Dahua DH-PFS6428-24T Instruction sheet

L3 Manage Switch
CLI Configuration Manual
(Applicable to DH-PFS6428-24T)

Contents
CLI Configuration Manual.....................................................................................................................1
1. System Status Commands.......................................................................................................7
1.1 Mode Description.............................................................................................................7
1.2 System information..........................................................................................................8
Function Brief..................................................................................................................8
1.2.1 show version..........................................................................................................8
1.2.2 show clock.............................................................................................................8
1.3 Log information.................................................................................................................9
Function Brief..................................................................................................................9
1.3.1 show logging..........................................................................................................9
1.4 Port statistics ....................................................................................................................9
Function Brief..................................................................................................................9
1.4.1 show interface.....................................................................................................10
1.5 LACP status....................................................................................................................10
Function Brief................................................................................................................10
1.5.1 lacp state..............................................................................................................10
1.6 View route.......................................................................................................................11
Function Brief................................................................................................................11
1.6.1 show ip route.......................................................................................................11
1.7 ERPS-RING status........................................................................................................12
Function Brief................................................................................................................12
1.7.1 show erps.............................................................................................................12
1.8 Power status...................................................................................................................12
Function Brief................................................................................................................12
1.8.1 show power..........................................................................................................12
2. System Setting Commands....................................................................................................13
2.1 IP config...........................................................................................................................13
Function Brief................................................................................................................13
2.1.1 ip address ............................................................................................................13
2.1.2 ip address dhcp...................................................................................................13
2.1.3 ip address old_ip.................................................................................................14
2.1.4 show interface.....................................................................................................14
2.2 User config......................................................................................................................15
Function Brief................................................................................................................15
2.2.1 username name..................................................................................................15
2.2.2 show user.............................................................................................................16
2.3 Time setting.....................................................................................................................16
Function Brief................................................................................................................17
2.3.1 sntp enable|disable.............................................................................................17
2.3.2 sntp unicast-server.............................................................................................17
2.3.3 sntp auto-sync timer...........................................................................................18
2.3.4 sntp connect........................................................................................................18
2.3.5 sntp timezone set................................................................................................18
2.3.6 local-time date.....................................................................................................19
3. Port configuration commands ................................................................................................20
3.1 Port config.......................................................................................................................20
Function Brief................................................................................................................20
3.1.1 duplex...................................................................................................................20
3.1.2 speed....................................................................................................................21
3.1.3 flow-control ..........................................................................................................21
3.1.4 shutdown..............................................................................................................22
3.1.5 description............................................................................................................22
3.2 Rate limit .........................................................................................................................22
Function Brief................................................................................................................22

3.2.1 rate-limit................................................................................................................23
3.3 Port mirroring..................................................................................................................23
Function Brief................................................................................................................23
3.3.1 monitor..................................................................................................................23
3.4 Link aggregation.............................................................................................................24
Function Brief................................................................................................................24
3.4.1 trunk......................................................................................................................24
3.4.2 load-balance........................................................................................................25
3.4.3 lacp enable | disable...........................................................................................25
3.4.4 lacp active | passive...........................................................................................26
3.4.5 lacp key................................................................................................................26
3.4.6 lacp port-priority..................................................................................................27
3.4.7 example................................................................................................................27
4. Advanced configuration commands......................................................................................29
4.1 VLAN config....................................................................................................................29
Function Brief................................................................................................................29
4.1.1 switchport mode..................................................................................................30
4.1.2 switchport pvid ....................................................................................................30
4.1.3 switchport trunk|hybrid| access.........................................................................31
4.1.4 show vlan.............................................................................................................31
4.1.5 example................................................................................................................32
4.2 QinQ config.....................................................................................................................33
Function Brief................................................................................................................33
4.2.1 qinq.......................................................................................................................33
4.2.2 qinq otpid..............................................................................................................33
4.3 MAC config......................................................................................................................34
Function Brief................................................................................................................34
4.3.1 mac-address aging-time....................................................................................34
4.3.2 show mac-address .............................................................................................35
4.4 ARP config......................................................................................................................35
Function Brief................................................................................................................35
4.4.1 show arp...............................................................................................................36
4.4.2 arp static...............................................................................................................36
4.4.3 arp timeout...........................................................................................................36
4.5 MSTP config...................................................................................................................37
Function Brief................................................................................................................37
4.5.1 spanning-tree.......................................................................................................38
4.5.2 spanning-tree mode ...........................................................................................38
4.5.3 spanning-tree max-age......................................................................................39
4.5.4 spanning-tree hello-time....................................................................................39
4.5.5 spanning-tree forward-delay.............................................................................39
4.5.6 spanning-tree max-hop......................................................................................40
4.5.7 spanning-tree instance.......................................................................................40
4.5.8 spanning-tree mstp name..................................................................................41
4.5.9 spanning-tree mstp revision..............................................................................41
4.5.10 show spanning-tree..........................................................................................41
4.5.11 show spanning-tree interface brief.................................................................42
4.6 IGMP-snooping ..............................................................................................................42
Function Brief................................................................................................................43
4.6.1 igmp-snooping.....................................................................................................43
4.6.2 igmp-snooping host-age-time...........................................................................43
4.6.3 igmp-snooping fast-leave..................................................................................44
4.6.4 igmp-snooping static-group...............................................................................44
4.6.5 show igmp-snooping group...............................................................................45
4.6.6 example................................................................................................................45
4.7 DHCP server...................................................................................................................46

Function Brief................................................................................................................46
4.7.1 ip dhcpd................................................................................................................46
4.7.2 dhcp pool..............................................................................................................47
4.7.3 network.................................................................................................................47
4.7.4 default-router.......................................................................................................48
4.7.5 dns-server............................................................................................................48
4.7.6 static......................................................................................................................48
4.7.7 lease.....................................................................................................................49
4.7.8 domain-name ......................................................................................................50
4.7.9 nbns-server..........................................................................................................50
4.7.10 example..............................................................................................................50
4.8 DHCP relay.....................................................................................................................51
Function Brief................................................................................................................51
4.8.1 ip helper-address................................................................................................51
4.9 DHCP snooping..............................................................................................................52
Function Brief................................................................................................................52
4.9.1 ip dhcp-snooping ................................................................................................52
4.9.2 ip dhcp-snooping trust........................................................................................53
4.9.3 show ip dhcp-snooping lease ...........................................................................53
4.10 QoS config....................................................................................................................54
Function Brief................................................................................................................54
4.10.1 remask................................................................................................................54
4.10.2 cos default.........................................................................................................55
4.10.3 trust.....................................................................................................................55
4.10.4 cos map..............................................................................................................56
4.10.5 dscp map...........................................................................................................56
4.10.6 scheduler policy................................................................................................57
4.10.7 example..............................................................................................................57
4.11 VRRP.............................................................................................................................59
Function Brief................................................................................................................59
4.11.1 vrrp advertisement............................................................................................59
4.11.2 vrrp ip..................................................................................................................60
4.11.3 vrrp preempt......................................................................................................60
4.11.4 vrrp preempt time..............................................................................................61
4.11.5 vrrp priority.........................................................................................................61
4.11.6 example..............................................................................................................62
5. Routing configuration commands..........................................................................................64
5.1 Interface config...............................................................................................................64
Function Brief................................................................................................................64
5.1.1 interface................................................................................................................64
5.1.2 shutdown / no shutdown....................................................................................64
5.1.3 ip address ............................................................................................................65
5.1.4 show interface.....................................................................................................65
5.2 Static routing...................................................................................................................66
Function Brief................................................................................................................66
5.2.1 ip route..................................................................................................................66
5.2.2 show ip route.......................................................................................................67
5.2.3 example................................................................................................................67
5.3 OSPF config....................................................................................................................70
Function Brief................................................................................................................70
5.3.1 router ospf .............................................................................................................70
5.3.2 network.................................................................................................................71
5.3.3 router-id................................................................................................................71
5.3.4 timers throttle spf................................................................................................72
5.3.5 default-metric.......................................................................................................72
5.3.6 passive-interface default....................................................................................73

5.3.7 redistribute...........................................................................................................73
5.3.8 default-information originate .............................................................................74
5.3.9 ip ospf...................................................................................................................74
5.3.10 show ip ospf.......................................................................................................76
5.3.11 example..............................................................................................................76
5.4 BGP config......................................................................................................................78
Function Brief................................................................................................................78
5.4.1 router bgp ............................................................................................................79
5.4.2 timers bgp............................................................................................................79
5.4.3 redistribute...........................................................................................................80
5.4.4 neighbor...............................................................................................................80
5.4.5 network..................................................................................................................80
5.4.6 example................................................................................................................81
5.5 RIP config........................................................................................................................82
Function Brief................................................................................................................83
5.5.1 default-information originate..............................................................................83
5.5.2 default-metric .......................................................................................................83
5.5.3 distance.................................................................................................................84
5.5.4 end.........................................................................................................................84
5.5.5 exit/quit..................................................................................................................85
5.5.6 network..................................................................................................................85
5.5.7 offset-list................................................................................................................85
5.5.8 passive-interface..................................................................................................86
5.5.9 redistribute............................................................................................................87
5.5.10 timer.....................................................................................................................87
5.5.11 version.................................................................................................................88
5.5.12 example.............................................................................................................88
6. Network security commands..................................................................................................91
6.1 Anti-attack .......................................................................................................................91
Function Brief................................................................................................................91
6.1.1 system ignore icmp-echo...................................................................................91
6.1.2 system protection syn-ack.................................................................................91
6.1.3 system rate-limit..................................................................................................92
6.2 MAC binding...................................................................................................................92
6.2.1 mac-address static .............................................................................................93
6.3 ARP binding....................................................................................................................93
Function Brief................................................................................................................93
6.3.1 ip-mac bind..........................................................................................................94
6.3.2 show ip-mac bind................................................................................................95
6.4 ACL config.......................................................................................................................95
Function Brief................................................................................................................95
6.4.1 mac acl.................................................................................................................96
6.4.2 ip acl......................................................................................................................96
6.4.3 rule........................................................................................................................97
6.4.4 ip/mac access-group..........................................................................................97
6.5 802.1X config..................................................................................................................98
Function Brief................................................................................................................98
6.5.1 dot1x.....................................................................................................................98
6.5.2 dot1x auth-server................................................................................................99
6.5.3 dot1x auth-server type.......................................................................................99
6.5.4 dot1x acct-sever................................................................................................100
6.5.5 dot1x timer.........................................................................................................100
6.5.6 dot1x auth-mode...............................................................................................101
6.5.7 dot1x controlled-mode .....................................................................................101
6.5.8 dot1x auth..........................................................................................................102
6.5.9 dot1x auth-user.................................................................................................102

6.6 Port isolation.................................................................................................................102
Function Brief..............................................................................................................103
6.6.1 switchport protected.........................................................................................103
6.7 Storm control.................................................................................................................103
Function Brief..............................................................................................................103
6.7.1 storm-control broadcast pps............................................................................104
6.7.2 storm-control multicast pps.............................................................................104
6.7.3 storm-control unicast pps ................................................................................105
6.8 ERPS-RING config......................................................................................................105
Function Brief..............................................................................................................105
6.8.1 loop-protection ..................................................................................................105
6.8.2 loop-protection tx-time .....................................................................................106
6.8.3 loop-protection transmit...................................................................................106
6.8.4 show loop-protection........................................................................................107
6.8.5 example..............................................................................................................107
6.9 ERPS-E config..............................................................................................................109
Function Brief..............................................................................................................109
6.9.1 erps..................................................................................................................... 110
6.9.2 erps xx................................................................................................................ 110
6.9.3 show erps........................................................................................................... 111
6.9.4 example.............................................................................................................. 111
6.10 IP source guard..........................................................................................................113
Function Brief.............................................................................................................. 113
6.10.1 ip source-guard............................................................................................... 113
6.10.2 ip source-guard trust...................................................................................... 114
6.10.3 ip dhcp-snooping binding..............................................................................114
6.10.4 show ip source-guard.....................................................................................115
7. Network management commands.......................................................................................116
7.1 HTTP config.................................................................................................................. 116
Function Brief.............................................................................................................. 116
7.1.1 ip http-server http.............................................................................................. 116
7.1.2 ip http-server https............................................................................................ 116
7.2 SNMP config................................................................................................................. 117
Function Brief.............................................................................................................. 117
7.2.1 snmp................................................................................................................... 117
7.2.2 snmp-server trap2sink .....................................................................................118
7.2.3 snmp-server trap............................................................................................... 118
7.2.4 snmp-server community..................................................................................119
7.2.5 snmp host ..........................................................................................................119
7.2.6 snmp-server user.............................................................................................. 119
7.2.7 example..............................................................................................................120
8. System maintenance commands.........................................................................................122
8.1 Reboot...........................................................................................................................122
Function Brief..............................................................................................................122
8.1.1 reboot..................................................................................................................122
8.2 Restore factory.............................................................................................................122
Function Brief..............................................................................................................122
8.2.1 default configure...............................................................................................123
8.3 Config management....................................................................................................123
Function Brief..............................................................................................................123
8.3.1 write ....................................................................................................................123
8.4 PING test.......................................................................................................................124
Function Brief..............................................................................................................124
8.4.1 ping.....................................................................................................................124

1. System Status Commands
1.1 Mode Description
Command Description
How to enter and exit each mode (the privilege mode, global mode,
and interface mode)
Parameter
None
Default
None
Command Mode
Privileged mode
Example
username: admin
password: admin（Hidden）
switch#
switch# exit
press ENTER to get started
username:
// This command is used to enter the privileged mode, and the exit
command is used to exit the privileged mode.
switch# configure terminal
switch(config)# exit
switch#
// This command is used to enter the global mode, and the exit command is
used to exit the global mode and return to the privileged mode.
switch# configure terminal
switch(config)# interface G1
switch(config-G1)# exit
switch(config)#
// This command is used to enter the G1 interface mode from the global
mode, and the exit command is used to exit the interface mode.
switch(config)# interface vlan1
switch(config-vlanif1)# exit
switch(config)#

// This command is used to enter the vlan1 interface mode from the global
mode, and the exit command is used to exit the vlan1 interface mode.
1.2 System information
Function Brief
This module is used to display the device name, software version,
hardware version, MAC address, compile time, run time, and current system
time.
1.2.1 show version
Command Description
This command is used to display the version information, including
the device name, software version, hardware version, MAC address,
compile time, system run time, current version information, and
backup version information.
Parameter
None
Default
None
Command Mode
Privileged mode(To enter the privileged mode, connect a serial port,
and enter the user name and password. To exit the privileged mode, run the
exit command.)
Example
username: admin
password: admin（The password is hidden.）
switch# show version
1.2.2 show clock
Command Description

This command is used to display the current system time.
Parameter
None
Default
None
Command Mode
Privileged mode
Example
switch# show clock
1.3 Log information
Function Brief
This module is used to display system logs when the system is
running, so that maintenance staff can conveniently analyze relevant
problems.
1.3.1 show logging
Command Description
This command is used to display the current log of the switch.
Parameter
None
Default
None
Command Mode
Privileged mode
Example
switch# show logging
1.4 Port statistics
Function Brief
The port statistics module is used to display the number of
sent/received packets, sent/received bytes, and number of sent/received
error packets on every port.

1.4.1 show interface
Command Description
This command is used to display the packet statistics of one or more
ports.
Parameter
<cr>
It is used to display data statistics of all ports.
G<1-24>
It is used to display data statistics
Default
None
Command Mode
Privileged mode
Example
switch# show interface G1
1.5 LACP status
Function Brief
This function module is used to display the LACP port configurations.
1.5.1 lacp state
Command Description
This command is used to display the status of the LACP system.
Parameter
None
Default
None
Command Mode

Global configuration mode
Example
switch(config)# lacp state
1.6 View route
Function Brief
The function module is used to display switch routing information.
1.6.1 show ip route
Command Description
This command is used to display the router information.
Parameter
bgp
View the BGP routing information
connected
View the connected routing information
ospf
View the ospf routing information
rip
View the rip routing information
static
View the static routing information
A.B.C.D
View contains specific IP routing information
A.B.C.D/M
View of a routing information
summary
View all routing summary information
Default
None
Command Mode
Privileged mode
Example
switch# show ip route connected

1.7 ERPS-RING status
Function Brief
The function module is used to display erps information.
1.7.1 show erps
Command Description
This command is used to display the erps information.
Parameter
None
Default
None
Command Mode
Privileged mode
Example
switch# show erps
1.8 Power status
Function Brief
The function module is used to display power supply information.
1.8.1 show power
Command Description
This command is used to display the power supply information.
Parameter
None
Default
None
Command Mode
Privileged mode
Example
switch# show power

2. System Setting Commands
2.1 IP config
IP address configuration commands include:
ip address
ip address dhcp
ip address old_ipA.B.C.D/M new_ipA.B.C.D/M
show ip interface
notice:A.B.C.D/M,Example:192.168.1.1/24
Function Brief
The IP configuration module is used to add, delete or display the
interface IP information of a switch.
2.1.1 ip address
Command Description
Configure IP port for A.B.C.D/M
no ip addressA.B.C.D/M
//Delete ports IP A.B.C.D/M
Parameter
None
Default
VLAN 1 interface
Command Mode
VLAN interface configuration mode
Example
switch(config)# interface vlanif1
switch(config-vlanif1)#ip address 192.168.100.1/24
switch(config-vlanif1)#no ip address 192.168.100.1/24
2.1.2 ip address dhcp
Command Description
Configure IP port for automatic access (network DHCP server will
assign a dynamic IP) for the switch port.
no ip address dhcp

//Disables the IP of the interface to access automatically.
Parameter
None
Default
Open port
Command Mode
Interface configuration mode
Example
switch(config)# interface vlanif1
switch(config-vlanif1)#ip address dhcp
switch(config-vlanif1)#no ip address dhcp
2.1.3 ip address old_ip
Command Description
ip address old_ipA.B.C.D/M new_ipA.B.C.D/M
Change the IP configuration of the interface (amend the old_ip to
new_ip)
Parameter
None
Default
None
Command Mode
Interface configuration mode
Example
switch(config)# interface vlanif1
switch(config-vlanif1)#ip address old_ip 192.168.255.1/24 new_ip
192.168.10.1/24
2.1.4 show interface
Command Description
This command is used to display the interface IP information.
Parameter
None
Default
Enabled port
Command Mode
Privileged mode and Global configuration mode

Example
switch(config)#show interface vlanif1
switch#show interface vlanif1
2.2 User config
User configuration commands include:
username name
show user
Note: name indicates the user name, which is a string of 1 to 32
characters. password indicates the password, which is a string of 1 -
32 characters.level indicates the user level, which ranges from 1
(lowest management rights) to 15 (highest management rights).
Function Brief
This function module is used to display, modify or add user
information so as to protect the switch configurations.
2.2.1 username name
Command Description
username name password passwd privilege level
//This command is used to add a user, modify the password of an existing
user, modify the management rights of an existing user, or modify the
password and management rights of an existing user.
no username name
//This command is used to delete a known user.
Parameter
guest
permissions for all users of the guest is limited to check the
system status information under the menu bar
admin
permissions for the admin user, you can add, modify, delete
all configuration

Default
admin
Command Mode
Global configuration mode
Example
switch(config)#username test password test
//Add a user "test", it is the default password is testing and rights: the
guest.
switch(config)#username test password test privilege admin
//Modify user: test, password: test, permissions: admin.
switch(config)#username test password test privilege guest
//Modify user: the test management authority for the guest.
switch(config)#no username test
//Delete user test.
2.2.2 show user
Command Description
This command is used to display all the current user configurations
of the switch.
Parameter
None
Default
None
Command Mode
Privileged mode
Example
Switch#show user
2.3 Time setting
The configuration commands include:
sntp enable|disable
sntp unicast-server
sntp auto-sync timer
sntp connect
sntp timezone
local-time date

Function Brief
When enabled, this function can be used to automatically
synchronize the switch time with the network time.
2.3.1 sntp enable|disable
Command Description
ntp:
//This command is used to enable the NTP function.
no ntp:
//This command is used to disable the NTP function.
Parameter
None
Default
Disable
Command Mode
Global configuration mode
Example
switch(config)#sntp enable
switch(config)#sntp disable
2.3.2 sntp unicast-server
Command Description
sntp unicast-server A.B.C.D
//This command is used to add the IP address of an NTP server.
no sntp unicast-serverA.B.C.D
//This command is used to delete the ip address of an NTP server.
Parameter
None
Default
None
Command Mode
Global configuration mode
Example
Switch(config)#sntp unicast-server 210.21.196.6

2.3.3 sntp auto-sync timer
Command Description
This command is used to set the SNTP synchronization time
interval.
Parameter
sntp auto-sync timer time,time Values range 5-65535s, 300s default
value.
Default
300s
Command Mode
Global configuration mode
Example
Switch(config)#sntp auto-sync timer 5
2.3.4 sntp connect
Command Description
sntp connect A.B.C.D
//This command is used to select the SNTP server to connect.
Parameter
None
Default
None
Command Mode
Global configuration mode
Example
switch(config)#sntp connect 210.21.196.6
2.3.5 sntp timezone set
Command Description
switch(config)# sntp timezone set<0-39>
//This command is used to select the time zone.
Parameter
<0-39>
Each number represents a time zone, can use SNTP
timezone show view the corresponding relationship

Default
0
Command Mode
Global configuration mode
Example
switch(config)#sntp timezone set 32
/ /Modify the time zone east eight area.
2.3.6 local-time date
Command Description
local-time date YYYY-MM-DD time HH:MM:SS
//Set the local time year - month - day hours: minutes: seconds
Parameter
None
Default
None
Command Mode
Global configuration mode
Example
switch(config)# local-time date 2015-3-18 time 12:12:12
// Note: due to the chip is limited, can only be set after January 1,1970.

3. Port configuration commands
3.1 Port config
Port configuration commands include:
duplex
speed
flow-control
shutdown
description
Function Brief
This module is used to configure basic parameters related to ports of
a switch. These basic parameters directly influence the port working mode.
3.1.1 duplex
Command Description
duplex {auto | full | half }
no duplex
//These commands are used to set the port rate mode.
Parameter
parameter
Parameters of the command mode
auto
Automatic negotiation.
full
Full duplex
half
Half duplex
Default
By default, the duplex modes of all ports areAuto. For an optical port,
the duplex mode is always set to full.
Command Mode
Interface configuration mode
Note:
Light port duplex is fixed, is a full-duplex mode (full).
Example
// This command is used to modify the duplex mode of the G1 port.
switch(config)# interface G1
switch(config-G1)# duplex full
