Dahua H User manual

Model H IR Dome Network Camera
Quick Start Guide
V1.0.0
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Foreword I
Foreword
General
This manual introduces the functions, installation, and operations of the camera.
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words
Meaning
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
NOTE
Provides additional information as the emphasis and supplement
to the text.
Revision History
Version
Revision Content
Release Time
V1.0.0
First release.
July 2019
Privacy Protection Notice
As the device user or data controller, you might collect personal data of others such as face,
fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be
in compliance with the local privacy protection laws and regulations to protect the legitimate
rights and interests of other people by implementing measures include but not limited to:
providing clear and visible identification to inform data subject the existence of surveillance
area and providing related contact.
About the Manual
The manual is for reference only. If there is inconsistency between the manual and the
actual product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the manual.
The manual would be updated according to the latest laws and regulations of related
regions. For detailed information, see the paper manual, CD-ROM, QR code or our official
website. If there is inconsistency between paper manual and the electronic version, the
electronic version shall prevail.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please

Foreword II
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or
errors in print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and the company names in the manual are the
properties of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem
occurred when using the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Important Safeguards and Warnings III
Important Safeguards and Warnings
Electrical Safety
All installation and operation should conform to your local electrical safety codes.
The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and
supply power with rated voltage which conforms to Limited power Source requirement
according to IEC60950-1. Please note that the power supply requirement is subject to the
device label.
Make sure the power supply is correct before operating the device.
A readily accessible disconnect device shall be incorporated in the building installation
wiring.
Prevent the power cable from being trampled or pressed, especially the plug, power socket
and the junction extruded from the device.
Environment
Do not aim the device at strong light to focus, such as lamp light and sun light; otherwise it
might cause over brightness or light marks, which are not the device malfunction, and
affect the longevity of Complementary Metal-Oxide Semiconductor (CMOS).
Do not place the device in a damp or dusty environment, extremely hot or cold
temperatures, or the locations with strong electromagnetic radiation or unstable lighting.
Keep the device away from any liquid to avoid damage to the internal components.
Keep the indoor device away from rain or damp to avoid fire or lightning.
Keep sound ventilation to avoid heat accumulation.
Transport, use and store the device within the range of allowed humidity and temperature.
Heavy stress, violent vibration or water splash are not allowed during transportation,
storage and installation.
Pack the device with standard factory packaging or the equivalent material when
transporting the device.
Install the device in the location where only the professional staff with relevant knowledge
of safety guards and warnings can access. The accidental injury might happen to the
non-professionals who enter the installation area when the device is operating normally.
Operation and Daily Maintenance
Do not touch the heat dissipation component of the device to avoid scald.
Carefully follow the instructions in the manual when performing any disassembly operation
about the device; otherwise, it might cause water leakage or poor image quality due to
unprofessional disassemble. Please contact after-sale service for desiccant replacement if
there is condensed fog found on the lens after unpacking or when the desiccant turns
green. (Not all models are included with the desiccant).

Important Safeguards and Warnings IV
It is recommended to use the device together with lightning arrester to improve lightning
protection effect.
It is recommended to ground the device to enhance reliability.
Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air
blower, or you can wipe the lens gently with soft cloth that moistened with alcohol.
Device body can be cleaned with soft dry cloth, which can also be used to remove
stubborn stains when moistened with mild detergent. To avoid possible damage on device
body coating which could cause performance decrease, do not use volatile solvent such as
alcohol, benzene, diluent and so on to clean the device body, nor can strong, abrasive
detergent be used.
Dome cover is an optical component, do not touch or wipe the cover with your hands
directly during installation or operation. For removing dust, grease or fingerprints, wipe
gently with moisten oil-free cotton with diethyl or moisten soft cloth. You can also air blower
to remove dust.
Please strengthen the protection of network, device data and personal information by
adopting measures which include but not limited to using strong password, modifying
password regularly, upgrading firmware to the latest version, and isolating computer
network. For some device with old firmware versions, the ONVIF password will not be
modified automatically along with the modification of the system password, and you need
to upgrade the firmware or manually update the ONVIF password.
Use standard components or accessories provided by manufacturer and make sure the
device is installed and maintained by professional engineers.
The surface of the image sensor should not be exposed to laser beam radiation in an
environment where a laser beam device is used.
Do not provide two or more power supply sources for the device unless otherwise specified.
A failure to follow this instruction might cause damage to the device.

Regulatory Information V
Regulatory Information
The regulatory information herein might vary according to the model you purchased. Some
information is only applicable for the country or region where the product is sold.
FCC Information
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
FCC conditions:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause
undesired operation.
FCC compliance:
This equipment has been tested and found to comply with the limits for a digital device,
pursuant to part 15 of the FCC Rules. This equipment generate, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communication.
For class A device, these limits are designed to provide reasonable protection against
harmful interference in a commercial environment. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
For class B device, these limits are designed to provide reasonable protection against
harmful interference in a residential installation. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.

Table of Contents VI
Table of Contents
Foreword.................................................................................................................................................... I
Important Safeguards and Warnings.................................................................................................... III
Regulatory Information............................................................................................................................V
1 Introduction............................................................................................................................................ 1
Device Ports.................................................................................................................................. 11.1 Connecting Alarm Input/Output..................................................................................................... 2
1.2
2 Network Configuration.......................................................................................................................... 4
Initializing Device.......................................................................................................................... 42.1 Modifying Device IPAddress........................................................................................................ 52.2 Logging in to Web Interface.......................................................................................................... 62.3
3 Installation.............................................................................................................................................. 7
Packing List................................................................................................................................... 73.1 Dimension..................................................................................................................................... 73.2 Installing Device............................................................................................................................ 83.3 3.3.1 Installation Method.............................................................................................................. 8
3.3.2 Installing SD Card (Optional).............................................................................................. 8
3.3.3 Threading Cable................................................................................................................. 8
3.3.4 Attaching Device................................................................................................................. 9
3.3.5 Wrapping Waterproof Tape (Optional)...............................................................................11
3.3.6 Adjusting Lens Angle........................................................................................................ 12

Introduction 1
1 Introduction
Device Ports1.1
Device ports might vary with different models, and the actual product shall prevail.
Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit
and water damage. For the detailed operation, see the FAQ Manual.
Device portsFigure 1-1
For more information about device ports, see Table 1-1.
Table 1-1 Device ports information
No.
Port Name
Description
1
Power input
Inputs 12V DC or 24V AC power. Please be sure to supply power
as instructed in the manual.
Device abnormity or damage could occur if power is not supplied
correctly.
2
Ethernet
Connects to network with network cable.

Provides power to the device with PoE.

3
RS-485
Controls external devices, such as PTZ.
4
Alarm I/O
(pin1–pin8)
Includes alarm signal input and output ports. See Table 1-2.
Power output
(pin9–pin10)
Outputs 12V DC 2W power.
5
Audio output
Connects to speaker to output audio signal.
Audio input
Connects to sound-pick-up device to receive audio signal.
6
CVBS
Outputs analog video signal.

Introduction 2
Table 1-2 Alarm I/O port introduction
Port
Port Name
Description
Alarm I/O
ALARM_IN (pin1–
pin3)
Receives the switch signal of external alarm
source.
Connect all the alarm input devices to the same
GND port.
GND (pin4)
ALARM_NO1 (pin5)
Outputs alarm signal to alarm output device.
When connecting to alarm output device, only the
ALARM_NO port andALARM_COM port with the
same number can be used together.
ALARM_NO2 (pin7)
ALARM_COM1 (pin6)
ALARM_COM2 (pin8)
Connecting Alarm Input/Output1.2
Alarm input/output is available on select models.
Connect alarm input device to the alarm input end of the I/O port. See Figure 1-2.Step 1 Device collects different states of alarm input port when the input signal is idling and
grounded.
Device collects logic "1" when input signal is connecting to +3V to +5V or idling.
Device collects logic "0" when input signal is grounded.
Alarm inputFigure 1-2
Connect alarm output device to the alarm output end of the I/O port. The alarm outputStep 2 is relay switch output, which can only connect to NO alarm devices.
The ALARM_OUT port and the ALARM_OUT_GND port with the same number
constitute a switch for alarm output. See Figure 1-3. The switch is open normally and
closes when there is alarm output.

Introduction 3
Alarm outputFigure 1-3
Log in web interface, and configure alarm input and alarm output in alarm setting.
Step 3
The alarm input on the web interface is corresponding to the alarm input end of the
I/O port. There will be high level and low level alarm signal generated by the alarm
input device when alarm occurs, set the input mode to "NO" (default) if the alarm
input signal is logic "0" and to "NC" if the alarm input signal is logic "1".
The alarm output on the web interface is corresponding to the alarm output end of
the device, which is also alarm output end of the I/O port.

Network Configuration 4
2 Network Configuration
Device initialization and IP address setting can be finished with the "ConfigTool" or on web
interface. For more information, see the WEB Operation Manual.
Device initialization is available on select models, and it is required at first use or after the
device being reset.
Device initialization is available only when the IP addresses of the device (192.168.1.108
by default) and the PC stay in the same network segment.
Plan useable network segment properly to connect the device to the network.
The following figures and interfaces are for reference only, and the actual product shall
prevail.
Initializing Device2.1
Double-click "ConfigTool.exe" to open the tool.Step 1
Click .Step 2
The Modify IP interface is displayed. See Figure 2-1.
Modify IPFigure 2-1
Click Search setting.Step 3 The Setting interface is displayed.
Enter the start IP address and end IP address of the network segment in which youStep 4 want to search devices, and then click OK.
All the devices found in the network segment are listed.
Select one or several devices whose Status shows Uninitialized, and then clickStep 5 Initialize.

Network Configuration 5
The Device initialization interface is displayed.
Select the devices that need initialization, and then click Initialize.Step 6 The password setting interface is displayed. See Figure 2-2.
Password settingFigure 2-2
Set and confirm the password of the devices, then enter a valid email address, and
Step 7 then click Next.
The final setting interface is displayed.
Password can be modified or reset in System Settings.
Select the options according to your needs, and then click OK.Step 8 The Initialization interface is displayed after initialization is completed. Click the
success icon ( ) or the failure icon ( ) for the details.
Click Finish.Step 9 The device status on the Modify IP interface (Figure 2-1) turns to Initialized.
Modifying Device IP Address2.2
You can modify IP address of one or multiple devices in one time. This section is based on
modifying IP addresses in batch.
Modifying IPaddresses in batch is available only when the corresponding devices have the
same login password.
Do "Step 1" to "Step 4" in "2.1 Initializing Device" to search for devices in your networkStep 1 segment.
After clicking Search setting, enter the username and password, and make sure they
are the same as what you set during initialization, otherwise there will be wrong
password notice.
Select the devices whose IP addresses need to be modified, and then click Modify IP.Step 2 The Modify IP Address interface is displayed. See Figure 2-3.

Network Configuration 6
Modify IPAddressFigure 2-3
Select Static mode, and then enter start IP, subnet mask, and gateway.Step 3
IP addresses of multiple devices will be set to the same if you select the Same IP
check box.
If DHCP server is available in the network, devices will automatically obtain IP
addresses from DHCP server when you select DHCP.
Click OK.Step 4
Logging in to Web Interface2.3
Open IE browser, then enter the IP address of the device in the address bar, and thenStep 1 press Enter.
If the setup wizard is displayed, finish the settings as instructed.
Enter the user name and password in the login box, and then click Login.Step 2 For the first login, click Click Here to Download Plugin, and then install the plugin asStep 3 instructed.
The main interface is displayed when the installation is finished. See Figure 2-4.
Main interfaceFigure 2-4

Installation 7
3 Installation
Packing List3.1
The tool required for the installation such as electric drill is not provided in the packing.
The operation manual and related tool are contained in the disk or the QR code, and the
actual packing shall prevail.
Dimension3.2
The following figures are for reference only, and the actual product shall prevail.
Unit (mm [inch])

Installation 8
Installing Device3.3
3.3.1 Installation Method
3.3.2 Installing SD Card (Optional)
Disconnect the power before installing or removing the SD card.
Press and hold the reset button for 10 s to reset the camera.
3.3.3 Threading Cable
This section takes threading network cable for example.

Installation 9
3.3.4 Attaching Device
Make sure the mounting surface is strong enough to hold at least three times of the weight of
the device and bracket.

Installation 10
Cable going through the mounting surface

Installation 11
Cable going through the side cable tray
3.3.5 Wrapping Waterproof Tape (Optional)
This part is needed when the cable connector is out of the junction box.

Installation 12
3.3.6 Adjusting Lens Angle

ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
Address: No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China
Postcode: 310053
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.dahuasecurity.com
