X14 SUS,STS 3
D25 DRUM AS 3617012500 &.7 1
D26 SPIDER AS 361A301200 &.7 1
D27 WATER SEAL 361A600100 NBR 1
D28 SEALING TUB 3612321601 '2&/.` 1
D29 FIXTURE HEATER 3612006700 SUS 1
D30 BEARING INNER 3616303100 6206Z 1
D31 UNIT MOTOR UNIVERSAL 36189L4H10 DC220/50 G&J 2P PI340 45T(CCA) 1
D32 BALANCER WEIGHT LOWER 3616110300 22&.7-) 1
D33 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D34 SPECIAL SCREW 3616062800 SWRCH18A 7.4*25.5 2
D35 DAMPER FRICTION 361A700130
0#-556&..1901+5' 2
D36 DAMPER PIN 361A700200 AKS D=14.5 2
D37 TUB REAR AS 36100T1400 &.7 1
D38 BALANCER WEIGHT T 3616110400 22%.7-) 1 FOR DRY
D39 BALANCER WEIGHT T(WASH) 3616110700 22&.7-) 1
FOR WASH
D40 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D41 CLAMP HOSE 3611204700 D26 1
D42 SPECIAL SCREW 3616007400 T2S TRS 4X10+24 2 OPTION
D43 UNIT BUBBLE PUMP AS 36189L4120 8&$-&$42%*5*+10 1 OPTION
D44 HOSE VENT 3613267100 EPDM 1
D45 BEARING OUTER 3616303200 6205Z 1
D46 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
D47 PIPE DUCT AS 3614414001 %.2+2'&7%6*15'%.#/2 1 FOR DRY
D48 PULLEY 3618434100 ALDC 1
D49 SPECIAL BOLT AS 3616029600 SWCH 10*30,F/L BOLT S.P/W SEAL LOCK 1
D50 BELT V 3616591120 GATES 4PJ1175 BUTADIENE RUBBER 1

16
7. TUB ASSY(DD MOTOR)
D26
D23
D22
D25
D24
D20
D18
D17
D19
D16
D15
D10
D21
D11
D04
D07
D05
D06
D08
D03
D01
D02 D39
D42
D34
D41
D43
D32
D31
D33
D36
D28
D30
D27
D29
D09
D13
D14
D12
D40
D38
D37
D35
D44
D45
D46
D47

17
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
D01 BALANCER WEIGHT L 3616110600 22&.7-) 1
D02 SPECIAL SCREW 3616029400 SWCH 8.5X30 8
D03 BALANCER WEIGHT R 3616110500 22&.7-) 1
D04 CLAMP GASKET AS 3611207000 %.7 1
D05 GASKET 3612325300 '2&/9#5*&.7 1
FOR WASH
D06 GASKET 3612325400 '2&/&4;%.7 1 FOR DRY
D07 NOZZLE SHOWER 3618111200 PP 1
D08 CLAMP GASKET BUSHING 3611206800
GI 1.2T 1 FOR DRY
D09 SPECIAL SCREW 3616029810 SWCH 6.5X45 4
D10 DUCT B AS 3610DUTL00 %.' 1 FOR DRY
D11 HOSE DRAIN *I 3613275200 '2&/&.7 1
D12 CLAMP AS 3611203210 ID=61, WIRE+GUIDE+BOLT, GS 1
D13 CLAMP HOSE 3611204700 D26 1
D14 CLAMP HOSE 3611201401 HSW3,YW,D2.6,ID36,W44.5 1
D15 AIR TRAP 361A500101 PP 1
D16 HOSE AIR(PRESSURE) 3613266930 +&1&.//.5'4+'5 1
D17 DAMPER FRICTION 361A700110
0#-556&..1901+5' 2
D18 DAMPER PIN 361A700200 AKS D=14.5 2
D19 TUB FRONT 3618830000 (422%.7 1
D20 SPRING SUSPENSION 3615116800 KGF 2
D21 SPECIAL SCREW 3616029800 SWCH 6.5X30 14
D22 SPECIAL SCREW 3616029500 SUS430 8*25 3
D23 LIFTER WASH 361A401300 PP,1PIECE,TWIST 3
D24 SCREW TAPPING 7122401408 T2S TRS 4X14 SUS,STS 3
D25 DRUM AS 3617012500 &.7 1
D26 SPIDER AS 361A301200
&.7 1
D27 WATER SEAL 361A600100 NBR 1
D28 SEALING TUB 3612321601 '2&/.` 1
D29 FIXTURE HEATER 3612006700 SUS 1
D30 BEARING INNER 3616303100 6206Z 1
D31 DAMPER FRICTION 361A700130
0#-556&..1901+5' 2
D32 DAMPER PIN 361A700200 AKS D=14.5 2
D33 TUB REAR AS 36100T1400 &.7 1
D34 BALANCER WEIGHT T 3616110400 22%.7-) 1 FOR DRY
D35 BALANCER WEIGHT T(WASH) 3616110700 22&.7-) 1
FOR WASH
D36 SPECIAL SCREW 3616029400 SWCH 8.5X30 2
D37 CLAMP HOSE 3611204700 D26 1
D38 SPECIAL SCREW 3616007400 T2S TRS 4X10+24 2 OPTION
D39 UNIT BUBBLE GENERATOR 36189L4177
HIGH,PAD B,BL/WH,320,RP4,GUIDE O,SPONGE 200 1 OPTION
D40 HOSE VENT 3613267100 EPDM 1
D41 BEARING OUTER 3616303200 6205Z 1
D42 HEATER WASH 3612803700 230V 2000W.1R5A721002.IRCA FUSE 2EA 1
D43 PIPE DUCT AS 3614414001 %.2+2'&7%6*15'%.#/2 1
D44 UNIT STATOR BLDC 36189L6200 AL,30T(28T),NMT 1
D45 SPECIAL BOLT AS 3616029900 SWCH M8 + SILOCK 6
D46 UNIT ROTOR BLDC 36189L6300 L'SERIES, NMT 1
D47 SPECIAL BOLT AS 3616029620 59%*59290105'#..1%- 1

18
&7%6$HQTFT[OQFGN
E01
E15
E13
E14
E12
E11
E04
E07
E06
E10
E08
E03
E05
E02
E09
