Daktronics LARGE MATRIX GALAXY GS6 Series User manual

201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
LARGE MATRIX
GALAXY®GS6 SERIES
INSTALLATION AND
OPERATION MANUAL
P1874
DD3125389
Rev 12
20 March 2020

Copyright © 2020
All rights reserved. While every precaution has been taken in the preparation of this manual, the publisher assumes no
responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be reproduced or copied
in any form or by any means—graphic, electronic, or mechanical, including photocopying, taping, or information
storage and retrieval systems—without written permission of the publisher.
Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.
FCC Statement
Supplier Declaration of Conformity (SDoC)
This product complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at their own
expense.
Warning: The user is cautioned that changes and
modications made to the equipment without the
approval of manufacturer could void the user’s
authority to operate this equipment.
Industry Canada Regulatory Information
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
Inquiries
Contact Daktronics with any questions regarding our
product compliance.
Mail:
Daktronics
201 Daktronics Dr.
Brookings, SD 57006 USA
Phone:
800-325-8766
Website:
www.daktronics.com

– i –
Table of Contents
1 Introduction�����������������������������������������1
Limitation of Liability ..................................1
Contact Information .................................1
Model Number Guide...............................1
2 Installation Preparation ����������������������2
Pre-Installation Checklist ...........................2
Structure Requirements.............................2
Required Tools............................................3
3 Display Installation������������������������������4
Display Installation Preparation ������������4
Display Installation .....................................4
4 Section Splicing ����������������������������������6
Display Section Numbering ......................6
Section Splicing..........................................6
5 Electrical Installation ��������������������������7
Electrical Installation Preparation ���������7
Conduit.......................................................7
Power Requirements .................................7
Important Notes About Power
Requirements �����������������������������������������8
Main Disconnect�������������������������������������8
Power Connection ....................................8
Earth Ground Installation ..........................9
Important Points About Grounding�������9
6 Signal Cable Installation ������������������10
Primary/Mirror Display Interconnections
...................................................................10
Sectional Display Signal Connections...10
7 System Start-Up Procedure��������������11
Boot Sequence........................................11
Start-Up Checklist ....................................11
8 Network and Communication
Installation �����������������������������������������12
Network and Communication
Installation Dos .........................................12
Requirements For Communication
Through A Network .................................12
Connecting A Display to A DHCP
Network.....................................................12
Display Currently Congured for DHCP
(Default)�������������������������������������������������12
Network Requirements .....................12
Installation/Start-up Steps.................12
Display Congured For Static IP
Address��������������������������������������������������12
Network Requirements .....................12
Conguration Steps Using IP Address
.............................................................13
Conguration Using DisplayFind To
Discover The Display ����������������������������14
Downloading DisplayFind ................14
Launching DisplayFind......................14
Connecting To A Display..................15
Connecting A Display To A Static IP
Network.....................................................16
Display Currently Congured for DHCP
(Default)�������������������������������������������������16
Network Requirements�������������������������16
Conguration Steps Using IP Address
.............................................................16
Display Congured For Static IP
Address��������������������������������������������������17
Network Requirements .....................17
Conguration Steps Using IP Address
.............................................................17
9 Venus Software Conguration���������19
First-Time Venus Login..............................19
Logging In - Daktronics Web-Hosted
Server�����������������������������������������������������19
Logging In - Customer Local-Hosted
Server�����������������������������������������������������19
Venus Menu Overview............................20
Contact Information and Where to Get
Help ...........................................................20
Telephone ..........................................21
Online .................................................21
10 Display Maintenance�����������������������22
Internal Display Access ...........................22
Ventilation System ...................................23
Fans��������������������������������������������������������23
Display Face Cleaning............................23
Wet Cleaning Process ��������������������������23
Dry Cleaning Process���������������������������23
11 Display Troubleshooting�������������������24
Power and Signal Routing ......................24
Power Routing ���������������������������������������24
Signal Routing ���������������������������������������25

– ii –
Table of Contents
Controller Diagnostics .............................26
PLR Diagnostics .......................................26
PLR Self-Test�������������������������������������������26
Module Diagnostics.................................27
Module Self-Test �����������������������������������27
12 Replacement Parts List ���������������������28
13 Replacing Parts���������������������������������29
Module Replacement.............................29
Power Supply Replacement ..................29
Controller Replacement.........................29
PLR Replacement ....................................30
14 Daktronics Exchange and Repair &
Return Programs��������������������������������31
Exchange Program .................................31
Before Contacting Daktronics�������������31
Repair & Return Program........................32
Shipping Address����������������������������������32
Daktronics Warranty and Limitation of
Liability ......................................................32
A Reference Drawings �������������������������33
B Daktronics Warranty and Limitation
of Liability�������������������������������������������35
C Legacy Remote Display
Conguration ������������������������������������37
Connecting A Display to A DHCP
Network.....................................................37
Display Currently Congured for DHCP
(Default)�������������������������������������������������37
Network Requirements .....................37
Installation/Start-up Steps.................37
Display Congured For Static IP
Address��������������������������������������������������37
Network Requirements .....................37
Conguration Steps Using IP Address�37
Installation/Start-up Steps.................37
Display Congured For Static IP
Address��������������������������������������������������37
Network Requirements .....................37
Conguration Steps Using IP Address
.............................................................38
Conguration Using DisplayFind To
Discover The Display ����������������������������39
Downloading DisplayFind ................39
Launching DisplayFind......................39
Connecting To A Display..................40
Connecting A Display To A Static IP
Network.....................................................41
Display Currently Congured for DHCP
(Default)�������������������������������������������������41
Network Requirements .....................41
Conguration Steps Using IP Address
.............................................................41
Display Congured For Static IP
Address��������������������������������������������������42
Network Requirements .....................42
Conguration Steps Using IP Address
.............................................................42

Introduction
1
1 Introduction
This manual provides the necessary information to install and service a large matrix
Galaxy®GS6 series display.
Please read and understand all steps in this manual before beginning the installation
process.
For a smooth installation, complete the steps in this manual in order. Contact Daktronics
Technical Support with any questions before or during the installation process.
Limitation of Liability
The factory warranty will be nullied if:
• The display is not installed according to the steps in this manual
• Proper electrical service is not provided or the display is not grounded properly
• Unauthorized modications are made to the display, display cabinet, or the control
system
Refer to Section B: Daktronics Warranty and Limitation of Liability (p�35) at the end of
this manual for the full Daktronics Warranty and Limitation of Liability.
Contact Information
For assistance before, during, or after display installation, please contact Daktronics
Technical Support: 800-325-8766.
Model Number Guide
Galaxy® GS6 model numbers are dened as follows:
GS6-RxC-M-X-F
GS6 = Outdoor Standard Galaxy®display
R= Number of pixel rows high
C= Number of pixel columns long
M= Pixel pitch in millimeters
X=LED Color: R (Red); A (Amber); RGB - R (Red), G (Green), B (blue)
F=Face setup: SF – Single Face or 2V – Primary/Mirror
Displays are either single face (SF) or two view (2V). In 2V units, the rst display is referred
to as the primary and the second is called the mirror. If the second display is mounted
more than 8 feet (2.4 m) from the primary display, two primary displays are used.

Installation Preparation
2
2 Installation Preparation
This section explains what to consider before installing a Daktronics Galaxy®GS6 display.
Follow all guidelines and safety precautions in this manual when installing the display. Do
not modify the display or control system in any manner without the written permission of
Daktronics engineering staff.
Any unauthorized modications nullify the display warranty.
Pre-Installation Checklist
• The display was not damaged during shipping
• The mounting structure will provide a straight and square mounting frame for the
display
• The support structure can carry the weight of the display and meets local and
national codes
• Ensure proper power is available at sign structure – refer to shop drawing for display
power requirements
• The display cabinet has no holes (accidental or intentional) that will allow water to
enter the display
• All display modules are fully latched into the display cabinet
Structure Requirements
Support structure design depends on mounting method, installation height, display size,
and weight. Because every installation site is unique, Daktronics approves no single
procedure for mounting displays.
Things to consider prior to installation:
• The display mounting requires a continuous horizontal stringer across the back
attached to all display mounting points to provide adequate wind load support for
the cabinet
• The structure can carry the weight of the display and wind load
• Display structure and mounting must not obstruct airow - refer to shop drawing for
ventilation space requirements
• Light sensor must not be obstructed for the display to function properly
For additional questions about display mounting requirements and specications, refer to
the display shop drawing or contact Daktronics Technical Support at 800-325-8766.

Installation Preparation
3
Required Tools
The following table lists the minimum tools to have on site for each installation. Daktronics
only provides the specialized tools needed to complete the installation.
Daktronics Provided Customer Provided
Splice Wrench Hex Head Wrenches – 1/8" and 3/16"
Flathead and Phillips Head Screw Drivers
Crane or Lift Truck
Step Ladders
Computer with Venus®Software and Internet access
Ratchet and/or Impact Wrench – 11/16"
Socket Set – Sizes up to 1 1/16" Needed
Tape Measure
Utility Knife

Display Installation
4
3 Display Installation
This section explains the steps necessary for proper lifting and installation of the display to
the sign structure.
Follow all guidelines and safety precautions in this manual when installing the display.
Do not modify the display or control system in any manner without the written permission
of Daktronics engineering staff. Any unauthorized modications will nullify the warranty.
Display Installation Preparation
• Do inspect the display for damage prior to installation
• Do use all T-clips for mounting
• Do provide an adequate support structure that is straight and level
• Do provide adequate ventilation that meets or exceeds display specications listed
on the shop drawing
• Do use all T-clips for mounting using a continuous horizontal member
• Do use all lift eyes when lifting the display
• Do not open the Galaxy®GS6 controller enclosure
• Do not block display ventilation system
• Do not use the lift eyes for display mounting
• Do not hang additional signage from GS6
display
Display Installation
1� Use a utility knife to carefully cut away all of
the white packaging material from the display.
Be careful not to damage the face of the
display or LEDs.
2� If the display is multi-sectional, refer to Section
4: Section Splicing (p�6) before continuing.
3� Attach a crane or lift truck to the lift eyes on
the display's top.
Lift eye spacing is set at Daktronics and should not be moved. Lift eyes should also
remain in place after installation is complete.
Ensure the angle between the top of the display and
the lifting strap is greater than 55 degrees. Refer to
Figure 1.
4� Apply tension to the lift lines.
5� Attach tag lines to the bracket. Refer to Figure 2.
6� Unbolt the display from the shipping braces.
7� Lift the display off the truck to the display structure.
Note: Do not lift displays in wind speeds greater than 20 mph.
From Back
Tag Line
Tie Off
Angle must be
greater than 55°
Lift-Eye Bolts
Set Bolts
Figure 1: Proper Display Lifting
Figure 2: Tag Line Bracket

Display Installation
5
8� Mount the display to the structure by welding or bolting all T-Clips to horizontal
stringers.
Use all T-Clips when mounting the display.
The T-Clips are installed in the recommended locations at Daktronics, but can be
moved 12 inches either way to avoid obstructions. Refer to the label on the display
for limitations.
9� Remove crane support and tag lines from the display once mounting is complete.
10� Locate the top border caps and install over lift eyes using provided Tek screws.

Section Splicing
6
4 Section Splicing
Display Section Numbering
For displays with multiple sections, each section is
numbered for easy installation. For a two-section display,
the bottom section is 201 and the top section is 101. Refer
to Figure 3.
For four-section displays, when looking from the front, the
lower-left display section is 201 and the section to the
right is 202; the second row of sections are 101 on the left
and 102 on the right. Refer to Figure 4.
Section Splicing
1� Ensure the splice key is inserted
in the channel of the bottom
section. Refer to Figure 5.
2� Attach a crane or lift truck to
the lift eyes of the top section
and apply tension.
3� Unbolt the top section of the
display from the truck bed and
unbolt A-frame.
4� Lift the display top section off
the truck high enough to spin around 180 degrees.
5� Starting at one end of the display,use the splice tool
to draw the top section into the bottom until the
splice key is fully engaged. Refer to Figure 6.
6� Ensure display sections are aligned and that LEDs are
also in alignment.
7� Attach the splice plates and splice T-clips along the
section splice. Refer to Figure 7. Use an 11/16" impact
wrench or ratchet to tighten all nuts on the splice
plates and splice T-clips.
Section 201
Section 101
Figure 3: Two-Section Display
Section Numbering
Section 201
Section 101
Section 202
Section 102
Figure 4: Four-Section Display Section Numbering
Top
Section
Bottom
Section
Splice
Key
Splice Channel
Figure 5: Installed Splice Key
Top
Section
Bottom
Section
Figure 6: Aligning Display Sections with
Splice Tool
Splice
Plate
Bolt
Nut
Washer
Display Face
Bottom
Section
Top
Section
Figure 7: Installed Flat Splice Plate

Electrical Installation
7
5 Electrical Installation
This section explains the steps necessary to make nal electrical connections to the
display from the primary power source. For display-specic power requirements, refer to
the shop drawing or label on the display's back.
Electrical Installation Preparation
• Do follow all installation guidelines
• Do route power to the display through a disconnect switch
• Do provide the required power per display requirements
• Do provide a separate circuit for each display
Note: Run a separate circuit to the electronic display(s) to isolate it and prevent
any issues that could be caused by line voltage uctuations or high
frequency noise on the power line caused by other types of equipment.
A separate circuit also makes display maintenance and troubleshooting
easier. Daktronics assumes no liability for any issues caused by line voltage
uctuations or other improper power conditions.
• Do connect each display face to a dedicated earth-ground electrode
• Do follow all local and national electrical codes
• Do not share circuits between displays and other electrical devices
• Do not connect the display to any voltage other than that listed on the product label
• Do not connect the neutral to the ground at the disconnect or the display
• Do not use the display support structure as an earth-ground per local and national
codes
Conduit
Daktronics does not provide conduit. Separate conduit must be used to route:
• Power
• Signal IN wires to the signal termination enclosure (when applicable).
• Signal OUT wires (if not using the provided interconnect cable).
For power, displays have either a J-box or a 3/4″ conduit access hole located near
the lower right on the back of the display. For signal, displays have signal input quick
connects or etched drilling guides for conduit.
Power Requirements
Install this display according to all applicable local and national electrical codes. This
includes proper grounding and bonding of the display.
Do not connect the display to any voltage other than that listed on the Daktronics
product label.
Displays use single-phase power. Proper power installation is imperative for display
operation. Find power specications on drawings shipped with the display.

Electrical Installation
8
Important Notes About Power Requirements
Run a separate circuit to the electronic display(s) to isolate it and prevent any issues that
could be caused by line voltage uctuations or high frequency noise on the power line
caused by other types of equipment. A separate circuit also makes display maintenance
and troubleshooting easier. Daktronics assumes no liability for any issues caused by line
voltage uctuations or other improper power conditions if these recommendations are
not followed.
Size conductors of circuits that deliver power to the display according to national and
local electrical codes so the power distribution system delivers full-load power to the
display while maintaining a voltage within 5 percent of the utility nominal voltage.
Main Disconnect
Daktronics requires using a power disconnect
switch with the display. Use a disconnect so that
all ungrounded conductors can be disconnected
near the point of power connection.
Locate the disconnecting means either in a direct
line of sight from the display or so it can be locked
in the open position. This ensures that power is not
reconnected while service personnel work on the
display.
Power Connection
1� Review the power requirements for the display.
Requirements are found on the display shop
drawing or label on the display's back.
2� Route conduit from the main distribution
panel/disconnect to each display power
entrance. Each display section has a power
entrance and requires a dedicated circuit.
3� Remove the four screws that attach the power
entrance access door. Refer to Figure 8.
4� Connect conduit to the 2" Myers hub at the
left of the power entrance box.
5� Feed power cable from the conduit into the power
entrance box.
6� Connect primary power lines to appropriate taps
in enclosure. Refer to Figure 9. Refer to label on
enclosure for wiring diagram
7� Reinstall power entrance cover.
8� Connect grounding electrode to ground lug, shown in
Figure 10, on each section.
Figure 8: Display Power Requirements
Label
Figure 9: Power Entrance Box
Figure 10: Ground Lug

Electrical Installation
9
Earth Ground Installation
Follow the steps below to connect
the Daktronics Galaxy®GS6 display
to an earth-ground electrode.
1� Install an earth-ground
electrode (ground rod, ground
plate, etc.) near the base of the
display. Refer to Figure 11 for
guidelines.
Note: Each display face
requires an earth-
ground electrode.
2� Connect a copper wire from
the grounding electrode to the
ground lug on the back of the
display.
3� Bury any copper cable or grounding electrodes so they are below grade.
Important Points About Grounding
• All components of a display system—including but not limited to displays, control
equipment, and connected peripheral equipment—must be electrically grounded.
Only qualied individuals may perform electrical work, including verication of
ground resistance. Daktronics is not responsible for improper grounding or damage
incurred as a result of improper grounding.
• Grounding methods must meet the provisions of all applicable local and national
codes. Inspect and verify all grounding methods meet the provisions of all applicable
local and national codes.
• Proper grounding is necessary for reliable equipment operation and general
electrical safety. Failure to properly ground the display system may void the warranty,
disrupt operation, damage equipment, and cause bodily harm or death.
Primary
Mirror
Display
Ground Lug
Thermal Weld
Connection
Preferred Conduit
Copper Ground Conductor
(One Per Display Face)
Copper Ground Rods
8 ft.(2.5 m)
min.
8 ft.(2.5 m)
min.
Figure 11: Proper Display Grounding

Signal Cable Installation
10
6 Signal Cable Installation
For specic details on installing the communications, consult the quick guide and manual
included with the communication equipment. Each type of communication is listed
below with its manual number.
Communication Type Communication Manual Communication Quick Guide
Wireless Ethernet Bridge DD1685027 DD1417586
Ethernet DD1417609 DD1417573
Fiber Ethernet DD1417611 DD1417581
These are the standard communication types but each site is unique and may include
additional equipment. If problems arise, contact the display's service company or
Daktronics Customer Service.
Primary/Mirror Display Interconnections
For data to get from the Primary display to the Mirror
display, the ber interconnect cable must be connected.
This cable typically comes attached to the back of the
display.
1� Locate cable and unpackage.
2� Connect one end of the cable to J34 on the back of
the Primary display. Refer to Figure 12.
3� Connect the other end of the cable to J32 on the
back of the Mirror display.
4� Coil up any excess cable and secure it to prevent
vandalism and weather-related damage.
Note: Anchor points are found on each fan hood for securing excess cable.
Sectional Display Signal Connections
For sectional displays, data is transmitted from one section to the next through ber
cables connected to the outside of each section.
Each section has multiple jacks labeled either A or B. Refer to DWG-3141399 for correct
cable routing between display sections. A label on the display's back also illustrates how
to connect the cables.
Figure 12: Signal Out Jack

System Start-Up Procedure
11
7 System Start-Up Procedure
Displays show a boot sequence about two minutes after power is turned. This information
is very useful when conguring the display in Venus®software. Prior to turning the display
on, make sure display communications and any network connections have been made.
Boot Sequence
Description
Firmware Name and Version
Display Size (Pixels High by Pixels Wide)
DHCP Name Assigned
IP Address and State
MAC Address
Conguration Port
Status Port
Management Port (Used to Access Conguration)
Description
Start-Up Checklist
• Conrm power is correctly connected to the display
• Conrm there is sufcient power according to display requirements
• Conrm a main disconnect is installed
• Conrm the display is grounded per local and national codes
• Conrm that all communication equipment is installed according to provided
documentation
• Conrm that any necessary network connections have been made
• Conrm ability to log in to venus.daktronics.com
• Inspect peripheral equipment (temperature sensor, light sensor, etc.) for proper
installation

Network and Communication Installation
12
8 Network and Communication Installation
This section explains how to setup communications with a GS6 series display through a
network or an individual computer. Obtain information about the available standard
communication options in the provided quick guides and reference manuals.
Daktronics is not responsible for setting up a customer's network system either a Local
Area Network (LAN) or a Wide Area Network (WAN).
Network and Communication Installation Dos
• Complete all network and communication installation prior to turning display on
• Have a laptop on site with Internet access (preferred)
• Work with the Customer's IT professional for network integration
Daktronics GS6 series displays use DHCP by default, which allows automatic display
conguration by the customer's network, and eliminates manual conguration of the
player.
When the display is connected to a network that supports DHCP, a default DHCP name
similar to "DMP8.xx.xxxx" or "DMP5.xx.xxxx", where "xxxx" represents a unique identier for
the display. This information is shown in the display boot sequence.
Requirements For Communication Through A Network
The display must be allowed to establish an outgoing Internet connection on Port 80
(http) and Port 443 (https).
Connecting A Display to A DHCP Network
Display Currently Congured for DHCP (Default)
The following steps explain how to congure a display and connect to a network that
supports DHCP. Using the display's DHCP name is desired for communication.
Network Requirements
• DHCP Server
• Existing Network
• Available network port, congured properly
Installation/Start-up Steps
1� Ensure the display has an established link with the network.
2� Turn display on.
Display Congured For Static IP Address
The following steps explain how to recongure a display for DHCP network when it has
previously been congured for a static IP address.
Network Requirements
• Existing Network
• Available network port, congured properly

Network and Communication Installation
13
• PC
• Internet Explorer or Firefox web browser
Conguration Steps Using IP Address
1� Connect a computer to the display.
2� Turn display on.
3� Observe boot sequence - recongure computer to same in the IP address range as
the display and same subnet.
4� Manually enter display IP address in web browser followed by :85 (for example,
http://169.254.13.87:85) to identify the correct connection port.
5� Enter User Name Dak and Password DakPassword! in the Windows Security window.
6� Click OK to connect to the display (refer to the help le for additional information
about the conguration utility).
7� Click the Network tile.
8� Click the Automatic button under both the IP and DNS Conguration headings.
9� Click the Save button.
10� Log out of the conguration utility.
11� Turn display off.
12� Disconnect the computer from the display and connect display to the network.
13� Ensure the display has an established link with the network.

Network and Communication Installation
14
14� Turn display on.
Conguration Using DisplayFind To Discover The Display
Downloading DisplayFind
Download the DisplayFind utility from the Internet.
1� Open Internet Explorer or Firefox web browser.
2� Navigate to dakles.daktronics.com.
3� Click Venus 1500 > Utils > DisplayFind > DisplayFind.exe.
4� When prompted, select Run to complete the installation of the DisplayFind utility or
Save to the computer for later use.
Launching DisplayFind
Double-click the DisplayFind icon on your desktop.
Each item listed at the top of the DisplayFind utility should have a green check mark. See
the explanations below for what each item means. If an item has a red X next to it, click
it for additional information or to access the download.
The Current User Is Not An Administrative User On This Computer
• Must have administrative rights to install SilverlightTM
• Once SilverlightTM is installed, administrative rights are not necessary
Windows Firewall Exception Is Currently Enabled
• Windows rewall should be temporarily disabled to allow discovery responses to be
received from any displays
• Other third party Antivirus/rewall applications (McAffee, Symantec, ZoneAlarm, etc)
should also be temporarily disabled
SilverlightTM Version – a green check mark tells you SilverlightTM is installed
• SilverlightTM 3.0 or newer installed

Network and Communication Installation
15
Connecting To A Display
1� Select the Network Adapter used to communicate with your display.
2� Click the Find Displays button to detect any displays using the selected network
adapter.
3� Detected displays are listed in the bottom window of the utility.
4� Click the desired display (VIP5-xx-xxx) to launch the conguration utility within your
web browser.
Note: Refer to the conguration utility help le for additional information.
• After running DisplayFind to determine the display's static IP address,
reconguration of the computer to the same IP address range and subnet may
be required.
5� Follow the steps in the Conguration Steps Using IP Address (p.13) section.

Network and Communication Installation
16
Connecting A Display To A Static IP Network
Display Currently Congured for DHCP (Default)
The following steps explain how to set a static IP address on the display.
Network Requirements
• Existing Network
• Available network port, congured properly
• PC
• Internet Explorer or Firefox web browser
Conguration Steps Using IP Address
1� Connect a computer to the display.
2� Congure the computer for DHCP.
3� Turn display on.
• Both the display and the computer should timeout searching for a DHCP server
and fall back to auto IP addresses of 169.25x.x.x.
4� Observe boot sequence - recongure computer to same in the IP address range as
the display and same subnet.
5� Manually enter display IP address in web browser followed by :85 (for example,
http://169.254.13.87:85) to identify the correct connection port. Or see the
Conguration Using DisplayFind To Discover The Display (p.14) section.
6� Enter User Name Dak and Password DakPassword! in the Windows Security window.
7� Click OK to connect to the display (refer to the help le for additional information
about the conguration utility).
8� Click the Network tile.
9� Click the Manual button under the IP Conguration heading.
