DAN DRYER 659 User manual

Read the installation instructions thoroughly before
commencing installation.
The design of the safety baby changing station makes it easy to
mount in even very small rooms. The changing table must be
mounted onto a wall which is suited to carry the weight of the
table as well as a baby –preferablya solid wall !
Where to mount the Baby Changing Station
Determine the ideal place to mount the baby changing table. Keep
in mind that the depth of the changing table is 625 mm in open
position. The distance from the floor to the lower edge of the table
mountings should be approx. 750 mm (see FIG. 1). Doorways,
sinks etc. should of course also be taken into consideration when
choosing where to mount the changing table.
IMPORTANT:Do NOT mount the table in a chlorine-containing
environment!
Marking and drilling holes
To mount the changing table onto brick, gas concrete or the like,
use 10 mm screws and matching universal plastic dowels –e.g.
Fischer fixings type S-12. When mounting the changing table onto
a cavity wall of min. 16 mm (or 2 x 13 mm) plaster board, we
recommend prior mounting of a reinforcement plate of stainless
steel, plywood or the like, onto which the changing table is
subsequently mounted. Attach reinforcement plate to the wall
using a considerable number of special metal cavity fixings,
Fischer part. no. BC 62328 or equivalent (part. no. BC 62315 for
double plate). The changing table itself is also mounted with these
screws and dowels –plus one metal washer per screw hole. For
further details, please refer to the instructions of the dowel
supplier. In places where plaster walls have not yet been finished,
we suggest mounting a 16 mm plywood board on the inside of the
plaster wall, rendering the need for a reinforcement plate on the
outside unnecessary. Mark and drill holes as indicated on FIG. 1.
The top holes for the table mountings should be drilled into solid
brick -not into a joint.
Mounting the Baby Changing Station
➊Disassemble the cover plates of the table mountings by
removing the 6 screws
(3 on each) with a Torx screwdriver no. 20.
➋Mount the table onto the wall, making sure that it is completely
level.
➌The baby change unit is factory pre-adjusted to easily close
when given a slight push from open position.
➍Check that the changing table is mounted solidly onto the wall.
➎Check that the shock absorbers can pass freely when opening
and closing the table.
➏Reassemble the cover plates onto the mountings.
IMPORTANT: Be sure to drill the holes for the mountings exactly
vertically underneath each other, or the pneumatic shock
absorbers inside the mountings may break
Fig. 1
The dimensions stated are based on a
work height of approx. 950 mm.

Maintenance, cleaning and malfunction
The table requires no specific maintenance, but regular inspection
and testing is recommended.
Make sure the table can be opened and closed smoothly.
If the table is fitted with a safety strap, this strap must be
inspected regularly to make sure it is intact, and the buckle is
working properly.
Contact your supplier or DAN DRYER A/S immediately if the table
is defective.
The table can be cleaned using a damp cloth. Use only neutral,
liquid cleaning products that do not contain solvents.
Never leave a child unsupervised on the table!
Do not use if damaged, defective or if not securely fixed to the
wall.
You are responsible for making sure the table is safe to use.
Accessory
We recommend that you supplement the Baby Changing Station
with the DAN DRYER Paper Roll Holder, article no. 656.
Installation Instructions
DAN DRYER®safety baby changing station
Art.No. 659 (with safety strap)
Art.No. 660 (without safety strap)
