Daitsu CADR-160 User manual

USER MANUAL
PURIFIER DAITSU
NATURE
Edition
11/21
Models
CADR-160
UM En

Performance
Product Name Air Purier
Rated Voltage 220V-240V~
Rated Frequency 50Hz/60Hz
Product Usage Removes pollutants such as particulate matter, gas
pollutants and microorganisms in the air.
Method of Cleaning 1. Washable pre-lter
2. Composite carbon cloth lter (HEPA+Activated carbon)
Rated Power 50W
Particulates CADR 159m3/h
Particulates CCM P1
Energy Efciency Index Qualied (Particulates)
Noise 57dB(A)
Applicable area 14-24 m2
Product size 325x172x515mm
Weight 5,7kg
Product Structure
Operation panel
Buckle
Air outlet
Handle
Sensor

Air Quality Indicator
Air quality indication lamp Power Sleep Mode Filter Reminder
Speed Child Lock
Installation
♦ Install lter
First, remove the lter from the plastic bag.
1. Remove the air inlet.
2. Remove the lter.
3. Remove the lter from the plastic bag.
Note: Make sure to remove the plastic
bag from the lter before use.
Press the “PUSH” on both sides of the front
cover and open the front cover.
Note: There are internal and external points, the one with the pull tab facing out; be sure to
install the front panel before use.

Filter care and maintenance
1. Pre-lter (about half a month).
Use a vacuum cleaner to remove dust from the surface of the lter, or
wash it with water and dry it thoroughly.
2. HEPA+ activated carbon composite lter (about once every two months).
When the 1500 hour lter replacement prompt ashes, press and
hold the reset button to clear the lter indicator light and reset the timing
function.
• Place the lter in a ventilated place so that the harmful gases and bacteria on the surface
of the lter can be volatilized. Do not expose it to excessive sunlight.
• Do not wash the lter with water.
Tips
• Unplug the power plug before cleaning and maintenance.
• Do not operate with the lter removed (no dust removal effect, and the dust that is
inhaled may cause equipment failure).
• Unplug the power cord when it is idle for a long time (it will also consume power in the
standby state).
• Depending on the place of use and the method of use (for example, households with a
large number of smokers or areas with severe air pollution), the lter replacement cycle
may be shortened. If the ltration effect is not obvious, replace the lter in time.
When replacing the lter, please turn off the power rst.

How to use
1. After plugging in the power, you will hear a sound “Di”, the machine enters standby
mode, and the power indicator will shows red color.
2. Boot
After the power is turned on, the air quality indicator light is completely white,
the machine enters the automatic mode.
3. Timer
The machine’s working time can be set by the timer button while the machine
is running. Set the time to 1 hour, 2 hours, 4 hours, 8 hours, press again to turn
off, the selected time is displayed on the screen.
4. Speed
Press the wind speed button to change the speed of the motor. It is divided into
AUTO, rst gear, second gear, third gear, sleep. When pressed, the machine
increases one gear from the current gear position, and then returns to the
automatic mode les.
In AUTO mode, PM2.5 corresponds to the corresponding table of air quality
and gear position in the intelligent mode of speed:
1~100 = green light = excellent air quality = rst gear.
101~200 = yellow light = good air quality = second gear.
201~500 = red light = poor air quality = third gear.
5. Child Lock
When the child lock button is pressed, the button function of the machine enters
the locked state, and all the buttons cannot be operated. Long Press this button
for 3 seconds to unlock.
6. Reset
This unit is equipped with a timing change lter function, which will ash until
the 1500 hour lter replacement prompt. Press and hold the reset button for
5 seconds to clear the lter indicator and reset the timing function.
7. Power off
When the power is on, touch the “Power” button on the operation, and the
machine enters the standby state. (The icon light is on when the machine
enters the standby state.)

Precautions
♦Installation instructions
1. Do not place in the following places:
• Direct sunlight or facing the air outlet and heated places (may
cause deformation, Deterioration, discoloration, and failure).
• Equipment accessories such as TVs and radios (which may
cause image distortion and noise). Please place it at a distance
of 1m or more. At the same time, if the same socket is used with
these devices, image plugging and noise may occur when the
power plug is inserted.
When this happens, plug the power cord into a different outlet.
2. For indoor dust such as pollen, the product should be placed
on the ground. Since pollen, dust, etc. are likely to fall near the
oor, it is recommended to place the product on a at oor in the
room.
3. In order to effectively circulate the air in the room.
In order not to block the air inlet and outlet, place the product
about 30cm or more from the left and right sides of the wall,
furniture, curtains, etc. In order to use this product more
effectively, please keep the back of the product at least 20cm
away from the wall.
4. Do not place objects on the main unit (otherwise it may cause
the machine to malfunction). Special Note: Do not place magnets
and metal objects.
5. Do not block the air inlet and outlet, for example, do not place
objects on the air outlet. Or in front of the air inlet.
Sun
1m
30cm
20cm
goods
outlet
inlet

Warning
Prohibited
1. The machine is prohibited from moving or shaking while it is running.
Do not pull on the power cord while moving or storing it. Pulling the
power cord may cause a short circuit or damage to the inside of the
power cord, resulting in re or electric shock.
2. Do not damage the power cord or plug, and do not cut, excessively
twist, pull, or twist the power cord. If the power cord is damaged,
it must be replaced by the manufacturer, service department or
professional to avoid danger. Non-professionals are prohibited from
disassembling the machine to avoid the risk of electric shock.
3. The plug and hand should not be exposed to water before plugging
in the power plug, otherwise there is a danger of electric shock.
4. Do not use power supplies, universal sockets or connected devices
that exceed the rated value.220V ~ 5A AC power. Using a universal
outlet that exceeds the rated value or power supply may cause the
power cord to overheat and cause a re.
5. Do not touch the power plug with wet hands, which may result in
electric shock.
6. Do not put your ngers or metal objects into the gap of the air outlet,
otherwise it may cause electric shock or injury. Do not allow water,
ammable detergents or other liquids to enter the product to avoid
electric shock or re.
7. This product is not a substitute for normal ventilation equipment,
daily vacuum cleaners and range hoods used in the kitchen.
8. Do not use this product in gas appliances, heating devices or stove
accessories.
9. Do not use this product in a wet or hot environment such as a
bathroom, toilet or kitchen.
10. Never place products in such locations.
• Unstable locations (otherwise the product may fall or fall over,
resulting in injury, electric leakage, electric shock or re).
• Locations that are hot, humid, or wet, such as bathrooms (air puriers
may cause electric shock or re due to electric leakage) a place
where the kitchen emits soot.
11. Do not use air puriers in indoors with incense-based insecticides.
• Chemical residues may accumulate in the machine and then be
released from the air outlet to endanger your health.
• After using the insecticide, allow the room to be thoroughly ventilated
before using the air purier.
220V~
5A

12. It is not recommended to use an air purier when burning incense or
mosquito coils, otherwise the lter of the air purier will leave an odor.
Mandatory matters
Mandatory matters
1. Turn off the power of the machine immediately when any of the following
conditions occur (may cause electric shock, sparks or smoke).
• There is abnormal sound or vibration during operation.
• The product is abnormally hot and has a burnt odor.
2. Please clean the power plug regularly.
• If the power plug is dusty, moisture may damage the insulated part of the plug, resulting
in a re.
• If the appliance is not used for a long time, please unplug the power cord.
3. Be sure to disconnect the power before performing maintenance on the
appliance.
• The product may suddenly start, causing electric shock and injury.
4. Plug the plug securely into the power outlet (if the plug is not securely inserted, it
may cause electric shock due to overheating or even cause a re).
• Do not use a damaged plug or a loose power outlet.
5. Please pull the power plug from the insulated part of the hand-held plug.
• Pull the power cord to pull off the power plug, which may cause damage to the power
cord, electric shock, short circuit, or re.
6. When any of the following conditions occur, please turn off the
power of the machine immediately and look for the maintenance
department.
• The switch does not work.
• The power cord or plug is abnormally hot.
• I noticed an abnormal sound or vibration.
• There are any other abnormalities or malfunctions.
7. Non-professionals are prohibited from disassembling the machine to avoid the
risk of electric shock.
For IEC: This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.
For EN: This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.

Troubleshooting
♦Common fault phenomenon, fault code description and
troubleshooting
Fault phenomenon Inspection / solution
Can’t turn on or press button no
response.
1. Is the power cord plug plugged in?
→ Plug in the power cord.
2. Is the front cover of the purier covered?
→ Cover the front cover of the purier.
Button no response.
1. Is the lter dirty?
→ Clean the lter.
2. Is the lter not replaced for a long time?
→ Replace the lter with a new one.
The smell of the air outlet makes
people feel uncomfortable.
1. Is the plastic bag on the lter screen removed
by the purier?
→ Remove the plastic bag from. The lter before
using it for the rst time.
2. Is the order of the purier lter incorrectly
installed?
→ Please refer to the instructions for the
installation sequence and precautions.
The purier runs for a long
time but the air quality is not
signicantly improved.
The lter alarm light is on: it indicates that the lter
timing change timer has reached the set value.
At this time, after changing the lter screen, press
and hold the sleep to reset.

Packing details
Body 1pc
Main lter 1set
Primary lter 1pc
Product Manual 1pc
Move control 1pc

WiFi Instructions
1. Scan and download
1) Download “Smart Life” APP.
2) Log in the APP after registration (suitable for Android or
ios system).
2. Add device
1) The air purier and the mobile phone need connecting with
same wi.
2) When the machine is standby, keep pressing “Reset”
Button on the control panel for 5 seconds until the WIFI or
indicator light ashing quickly.
3) Click “Add device” and then choose “air purier”.
3. Conguration mode
Conrming the WIFI indicator light on control panel is ashing
quickly, then click “Finish Network conguration”.

4. Choose wi
Choosing the same WIFI mobile phone is connecting, enter
WIFI password, and click “conrm”.
5. Conguration process
Wait for the conguration to be completed.
6. Conguration completed
Choose “Done” and enter control interface.

Eurofred S.A.
Marqués de Sentmenat 97
08029 Barcelona
www.eurofred.es
