OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET D'ENTRETIEN
MODEL • MODÈLE
DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
2016.12.01
DPA060BACBDB / DPA080BACBDB
PORTABLE AIR CONDITIONER
CLIMATISEUR PORTATIF

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDE A VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
POUR OBTENIR LE SERVICE SUR GARANTIE, VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
This product is factory equipped with a power supply cord that has a three-pronged ground-
ed plug. It must be plugged into a mating grounding type receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. If the circuit does not
have a grounding type receptacle, it is the responsibility and obligation of the customer to
exchange the existing receptacle in accordance with the National Electrical Code and ap-
plicable local codes and ordinances. The third ground prong should not, under any circum-
stances, be cut or removed. Never use the cord, the plug or the appliance when they show
any sign of damage. Do not use your appliance with an extension cord unless it has been
checked and tested by a qualified electrician or electrical supplier. Improper connection of
the grounding plug can result in risk of fire, electric shock and/or injury to persons associat-
ed with the appliance. Check with a qualified service representative if in doubt that the appli-
ance is properly grounded.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il
doit être branché dans une prise avec une fiche de mise à la terre en conformité avec le Code
national de l’électricité et les codes et règles locaux applicables. Si la prise murale n’a pas de
mise à la terre, il est de la responsabilité et l’obligation du client de changer la prise existante
pour la rendre conforme au Code national de l’électricité et aux codes et règles locaux
applicables. La fiche de mise à la terre ne doit pas, en aucune circonstance, être coupée ou
retirée. Si vous apercevez des signes de dommage, n’utilisez jamais le cordon d’alimentation,
la prise ou l’appareil. N’utilisez jamais l’appareil avec une rallonge sauf si elle a été vérifiée
et testée par un électricien qualifié ou un fournisseur de matériel électrique. Une fiche de
mise à la terre mal branchée peut entraîner un risque d’incendie, de choc électrique ou de
blessures aux personnes qui utilisent l’appareil. Si vous n’êtes pas certain que l’appareil est
correctement mis à la terre, consultez un préposé du service qualifié.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE

PORTABLE AIR CONDITIONER
Owner’s Use and Care Guide ................................1-15
• Welcome
• Important Safety Information
• Features
• Installation Instructions
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
CLIMATISEUR PORTATIF
Guide d’utilisation et d’entretien............................16-30
• Bienvenue
• Consignes de sécurité importantes
• Caractéristiques
• Consignes d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
CONTENTS / TABLE DES MATIÈRES
Model • Modèle
DPA060BACBDB / DPA080BACBDB
Read and follow all safety rules and operating instructions before first
use of this product.
Veuillez lire attentivement les consignes de sécurité et les instructions
d’utilisation avant l’utilisation initiale de ce produit.

1
Welcome
Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will
find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best
of all, you will experience these values each and every time you use your Danby appliance. That is important, because
your new appliance will be a part of your family for a long time.
Note the information below; you will need this information to obtain service under warranty.
To receive service, you must provide the original receipt.
Model Number:
Serial Number:
Date of Purchase:
NEED HELP?
Before you call for service, here are a few things you can do to help
us serve you better:
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your
appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the
appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide before call-
ing. This section helps you solve common problems that may occur.
If you do need service, you can relax, knowing help is only a phone
call away.
1-800-26-
(1-800-263-2629)

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
SAFETY PRECAUTIONS
ALWAYS DO THIS
Your air conditioner should be used in such a way that it is protected from moisture, e.g. condensation,
splashed water, etc. Do not place or store your air conditioner where it can fall or be pulled into water or
any other liquid. Unplug unit immediately if this occurs.
Always transport your air conditioner in a vertical position and place on a stable, level surface during use.
If the unit is transported laying on its side it should be stood up and left unplugged for 6 hours.
Turn off the unit when not in use.
Always contact a qualified person to perform repairs. If the power cord is damaged it must be repaired by
a qualified technician.
Keep the unit away from walls, furniture and curtains with a clearance of at least 30 cm all around.
If the air conditioner is knocked over during use, turn off the unit and unplug it immediately.
Always use the switch on the control panel to turn the unit on or off.
NEVER DO THIS
Do not operate your air conditioner in a wet room such as a bathroom or laundry room.
Do not touch the unit with wet or damp hands.
Do not press the buttons on the control panel with anything other than your fingers.
Do not remove any fixed components. Never use this appliance if it is not working properly, or if it has
been dropped or damaged.
Never use the plug to start and stop the unit.
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come into contact with the unit.
Do not use the unit in the presence of inflammable substances or vapour such as alcohol, insecticides,
gasoline, etc.
Do not allow children to operate the unit unsupervised.
Do not use this product for functions other than those described in this instruction manual.
2

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
ENERGY SAVING TIPS
OPERATING
CONDITIONS
TOOLS FOR WINDOW KIT
INSTALLATION
• Use the unit in the recommended room size.
• Locate the unit where furniture cannot obstruct the air flow.
• Keep blinds/curtains closed during the sunniest part of the day.
• Keep the filters clean.
• Keep doors and windows closed to keep cool air in and warm air out (cooling mode)
The air conditioner must be operated within the temperature range
indicated below:
Note: Performance may be reduced outside of these operating temperatures.
1. Screwdriver (medium size, Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw (In the event that the window kit needs to be cut down in size
because the window is too narrow for direct installation).
See www.danby.com for general instruction guide
Identifying Parts
WARNING
• Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other
appliance.
• Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any
prong from the power cord.
ELECTRICAL INFORMATION
WARNING
• Be sure the electrical supply is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
• Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding
is important. The power cord is equipped with a three-prong grounding plug for protection against
shock hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you
intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a
qualified electrician install the proper receptacle.
• Ensure the receptacle remains accessible after the unit is installed.
3
MODE ROOM TEMPERTURE
Cool 17°C (62°F) ~ 35°C (95°F)
Dry 13°C (55°F) ~ 35°C (95°F)
POWER OUTAGE In the case of a power outage, the unit will automatically re-start with the last setting
after the power is restored.
Wait 3 minutes before resuming operation
After the unit has stopped, it cannot operate for the first 3 minutes. This is to protect
the unit. Operation of the compressor will automatically start after 3 minutes.

Identifying Parts
ACCESSORIES
Ensure that all the accessories are
included in the package and refer to
the installation instructions for their
usage.
Note: All the illustrations in this man-
ual are for explanatory purposes only.
Your air conditioner may be slightly
different.
UNIT STRUCTURE
4
 "74&2;&/.F >.;&;DF
.&;F 3;05F 
  C%?8;F08#F 
 &. 0AF*' #5F 3;15F 
 0+;F 
  &. 0AF,' #5FF 
    &. 0AF*' #5FF. FF 
 0-F#*FF %#9(@#F
 
  0-F#*FF %#9(@#F 
 1-F#*FF1. %#9'@#F 
  $?6'<EF6)$=F.!FF6$B:F 
  4&.F09#F 
#-1;#F0.;50**#5F. F;;#5DF
  
 

Features
ELECTRONIC CONTROL INSTRUCTIONS AND OPERATING MODES
5
Mode Button: Press to select the desired mode. Modes will cycle in sequence with each press
of the button; COOL, DRY, FAN. Light will indicate current mode. Fan speed can be chosen on
COOL and FAN modes using the remote control.
COOL mode Note: The hose should be exhausted during COOL mode
- Press the mode button until the COOL icon illuminates
- Press the UP or DOWN arrow buttons to select the desired room temperature
- The temperature can be set within a range of 17-30°C / 62-86°F
FAN mode
- Press the mode button until the FAN icon illuminates
- Fan speed can be adjusted using the remote control
DRY mode
- Press the mode button until the DRY icon illuminates
- The display will show the current room temperature
- Fan speed and temperature cannot be adjusted in this mode
Up and Down Buttons: Used to adjust temperature settings in COOL mode. Press and hold
both Up and Down buttons for 3 seconds to change the temperature display from °C to °F.
Power Button: Press to turn the unit on or off.
LED Display:
- While on COOL mode shows the set temperature in °C or °F
- When on FAN and DRY mode shows the room temperature
- Displays error codes
AUTO mode
- Can only be activated by remote control
- There is noAUTO mode display on the control panel
- Display will show COOL or FAN based on ambient room temperature
SLEEP mode
- Can only be activated from the remote control
- Conserves energy during sleeping hours
- Once activated, SLEEP mode will increase the set temperature by 1 degree for 30 minutes.
The set temperature will increase another degree in the next 30 minutes and then will maintain
temperature for 7 hours before returning to the original setting.
- The SLEEP function is only available in COOL mode

6
Operating Instructions
OPERATING MODES
Timer Operation
Note: Timer function can only be activated by the remote control.
This unit has two timer related functions:
• Timer on: sets the amount of time after which the unit will turn on
• Timer off: sets the amount of time after which the unit will turn off
Timer On Function:
• Press the Timer On button on the remote control
• The last time period that was set will show on the display
• Press the Timer On button repeatedly to set the amount of hours that should pass before the unit
turns on
• Wait two seconds for the programming to be accepted by the unit
Timer Off Function:
• Press the Timer Off button on the remote control
• The last time period that was set will show on the display
• Press the Timer Off button repeatedly to set the amount of hours that should pass before the unit
turns off
• Wait two seconds for the programming to be accepted by the unit
Notes:
• Pressing the Timer On or Timer Off buttons will increase the set time in 0.5 hour increments up to
10 hours and then in 1 hour increments up to 24 hours
• The display will revert back to showing the previous temperature setting if the unit does not re-
ceive a signal within a 5 second period during programming
• Adjusting the timer setting to 0.0 hours will cancel the Auto-timer settings
Using the Auto-on and Auto-off feature at the same time
You can set the air conditioner to run the Auto-on and Auto-off features at the same time. Keep in
mind that the hours displayed on the unit refer to the number of hours that will pass from the current
time before the action is taken.
For example:
• First, set the Timer On or Timer Off function as per above
• Wait three seconds for programming to be accepted by the unit
• Set the Timer Off or Timer On function
• Wait three seconds for programming to be accepted by the unit
Auto-Restart: If the unit looses power unexpectedly, it will restart with the previous function settings
when power is restored.
Note: Once the unit has stopped, it cannot be restarted for 3 minutes. Operation will resume after 3
minutes.

7
REMOTE CONTROL INSTRUCTIONS
Operating Instructions
• Use the remote control within a distance of 8 m
(26 ft.) from the appliance, pointing it towards the
receiver. Reception is confirmed by a beep.
MODE: Selects mode operation
in the following order:
Auto -->Cool -->Dry -->Fan
FAN SPEED: Selects fan speed
in the following order:
Auto -->Low -->High
ON/OFF: Turns the unit on or off
Model RG57H1(B)/BGCE-M
Rated Voltage 3.0V (dry batteries R03/LR03x2)
Signal Receiving Range 8m (26 feet)
Environment -5°C to 60°C (23°F to 140°F)
TEMP
SLEEP: Conserves energy
during sleeping hours
LED: Turns the LED
display on or off
TIMER OFF: Used to set
Auto-off function
TIMER ON: Used to set
Auto-on function
SHORTCUT: Sets and activates
favourite setting
SHORTCUT function (only available on remote):
- Used to save a favourite setting
- Set the unit to the temperature and fan speed that you would like to set as a favourite
- Press and hold the SHORTCUT button for 2 seconds
- Press the SHORTCUT button at any point in future to return to the favourite setting
- If no favourite is set, pressing the SHORTCUT button will cause the unit to run in AUTO mode at
26°C (79°F), with fan speed set to AUTO
