Dallas Semiconductor MAXIM DS21354 User manual

1 of 124
REV: 021004
Note: Some revisions of this device may incorporate deviations from published specifications known as errata. Multiple revisions of any device
may be simultaneously available through various sales channels. For information about device errata, click here: www.maxim-ic.com/errata.
GENERAL DESCRIPTION
The DS21354/DS213554 single-chip transceivers
(SCTs) contain all the necessary functions to connect to
E1 lines. The devices are upward-compatible versions
of the DS2153 and DS2154 SCTs. The on-board
clock/data recovery circuitry coverts the AMI/HDB3 E1
waveforms to an NRZ serial stream. Both devices
automatically adjust to E1 22AWG (0.6mm) twisted-
pair cables from 0 to over 2km in length. They can
generate the necessary G.703 waveshapes for both 75W
coax and 120Wtwisted cables. The on-board jitter
attenuator (selectable to either 32 bits or 128 bits) can
be placed in either the transmit or receive data paths.
The framer locates the frame and multiframe
boundaries and monitors the data stream for alarms. It is
also used for extracting and inserting signaling data, Si,
and Sa-bit information. The on-board HDLC controller
can be used for Sa-bit links or DS0s. The devices
contain a set of internal registers that the user can
access to control the operation of the units. Quick
access through the parallel control port allows a single
controller to handle many E1 lines. The devices fully
meet all the latest E1 specifications, including ITU-T
G.703, G.704, G.706, G.823, G.732, and I.431, ETS
300 011, 300 233, and 300 166, as well as CTR12 and
CTR4.
PIN CONFIGURATION
FEATURES
§ Complete E1 (CEPT) PCM-30/ISDN-PRI
Transceiver Functionality
§ On-Board Long- and Short-Haul Line Interface
for Clock/Data Recovery and Waveshaping
§ 32-Bit or 128-Bit Crystal-Less Jitter Attenuator
§ Frames to FAS, CAS, CCS, and CRC4 Formats
§ Integral HDLC Controller with 64-Byte Buffers
Configurable for Sa Bits, DS0, or Sub-DS0
Operation
§ Dual Two-Frame Elastic Store Slip Buffers that
can Connect to Asynchronous Backplanes up to
8.192MHz
§ Interleaving PCM Bus Operation
§ 8-Bit Parallel Control Port that can be used
Directly on Either Multiplexed or
Nonmultiplexed Buses (Intel or Motorola)
§ Extracts and Inserts CAS Signaling
§ Detects and Generates Remote and AIS Alarms
§ Programmable Output Clocks for Fractional E1,
H0, and H12 Applications
§ Fully Independent Transmit and Receive
Functionality
§ Full Access to Si and Sa Bits Aligned with
CRC-4 Multiframe
§ Four Separate Loopback Functions for Testing
Functions
§ Large Counters for Bipolar and Code Violations,
CRC4 Codeword Errors, FAS Word Errors, and
E Bits
§ IEEE 1149.1 JTAG-Boundary Scan Architecture
§ Pin Compatible with DS2154/52/352/552 SCTs
§ 3.3V (DS21354) or 5V (DS21554) Supply; Low-
Power CMOS
§ 100-pin LQFP package (14mm x 14mm)
ORDERING INFORMATION
PART TEMP RANGE PIN-PACKAGE
DS21354L 0°C to +70°C 100 LQFP
DS21354LN -40°C to +85°C 100 LQFP
DS21554L 0°C to +70°C 100 LQFP
DS21554LN -40°C to +85°C 100 LQFP
DS21354/DS21554
3.3V/5V E1 Single-Chip Transceivers
www.maxim-ic.com
1
100
Dallas
Semiconductor
DS21354/DS21554
LQFP
TOP VIEW

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
2 of 124
TABLE OF CONTENTS
1. INTRODUCTION.................................................................................................................. 6
1.1. FUNCTIONAL DESCRIPTION..............................................................................................................................7
1.2. DOCUMENT REVISION HISTORY .............................................................................................................8
2. BLOCK DIAGRAM .............................................................................................................. 9
3. PIN DESCRIPTION............................................................................................................ 10
3.1. PIN FUNCTION DESCRIPTION ................................................................................................................14
3.1.1. Transmit-Side Pins..............................................................................................................................14
3.1.2. Receive-Side Pins...............................................................................................................................17
3.1.3. Parallel Control Port Pins ....................................................................................................................20
3.1.4. JTAG Test Access Port Pins...............................................................................................................22
3.1.5. Interleave Bus Operation Pins ............................................................................................................22
3.1.6. Line Interface Pins ..............................................................................................................................23
3.1.7. Supply Pins .........................................................................................................................................24
4. PARALLEL PORT ............................................................................................................. 25
4.1. REGISTER MAP ........................................................................................................................................25
5. CONTROL, ID, AND TEST REGISTERS .......................................................................... 30
5.1. POWER-UP SEQUENCE ..........................................................................................................................30
5.2. SYNCHRONIZATION AND RESYNCHRONIZATION...............................................................................32
5.3. FRAMER LOOPBACK ...............................................................................................................................36
5.4. AUTOMATIC ALARM GENERATION........................................................................................................38
5.5. REMOTE LOOPBACK ...............................................................................................................................40
5.6. LOCAL LOOPBACK...................................................................................................................................40
6. STATUS AND INFORMATION REGISTERS .................................................................... 43
6.1. CRC4 SYNC COUNTER............................................................................................................................45
7. ERROR COUNT REGISTERS........................................................................................... 50
7.1. BPV OR CODE VIOLATION COUNTER ...................................................................................................50
7.2. CRC4 ERROR COUNTER.........................................................................................................................51
7.3. E-BIT COUNTER .......................................................................................................................................51
7.4. FAS ERROR COUNTER .................................................................................................................................52
8. DS0 MONITORING FUNCTION ........................................................................................ 53
9. SIGNALING OPERATION................................................................................................. 56
9.1. PROCESSOR-BASED SIGNALING ..........................................................................................................56
9.2. HARDWARE-BASED SIGNALING ............................................................................................................58
9.2.1. Receive Side .......................................................................................................................................58
9.2.2. Transmit Side ......................................................................................................................................59
10. PER-CHANNEL CODE GENERATION AND LOOPBACK............................................... 60
10.1. TRANSMIT-SIDE CODE GENERATION ................................................................................................60
10.1.1. Simple Idle Code Insertion and Per-Channel Loopback.....................................................................60
10.1.2. Per-Channel Code Insertion ...............................................................................................................61
10.2. RECEIVE-SIDE CODE GENERATION...................................................................................................62
11. CLOCK BLOCKING REGISTERS..................................................................................... 63

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
3 of 124
12. ELASTIC STORES OPERATION...................................................................................... 65
12.1. RECEIVE SIDE .......................................................................................................................................65
12.2. TRANSMIT SIDE.....................................................................................................................................65
13. ADDITIONAL (SA) AND INTERNATIONAL (SI) BIT OPERATION .................................. 66
13.1. HARDWARE SCHEME ...........................................................................................................................66
13.2. INTERNAL REGISTER SCHEME BASED ON DOUBLE FRAME .........................................................66
13.3. INTERNAL REGISTER SCHEME BASED ON CRC4 MULTIFRAME....................................................68
14. HDLC CONTROLLER FOR THE SA BITS OR DS0 ......................................................... 70
14.1. GENERAL OVERVIEW ...........................................................................................................................70
14.2. HDLC STATUS REGISTERS..................................................................................................................71
14.3. BASIC OPERATION DETAILS ...............................................................................................................72
14.3.1. Example: Receive an HDLC Message................................................................................................72
14.3.2. Example: Transmit an HDLC Message...............................................................................................72
14.4. HDLC REGISTER DESCRIPTION..........................................................................................................73
15. LINE INTERFACE FUNCTIONS........................................................................................ 80
15.1. RECEIVE CLOCK AND DATA RECOVERY.......................................................................................................81
15.2. TRANSMIT WAVESHAPING AND LINE DRIVING ..............................................................................................81
15.3. JITTER ATTENUATOR..................................................................................................................................82
15.4. PROTECTED INTERFACES ...........................................................................................................................86
15.5. RECEIVE MONITOR MODE ..........................................................................................................................89
16. JTAG BOUNDARY SCAN ARCHITECTURE AND TEST ACCESS PORT...................... 90
16.1. INSTRUCTION REGISTER.............................................................................................................................95
16.2. TEST REGISTERS.......................................................................................................................................96
17. INTERLEAVED PCM BUS OPERATION .......................................................................... 98
17.1. CHANNEL INTERLEAVE ...............................................................................................................................99
17.2. FRAME INTERLEAVE ...................................................................................................................................99
18. FUNCTIONAL TIMING DIAGRAMS................................................................................ 100
18.1. RECEIVE .................................................................................................................................................100
18.2. TRANSMIT ...............................................................................................................................................104
19. OPERATING PARAMETERS.......................................................................................... 111
20. AC TIMING PARAMETERS AND DIAGRAMS ............................................................... 112
20.1. MULTIPLEXED BUS AC CHARACTERISTICS ................................................................................................112
20.2. NONMULTIPLEXED BUS AC CHARACTERISTICS..........................................................................................115
20.3. RECEIVE-SIDE AC CHARACTERISTICS ......................................................................................................117
20.4. TRANSMIT AC CHARACTERISTICS.............................................................................................................121
21. PACKAGE INFORMATION............................................................................................. 124

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
4 of 124
LIST OF FIGURES
Figure 2-1. DS21354/554 Block Diagram ............................................................................................................................. 9
Figure 15-1. Basic External Analog Connections .............................................................................................................. 83
Figure 15-2. Optional Crystal Connection........................................................................................................................... 83
Figure 15-3. Jitter Tolerance................................................................................................................................................. 84
Figure 15-4. Jitter Attenuation .............................................................................................................................................. 84
Figure 15-5. Transmit Waveform Template........................................................................................................................ 85
Figure 15-6. Protected Interface Example for the DS21554 ............................................................................................ 87
Figure 15-7. Protected Interface Example for the DS21354 ............................................................................................ 88
Figure 15-8. Typical Monitor Port Application .................................................................................................................... 89
Figure 16-1. JTAG Functional Block Diagram.................................................................................................................... 91
Figure 16-2. TAP Controller State Diagram........................................................................................................................ 94
Figure 17-1. IBO Basic Configuration Using Four SCTs .................................................................................................. 99
Figure 18-1. Receive-Side Timing...................................................................................................................................... 100
Figure 18-2. Receive-Side Boundary Timing (with Elastic Store Disabled)................................................................. 100
Figure 18-3. Receive-Side 1.544MHz Boundary Timing (with Elastic Store Enabled) .............................................. 101
Figure 18-4. Receive-Side 2.048MHz Boundary Timing (with Elastic Store Enabled) .............................................. 101
Figure 18-5. Receive-Side Interleave Bus Operation, Byte Mode ................................................................................ 102
Figure 18-6. Receive-Side Interleave Bus Operation, Frame Mode ............................................................................. 103
Figure 18-7. Transmit-Side Timing .................................................................................................................................... 104
Figure 18-8. Transmit-Side Boundary Timing (with Elastic Store Disabled)................................................................ 104
Figure 18-9. Transmit-Side 1.544MHz Boundary Timing (with Elastic Store Enabled) ............................................. 105
Figure 18-10. Transmit-Side 2.048MHz Boundary Timing (with Elastic Store Enabled) ........................................... 105
Figure 18-11. Transmit-Side Interleave Bus Operation, Byte Mode ............................................................................. 106
Figure 18-12. Transmit-Side Interleave Bus Operation, Frame Mode.......................................................................... 107
Figure 18-13. G.802 Timing ................................................................................................................................................ 108
Figure 18-14. DS21354/DS21554 Framer Synchronization Flowchart ........................................................................ 109
Figure 18-15. DS21354/DS21554 Transmit Data Flow .................................................................................................. 110
Figure 20-1. Intel Bus Read Ac Timing (BTS = 0/MUX = 1)........................................................................................... 113
Figure 20-2. Intel Bus Write Timing (BTS = 0/MUX = 1)................................................................................................. 113
Figure 20-3. Motorola Bus AC Timing (BTS = 1/MUX = 1) ............................................................................................ 114
Figure 20-4. Intel Bus Read AC Timing (BTS = 0/MUX = 0).......................................................................................... 115
Figure 20-5. Intel Bus Write AC Timing (BTS = 0/MUX = 0) .......................................................................................... 116
Figure 20-6. Motorola Bus Read AC Timing (BTS = 1/MUX = 0).................................................................................. 116
Figure 20-7. Motorola Bus Write AC Timing (BTS = 1/MUX = 0).................................................................................. 116
Figure 20-8. Receive-Side AC Timing ............................................................................................................................... 118
Figure 20-9. Receive System Side AC Timing................................................................................................................. 119
Figure 20-10. Receive Line Interface AC Timing............................................................................................................. 120
Figure 20-11. Transmit-Side AC Timing............................................................................................................................ 122
Figure 20-12. Transmit System Side AC Timing.............................................................................................................. 123
Figure 20-13. Transmit Line Interface Side AC Timing................................................................................................... 123

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
5 of 124
LIST OF TABLES
Table 3-1. Pin Description Sorted by Pin Number............................................................................................................. 10
Table 3-2. Pin Description by Symbol ................................................................................................................................. 12
Table 4-1. Register Map Sorted by Address ...................................................................................................................... 25
Table 5-1. Device ID Bit Map ................................................................................................................................................ 30
Table 5-2. SYNC/RESYNC Criteria ..................................................................................................................................... 32
Table 6-1. Alarm Criteria ....................................................................................................................................................... 46
Table 14-1. HDLC Controller Register List ......................................................................................................................... 70
Table 15-1. Line Build-Out Select in LICR for the DS21554............................................................................................ 81
Table 15-2. Line Build-Out Select in LICR for the DS21354............................................................................................ 82
Table 15-3. Transformer Specifications .............................................................................................................................. 82
Table 15-4. Receive Monitor Mode Gain ............................................................................................................................ 89
Table 16-1. Instruction Codes for IEEE 1149.1 Architecture ........................................................................................... 95
Table 16-2. ID Code Structure.............................................................................................................................................. 96
Table 16-3. Device ID Codes................................................................................................................................................ 96
Table 16-4. Boundary Scan Control Bits............................................................................................................................. 97
Table 17-1. IBO Master Device Select ................................................................................................................................98

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
6 of 124
1. INTRODUCTION
The DS21354/DS21554 are superset versions of the popular DS2153 and DS2154 SCTs offering the new
features listed below. All the original features of the DS2153 and DS2154 have been retained, and the
software created for the original devices is transferable into the DS21354/DS21554.
New Features in the DS21354 and DS21554
FEATURE SECTION
HDLC controller with 64-Byte Buffers for Sa Bits or DS0s or Sub DS0s 14
Interleaving PCM Bus Operation 17
IEEE 1149.1 JTAG-Boundary Scan Architecture 16
3.3V (DS21354 Only) Supply 1.1 and 2
Line Interface Support for the G.703 2.048 Synchronization Interface 15
Customer Disconnect Indication (...101010...) Generator 5.6
Open-Drain Line Driver Option 5.6
Additional Features in the DS21354 and DS21554
FEATURE SECTION
Option for nonmultiplexed bus operation 1.1 and 20.2
Crystal-less jitter attenuation 15.3
Additional hardware signaling capability including:
Receive signaling reinsertion to a backplane multiframe sync
Availability of signaling in a separate PCM data stream
Signaling freezing Interrupt generated on change of signaling data
9
Improved receive sensitivity: 0 to -43dB 1.1
Per-channel code insertion in both transmit and receive paths 10
Expanded access to Sa and Si bits 13
RCL, RLOS, RRA, and RAIS alarms now interrupt on change of state 6
8.192MHz clock synthesizer 1.1
Per-channel loopback 10
Addition of hardware pins to indicate carrier loss and signaling freeze 1.1
Line interface function can be completely decoupled from the framer/formatter to
allow:
Interface to optical, HDSL, and other NRZ interfaces
“tap” the transmit and receive bipolar data streams for monitoring purposes
Be able to corrupt data and insert framing errors, CRC errors, etc.
1.1
Transmit and receive elastic stores now have independent backplane clocks 1.1
Ability to monitor one DS0 channel in both the transmit and receive paths 8
Access to the data streams in between the framer/formatter and the elastic stores 1.1
AIS generation in the line interface that is independent of loopbacks 1.1 and 5
Transmit current limiter to meet the 50mA short circuit requirement 15
Option to extend carrier loss criteria to a 1ms period as per ETS 300 233 5.4
Automatic RAI generation to ETS 300 011 specifications 5.4

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
7 of 124
1.1. Functional Description
The analog AMI/HDB3 waveform off the E1 line is transformer coupled into the RRING and RTIP pins
of the DS21354/554. The device recovers clock and data from the analog signal and passes it through the
jitter attenuation mux to the receive-side framer where the digital serial stream is analyzed to locate the
framing/multiframe pattern. The DS21354/DS21554 contain an active filter that reconstructs the analog-
received signal for the nonlinear losses that occur in transmission. The devices have a usable receive
sensitivity of 0 to -43dB, which allows the device to operate on cables over 2km in length. The receive-
side framer locates FAS frame and CRC and CAS multiframe boundaries as well as detects incoming
alarms including, carrier loss, loss of synchronization, AIS, and Remote Alarm. If needed, the receive-
side elastic store can be enabled to absorb the phase and frequency differences between the recovered E1
data stream and an asynchronous backplane clock, which is provided at the RSYSCLK input. The clock
applied at the RSYSCLK input can be either a 2.048MHz/4.096MHz/8.192MHz clock or a 1.544MHz
clock.
The transmit-side framer is totally independent from the receive side in both the clock requirements and
characteristics. Data off a backplane can be passed through a transmit-side elastic store if necessary. The
transmit formatter provides the necessary frame/multiframe data overhead for E1 transmission.
Reader’s Note: This data sheet assumes a particular nomenclature of the E1 operating environment. In
each 125ms frame, there are 32 eight-bit time slots numbered 0 to 31. Time slot 0 is transmitted first and
received first. These 32 time slots are also referred to as channels with a numbering scheme of 1 to 32.
Time slot 0 is identical to channel 1, time slot 1 is identical to Channel 2, and so on. Each time slot (or
channel) is made up of eight bits, which are numbered 1 to 8. Bit number 1 is the most significant bit
(MSB) and is transmitted first. Bit number 8 is the least significant bit (LSB) and is transmitted last. The
term “locked” refers to two clock signals that are phase or frequency locked, or derived from a common
clock (i.e., a 1.544MHz clock may be locked to a 2.048MHz clock if they share the same 8kHz
component). Throughout this data sheet, the following abbreviations are used:
NAME FUNCTION
FAS Frame-Alignment Signal
CAS Channel-Associated Signaling
MF Multiframe
Si International Bits
CRC4 Cyclical Redundancy Check
CCS Common-Channel Signaling
Sa Additional Bits
E-Bit CRC4 Error Bits

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
8 of 124
1.2. Document Revision History
REVISION DESCRIPTION
012799 Initial release
012899 Corrected TSYSCLK and RSYSCLK timing and added 4.096MHz and 8.192MHz
timing
020399 Corrected definition and label of TUDR bit in the THIR register.
021199 Corrected address of IBO register in text.
040199 Added Receive Monitor Mode section
041599 Added section on Protected Interfaces
050799 Corrected pin number and description of FMS in JTAG section
072999 Added list of tables and figures
091499 Added 10mF cap to interface examples
092399 Corrected definition of DS in pin description.
072401 Typo corrected in JTAG Test Access Port Pins.
021004
Added note to the Receive Information Register, FAS Resync Criteria Met.
Corrected Figures 20-1, 20-2, 20-3 with respect to CS.
Corrected typo in Figure 18-14 (RCR1.1 reference corrected).
Corrected formatting issues.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
9 of 124
2. BLOCK DIAGRAM
Figure 2-1. DS21354/554 Block Diagram
Receive Side
Framer
Transmit Side
Formatter
Elastic
Store
TSYNC TCLK TCHCLK
TSER
TCHBLK
RCHCLK RCHBLK RMSYNC
TSSYNC TSYSCLK
RSER RSYSCLK RSYNC RFSYNC
TLINK TLCLK
Timing Control
Elastic
Store
Sync Control
Timing Control
RLOS/LOTC
Signaling
Buffer
Hardware Signaling Insertion TSIG
RSIGF
RCL
Local Loopback
TRING
TTIP
Jitter Attenuator
Either transmit or receive path
Receive
Line I/F
Clock / Data
Recovery
RRING
RTIP
Remote Loopback
VCO / PLL
MCLK
8XCLK
8MCLK
8.192MHz Clock
Synthesizer
32.768MHz
16.384 MHz
XTALD
RCLK
RPOSO
RNEGO
RNEGI
RPOSI
TPOSI
TNEGI
TNEGO
TPOSO
TESO TDATA
RCLKO
RCLKI
RDATA
TCLKI
TCLKO
LIUC
LIUC
Parallel & Test Control Port
(routed to all blocks)
D0 to D7 /
AD0 to AD7
BTS
INT*
WR*(R/W*)
RD*(DS*)
CS*
TEST
ALE(AS) / A7
A0 to A6
MUX
8
7
Interleave Bus
CI
RSYSCLK
Interleave Bus
MUX
MUX
Transmit
LineI/F
DATA
CLOCK
SYNC
Framer Loopback
HDLC/BOC Controller Sa / DS0
LOTC MUX
HDLC/BOC Controller Sa / DS0
SYNC
CLOCK
DATA
CO
JTAG PORT
JRST*
JTMS
JTCLK
JTDI
JTDO
RLINK RLCLK RSIG
Sa
DS21354
/
DS21554

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
10 of 124
3. PIN DESCRIPTION
Table 3-1. Pin Description Sorted by Pin Number
PIN NAME TYPE FUNCTION
1 RCHBLK O Receive Channel Block
2 JTMS I IEEE 1149.1 Test Mode Select
3 8MCLK O 8.192 MHz Clock
4 JTCLK I IEEE 1149.1 Test Clock Signal
5 JTRST I IEEE 1149.1 Test Reset, Active Low
6 RCL O Receive Carrier Loss
7 JTDI I IEEE 1149.1 Test Data Input
8, 9, 15,
23, 26, 27,
28
N.C. — No Connect. Do not connect any signal to this pin.
10 JTDO O IEEE 1149.1 Test Data Output
11 BTS I Bus Type Select
12 LIUC I Line Interface Connect
13 8XCLK O Eight Times Clock
14 TEST I Test
16 RTIP I Receive Analog Tip Input
17 RRING I Receive Analog Ring Input
18 RVDD – Receive Analog Positive Supply
19, 20, 24 RVSS – Receive Analog Signal Ground
21 MCLK I Master Clock Input
22 XTALD O Quartz Crystal Driver
25 INT O Interrupt, Active Low
29 TTIP O Transmit Analog Tip Output
30 TVSS – Transmit Analog Signal Ground
31 TVDD – Transmit Analog Positive Supply
32 TRING O Transmit Analog Ring Output
33 TCHBLK O Transmit Channel Block
34 TLCLK O Transmit Link Clock
35 TLINK I Transmit Link Data
36 CI I Carry In
37 TSYNC I/O Transmit Sync
38 TPOSI I Transmit Positive Data Input
39 TNEGI I Transmit Negative Data Input
40 TCLKI I Transmit Clock Input
41 TCLKO O Transmit Clock Output
42 TNEGO O Transmit Negative Data Output
43 TPOSO O Transmit Positive Data Output
44, 61,
81,83 DVDD — Digital Positive Supply
45, 60, 80,
84 DVSS — Digital Signal Ground
46 TCLK I Transmit Clock
47 TSER I Transmit Serial Data
48 TSIG I Transmit Signaling Input

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
11 of 124
PIN NAME TYPE FUNCTION
49 TESO O Transmit Elastic Store Output
50 TDATA I Transmit Data
51 TSYSCLK I Transmit System Clock
52 TSSYNC I Transmit System Sync
53 TCHCLK O Transmit Channel Clock
54 CO O Carry Out
55 MUX I Bus Operation
56 D0/AD0 I/O Data Bus Bit0/Address/Data Bus Bit 0
57 D1/AD1 I/O Data Bus Bit1/Address/Data Bus Bit 1
58 D2/AD2 I/O Data Bus Bit 2/Address/Data Bus 2
59 D3/AD3 I/O Data Bus Bit 3/Address/Data Bus Bit 3
62 D4/AD4 I/O Data Bus Bit4/Address/Data Bus Bit 4
63 D5/AD5 I/O Data Bus Bit 5/Address/Data Bus Bit 5
64 D6/AD6 I/O Data Bus Bit 6/Address/Data Bus Bit 6
65 D7/AD7 I/O Data Bus Bit 7/Address/Data Bus Bit 7
66 A0 I Address Bus Bit 0
67 A1 I Address Bus Bit 1
68 A2 I Address Bus Bit 2
69 A3 I Address Bus Bit 3
70 A4 I Address Bus Bit 4
71 A5 I Address Bus Bit 5
72 A6 I Address Bus Bit 6
73 ALE (AS)/A7 I Address Latch Enable/Address Bus Bit 7
74 RD (DS) I Read Input (Data Strobe), Active Low
75 CS I Chip Select, Active Low
76 FMS I Framer Mode Select
77 WR (R/W) I Write Input (Read/Write), Active Low
78 RLINK O Receive Link Data
79 RLCLK O Receive Link Clock
82 RCLK O Receive Clock
85 RDATA O Receive Data
86 RPOSI I Receive Positive Data Input
87 RNEGI I Receive Negative Data Input
88 RCLKI I Receive Clock Input
89 RCLKO O Receive Clock Output
90 RNEGO O Receive Negative Data Output
91 RPOSO O Receive Positive Data Output
92 RCHCLK O Receive Channel Clock
93 RSIGF O Receive Signaling Freeze Output
94 RSIG O Receive Signaling Output
95 RSER O Receive Serial Data
96 RMSYNC O Receive Multiframe Sync
97 RFSYNC O Receive Frame Sync
98 RSYNC I/O Receive Sync
99 RLOS/LOTC O Receive Loss Of Sync/ Loss Of Transmit Clock
100 RSYSCLK I Receive System Clock

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
12 of 124
Table 3-2. Pin Description by Symbol
PIN NAME TYPE FUNCTION
3 8MCLK O 8.192MHz Clock
13 8XCLK O Eight-Times Clock
66 A0 I Address Bus Bit 0
67 A1 I Address Bus Bit 1
68 A2 I Address Bus Bit 2
69 A3 I Address Bus Bit 3
70 A4 I Address Bus Bit 4
71 A5 I Address Bus Bit 5
72 A6 I Address Bus Bit 6
73 ALE (AS)/A7 I Address Latch Enable/Address Bus Bit 7
11 BTS I Bus Type Select
36 CI I Carry In
54 CO O Carry Out
75 CS I Chip Select, Active Low
56 D0/AD0 I/O Data Bus Bit0/ Address/Data Bus Bit 0
57 D1/AD1 I/O Data Bus Bit1/ Address/Data Bus Bit 1
58 D2/AD2 I/O Data Bus Bit 2/Address/Data Bus 2
59 D3/AD3 I/O Data Bus Bit 3/Address/Data Bus Bit 3
62 D4/AD4 I/O Data Bus Bit4/Address/Data Bus Bit 4
63 D5/AD5 I/O Data Bus Bit 5/Address/Data Bus Bit 5
64 D6/AD6 I/O Data Bus Bit 6/Address/Data Bus Bit 6
65 D7/AD7 I/O Data Bus Bit 7/Address/Data Bus Bit 7
44, 61, 81, 83 DVDD — Digital Positive Supply
45, 60, 80, 84 DVSS — Digital Signal Ground
76 FMS I Framer Mode Select
25 INT O Interrupt
4 JTCLK I IEEE 1149.1 Test Clock Signal
7 JTDI I IEEE 1149.1 Test Data Input
10 JTDO O IEEE 1149.1 Test Data Output
2 JTMS I IEEE 1149.1 Test Mode Select
5 JTRST I IEEE 1149.1 Test Reset, Active Low
12 LIUC I Line Interface Connect
21 MCLK I Master Clock Input
55 MUX I Bus Operation
8, 9, 15, 23, 26,
27, 28 N.C. — No Connect. Do not connect any signal to this pin.
1 RCHBLK O Receive Channel Block
92 RCHCLK O Receive Channel Clock
6 RCL O Receive Carrier Loss
82 RCLK O Receive Clock
88 RCLKI I Receive Clock Input
89 RCLKO O Receive Clock Output
74 RD (DS) I Read Input (Data Strobe), Active Low
85 RDATA O Receive Data
97 RFSYNC O Receive Frame Sync
79 RLCLK O Receive Link Clock

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
13 of 124
PIN NAME TYPE FUNCTION
78 RLINK O Receive Link Data
99 RLOS/LOTC O Receive Loss of Sync/Loss of Transmit Clock
96 RMSYNC O Receive Multiframe Sync
87 RNEGI I Receive Negative Data Input
90 RNEGO O Receive Negative Data Output
86 RPOSI I Receive Positive Data Input
91 RPOSO O Receive Positive Data Output
17 RRING I Receive Analog Ring Input
95 RSER O Receive Serial Data
94 RSIG O Receive Signaling Output
93 RSIGF O Receive Signaling Freeze Output
98 RSYNC I/O Receive Sync
100 RSYSCLK I Receive System Clock
16 RTIP I Receive Analog Tip Input
18 RVDD — Receive Analog Positive Supply
19, 20, 24 RVSS — Receive Analog Signal Ground
33 TCHBLK O Transmit Channel Block
53 TCHCLK O Transmit Channel Clock
46 TCLK I Transmit Clock
40 TCLKI I Transmit Clock Input
41 TCLKO O Transmit Clock Output
50 TDATA I Transmit Data
49 TESO O Transmit Elastic Store Output
14 TEST I Test
34 TLCLK O Transmit Link Clock
35 TLINK I Transmit Link Data
39 TNEGI I Transmit Negative Data Input
42 TNEGO O Transmit Negative Data Output
38 TPOSI I Transmit Positive Data Input
43 TPOSO O Transmit Positive Data Output
32 TRING O Transmit Analog Ring Output
47 TSER I Transmit Serial Data
48 TSIG I Transmit Signaling Input
52 TSSYNC I Transmit System Sync
37 TSYNC I/O Transmit Sync
51 TSYSCLK I Transmit System Clock
29 TTIP O Transmit Analog Tip Output
31 TVDD — Transmit Analog Positive Supply
30 TVSS — Transmit Analog Signal Ground
77 WR (R/W) I Write Input (Read/Write), Active Low
22 XTALD O Quartz Crystal Driver

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
14 of 124
3.1. Pin Function Description
3.1.1. Transmit-Side Pins
Signal Name: TCLK
Signal Description: Transmit Clock
Signal Type: Input
A 2.048MHz primary clock. Used to clock data through the transmit side formatter.
Signal Name: TSER
Signal Description: Transmit Serial Data
Signal Type: Input
Transmit NRZ serial data. Sampled on the falling edge of TCLK when the transmit side elastic store is
disabled. Sampled on the falling edge of TSYSCLK when the transmit side elastic store is enabled.
Signal Name: TCHCLK
Signal Description: Transmit Channel Clock
Signal Type: Output
A 256kHz clock that pulses high during the LSB of each channel. Synchronous with TCLK when the
transmit side elastic store is disabled. Synchronous with TSYSCLK when the transmit side elastic store is
enabled. Useful for parallel to serial conversion of channel data.
Signal Name: TCHBLK
Signal Description: Transmit Channel Block
Signal Type: Output
A user-programmable output that can be forced high or low during any of the 32 E1 channels.
Synchronous with TCLK when the transmit side elastic store is disabled. Synchronous with TSYSCLK
when the transmit-side elastic store is enabled. Useful for blocking clocks to a serial UART or LAPD
controller in applications where not all E1 channels are used such as Fractional E1, 384kbps (H0),
768kbps, or ISDN–PRI. Also useful for locating individual channels in drop-and-insert applications, for
external per-channel loopback, and for per-channel conditioning. See Section 12 for details.
Signal Name: TSYSCLK
Signal Description: Transmit System Clock
Signal Type: Input
1.544MHz, 2.048MHz, 4.096MHz, or 8.192MHz clock. Only used when the transmit-side elastic store
function is enabled. Should be tied low in applications that do not use the transmit-side elastic store. See
Section 17 for details on 4.096MHz and 8.192MHz operation using the Interleave Bus Option.
Signal Name: TLCLK
Signal Description: Transmit Link Clock
Signal Type: Output
4kHz to 20kHz demand clock (Sa bits) for the TLINK input. See Section 17 for details.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
15 of 124
Signal Name: TLINK
Signal Description: Transmit Link Data
Signal Type: Input
If enabled, this pin will be sampled on the falling edge of TCLK for data insertion into any combination
of the Sa bit positions (Sa4 to Sa8). See Section 13 for details.
Signal Name: TSYNC
Signal Description: Transmit Sync
Signal Type: Input/Output
A pulse at this pin will establish either frame or multiframe boundaries for the transmit side. Via TCR1.1,
the DS21354/DS21554 can be programmed to output either a frame or multiframe pulse at this pin. This
pin can also be configured as an input via TCR1.0. See Section 18 for details.
Signal Name: TSSYNC
Signal Description: Transmit System Sync
Signal Type: Input
Only used when the transmit-side elastic store is enabled. A pulse at this pin will establish either frame or
multiframe boundaries for the transmit side. Should be tied low in applications that do not use the
transmit-side elastic store.
Signal Name: TSIG
Signal Description: Transmit Signaling Input
Signal Type: Input
When enabled, this input will sample signaling bits for insertion into outgoing PCM E1 data stream.
Sampled on the falling edge of TCLK when the transmit-side elastic store is disabled. Sampled on the
falling edge of TSYSCLK when the transmit-side elastic store is enabled.
Signal Name: TESO
Signal Description: Transmit Elastic Store Data Output
Signal Type: Output
Updated on the rising edge of TCLK with data out of the transmit-side elastic store whether the elastic
store is enabled or not. This pin is normally tied to TDATA.
Signal Name: TDATA
Signal Description: Transmit Data
Signal Type: Input
Sampled on the falling edge of TCLK with data to be clocked through the transmit-side formatter. This
pin is normally tied to TESO.
Signal Name: TPOSO
Signal Description: Transmit Positive Data Output
Signal Type: Output
Updated on the rising edge of TCLKO with the bipolar data out of the transmit-side formatter. Can be
programmed to source NRZ data via the Output Data Format (TCR2.2) control bit. This pin is normally
tied to TPOSI.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
16 of 124
Signal Name: TNEGO
Signal Description: Transmit Negative Data Output
Signal Type: Output
Updated on the rising edge of TCLKO with the bipolar data out of the transmit-side formatter. This pin is
normally tied to TNEGI.
Signal Name: TCLKO
Signal Description: Transmit Clock Output
Signal Type: Output
Buffered output of signal that is clocking data through the transmit-side formatter. This pin is normally
tied to TCLKI.
Signal Name: TPOSI
Signal Description: Transmit Positive Data Input
Signal Type: Input
Sampled on the falling edge of TCLKI for data to be transmitted out onto the T1 line. Can be internally
connected to TPOSO by tying the LIUC pin high. TPOSI and TNEGI can be tied together in NRZ
applications.
Signal Name: TNEGI
Signal Description: Transmit Negative Data Input
Signal Type: Input
Sampled on the falling edge of TCLKI for data to be transmitted out onto the T1 line. Can be internally
connected to TNEGO by tying the LIUC pin high. TPOSI and TNEGI can be tied together in NRZ
applications.
Signal Name: TCLKI
Signal Description: Transmit Clock Input
Signal Type: Input
Line interface transmit clock. Can be internally connected to TCLKO by tying the LIUC pin high.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
17 of 124
3.1.2. Receive-Side Pins
Signal Name: RLINK
Signal Description: Receive Link Data
Signal Type: Output
Updated with the fully recovered E1 data stream on the rising edge of RCLK.
Signal Name: RLCLK
Signal Description: Receive Link Clock
Signal Type: Output
4kHz to 20kHz clock (Sa bits) for the RLINK output. See Section 13 for details.
Signal Name: RCLK
Signal Description: Receive Clock
Signal Type: Output
2.048MHz clock that is used to clock data through the receive-side framer.
Signal Name: RCHCLK
Signal Description: Receive Channel Clock
Signal Type: Output
A 256kHz clock that pulses high during the LSB of each channel. Synchronous with RCLK when the
receive-side elastic store is disabled. Synchronous with RSYSCLK when the receive-side elastic store is
enabled. Useful for parallel to serial conversion of channel data.
Signal Name: RCHBLK
Signal Description: Receive Channel Block
Signal Type: Output
A user-programmable output that can be forced high or low during any of the 32 E1 channels.
Synchronous with RCLK when the receive-side elastic store is disabled. Synchronous with RSYSCLK
when the receive-side elastic store is enabled. Useful for blocking clocks to a serial UART or LAPD
controller in applications where not all E1 channels are used such as Fractional E1, 384kbps service,
768kbps, or ISDN–PRI. Also useful for locating individual channels in drop-and-insert applications, for
external per-channel loopback, and for per-channel conditioning. See Section 10 for details.
Signal Name: RSER
Signal Description: Receive Serial Data
Signal Type: Output
Received NRZ serial data. Updated on rising edges of RCLK when the receive-side elastic store is
disabled. Updated on the rising edges of RSYSCLK when the receive-side elastic store is enabled.
Signal Name: RSYNC
Signal Description: Receive Sync
Signal Type: Input/Output
An extracted pulse, one RCLK wide, is output at this pin that identifies either frame or CAS/CRC
multiframe boundaries. If the receive-side elastic store is enabled, then this pin can be enabled to be an
input at which a frame or multiframe boundary pulse synchronous with RSYSCLK is applied.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
18 of 124
Signal Name: RFSYNC
Signal Description: Receive Frame Sync
Signal Type: Output
An extracted 8kHz pulse, one RCLK wide, is output at this pin that identifies frame boundaries.
Signal Name: RMSYNC
Signal Description: Receive Multiframe Sync
Signal Type: Output
If the receive-side elastic store is enabled, an extracted pulse, one RSYSCLK wide, is output at this pin
that identifies multiframe boundaries. If the receive-side elastic store is disabled, then this output will
output multiframe boundaries associated with RCLK.
Signal Name: RDATA
Signal Description: Receive Data
Signal Type: Output
Updated on the rising edge of RCLK with the data out of the receive-side framer.
Signal Name: RSYSCLK
Signal Description: Receive System Clock
Signal Type: Input
1.544MHz, 2.048MHz, 4.096MHz, or 8.192MHz clock. Only used when the receive-side elastic store
function is enabled. Should be tied low in applications that do not use the receive-side elastic store. See
Section 17 for details on 4.096MHz and 8.192MHz operation using the Interleave Bus Option.
Signal Name: RSIG
Signal Description: Receive Signaling Output
Signal Type: Output
Outputs signaling bits in a PCM format. Updated on rising edges of RCLK when the receive-side elastic
store is disabled. Updated on the rising edges of RSYSCLK when the receive-side elastic store is enabled.
Signal Name: RLOS/LOTC
Signal Description: Receive Loss of Sync / Loss of Transmit Clock
Signal Type: Output
A dual function output that is controlled by the TCR2.0 control bit. This pin can be programmed to either
toggle high when the synchronizer is searching for the frame and multiframe or to toggle high if the
TCLK pin has not been toggled for 5ms.
Signal Name: RCL
Signal Description: Receive Carrier Loss
Signal Type: Output
Set high when the line interface detects a carrier loss.
Signal Name: RSIGF
Signal Description: Receive Signaling Freeze
Signal Type: Output
Set high when the signaling data is frozen via either automatic or manual intervention. Used to alert
downstream equipment of the condition.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
19 of 124
Signal Name: 8MCLK
Signal Description: 8MHz Clock
Signal Type: Output
An 8.192MHz clock output that is referenced to the clock that is output at the RCLK pin.
Signal Name: RPOSO
Signal Description: Receive Positive Data Input
Signal Type: Output
Updated on the rising edge of RCLKO with bipolar data out of the line interface. This pin is normally tied
to RPOSI.
Signal Name: RNEGO
Signal Description: Receive Negative Data Input
Signal Type: Output
Updated on the rising edge of RCLKO with the bipolar data out of the line interface. This pin is normally
tied to RNEGI.
Signal Name: RCLKO
Signal Description: Receive Clock Output
Signal Type: Output
Buffered recovered clock from the T1 line. This pin is normally tied to RCLKI.
Signal Name: RPOSI
Signal Description: Receive Positive Data Input
Signal Type: Input
Sampled on the falling edge of RCLKI for data to be clocked through the receive-side framer. RPOSI and
RNEGI can be tied together for a NRZ interface. Can be internally connected to RPOSO by tying the
LIUC pin high.
Signal Name: RNEGI
Signal Description: Receive Negative Data Input
Signal Type: Input
Sampled on the falling edge of RCLKI for data to be clocked through the receive-side framer. RPOSI and
RNEGI can be tied together for a NRZ interface. Can be internally connected to RNEGO by tying the
LIUC pin high.
Signal Name: RCLKI
Signal Description: Receive Clock Input
Signal Type: Input
Clock used to clock data through the receive-side framer. This pin is normally tied to RCLKO. Can be
internally connected to RCLKO by tying the LIUC pin high.

DS21354/DS21554 3.3V/5V E1 Single-Chip Transceivers
20 of 124
3.1.3. Parallel Control Port Pins
Signal Name: INT
Signal Description: Interrupt
Signal Type: Output
Active-low, open-drain output that flags host controller during conditions and change of conditions
defined in the Status Registers 1 and 2 and the HDLC Status Register.
Signal Name: FMS
Signal Description: Framer Mode Select
Signal Type: Input
Selects the DS2154 mode when high or the DS21354/DS21554 mode when low. If high, the JTRST is
internally pulled low. If low, JTRST has normal JTAG functionality. This pin has a 10kWpullup resistor.
Signal Name: TEST
Signal Description: Tri-State Control
Signal Type: Input
Set high to tri-state all output and I/O pins (including the parallel control port). Set low for normal
operation. Useful in board-level testing.
Signal Name: MUX
Signal Description: Bus Operation
Signal Type: Input
Set low to select nonmultiplexed bus operation. Set high to select multiplexed bus operation.
Signal Name: AD0 to AD7
Signal Description: Data Bus [D0 to D7] or Address/Data Bus
Signal Type: Input
In nonmultiplexed bus operation (MUX = 0), serves as the data bus. In multiplexed bus operation
(MUX = 1), serves as an 8-bit multiplexed address/data bus.
Signal Name: A0 to A6
Signal Description: Address Bus
Signal Type: Input
In nonmultiplexed bus operation (MUX = 0), serves as the address bus. In multiplexed bus operation
(MUX = 1), these pins are not used and should be tied low.
Signal Name: BTS
Signal Description: Bus Type Select
Signal Type: Input
Strap high to select Motorola bus timing; strap low to select Intel bus timing. This pin controls the
function of the RD (DS), ALE (AS), and WR (R/W) pins. If BTS = 1, then these pins assume the function
listed in parentheses ().
