DAN DRYER 3000 Manual

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 1 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
3000 DAN DRYER Hand dryer
Maintenance and service manual
Version: Description of changes: Page(s):
Version history

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 2 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Preface 2
General 2
Intended product use 2
The supplier’s product liability 2
Safety and warnings 2
Installation and connection 3
Adjustment of the machine 4
Regular maintenance 5
Fault nding and solutions 5
Cleaning the inside of the machine 6
Spare parts 9
Carbon brush replacement 10
Heating element replacement 11
Technical specications 12
Dimensions 12
Wiring chart 12
Table of Contents:
Preface
Thank you for purchasing your equipment from
DAN DRYER A/S and congratulations on your
new hand dryer. If you use and maintain your
hand dryer according to our manual, it will work
to your satisfaction for many years.
General
The hand dryer must only be installed and
used in accordance with these instructions and
safety precautions. All service sta󰀨 who work
with installation, servicing and repair of the
machine must have read and understood this
manual. If you have questions concerning the
use or maintenance of your machine, you are
welcome to contact us.
Intended product use
The hand dryer is designed for installation in
indoor public or private restrooms and may
only be used for hand drying.
The supplier’s product liability:
DAN DRYER A/S accepts no responsibility if
the machine is installed, used, modied or
composed otherwise than specied in this
manual.
Note !!!
The machine is designed for indoor use only.
Warning !!!
If the hand dryer is not installed and connected
properly it can be dangerous to use due to the
risk of electric shock.
Always follow the installation instructions in this
manual.
All service sta󰀨 who work with servicing and
repairing of the machine must have read and
understood this manual.
Warning !!!
During cleaning, inspection, service etc. the hand
dryer must always be disconnected from the
power supply.
All service sta󰀨 who work with servicing and
repairing of the machine must have read and
understood this manual.
Safety Precautions:
Maintenance work requiring dismantling of the
machine must only be carried out by sta󰀨 with
proper training so the work can be carried out in
a secure manner.
Safety Precautions:
• Check before use that:
• the hand dryer is securely attached to the wall.
• the hand dryer is properly cleaned.
• the hand dryer is not damaged or otherwise in
disorder.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 3 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Installation and connection:
To protect the user against electric shock, it is important that the hand dryer is connected to the earth wire.
For xed installation, connect via circuit breaker.
1. Remove the two cover screws at the bottom
of the cover using the supplied special Allen
key. Carefully remove the housing from the
base plate.
Remove the
cover screws
2. Attach the base plate to the wall using ap-
propriate screws in the four mounting holes.
Wiring can be hidden behind the machine or
may alternatively be fed through the bottom
of the cover.
Hole for wall
mounting
screw
Hole for wall
mounting
screw
Hole for wall
mounting
screw
Hole for wall
mounting
screw
Hole for hidden
wiring
Cut-out
for wiring
through the
bottom
4. Connect wires as follows:
A. Connect the live wire (red or brown) to the
terminal block marked ”L”.
B. Connect the neutral wire (blue or black) to
the terminal block marked ”N”.
C. Connect the green and yellow earth wire to
the screw marked ” ”.
3. Do not mount directly above sink or the like.
Minimum distance 300 mm.
5. Remount the cover using the two cover
screws at the bottom of the cover and test
run the hand dryer.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 4 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Sensing range adjustment:
The sensing range of the hand dryer is preset by the manufacturer.
We recommend that the sensing range is NOT adjusted by the user.
If you wish to modify the sensing range anyway, please proceed according to the following instructions:
1. Cut o󰀨 the power supply to the hand dryer
2. Remove the cover by loosening the Allen screws at the
bottom of the housing. This can be done with the special
Allen key originally supplied with your hand dryer.
3. The sensing range adjusting screw is located as shown
in Fig. 1.
Use a tiny screwdriver to carefully turn the adjusting screw.
a. Turn clockwise to lengthen the sensing range.
b. Turn counter-clockwise to shorten the sensing range.
4. Remount housing and test run the hand dryer.
Remove the
cover screws
Turn clockwise to lengthen
the sensing range
Turn counter-clockwise to
shorten the sensing range
Air speed adjustment:
If a lower noise level is desired, air speed may be
adjusted by turning the adjusting screw located
inside at the bottom of the hand dryer cover.
Turn clockwise to increase air
speed and anti-clockwise to
reduce air speed.
Fig. 1.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 5 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Regular maintenance:
To ensure a continued satisfactory function of the hand
dryer it is recommended regularly to remove dust etc.
from the machine.
The frequency of cleaning depends on the environment in
which the hand dryer is installed and how often it is used.
If the machine is used often cleaning is recommended at
least once a month.
• Exhaust pipe and sensor must be cleaned with a
damp cloth.
• Cleaning / vacuuming of the air intake holes in the
handdryer’s cover.
If the machine is rarely used, we recommend cleaning
once every 6 months.
• Exhaust pipe and sensor must be cleaned with a
damp cloth.
• Cleaning / vacuuming of the air intake holes in the
hand dryer’s cover.
In the event that the machine is used extensively and the
environment is very dusty, it may be necessary to clean
the inside of the machine regularly. See more in the
section ”Cleaning the inside of the machine”
Important: To ensure
correct function the IR
sensor must always be
completely clean.
Cleaning / vacuuming
of the air intake holes.
Problem: Solution:
Hand dryer does not start: • Check the 230V power supply.
• Check IR sensor for dirt or damages.
• Check that all electrical connections, wires etc. are intact.
• If none of the above actions corrects the problem, it is either the IR sensor
or the relay that causes the problem and must be replaced.
Blows cold air only: • Heating element unit has been overheated and must be replaced.
• Timer is defective and must be replaced.
Poor air ow: • Dirt and dust in inlet and outlet impair the air ow. Clean the machine,
according to the section “Regular maintenance”.
Other problems not covered by this
guide:
• If the problem is not resolved by the above actions the entire hand dryer
unit must be sent for repair to DAN DRYER or replaced with a new one.
Trouble shooting:
IMPORTANT:
If the unit is returned to DAN DRYER it must be accompanied by a detailed
description of the problem.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 6 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Warning !!!
During cleaning and service the hand dryer must always be disconnected from the power supply
Cleaning the inside of the machine
Remove the
cover screws
1. Disassemble cover by removing the two cover
screws at the bottom of the housing. Use the
special Allen key which was originally supplied
with the hand dryer.
2. Disassemble angle bracket by removing the
screw (A)
(A)
3. Remove the four screws (B). Disassemble
the top half of the motor housing
(B)
(B)
(B)
(B)
4. Carefully lift up the motor whilst taking note how
the motor was positioned inside the housing and
how the motor wires are placed in the protective
grooves (C)
(C)
5. Disconnect motor wires from the timer unit
(appearance depends on the timer type).
Place the motor on a table upside-down.
6. Check whether carbon brushes are worn down
and need to be replaced. If so, disassemble
by removing the screws and by disconnecting
wires from carbon brush terminals.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 7 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Cleaning the inside of the machine
7. Use compressed air (max. 8 bar) to remove
dirt and carbon dust from the motor and motor
housing. If compressed air is not available, parts
may be cleaned with a soft brush or gently with a
vacuum cleaner.
8. Lift the large rubber gasket out of the top of the
motor housing. Clean it and degrease with alco-
hol. Clean the small rubber gasket placed at the
bottom of the motor housing in the same manner.
9. The heating element is placed at the bottom of
the motor housing. Clean it using compressed
air (max. 8 bar). Blow from both sides, and be
careful not to damage the heating element.
10. Put the small rubber gasket back in place at the
bottom of the fan housing. Be careful not to turn it
upside down.
11. Put the motor back in the bottom part of the fan
housing. Make sure that the motor rests properly
between the two ”forks” and on the small rubber
gasket.
12. Reconnect motor wires to the timer unit
(appearance depends on the timer type).
Please be careful not to damage wires.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 8 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Cleaning the inside of the machine
13. Put the large rubber gasket back on top of the
motor.
14. Reassemble the top half of the motor housing.
Make certain that motor wires are safely placed in
the protective groove.
15. Assemble the top of the fan housing onto the
bottom part by tightening the four screws. Be ca-
reful not to overtighten. Fix angle bracket to base
plate of the motor.
16. Reassemble hand dryer cover.
17. Reconnect power supply and test run the
hand dryer.
Ret the cover
screws

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 9 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Spare parts
1. Housing
2. Bracket for terminal block
3. Tensile relief clamp
4. Terminal block
5. Earth screw
6. Shock absorber
7. Fan housing, top
8. Rubber gasket for fan housing (large)
9. Motor, 700 W
10. Rubber gasket for fan housing (small)
11. Heating element, 900 W
12. LED unit
13. Air outlet
14. Mounting bracket for sensor
15. Sensor
16. Mounting bracket for fan housing
17. Base plate
18. Potentiometer
19. Mounting bracket for potentiometer
20. Timer
21. Fan housing, bottom part
22. Housing screw (2 pcs.)
23. Allen key for housing screws

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 10 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Warning !!!
During cleaning and service the hand dryer
must always be disconnected from the power
supply
Cleaning the inside of the machine
1. Disconnect power supply.
2. Disassemble cover by removing the two cover
screws at the bottom of the housing. Use the
special Allen key which was originally supplied
with the hand dryer.
3. Disassemble angle bracket.
4. Loosen the 4 screws
on the fan housing
and disassemble fan
housing lid
5. Gently lift up the motor.
Be careful not to dama-
ge motor wiring.
6. Loosen carbon brush wiring.
9. Reassemble all components
and test run the hand dryer.
7. Loosen the 2 x 2 screws,
allowing for the worn
brushes to be disassem-
bled from the motor.
8. Assemble new carbon
brushes and reassemble
screws and wires

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 11 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Warning !!!
During cleaning and service the hand dryer
must always be disconnected from the power
supply
Heating element replacement
1. Disconnect power supply.
2. Disassemble cover by removing the two cover
screws at the bottom of the housing. Use the
special Allen key which was originally supplied
with the hand dryer.
3. Disconnect wires from timer unit.
4. Disassemble sensor bracket and
timer unit from fan housing.
5. Loosen the two screws and dismount fan housing
from base plate.
9. Reassemble all components and test run
the hand dryer.
6. Loosen the screws and disassemble air outlet
from fan housing.
7. Disassemble heating element from air outlet.
8. Assemble new heating element and reassemble
all other components.

Reference Version Document Lang. Page
3000-ENG 08.01.2018 3000 DAN DRYER Hand dryer.
Maintenance and service manual
UK 12 of 12
DAN DRYER A/S • Alsikevej 8 • DK-8920 Randers NV • www.dandryer.com • [e-mail]
Technical specications
Power supply: 220 - 240 V 50-60Hz
Power consumption: 1600 W
Thermal cut-out: 142 C
CE labeled according to relevant EN standards in the directives 2004/108 / EC (EMC)
and 2006/95 / EC (Low Voltage).
Expected total lifetime
• Expected lifetime of hand dryer (before replacing the brushes): 216.000 hand dryings
• Expected lifetime of hand dryer (after replacing the brushes): 108.000 hand dryings.
• Expected total lifetime of hand dryer before disposal: 324.000 hand dryings.
Dimensions:
Wiring chart:
