Danby DPAC10010 Assembly instructions

Owner’s Use and Care Guide
Guide d’utilisation et soins de Propriètaire
Model • Modèle
DPAC9010, DPAC10010
Danby Products Ltd, Guelph, Ontario Canada N1H 6Z9
Danby Products Inc, Findlay, Ohio USA 45840
V1.12.09 JF
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE:
If the unit changes ownership, be sure the manual accompanies this unit.
CONSERVER CES INSTRUCTIONS POUR CONSULTATION ULTÉRIEUR:
En cas de revente l’appareil, ce manuel doit être inclus avec l’appareil.
CAUTION:
Read and follow all
safety rules and
operating instructions
before first use
of this product.
MISE EN GARDE :
Veuillez lire
attentivement les
consignes de sécurité et
les directives
d'utilisation avant
l'utilisation initiale de
ce produit.
PORTABLE AIR CONDITIONER
Owner’s Use and Care Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 10
• Welcome
• Important Safety Information
• Features
• Installation
• Operation
• Care and Maintenance
• Troubleshooting
CLIMATISEUR PORTATIF
Guide d’utilisation et soins de Propriètaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 20
• Bienvenue
• Consignes de Sécurité Importante
• Caractéristiques
• Installation
• Fonctionnement
• Soins et Entretien
• Dépannage

Thank you for choosing a Danby appliance to provide you and your family with all of the “Home
Comfort” requirements of your home, cottage, or office. This Owner’s Use and Care Guide will
provide you with valuable information necessary for the proper care and maintenance of your new
appliance. If properly maintained, your Danby appliance will give you many years of trouble free
operation. Please take a few moments to read the instructions thoroughly and familiarize yourself
with all of the operational aspects of this appliance.
Your Danby Portable Air-Conditioner is a multi-functional room air-exchanging, air-processing
appliance, designed to offer you the functions of; Air Conditioning, Dehumidifying, and Independent
Fan. Each individual mode is featured with “oscillating” air swing capabilities. This unit can be
conveniently moved from room to room within your home and set up in just minutes. Imagine the
convenience of 4 Season Home Comfort at your fingertips, anywhere, anytime.
For easy reference, may we suggest you attach a copy of your sales slip/receipt to this page, along
with the following information, located on the manufacturers nameplate on the rear panel of the unit.
Model Number:
Serial Number:
Date of Purchase:
This information will be necessary if your unit requires servicing and/or for general inquiries. To contact a
Customer Service Representative, call Danby TOLL FREE: 1-800-26- (1-800-263-2629)
WELCOME
1

READ ALL SAFETY INFORMATION BEFORE USING
1) Check available power supply and resolve any wiring problems
BEFORE installation and operation of this unit. All wiring must
comply with local and national electrical codes and be installed by
a qualified electrician. If you have any questions regarding the
following instructions, contact a qualified electrician.
2) This appliance draws 7.8 nameplate amps under Cooling Mode
and may be used in any properly wired, general purpose 15 amp
household grounded receptacle.
3) For your safety and protection, this unit is grounded through the
power cord plug when plugged into a matching wall outlet. If you
are not sure whether the wall outlets in your home are properly
grounded, please consult a qualified electrician.
WARNING: Improper connection of the grounding plug can
result in risk of Fire, Electric Shock, and/or injury to Persons
associated with the appliance. Check with a qualified service
representative if in doubt that the appliance is proplery grounded.
4) DO NOT USE PLUG ADAPTERS OR EXTENSION CORDS
WITH THIS UNIT. If it is necessary to use an extension cord with
this unit, use an approved “air conditioner” extension cord only
(available at most local hardware stores).
5) To avoid the possibility of personal injury, always disconnect the
power supply to the unit before installing and/or servicing.
TABLE 1
Suggested Individual Branch Circuit
Nameplate Amps *AWG Wire Size
9.5 16
AWG- American Wire Gauge
*Based on copper wire at 60°C temperature rating.
TABLE 2
Receptacle and Fuse Types
Rated Volts 125
Amps 13
Wall Outlet
Fuse Size 15
Time Delay Fuse Plug Type
(or Circuit Breaker)
IMPORTANT SAFETY INFORMATION
ELECTRICAL
SPECIFICATIONS
CAUTION: Do not leave this unit
unattended in a space where people or
animals cannot react to a failed unit are
located. A failed unit can cause extreme
overheating or death in such an enclosed,
unattended space.
2
The power cord supplied with this air conditioner contains a device that senses damage to
the power cord. To test if your power cord is working properly, you must do the following:
1) Connect the power supply cord to an electrical
outlet.
2) The power supply cord has two buttons located on
the head of the plug. One button is marked
“TEST”, and the other is marked “RESET”. Press
the “TEST” button; you will hear a click as the
“RESET” button pops out.
3) Press the “RESET” button; you will hear a click
as the button engages.
4) The power supply cord is now energized and
supplying electricity to the air conditioner (on
some products this is also indicated by a light on
the plug head).
NOTE: The power cord supplied with this air
conditioner contains a current leakage detection
device designed to reduce the risk of fire. In the event
the power supply cord is damaged, it cannot be
repaired and must be replaced with a new cord from
the product manufacturer.
• Under no circumstances should this device be used
to turn the unit on or off.
• The “RESET” button must always be pushed in
(engaged) for correct operation.
• The power supply cord must be replaced if it fails to
reset when the “TEST” button is pushed in.
POWER
SUPPLY CORD

Your Danby appliance is designed to be highly efficient in energy savings. Follow these
recommendations for greater efficiency.
1) Select a thermostat setting that suits your comfort
needs and leave at that chosen setting.
2) The air filter is very efficient in removing
airborne particles. Keep the air filter clean at all
times.
3) Use drapes, curtains or shades to keep direct
sunlight from penetrating and heating room, but do
not allow drapes or curtains to obstruct the air flow
around the unit.
4) Start your air conditioner before the outdoor air
becomes hot and uncomfortable, to avoid an initial
period of discomfort while the unit is cooling off
the room. Use of the automatic start/stop
programmable TIMER feature can be a major asset
in this regard if utilized to the fullest extent.
5) When outdoor temperatures are cool enough, turn
the air conditioner off and use the FAN MODE.
This circulates indoor air, providing some cooling
comfort while utilizing less electricity.
IMPORTANT SAFETY INFORMATION (cont’d)
ENERGY-SAVING
TIPS
3
Air Exhaust
LCD
Display
Front
Panel
Handles
Wheels
Air Filter
Air inlet
Air outlet
Cover
Electricity cable Water drain
Air inlet
FEATURES

Air Conditioning Mode ONLY: Your window kit
has been designed to fit most standard “vertical”/
”horizontal” windows up to a maximum height of 80”
(203cm). For vertical window applications, multi lock
positions are provided on the edge of each slider
section to secure each sliding section together.
1) Select a suitable location, making sure you have
access to an electrical outlet.
2) Install the flexible hose to the rear side of the unit.
Insert the hose collar on top of the exhaust opening
and twist to lock into position.
3) Install the adjustable Sliding Window Kit as
required (see Fig. 4a & 4b).
4) Install the opposite end of the flexible exhaust
hose into the window exhaust adapter.
5) Install the window exhaust adapter into the
opening in the slider section, making sure the
window slider sections are secure.
6) Plug the unit into a 115V/60Hz grounded electrical
outlet.
Sliding Window Kit:
Min.: 28 1/3” (67.5cm)
Max.: 80” (203cm)
Sliding Window
Kit:
Min.: 28 1/3”
(72cm)
Max.: 80”
(203cm)
Horizontal Window
Vertical
Window
WINDOW KIT
INSTALLATION
Back of window panel
Tube Adapters
Fig. 2
Instructions for Assembling the Sliding Window Kit- Fig. 2
1) Insert tube adapters through the back of the window panel.
2) Secure each tube adapter with four screws through the front of the
window panel.
3) Insert window panel extensions into window panel. Lightly tighten the
screws in the window panel to hold the extensions in place.
Fig 3a Fig 3b
4
INSTALLATION
Fig. 1 INSTALLATION ACCESSORIES
Flexible Exhaust Hose
Exhaust Nozzle
Connector
Fixture
Sliding Window Kit:
28 1/3” (72cm)- 80” (203cm)
Screws
Water hose (79”/ 200cm)
ELECTRIC SHOCK HAZARD: To avoid the possibility of
personal injury, disconnect power to the unit before installing or
servicing.
Caution: To avoid installation/operation difficulties, read these
instructions thoroughly.
Flexible Exhaust Hose (13cm) & Exhaust nozzle connector (2
pcs)... from 17 7/10 (45cm) to 53 1/6” (135cm)
Flexible Exhaust Hose (11cm) & Exhaust nozzle
connector (2pcs)...from 15 3/4” (40cm) to 51 1/5” (130cm)
Adjustable sliding window/door kit (3 pcs)... from 28 1/3”(72cm) to
80” (203cm)
Fixture..... (2 pcs) & Screws..... (8 pcs)
NOTE: The exhaust/window kit must be installed at all times when
the unit is operating under AIR CONDITIONING mode. There
should be at least 11.8” (30cm) clearance between the unit and any
other objects or building structures, and should be installed on a
level surface.

Warning Light Receiving Sensor
KEY PAD FUNCTIONS
POWER SWITCH: Turns unit ON/OFF
MODE: Allows you to scroll through and
select desired operating mode.
FAN: Select from three different fan settings;
High, Medium, and Low.
AUTO-TIMER
AUTO-TIMER Adjust:
AUTO TURN OFF- With machine in running mode,
press timer button to set timer control. Press
buttons to select number of hours you would
like the unit to run before it automatically shuts off.
AUTO TURN ON- With machine in stand by mode,
press timer button to set timer control. Press
buttons to select number of hours before the unit
automatically starts running in air conditioning mode.
NOTE: The time is adjustable between 1-24 hours.
TEMPERATURE Adjust:
• Used for adjusting the thermostat.
• The default display is room temperature.
• In cooling mode, when button is pressed,
the set temperature is displayed and may be adjusted.
After 15 seconds the display will revert back to room
temperature. Temperature is only adjustable in cool
mode.
Warning Light
Condensed water may accumulate in the unit. If the
internal tank becomes full, the Warning signal in the
LCD Display will light up and the unit will not
operate until it has been drained.
NOTE: By pressing both buttons at
the same time for more than 3 seconds, the display
will toggle between Celsius and Fahrenheit.
LCD Display
Cooling Mode
Dehumidify Mode
Fan Only Mode
High Fan Speed
Medium Fan Speed
Low Fan Speed
Display Set Temperature
Display Timer Setting of Auto Switch ON /
OFF
Warning Light (the machine will stop
running)
OPERATION
5

AIR CONDITIONING
NOTE: The exhaust hose must be properly vented outdoors during air
conditioning mode.
1) Press the POWER SWITCH key (Fig. A) to switch on the unit, and the
previous set temperature will be shown in the temperature display area of the
control panel.
2) Press the MODE key (Fig. B) until the COOL indicator light illuminates on the
control panel (Fig.C). Each depression of the MODE key will advance to a
different mode setting (Cool- Dehumidifier-Fan)
3) Press the appropriate increase or decrease buttons (Fig. D1 & D2) to
select a suitable operating temperature setting. Temperature settings are
adjustable between 16°C (61°F) to 32°C (89°F).
4) Press the FAN key (Fig. E) to select the desired fan speed setting (Auto-High-
Med.-Low). Your selection will appear on the control panel (each depression of
the fan key will advance to a different setting).
• Cooling stops automatically when the set temperature is achieved. Cooling
resumes when the room temp. rises above the “set” temperature level.
DEHUMIDIFIER:
NOTE: The exhaust hose does NOT have to be vented outdoors during
dehumidifier mode.
1) Press the ON/OFF key pad to switch the unit on (Fig. A)
2) Press the MODE key (Fig. B) until the DRY indicator illuminates on the
control panel (Fig. G).Each press of the MODE key will advance to a different
mode setting (Cool-Dehumidifier-Fan).
3) If room temperature is 25°C (77°F), fan speed can be adjusted. Press the Fan
key (Fig. E) to select the desired FAN SPEED setting. Your selection will
appear on the contol panel. Each depression of the fan key will advance to a
different fan speed (High- Med.- Low) as shown in Fig. F. Otherwise, fan
speed is fixed to “low”.
Note: THE WARM AIR EXCHANGE HOSES MUST VENT INSIDE THE
ROOM WHEN USING DEHUMIDIFY MODE, NOT OUTSIDE AS IT DOES
WHEN COOLING.
FAN:
NOTE: During Fan Mode, the exhaust hose does NOT have to be vented
outdoors.
1) Press the POWER SWITCH key pad to switch the unit on (Fig. A).
2) Press the MODE key (Fig. B) until the FAN indicator illuminates on the
control panel (Fig. C). Each press of the MODE key will advance to a different
mode setting (Cool- Dehumidifier-Fan).
3) Press the FAN Key (Fig. E) to select the desired FAN SPEED setting. Your
selection will appear on the control panel. Each press of the fan key will
advance to a different fan speed (High- Med- Low) as shown in Fig. F.
Fig. A
Fig. B
Fig. C
Fig. E
Fig. F
OPERATION (cont’d)
Fig. D1
Fig. D2
6
IMPORTANT: The drain
hose must be installed during
dehumidifier mode.
Drain Hose (79” / 200cm)
Fig. G

The AUTO-TIMER feature offers a unique selection of multiple choice, fully automatic
on and/or off (start/stop) programs between 1-24 hours under any one mode of your Home
Comfort unit.
The programs are as follows:
a) Auto-Off: Pre-select a time that will turn off the
unit automatically (between 1-12hrs).
b) Auto-On: Pre-select a time that will turn on the
unit automatically (between 1-12hrs).
c) Auto-On & Auto Off: Pre-select a time that will
turn the unit ON / OFF automatically at specified
times (between 1-12hrs).
Note: These functions must be performed daily, as
the program is automatically canceled/erased after the
program has ended.
Control Buttons:
1) Power Switch
2) Mode
3) Fan Speed
4) On / Off Timer
5) Time / Temperature Set
• Used for adjusting the timer and temperature.
• The default display on control panel is room temperature.
• When or key is pressed in cool mode, the set temperature is displayed
and may be adjusted. After 10 seconds, the display will revert back to room
temperature.
• Timer setting is available from 1-24 hours by pressing or keys.
To operate the hand held remote control you will require two “AAA” Alkaline
batteries (included).
Batteries should be replaced when:
a) No signal (beep) is heard when attempting to program the main unit.
b) The main unit does not respond to a command issued by the remote control.
Battery replacement:
1) Slide the rear cover on the remote in the direction of the arrow. Continue pulling (gently) until the cover
separates completely from the unit.
2) Insert (2) batteries (AAA) following the same orientation (polarity) depicted inside the battery chamber (+ / -).
3) Re-install rear cover.
4) If the remote control will not be used for extended periods of time, batteries should be removed.
The remote operates within a range of 8 meters (26 ft.) from the receiver located inside the main unit. Any
obstruction between the receiver and remote may cause signal interference, limiting the ability to program the unit.
Notes:
1) Do not drop the remote control.
2) Do not place the remote control in a location exposed to direct sunlight.
3) The remote control should be placed about 1 meter or more away from TV, or any electrical appliances.
This Class B digital apparatus complies with canadian ICES-003.
OPERATION (cont’d)
AUTO-TIMER
REMOTE
CONTROL FEATURES
7
1
3
4
2
5

CAUTION: Before cleaning or servicing this unit,
disconnect from any electrical supply outlet.
1) DO NOT use gasoline, benzene, thinner, or any
other chemicals to clean this unit, as these
substances may cause damage to the finish and
deformation of plastic parts.
2) Never attempt to clean the unit by pouring water
directly over any of the surface areas, as this will
cause deterioration of electrical components and
wiring insulation.
3) Unplug the unit.
4) Clean the unit by wiping off any dirt/dust with a
soft damp cloth or vacuum cleaner, then wipe dry
with a dry soft cloth.
CAUTION: Always store the unit in vertical
position. DO NOT put heavy objects on top of the
unit.
If the air filter becomes clogged with dust/dirt, air flow is restricted, which reduces
cooling efficiency. The air filter should be cleaned every two (2) weeks. More
frequent cleaning may be necessary depending on indoor air quality.
NOTE: The air filter is located at the upper rear side of the unit.
1) To remove the air filter: Pull the air filter cover upward in the direction of the
arrow (Fig. 4) and remove the air filter.
2) Dust/dirt clogged in the filter can be removed by vacuum cleaning the soiled
areas.
3) The filter can also be washed in lukewarm, soapy water while rubbing it lightly
with a brush. A mild detergent (diswashing liquid) is recommended.
4) Rinse the filter well using clean water. Allow time to dry before reinstalling
into the unit.
5) Replace the air filter and cover.
6) Replacement air filter information is available by contacting the Customer Service
Department at: 1-800-26- (1-800-263-2629).
CAUTION: Never operate this unit without the air filter in place, as this may result in
damage to the unit.
Fig. 4
CARE AND MAINTENANCE
CLEANING
THE UNIT
CLEANING THE
AIR FILTER
8

TROUBLESHOOTING
9
PROBLEM POSSIBLE CAUSE SOLUTIONS
1) Unit does not work
• Power is out.
• The plug is not plugged in properly.
• The full-tank indicator is ON; tank is
full.
• Current leaking or pressing test
button on LCDI plug.
• Wait for power to return.
• Plug in properly.
• Remove drain water from the drain
tank.
• Press the reset button after resolving
problem.
2) Unit suddenly stops during operation.
• Indoor set temperature has been
reached.
• The preset time is up.
• The full-tank indicator is ON; tank is
full.
• Reset the temperature level.
• Reset the timer.
• Remove drain water from the drain
tank.
3) Unit runs intermittently • Malfunction.
• Surrounding temp. is too high/low.
• Exhaust duct hose is blocked.
• Contact your dealer.
• This is normal.
• Check the duct hose.
4) Unit functions but the room is not
cooled.
• Window or door is open in room.
• There is a heat source or too many
people in the room.
• Air intake grill is clogged.
• Filter is too dirty.
• Temperature setting is too high.
• Close all windows/doors.
• Move any heat sources from room.
• Clean air intake grill.
• Replace the filter.
• Lower temp. setting.
5) Condensed water spills out when
moving the unit. • The tank is nearly full. • Remove drain plug on rear bottom and drain out water.
Occasionally, a problem may occur that is minor, and a service call may not be necessary. Use this
troubleshooting guide for a possible solution. If the unit continues to operate improperly, call an authorized
service depot for assistance, or Danby’s Toll Free Number: 1-800-26-
