Dakota Alert DCPAS-4000 User manual

DCPAS-4000 Kit
DCR-4000+DCPT-4000
USER GUIDE
www.dakotaalert.com
Dakota Alert®
WIRELESS SECURITY EQUIPMENT
TM

2

3
PACKAGE CONTENTS
• Receiver
• Power adapter
• User Guide
POWERING YOUR RECEIVER
1. Connect the power adapter to the bottom of the receiver, threading the cord through a
groove in the bottom.
2. Plug the adapter into a power outlet.
Bottom
Power adapter

4
SETTING UP YOUR RECEIVER
Note: You can connect up to 16 transmitters to your receiver.
1. Place your receiver and transmitter next to each other.
Note: Be careful not to activate your transmitter until you nd the tune you want. If your transmitter is a
motion sensor, consider covering the sensor to avoid accidentally activating it.
2. Press and hold the MODE and (volume) buttons for three seconds. When all four LEDs
ash, release the buttons.
Speaker
Mode
LEDs
Volume

5
3. Press (volume) repeatedly until you nd the tune you want to use.
1 Ding Dong (high) 5 Alarm/Siren 9 William Tell
2 Ding Dong (low) 6 Coo Coo Clock 10 Cannon in D
3 Westminster 7 Bird Chirping 11 Morning
4 Fur Elise 8 Twinkle Twinkle 12 Toreador March
4. After you choose a tune, activate the transmitter (for example, press its button or activate
the motion sensor). The receiver emits a short beep.
Note: If you accidentally activate the transmitter on a tune you don’t want, press the (volume) button
to continue cycling through the tunes to select the tune you want, then reactive the transmitter.
5. If you are coding more than one transmitter, repeat steps 3 and 4.
6. After your transmitter(s) are coded, press and hold the MODE button until the LEDs stop
ashing.
7. To test the transmitter tune, activate the transmitter. You’ll hear the selected tune through
your receiver and the LEDs will ash.
ADJUSTING THE VOLUME
• Press the (volume) button repeatedly to adjust the volume (four levels and o). The lights
show the volume level for four seconds.

6
MOUNTING THE RECEIVER
Attach two screws (not included) or nails to your wall 2.6 inches (6.7 cm) apart, then hang your
receiver.
DELETING ALL SENSORS
1. Press and hold the MODE and (volume) buttons for three seconds until the four lights
ash slowly.
2. Press and hold the MODE and (volume) buttons again for ve seconds. The four lights
ash quickly, then turn o. The receiver is reset.
Note: To relearn the sensors, see ”Setting up your receiver” on page 4.

Dakota Alert
TM
WIRELESS SECURITY EQUIPMENT
Wireless Probe
Transmitter
DCPT-4000
USER GUIDE
www.dakotaalert.com

This DCPT-4000 Wireless Probe Transmitter transmits a signal to your DCR-4000 or RE-4k
Plus receiver when it detects a vehicle in the monitored location, such as a driveway or a
drive-up window. Connect multiple wireless probe transmitters (or other transmitters)
to your receiver to create a complete security system.
PACKAGE CONTENTS
• Wireless Probe Transmitter
• Probe with 50 ft. of direct burial wire
•User Guide
SETTING UP YOUR WIRELESS PROBE
1. Install the batteries. See “Installing the batteries”on page 3.
2. Select a tune and connect your wireless probe to your receiver. See “Coding your
receiver” on page 4.
3. Position your probe and transmitter box. See “Positioning your transmitter” on
page 6.
2

INSTALLING THE BATTERIES
1. Open the transmitter box.
2. Install new CR123A batteries. Make sure that the + and - symbols on the
batteries match the symbols in the compartment.
LOW BATTERY ALERT: If you hear a second alert after the rst alert, and nothing has
activated the transmitter again, the batteries in the transmitter box are low and should
be replaced.
3

4. After you choose a tune, activate the wireless probe transmitter by pressing the“A”
button on the transmitter board (SEE DIAGRAM NEXT PAGE).
5. If you are programming more than one transmitter, repeat steps 3 & 4.
6. After your transmitter(s) are coded, press and hold the MODE button until the LEDs stop
ashing (about three seconds).
7. To test the tune, activate the wireless probe transmitter by pressing the “A” button again.
You should hear the selected tune and see the lights ash on your receiver.
Note: You can connect up to 16 transmitters with your receiver
1. Place your receiver and wireless probe transmitter near each other.
Note: Do not move or place metal near the probe until you select the tune you want.
2. Press and hold the MODE button for three seconds. When all four lights ash, release
the button.
3. Press the (volume) repeatedly until you nd the tune you want to use.
CODING YOUR RECEIVER
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Ding Dong (high)
Ding Dong (low)
Westminster
Fur Elise
Alarm/Siren
Coo Coo Clock
Bird Chirping
Twinkle Twinkle
William Tell
Cannon in D
Morning
Toreador March
Beep (high)
Beep (low)
Beep, Beep
Beep, Beep,
Beep Beep
DCR-4000 & RE-4k Plus
RE-4k Plus
