Danby DPA085CB1GDB Assembly instructions

2014.12.01
Danby Products Limited, Guelph, ON, Canada N1H 6Z9
Danby Products Inc., Findlay, Ohio, USA 45840
MODEL • MODÈLE
DPA085CB1GDB
DPA085UB1GDB
PORTABLE AIR CONDITIONER
CLIMATISEUR PORTATIF
• OWNER’S USE AND CARE GUIDE
• GUIDE D’UTILISATION ET D’ENTRETIEN

DO NOT RETURN THIS UNIT TO THE RETAILER
WITHOUT FURTHER INSTRUCTIONS
Dear valued customer, we hope your Danby product purchase fulfills all
your requirements. Your satisfaction is our priority!
Please contact us at our toll free consumer service number for any inquiries
you may have about your new unit.
NE PAS RETOURNER CET APPAREIL CHEZ LE
DÉTAILLANT SANS CONSIGNES SUPPLÉMENTAIRES
Cher(ère) client(e) important(e), nous espérons que votre produit Danby
répond à tous vos besoins. Votre satisfaction est notre priorité!
Veuillez nous contacter au numéro gratuit de service après-vente, si
vous avez des questions quelconques à propos de votre nouvel appareil.
NO DEVUELVA ESTA UNIDAD A LA TIENDA SIN
INSTRUCCIONES ADICIONALES
Estimado cliente, esperamos que el producto Danby que ha comprado
satisfaga completamente sus necesidades. Su satisfacción
es nuestra prioridad!
Por favor, contáctenos gratuitamente a nuestro número de Servicio al
Cliente para cualquier pregunta que tenga sobre su nuevo electrodoméstico.
1-800-263-2629
(1-800-26-DANBY)
Danby 28.08.2014

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDE A VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
POUR OBTENIR LE SERVICE SUR GARANTIE, VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must
be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and
applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the
responsibility and obligation of the customer to exchange the existing receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. The third ground prong should not,
under any circumstances, be cut or removed. Never use the cord, the plug or the appliance when they show
any sign of damage. Do not use your appliance with an extension cord unless it has been checked and test-
ed by a qualified electrician or electrical supplier.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il doit être
branché dans une prise avec une fiche de mise à la terre en conformité avec le Code national de l’électricité
et les codes et règles locaux applicables. Si la prise murale n’a pas de mise à la terre, il est de la
responsabilité et l’obligation du client de changer la prise existante pour la rendre conforme au Code
national de l’électricité et aux codes et règles locaux applicables. La fiche de mise à la terre ne doit pas, en
aucune circonstance, être coupée ou retirée. Si vous apercevez des signes de dommage, n’utilisez jamais le
cordon d’alimentation, la prise ou l’appareil. N’utilisez jamais l’appareil avec une rallonge sauf si elle a été
vérifiée et testée par un électricien qualifié ou un fournisseur de matériel électrique.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE

PORTABLE AIR CONDITIONER
Owner’s Use and Care Guide ................................1-16
• Welcome
• Important Safety Information
• Features
• Installation Instructions
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
CLIMATISEUR PORTATIF
Guide d’utilisation et d’entretien............................17-32
• Bienvenue
• Consignes de sécurité importantes
• Caractéristiques
• Consignes d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
CONTENTS
CAUTION:
Read and follow all safety rules and operating
instructions before first use of this product.
AVERTISSEMENT :
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
TABLE DES MATIÈRES
WARNING
Improper connection of the grounding plug can
result in risk of fire, electric shock and/or injury to
persons associated with the appliance. Check with
a qualified service representative if in doubt that
the appliance is properly grounded.
Model • Modèle
DPA085CB1GDB / DPA085UB1GDB
AVERTISSEMENT
Une fiche de mise à la terre mal branchée peut
entraîner un risque d’incendie, de choc électrique
ou de blessures aux personnes qui utilisent
l’appareil. Si vous n’êtes pas certain que l’appareil
est correctement mis à la terre, consultez un
préposé du service qualifié.

Welcome
Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will
find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best
of all, you will experience these values each and every time you use your Danby appliance. That is important, because
your new appliance will be a part of your family for a long time.
Note the information below; you will need this information to obtain service under warranty.
To receive service, you must provide the original receipt.
Serial Number:
Date of Purchase:
NEED HELP?
Before you call for service, here are a few things you can do to help
us serve you better:
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your
appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the
appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide before call-
ing. This section helps you solve common problems that may occur.
If you do need service, you can relax, knowing help is only a phone
call away.
1-800-26-
(1-800-263-2629)
1

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
SAFETY
PRECAUTIONS
ALWAYS DO THIS
Your air conditioner should be used in such a way that it is protected from
moisture. e.g. condensation, splashed water, etc. Do not place or store
your air conditioner where it can fall or be pulled into water or any other
liquid. Unplug unit immediately if this occurs.
Always transport your air conditioner in a vertical position and place on a
stable, level surface during use. If the unit is transported laying on its side it
should be stood up and left unplugged for 4 hours.
Turn off the unit when not in use.
Always contact a qualified person to perform repairs. If the power cord is
damaged it must be repaired by a qualified technician.
Keep the unit away from walls, furniture and curtains with a clearance of at
least 30 cm all around.
If the air conditioner is knocked over during use, turn off the unit and
unplug it immediately.
Always use the switch on the control panel to turn the unit on or off.
Portable air conditioners exhaust large amounts of room air.Always ensure
an adequate supply of make-up air to operate efficiently.
NEVER DO THIS
Do not operate your air conditioner in a wet room such as a bathroom or
laundry room.
Do not touch the unit with wet or damp hands.
Do not press the buttons on the control panel with anything other than your
fingers.
Do not remove any fixed components. Never use this appliance if it is not
working properly, or if it has been dropped or damaged.
Never use the plug to start and stop the unit.
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come into contact with the unit.
Do not use the unit in the presence of inflammable substances or vapour
such as alcohol, insecticides, gasoline, etc.
Do not allow children to operate the unit unsupervised.
Do not use this product for functions other than those described in this
instruction manual.
2

Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation resulting from ignoring these instructions may cause harm or damage.
ENERGY SAVING
TIPS
OPERATING
CONDITIONS
TOOLS FOR
WINDOW KIT
INSTALLATION
• Use the unit in the recommended room size.
• Locate the unit where furniture cannot obstruct the air flow.
• Keep blinds/curtains closed during the sunniest part of the day.
• Keep the filters clean.
• Keep doors and windows closed to keep cool air in and warm air out
(cooling mode)
MODE ROOM TEMPERTURE
COOL 17°C (62°F) ~ 35°C (95°F)
DRY 13°C (55°F) ~ 35°C (95°F)
The air conditioner must be operated within the temperature range
indicated below:
Note: Performance may be reduced outside of these operating tempera-
tures.
1. Screwdriver (medium size, Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw (In the event that the window kit needs to be cut down in size
because the window is too narrow for direct installation).
See www.danby.com for general instruction guide
Identifying Parts
WARNING
• Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other
appliance.
• Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any
prong from the power cord.
ELECTRICAL INFORMATION
WARNING
• Be sure the electrical supply is adequate for the model you have chosen. This information can be found
on the serial plate, which is located on the side of the cabinet and behind the grille.
• Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding
is important. The power cord is equipped with a three-prong grounding plug for protection against
shock hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you
intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a
qualified electrician install the proper receptacle.
• Ensure the receptacle remains accessible after the unit is installed.
3

Identifying Parts
ACCESSORIES
PARTS PART NAME QUANTITY
• Exhaust hose and adaptor
(round mouth)
• Window slider kit and pins
1 set
Foam seal 6/pc
Remote controller and battery
(for remote control models only)
1 set
Drain hose 1 pc
Note: Optional parts (*), some models do not include.
• Ensure that all the accessories are included in the package and refer to the installation instructions for their
usage.
Note: All the illustrations in this manual are for explanatory purposes only. Your air conditioner may be slightly
different.
UNIT STRUCTURE
4
P
M
ET
O
T
U
A
L
OO
C
R
DY
E
HT
A
FN
A
H
G
IH
D
E
M
O
LW
EDOM FDE
E
P
S
N
A
G
N
IWS
N
O
REMI
T
Y
MO
NOCE
FF
O/
N
O
F
FORE
M
I
T
RESE TLOC K
W
O
L
L
O
FE
MD
E
LY
A
L
P
S
I
D
N
O
I
O
B
RUT
1
2
3
5
4
FRONT
1
2
3
4
Control Panel
Horizontal Louver Blade
(adjusts manually)
Carrying Handle
(both sides)
Remote Signal Receptor
Front Panel
Fig.1
5

Identifying Parts
Features
ELECTRONIC CONTROL
INSTRUCTIONS
Before you begin, thoroughly familiarize yourself with the control panel and remote control and all its functions. Select the
functions you desire based on the associated symbol.
The unit can be controlled by the control panel alone or with the remote control.
5
REAR
6
7
8
9
10
11
12
13
Upper Air Filter (behind the grille)
Air Outlet
Castor
Air Intake
Drain Outlet
Air Intake
Lower Air Filter (behind the grill)
Bottom tray drain outlet
Fig.2
8
9
12
11
6
7
13
10
Fig.3
4427
5136
grill)

Features
ELECTRONIC CONTROL
INSTRUCTIONS
6
POWER button
Turns power on/off.
SLEEP button
Used to initiate the SLEEP operation.
FAN button
Controls the fan speed. Press to toggle between three fan
speeds: LOW (press 1 time) and
HIGH (press 2 times). The fan speed indicator light indicates
the corresponding fan setting. Press the button a third time to
initiate AUTO-FAN mode. In this mode, all indicator lights
will light up.
UP and DOWN buttons
Used to adjust (increase / decrease) temperature settings
(1°C/1°F increments) in a range of 17°C (62°F) to 30°C (86°F)
or the TIMER setting in a range of 0~24hrs. The control is
capable of displaying temperature in degrees Fahrenheit or
degrees Celsius. To convert from one to the other, press and
hold the Up and Down buttons at the same time for 3 seconds.
MODE select button
Selects the appropriate operating mode. Each time you press
the button, a mode is selected in a sequence that goes from
AUTO, COOL, DRY, and FAN. The mode indicator light
illuminates depending on the mode settings.
TIMER button
Used to initiate the AUTO ON start time andAUTO OFF stop time program,
in conjunction with the up & down buttons.
LED DISPLAY
Shows the set temperature in °C or °F and the Auto-timer settings.
While on DRY and FAN modes, it shows the room temperature.
Error codes:
E1 - Room temperature sensor error -Unplug the unit and plug
it back in. If error repeats, call for service.
E2 - Evaporator temperature sensor error- Unplug the unit and
plug it back in. If error repeats, call for service.
E4 - Display panel communication error - Unplug the unit and
plug it back in. If error repeats call for service.
P1 - Bottom tray is full - Connect the drain hose and drain the
collected water away. If error repeats, call for service.
1
2
3
4
5
6
7
