Danby DAC060EB2GDB Assembly instructions

Model  Modèle  Modelo
OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET SOINS DE PROPRIÈTAIRE
MODEL MODÈLE
DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA45840
AIR CONDITIONER
CLIMATISEUR
DAC060EB2GDB
03.01.14

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDE A VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
-------------------------------------------------------------------------------------------------------------------
POUR OBTENIR LE SERVICE SUR GARANTIE VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
-------------------------------------------------------------------------------------------------------------------
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must
be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and
applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the
responsibility and obligation of the customer to exchange the existing receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. The third ground prong should not,
under any circumstances, be cut or removed.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il doit être
branché dans une prise avec une fiche de mise à la terre en conformité avec le Code National de l’Électricité
et les codes et règles locales applicables. Si le prise murale n’a pas de mise à la de terre, il est de la
responsabilité et l’obligation du client de changer la prise existante pour la rendre conforme aux Codes
Nationaux de l’Électricité, aux codes et règles locaux applicables. La fiche de la mise à la terre ne doit pas,
en aucune circonstance, être coupée ou retirée.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE

AIR CONDITIONER
Owner’s Use and Care Guide ................................1-16
• Welcome
• Important Safety Information
• Features
• Installation Instructions
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
CLIMATISEUR
Guide d’utilisation et d’entretien du propriétaire...17-32
• Bienvenue
• Consignes de sécurité importantes
• Caractéristiques
• Consignes d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
CONTENTS
Model • Modèle DAC060EB2GDB
CAUTION:
Read and follow all safety rules and operating
instructions before ¿rst use of this product.
PRÉCAUTION:
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.

WELCOME
1
Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will
find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best of
all, you will experience these values each and every time you use your Danby appliance. That is important, because your
new appliance will be a part of your family for a long time.
For easy reference, we suggest you attach a copy of your sales slip/receipt to this page, along with the following
information, located on the manufacturer’s nameplate on the right side of the unit above the powercord.
Note the information below; you will need this information to obtain service under warranty.
To receive service, you must provide the original receipt.
NOTE: THIS UNIT IS NOT DESIGNED FOR “THROUGH-THE-WALL” INSTALLATION
Model No:
Serial No:
Date Purchased:
NEED HELP?
Before you call for service, here are a few things you can do to
help us serve you better:
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your
appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the
appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide
before calling. This section helps you solve common problems
that may occur.
If you do need service, you can relax, knowing help is only a
phone call away.
Tel: 1-800-26-
(1-800-263-2629)
WARNING
Improper connection of the grounding plug can result in risk of
fire, electric shock and/or injury to persons associated with the
appliance. Check with a qualified service representative if in doubt
that the appliance is properly grounded.

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ELECTRICAL
SPECIFICATIONS
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
2
TABLE 1 DAC060EB2GDB
Suggested Individual Branch Circuit
Nameplate Amps *AWG Wire Size
815
AWG- American Wire Gauge
*Based on copper wire at 60°C temperature rating.
TABLE 2
Receptacle and Fuse Types
521stloVdetaR
51spmA
Wall Outlet
51eziSesuF
epyTgulPesuFyaleDemiT
(or Circuit Breaker)
1) All wiring must comply with local and national electrical codes and must
be installed by a qualified electrician. If you have any questions
regarding the following instructions, contact a qualified electrician.
2) Check available power supply and resolve any wiring problems
BEFORE installing and operating this unit.
3) This 115V air conditioner uses 5 or less nameplate amps and may
be used in any properly wired, general purpose household receptacle.
See Table 1 for the specifications for the individual branch circuit.
4) For your safety and protection, this unit is grounded through the power
cord plug when plugged into a matching wall outlet. If you are not sure
whether your wall outlet is properly grounded, please consult a qualified
electrician.
5) The wall outlet must match the 3-prong plug on the service cord
supplied with the unit. DO NOT use plug adapters. See Table 2 for
receptacle and fuse information. If it is necessary to use an extension
cord to connect your air conditioner, use an approved “air
conditioner” extension cord only (available at most local hardware
stores).
6) The rating plate on the unit contains electrical and other technical data.
The rating plate is located on the right side of the unit, above the power
cord.

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ENERGY SAVING TIPS
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
Your Danby appliance is designed to be highly efficient in energy
savings. Follow these recommendations for greater efficiency.
1) Select a thermostat setting that suits your comfort needs and leave at
that chosen setting.
2) The air filter is very efficient in removing airborne particles. Keep the air
filter clean at all times. (usually cleaned every 2 weeks depending on
indoor air quality).
3) Use drapes, curtains or shades to keep direct sunlight from penetrating
and heating the room, but do not allow drapes or curtains to obstruct
the air flow around the unit.
4) Start your air conditioner before the outdoor air becomes hot and
uncomfortable, to avoid an initial period of discomfort while the unit is
cooling off the room.
5) When outdoor temperatures are cool enough, use the FAN MODE only, on
HIGH, MED., or LOW setting.This circulates indoor air, providing some
cooling comfort, and utilizes less electricity than when operating on a cooling
setting.
3
Features
Installation Instructions
CAUTION
Because the compressor is located on the controls side of the unit
(left side), this side will be heavier and more awkward to manipu-
late. Inadequate support on control side of the unit can result in
personal injury and damage to your unit and property. Therefore, it
is recommended that you have someone assist you during the
installation of this unit.
TOOLS NEEDED FOR INSTALLATION:
NOTE: Save the shipping carton and packing materials for future storage
or transportation. From carton, remove the plastic bag containing the
installation hardware kit necessary for the installation of your air
conditioner. Please check the contents of hardware kit against the corre-
sponding model check list, prior to installation of the unit. See Fig. 1.
ELECTRIC SHOCK HAZARD
To avoid the possibility of personal
injury, disconnect power to the unit
before installing or servicing.
NOTE: Your Room Air Conditioner is
designed for easy installtion in a single or
double-hung window. This unit is NOT
designed for vertical (slider type) windows
and/or through-the-wall applications.
Air FIlter
Exterior
Air Inlet
Cabinet
Interior Air Inlet
Control Panel
Interior Air Outlet
Screwdrivers: Phillips and flat head.
Power Drill: 1/8” (3.2mm) diameter drill bit.
Pencil
Measuring Tape
Scissors
Carpenter’s Level

Installation Instructions
Fig. 1
INSTALLATION
HARDWARE
LOCATION A) This room air conditioner is designed to fit easily into a single or double
hung window. However, since window designs vary, it may be
necessary to make some modifications for safe, proper installation.
B) Make sure window and frame are structurally sound and free from dry
and rotted wood.
C) For maximum efficiency, install the air conditioner on a side of the
house or building which favours more shade than sunlight. If the unit is
in direct sunlight, it is advisable to provide an awning over the unit.
D) Provide sufficient clearance around the cabinet to allow for ample air
circulation through the unit (See Fig. 2). The rear of the unit should be
outdoors and not in a garage nor inside a building. Keep unit as far
away as possible from obstacles/obstructions and at least 30” above
the floor or ground. Curtains and other objects within a room should be
prevented from blocking the air flow.
E) Be certain the proper electrical outlet is within reach of the installation.
Use only a single outlet circuit rated at 15 amps. All wiring should be in
accordance with local and national electrical codes.
F) DO NOT install unit where leakage of combustible gas is suspected.
Your air conditioner may fail to operate in air containing oils (including
machine oils), sulfide gas, near hot springs, etc.
NOTE: Your unit is designed to evaporate condensation under normal
conditions. However, under extreme humidity conditions, excess conden-
sation may cause the basepan to overflow to the outside. The unit should
be installed where condensation run-off cannot drip on pedestrians or
neighboring properties.
4
1/2in. (13mm)
screws (7) Safety Lock (1)
3/8in. (9.5mm) screws
(4) *Factory installed
on some models
“L” Shaped
mounting
bracket (1)
* Factory installed
on some models
Sash bracket (2)
Adhesive
Foam Seal(1)
Regular
Foam Seal(1)
Side Curtain LH (1)
Side Curtain RH (1)

LOCATION
Installation Instructions
Awning
Fence,
wall, or
other
obstacle
Ground
Side
Obstruction
20”
Min
30”
Min
20”
Min
12” Min
Fig. 2
1) Assembly of the Upper Channel to Cabinet.
“L” ShapedTRSChannel: InstDOOWKH“L” shapedchannelWRWKHWRSRIthe
cabinetDVshownLQFig. 3usingIRXU´screws.
2) Assembly of the Side Curtains to Cabinet.
([WHQGWKHVKXWWHUIURPWKHVKXWWHUIUDPHDQGslideLWLQWRWKHVKXWWHUtabs
RQWKHVLGHchannelRIWKHDLUconditionerDVshownLQFig. 4.
SlideWKHVKXWWHUVLQWRWKHWRS(“L” Shaped)DQGERWWRP(“U” Shaped)
channels.7KHVKXWWHUVDUHidentifiedRQIUDPHDVlefWDQGULJKW
3) Completing the Installation
&XWWKHIRDPQRQadhesive)sealingVWULSWRILWWKHDUHDRIWKHwindowsill
WKDWWKHDLUconditionerwillUHVWRQ 3/8” screws
“L” shaped mounting
bracket
“U” shaped Channel
(Factory Installed)
Slide down into tabs
Shutter tabs
Shutter
Shutter frame
Fig. 3
Fig. 4
5
)DFWRU\LQVWDOOHGRQVRPH
units.)

Fig. 7.
6).
is tilted downwards to the outside, about 3° to 4°, as shown in
6
Installation Instructions
3) Completing the Installation (cont)
CarefullySODFHWKHDLUconditionerLQWRWKHwindowZLWKWKH“L” shaped
mountingEUDFNHWRQWRSpositionedLQIURQWRIWKHupperwindowsash.
7KHERWWRPRIWKHcabinetshouldEHpositionedRQWKH“recessed”portion
RIWKHwindowIUDPH3XOOWKHwindowdownXQWLOLWrestVMXVWbehindthe
IURQWflangeRIWKH(top) “L” shapedmountingEUDFNHW(See Fig. 5).
ExpDQGWKHVKXWWHUIUDPHVIXOO\RQHDFKVLGHDQGVHFXUHWKHWRSRIthe
IUDPHVWRWKHwindowVDVKusingRQH´VFUHZRQHDFKVLGHDQGRQHin
WKH“L” shapedmountingEUDFNHW(Fig. 5).
6HFXUHWKHVKXWWHUFODPSRQHDFKVLGHRIWKHORZHUSDUWRIWKHVKXWWHUDQG
VHFXUHWRWKHZLQGRZVLOOXVLQJRQH´VFUHZRQHDFKVLGH(Fig. 5)
3ODFHWKHsecondIRDPsealingVWULSWRILWWKHopeningbetweenWKHinside
DQGoutVLGHZLQGRZVWKHQattDFKWKHVDIHW\ORFNWRWKHoutVLGHwindow
IUDPHusing
RQH´VFUHZ(See Fig.
Fig. 7 Measure the tilt angle from the cabinet’s edge
WINDOW
: approximately 3/4” to 1”
PLEASE NOTE: Window applications come in a variety of different styles. Therefore, it may
$IWHUSURSHULQVWDOODWLRQFRQGHQVHGZDWHUVKRXOGQRWGUDLQIURPWKHRYHUIORZGUDLQKROHGXULQJ
QRUPDOXVH,I\RXQRWLFHZDWHUOHDNLQJRXWFKHFNWKHDQJOHRIWLOWDQGPDNHDQ\QHFHVVDU\
DGMXVWPHQWV+RZHYHURQDYHU\KXPLGGDyZDWHUOHDNDJHFDQRFFXU±WKLVLVQRUPDO
0HDVXUHWKHWLOWDQJOHIURPWKHFDELQHW¶VHGJH7KHGLVWDQFH+VKRXOGEHDSSUR[LPDWHO\
´WR´IRU'$&(%*'%
WLQGRZ sash
³/´ Shaped
Mounting
%UDFNHW
6KXWWHU clamps
1/2” screws
Fig. 5
6DIHW\ Lock
´ screw
)RDP
(adhesive)
Seal
Fig. 6
be necessary to modify or improvise your particular installation.
Check that the air conditioner

7
Operating Instructions
KEY PAD FEATURES
MODE
Auto Auto
68
Temp / Timer
Control
Check
Filter
Mode
Selector
Energy
Saver
LED
Display
Auto
Timer
Sleep
Mode
Fan
Speed
Power
Button
LED DISPLAY:Displays the following information independently - Set
Temperature, Ambient RoomTemperature and Auto Timer On/Off settings.
POWER: Turns unit On/Off.
MODE: Allows you to scroll through and select the desired operating
mode:
NOTE: The unit will automatically launch the Energy Saver function when it is
in Cool, Dry, and Auto modes (only Auto-Cool and Auto-Fan modes).
Cool , Dry , Fan Only and *Auto. The selected mode will be denot-
ed by the adjacent indicator light. * ‘Auto’ is a pre-set factory programthat
automatically defines the mode (Cool or Dry) and fan speed, based on the
set temperature. The unit will automatically launch the Energy Saver function
FAN SPEED: Select from four different fan settings: Low, Medium,
High and Auto during Cool and Fan Only mode. Please note,during ‘Dry’
mode the fan speed is automatically defined.
ENERGY SAVER: Automatically cycles the fan on and off while the
compressor is not in use. This function is available in Cool, Dry, and Auto
TEMP / TIMER CONTROL: Used to increase or decrease
the Temperature setting in 1°C / °F increments, and Auto-Timer On/Off set-
tings in 30min./1hr. increments. Note: This appliance allows you select the
temperature scale to be displayed in either “Celsius” or “Fahrenheit”
according to your preference.To change the temperature scale displayed
on the electronic display, press both the “Temp/Timer”adjust arrows simul-
taneously to alternate between “Celsius” & “Fahrenheit”.
CHECK FILTER: The adjacent indicator light will illuminate as a
been cleaned and replaced, depress the Check Filter button in order to
resume operation.
AUTO-TIMER: Used to initiate the Auto On/ Auto Off timer.
While the Air Conditioner is off (Auto-On):
1) Press the Auto-Timer button once and the adjacent Auto-On indicator
light will illuminate.
2) Use the Temp/Timer control cursors to select a delayed On time of
up to 24 hours.
3) Select the appropriate mode under which you want the unit to operate
(Auto-Cool-Dry-Fan Only)
4) Select the fan speed setting.
5) The time you selected will appear in the LED display.
modes (only Auto-Cool and Auto-Fan modes). The fan will continue to run for
3 minutes after the compressor shuts off. The fan then cycles on for 2
minutes at 10 minute intervals, until the room temperature is above the set
temperature. At this point, the compressor turns back on and cooling starts.
reminder to clean the air conditioner filter (see page 14). Once the filter has
SLEEP MODE: In this mode, the selected temperature will increase
(when in cooling mode) by 2°F one half-hour after Sleep mode has been
selected. The temperature will then increase by another 2°F after an addi-
tional half hour. This new temperature will be maintained for 6 hours before
returning to the originally selected temperature. This ends the Sleep mode
and the unit will continue to operate as originally programmed. The Sleep
mode program can be cancelled at any time during operation by pressing the
Sleep button again.
