AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 1 of 12
User Manual
AGCO AgCam® 9” AHD Quad Monitor Kit
Dakota Micro Part Number: AGCO Part Number
AG-H9QDTM2 ACX308490A
Thank you for purchasing equipment from Dakota Micro, Inc.
Always read the manual prior to operating this equipment. Also, please follow all safety signs and precautions.
See the Dakota Micro, Inc. website for installation training videos at www.dakotamicro.com.
Table of Contents
I. Standard Features 3
II. Important Information About Analog & AHD 3
III. Parts of an AgCam 4
IV. Camera Mounting 4
V. Cable Routing Tips & Warnings 5
VI. Monitor & Remote Operations 6-7
A. Monitor Operations
B. Remote Operations
VII. Menu Settings 8-9
VIII. Specifications 10
IX. Warnings 10
X. Product Warranty/Repair Process 11
XI. Consumer Limited Warranty 12
XII. Disclaimer 12
XIII. Contact Us 12

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 2 of 12
PAGE INTENTIONALLY
LEFT BLANK

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 3 of 12
I. STANDARD FEATURES
A. Cameras
•True HD Resolution (720P)
•Made in the USA with US and Global Components
•3 Year Warranty
•3 way programmability –Video System (NTSC or PAL), Video Output Type (AHD or Analog) and Mirroring
•16:9 aspect ratio so image doesn’t need to be “stretched” to match monitors
•Improved color and clarity over standard analog video cameras
•Increased ability to interpret shadowed areas, allowing for a larger viewing area
•IP69 Anodized Aluminum camera body - Waterproof, shockproof, and suitable for nearly any use.
•Built-in, high quality CCD camera with high performance IR’s
•IR has effective range of 75’+ in complete darkness, resists blooming and back reflection
•Our exclusive camera body lens darkens in bright conditions and becomes completely transparent under low light
conditions. This lens is also transparent of infrared light, allowing the LED’s to penetrate even when it is darkened
•Solid billeted aluminum camera body featured Dakota Micro’s proprietary triple o-ring seal making the 100%
waterproof even under direct high pressure spray and underwater use
•Triple hardened glass lens resists scratching, scuffing and static buildup
•Anodized camera body resists corrosion even in the harshest environments
•Standard camera lens features a 92° horizontal field of view.
•Optional lenses available for a narrower viewing angle, giving the option to view subjects further away. Optional
cameras can view the following Field of View: 46°, 21°, and 15°.
•Removable/replaceable camera tail for easy replacement
B. Monitors
•Feature the latest in Analog HD technology
•View 1, 2, 3 or 4 cameras at the same time
•LED backlit
•Compatible with NTSC or PAL cameras, simultaneously
•Compatible with AHD or CVBS cameras, simultaneously
•Advanced LCD technology allows you to clearly see your image from any angle
•Mirror the view of any of your cameras for use as a backup camera
•2 Year Warranty
•16:9 aspect ratio
•4 Camera Inputs
•Available in 9in size
•Event triggers for each camera allow for triggered events to bring your camera to full view (IE: putting the vehicle
in reverse)
•Color, brightness, contrast, and volume controls that allow compensation for use in different environments
•Remote control, sun shield, and metal U-bracket monitor stand included
C. Cables
•Made in the USA
•Silicone jacketing resists heat, cold, compression & crimping
•Gold plated, corrosion resistant pins
•Watertight connections
•¼ twist lock keeps cables securely locked together
•Our durable power/video extension cables come in 10ft, 20ft, 30ft, 40ft, 50ft, 60ft & 80ft lengths and feature
sturdy, watertight connectors
II. IMPORTANT INFORMATION ABOUT ANALOG & AHD
•For multi-camera systems, all cameras can be either AHD or Analog, simultaneously

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 4 of 12
III. PARTS OF AN AGCAM (Part Number: AG-LCP)
IV. CAMERA MOUNTING
After camera is securely mounted, plug the camera pigtail into rear of AgCam® / EnduraCam camera. You can now plug the
remaining end of the pigtail into your power/video extension cable. Make sure the extension cables are securely attached and
locked (¼ turn will lock the cables together).
A. Temporary Mounting
oFor temporary mounting, it is recommended that you use the supplied 65# pull magnet. If using magnetic mount,
fasten camera cable with a zip tie or other style fastener. This will act as a “safety wire” in the event your camera is
knocked loose for some reason. When selecting a location, make sure that the equipment surface is clean of all
foreign material and as flat as possible to ensure that the magnetic camera base will have good contact and not
vibrate off. The thicker the metal base, the more securely your magnet will hold.
B. Permanent Mounting
oFor permanent mounting, it is recommended that you remove the magnet and attach the camera bracket to any
solid surface with two (2) screws.
C. Suggestions for Camera Mounting
oWhen determining the location for the camera, it is always best to use a solid surface to minimize vibration.
oImportant- Ladders are not good mounting choices due to lack of stability.
If you will be using your AgCam® for assisting in visibility for towing, you will want to position the camera so you can
see the desired area and a portion of the vehicle/trailer in tow; this will give you some reference to distance.
WARNING:
A. NEVER RELY ON YOUR AGCAM® AS A SAFETY FEATURE.
It is up to your discretion to keep your road travel and other operations safe. Your AgCam® will provide you with
information only based on what it sees. Operation of machinery safety guidelines still apply.

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 5 of 12
V. CABLE ROUTING TIPS & WARNINGS
There are two (2) lengths of cable that come standard with our AgCam® camera kits: One (1) 20’ and one (1) 60’. Extra cables in
varying lengths available for purchase through your local AgCam® dealer.
A. Cable routing is important; where you choose to run the cables should not interfere with the normal operation of the
machine or any safety equipment.
B. ALWAYS be aware of any “pinch points” or other potential hazards to the cable(s).
C. Secure all cables to vehicle/equipment using cable clips, zip ties or other style fasteners.
D. If you intend to use your AgCam® for short length PTO operated implement, avoid excess cable lengths, if possible. When
you decide on a location, you should fix the camera to a permanent bracket using ¼ inch bolts and attach any loose cable
securely so there is no chance of entanglement in the PTO or other moving parts.
E. If you use your AgCam® to monitor a combine hopper or other combine operations, take care to remember that combines
have many moving parts. Use extreme care when routing cables, and it is strongly recommended that you use bolts to secure
the camera. While it would be sufficient to use the magnetic base for monitoring purposes during road travel, it is advised
to secure the camera with bolts during operation of the combine.

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 6 of 12
VI. MONITOR & REMOTE OPERATIONS
A. Monitor Operations
1
Headphone Jack
Output for audio (disabled)
2
Full Screen
Will show cameras 1/2/3/4 each time pressed.
3
Duplex Screen/Triplex
Will show two or three cameras in different
combinations each time pressed. Adjust default
selections in Display Mode Settings.
4
Quad Screen/H
First press displays all four cameras in quad view. Second
press views all four cameras in H view. Adjust viewing
options in Display Settings. Duration between screen
views can be adjusted in Loop Preview under Display
Settings Mode.
5
- Key
To decrease parameter/Up/Down
6
+ Key
To increase parameter/Up/Down
7
MENU
Enables / Disables Menu
8
AV Key
Will show cameras 1/2/3/4 each time pressed/ In MENU
acts as ENTER key & Down arrow
9
POWER
Turns monitor ON/OFF.
Port 10 and 11 is located on the back side of the monitor
10
Battery
N/A (only on DVR versions)
11
SD Card
N/A (only on DVR versions)

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 7 of 12
B. Remote Operations
Standard Remote
POWER ON (give it a few seconds) / OFF
Switches between video channels
Displays Menu
Navigation Arrows
Navigation Arrows
Navigation Arrows
Navigation Arrows
Brings Channel 1/Camera 1 Full screen
Brings Channel 2/Camera 2 Full screen
Brings Channel 3/Camera 3 Full screen
Brings Channel 4/Camera 4 Full screen

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 8 of 12
VII. MENU SETTINGS
A. Monitor Menu Settings
1. Press the MENU key on the face of monitor or remote. MENU key also acts as “enter” key once within menu.
2. Use the AV key on the monitor (up and down arrows on remote) to select an item under each section. Selected
menu items turn blue.
3. Use –or + on the monitor (left and right arrows on remote) to change the value of the highlighted item.
4. To exit: Press the MENU button monitor (left or right arrow on remote) multiple times until the menu goes away.
Allow monitor to time out (approximately 10 seconds).
MAIN MENU
Display: Adjusts monitor display settings
System: System Settings including time setup
Installation Mode (pictured below)
DISPLAY SETTING
DISPLAY ADJUSTMENT: When utilizing microphone, allows for noise
reduction settings
Scene Mode: Adjusts look of entire display –highlight, film,
brilliance, cool, warm, custom. Adjustment of
brightness, contrast, saturation & hue of
chosen scene also available
Image Adjust: Allows adjustment of individual cameras –
brightness, contrast, saturation, hue. You can
also individually flip each camera.
LOOP PREVIEW: Set auto rotation time between screen views–
OFF, 3, 5, 8, 10 or 15 seconds
POWER ON MODE: Select the default camera view when you
power on. Select from cameras: 1, 2, 3, 4, ½, ¾,
H, and Quad
INSTALLATION MODE: Choose from more default camera view
options.
Install Select: Mode 1 is regular screen view and Mode 2 flips
screen upside down.
Reverse Line: Check the boxes of which cameras (or none)
you’d like to view the reverse guidelines. Note,
reverse lines can only be displayed in full
screen one at a time.
Turn Light Mode: N/A
Reverse Priority: Select which single camera overrides any other
trigger event when reversing
AUTO DIMMER: Mark “On” if you want the monitor to
automatically dim in low-light conditions

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 9 of 12
Display Mode (pictured below)
DISPLAY MODE: Allows adjustment of how cameras are
displayed on screen as well as background &
border colors
SYSTEM SETTING
LANGUAGE SETTING: Select Language
POWER SAVING MODE: Set Power Saving Mode duration –Off, 10min,
30min, 1 hr, 2 hr.
RESTORE FACTORY: Restore monitor to factory settings
SYSTEM UPGRADE: Install firmware updates (SD card would need
to be supplied by manufacturer to update;
updates generally not needed)

AG-H9QDTM2 User Manual
Author: MES Revised by: MES Rev: 09/07/21 Page 10 of 12
VIII. SPECIFICATIONS
B. LCD Monitor
Screen Size
16:9 digital panel
Overall Size
9.25in(L)x 6.1in(H)x1.44in(D) 235mm(L)X155mm(H)X36.5mm(D)
Weight
30.4oz (862g)
Power Input
DC 12v-24v
Color System
NTSC/PAL auto switch
Operating Temp.
-30°F~130°F (-34°C~+54°C)
Brightness
350cd/m2
Resolution (HxV)
1024(H)x600(V)
Contrast
500:1
Viewing Angle
L/R: 70° Up: 50° Down: 70°
Operating Voltage
Min. 12v (Check monitor label for specific voltage range)
Lighting Source
LED Backlit
Environmental Rating
IP50
Video Output Format
Full/Quad/split/ Auto Switch
Video Output Port
RCAx1 Video Out - Analog (CVBS) ONLY
Video Input Port
X4 AHD video input channels
IX. WARNINGS
•When selecting a camera system from Dakota Micro, be sure to utilize the appropriate system for your use. AgCam and
EnduraCam cameras are designed for high impact, moisture, vibration, and a variety of other rough conditions. OverView
cameras and kit components are designed for light use, low vibration, and low moisture. OverView equipment is not
warranted when used in situations outside of the above-mentioned parameters. We always request that customers keep
in mind that our less expensive OverView product line is cheaper because it does not feature the reliability and durability
of our AgCam and EnduraCam lines. The warranty available on these products reflects that durability.
•To avoid electrical shock and maintain optimal functionality, do not open the enclosures. High voltage may be present and
there are no user serviceable parts inside. All warranties will be void should any enclosures be tampered with in any way.
•Do not use any harsh chemical solvents, cleaning agents or corrosive detergent to clean away dirt on the surface of the
screen or lens.
•On AgCam and EnduraCam products, the photo-chromic camera lenses have been made impact-resistant and have been
drop-ball tested according to Sec. 3.84,21 CRF BUT ARE NOT UNBREAKABLE. Because they have been hardened chemically,
they show no stress pattern. Inspect your lenses frequently. Chipped or scratched surfaces will reduce protection. Such
lenses should be replaced only by the manufacturer.
•Power to cameras is not interrupted by turning off monitor; 12v power source must be terminated when not in use to
avoid battery drain. To avoid this problem be sure when hard wiring a unit, use a 5-amp fused circuit.
•Do not use your Dakota Micro camera system for anything other than legal surveillance and observation uses. Dakota
Micro, Inc. is not liable for any illegal or nefarious usage.
