OWNER’S MANUAL
Child Safety Gate Latch With Electronic Alarm System
MANUAL DEL PROPIETARIO
www.ddtechglobal.com
•owners manual ML3 alert_ENGLISH.indd 1 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
2
IMPORTANT: This manual contains important information regarding the operation
of your MagnaLatch®ALERT gate alarm. Ensure you read this manual fully before
installing and operating the alarm. If you are installing this gate alarm for use by
others, you must leave this Manual (or a copy of it) with the end user.
IMPORTANT: 3.6V Lithium Thionyl Chloride Battery (Li-SOCl2) supplied. Battery
type ER14250 - 1/2 AA (3.6V). Fire, explosion & severe burn hazard. Do not
recharge, crush, disassemble, heat above 100°C (212°F) or expose contents to water.
IMPORTANT: Never ignore the alarm. Ignoring the alarm may result in injury or death.
IMPORTANT: Always check your local swimming pool Standards/Codes before
installing the MagnaLatch®ALERT onto a pool fence.
NOTE: MagnaLatch®ALERT is designed to fit and work with MagnaLatch “Series 3” Top Pull
and Vertical Pull models only. See installation instructions provided with the product.
The MagnaLatch®ALERT will NOT fit or work on any other gate latch or previous model of
MagnaLatch®.
1 INTRODUCTION 4
1.1 SCOPE 4
1.2 PURPOSE 4
2 SYSTEM DESCRIPTION 4
2.1 SPECIFICATION 4
2.2 ELECTRICAL DATA 5
2.3 ENVIRONMENT 5
2.4 STANDARDS 5
3.1 ATTACHING ALERT TO LATCH BODY 6
3.2 INSTALLATION 7
3.3 POWERING UP 7
3.3 POWERING UP - CONTINUED 8
3.4 ACTIVATING THE DISARM FEATURE ON
ALERT - OPTIONAL 9
3.4 ACTIVATING THE DISARM FEATURE ON
ALERT - OPTIONAL (CONT) 10
CONTENTS
•owners manual ML3 alert_ENGLISH.indd 2 22/10/14 2:43 PM

3
MagnaLatch®ALERT Gate Alarm System
IMPORTANT: This manual contains important information regarding the operation
of your MagnaLatch®ALERT gate alarm. Ensure you read this manual fully before
installing and operating the alarm. If you are installing this gate alarm for use by
others, you must leave this Manual (or a copy of it) with the end user.
IMPORTANT: 3.6V Lithium Thionyl Chloride Battery (Li-SOCl2) supplied. Battery
type ER14250 - 1/2 AA (3.6V). Fire, explosion & severe burn hazard. Do not
recharge, crush, disassemble, heat above 100°C (212°F) or expose contents to water.
IMPORTANT: Never ignore the alarm. Ignoring the alarm may result in injury or death.
IMPORTANT: Always check your local swimming pool Standards/Codes before
installing the MagnaLatch®ALERT onto a pool fence.
NOTE: MagnaLatch®ALERT is designed to fit and work with MagnaLatch “Series 3” Top Pull
and Vertical Pull models only. See installation instructions provided with the product.
The MagnaLatch®ALERT will NOT fit or work on any other gate latch or previous model of
MagnaLatch®.
1 INTRODUCTION 4
1.1 SCOPE 4
1.2 PURPOSE 4
2 SYSTEM DESCRIPTION 4
2.1 SPECIFICATION 4
2.2 ELECTRICAL DATA 5
2.3 ENVIRONMENT 5
2.4 STANDARDS 5
3.1 ATTACHING ALERT TO LATCH BODY 6
3.2 INSTALLATION 7
3.3 POWERING UP 7
3.3 POWERING UP - CONTINUED 8
3.4 ACTIVATING THE DISARM FEATURE ON
ALERT - OPTIONAL 9
3.4 ACTIVATING THE DISARM FEATURE ON
ALERT - OPTIONAL (CONT) 10
CONTENTS
3.5 DISARMING THE ALERT TEMPORARILY -
OPTIONAL 11
3.6 OPERATIONAL SEQUENCE 12
3.7 CHANGING THE BATTERY 13
3.8 DISPOSAL OF BATTERIES 13
3.9 ENVIRONMENTAL PROTECTION 13
4 STATEMENTS OF COMPLIANCE 14
5 FREQUENTLY ASKED QUESTIONS 15
6 TROUBLESHOOTING 16
7 POOL SAFETY INFORMATION 17
8 CLEANING & MAINTENANCE 17
9 POOL SAFETY RESOURCES 18
10 WARRANTY 19
CONTACT 22
For a French version of this manual, go to
www.ddtechglobal.com
•owners manual ML3 alert_ENGLISH.indd 3 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
4
1 INTRODUCTION
1.1 SCOPE
Congratulations on purchasing a MagnaLatch®ALERT gate alarm. The MagnaLatch®ALERT is a
sensor with audible and visual signals to alert that a gate has been opened and remains unlatched.
It is ideal for a location where children need to be protected, such as a play area or swimming pool.
1.2 PURPOSE
The purpose of this guide is to provide information for the installer and user of the MagnaLatch®ALERT
to ensure that the product operates and functions correctly for many years.
IMPORTANT: The MagnaLatch® ALERT is intended only to signal that the latch is
not fully engaged and providing its intended protection. It is NOT to be used as a
substitute for adult supervision.
WARNING: The alarm is very loud. Never hold the alarm next to ears, as it may
affect hearing.
2 SYSTEM DESCRIPTION
Peak Alarm Sound Level (@ source) 91 dB
Peak Alarm Sound Level (@ 3m/10feet): 70 dB
Alarm Sound Frequency: 2.5 - 5 kHz
Tested and rated to IP55
2.1 SPECIFICATION
2.2 ELECTRICAL DATA
Power Source Supplied: Lithium Thionyl Chloride Battery (Li-SOCl2).
Battery Type: ½ AA (3.6V). For best results, use type ER14250.
Battery Life Expectancy (usage): 3.6V Lithium batteries are designed for long life. As with
any battery used outdoors, environmental conditions can effect their performance and longevity.
NOTE: If the ALERT has not been used for long periods of time, follow the instructions in section
3.3 on Powering Up.
LOW BATTERY WARNING: Alarm unit will emit a “ramp-down” sound when gate is opened,
and will repeat each time until the battery is replaced or completely dead.
2.3 ENVIRONMENT
OPERATING TEMPERATURE: -20°C to 60°C (-4°F to 140°F).
2.4 STANDARDS
EU EMC Directive EN 61000-6-3:2007:
Radiated disturbance - 30 MHz to 1000 MHz
EU EMC Directive EN 61000-6-1:2007:
EN 61000-4-2 - Electrostatic discharge (ESD)
EN 61000-4-3 - RF radiated susceptibility
EN 61000-4-8 - Magnetic field immunity
EMC Framework to AS/NZS 61000.6.3:2007.
•owners manual ML3 alert_ENGLISH.indd 4 22/10/14 2:43 PM

5
MagnaLatch®ALERT Gate Alarm System
1 INTRODUCTION
1.1 SCOPE
Congratulations on purchasing a MagnaLatch®ALERT gate alarm. The MagnaLatch®ALERT is a
sensor with audible and visual signals to alert that a gate has been opened and remains unlatched.
It is ideal for a location where children need to be protected, such as a play area or swimming pool.
1.2 PURPOSE
The purpose of this guide is to provide information for the installer and user of the MagnaLatch®ALERT
to ensure that the product operates and functions correctly for many years.
IMPORTANT: The MagnaLatch® ALERT is intended only to signal that the latch is
not fully engaged and providing its intended protection. It is NOT to be used as a
substitute for adult supervision.
WARNING: The alarm is very loud. Never hold the alarm next to ears, as it may
affect hearing.
Alarm Sound Frequency: 2.5 - 5 kHz
Tested and rated to IP55
2.2 ELECTRICAL DATA
Power Source Supplied: Lithium Thionyl Chloride Battery (Li-SOCl2).
Battery Type: ½ AA (3.6V). For best results, use type ER14250.
Battery Life Expectancy (usage): 3.6V Lithium batteries are designed for long life. As with
any battery used outdoors, environmental conditions can effect their performance and longevity.
NOTE: If the ALERT has not been used for long periods of time, follow the instructions in section
3.3 on Powering Up.
LOW BATTERY WARNING: Alarm unit will emit a “ramp-down” sound when gate is opened,
and will repeat each time until the battery is replaced or completely dead.
2.3 ENVIRONMENT
OPERATING TEMPERATURE: -20°C to 60°C (-4°F to 140°F).
2.4 STANDARDS
EU EMC Directive EN 61000-6-3:2007:
Radiated disturbance - 30 MHz to 1000 MHz
EU EMC Directive EN 61000-6-1:2007:
EN 61000-4-2 - Electrostatic discharge (ESD)
EN 61000-4-3 - RF radiated susceptibility
EN 61000-4-8 - Magnetic field immunity
EMC Framework to AS/NZS 61000.6.3:2007.
AS1217.5 – “Acoustics Determination of sound
power levels of noise sources”
AS1926-1 2012 - “Strength & Durability, Closing
And Latching And Security of Closure of Gate
Units”
USA: FCC Part 15 (B) Class B (ANSI C63.4:2003)
- “Reasonable protection against harmful
interference”
•owners manual ML3 alert_ENGLISH.indd 5 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
6
3.1 ATTACHING ALERT MODULE TO LATCH BODY
TOP PULL VERTICAL PULL
1. Slide top of ALERT Module underneath top housing.
2. Snap into place starting at the top.
3. Snap bottom section into place. Ensure ALERT
is fully snapped into place at all positions.
3 INSTALLATION & OPERATION 3.2 INSTALLATION
MagnaLatch®ALERT is designed to fit and work with MagnaLatch “Series 3” Top Pull and Vertical
Pull models only. See installation instructions provided with the product.
NOTE: MagnaLatch®ALERT will NOT fit or work on any other gate latch or previous model of
MagnaLatch®.
3.3 POWERING UP
1.Remove screw and front cover by using a
#1 Phillips-head screwdriver.
DO NOT lose the screw.
2.Insert battery as indicated into the battery
compartment with the (+) symbol on top and
the (-) on the bottom.
1
(Note: MagnaLatch®installation instructions are included separately and are not inside this manual.)
•owners manual ML3 alert_ENGLISH.indd 6 22/10/14 2:43 PM

7
MagnaLatch®ALERT Gate Alarm System
1. Slide top of ALERT Module underneath top housing.
2. Snap into place starting at the top.
3. Snap bottom section into place. Ensure ALERT
is fully snapped into place at all positions.
3.2 INSTALLATION
MagnaLatch®ALERT is designed to fit and work with MagnaLatch “Series 3” Top Pull and Vertical
Pull models only. See installation instructions provided with the product.
NOTE: MagnaLatch®ALERT will NOT fit or work on any other gate latch or previous model of
MagnaLatch®.
3.3 POWERING UP
1.Remove screw and front cover by using a
#1 Phillips-head screwdriver.
DO NOT lose the screw.
2.Insert battery as indicated into the battery
compartment with the (+) symbol on top and
the (-) on the bottom.
1 2
Battery Type:
ER14250
1/2 AA (3.6V)
(Note: MagnaLatch®installation instructions are included separately and are not inside this manual.)
•owners manual ML3 alert_ENGLISH.indd 7 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
8
3.3 POWERING UP - CONTINUED
3.Open & close the gate 5 times to calibrate
the system. This will also ensure the battery
operates at peak performance (see section 2.2).
NOTE: A false sounding of a low battery
(ramp down) may occur during the calibration
process. If this continues, replace with new
battery or contact D&D Technologies.
4. Re-attach front cover and screw by using
#1 Phillips-head screwdriver.
43
3.4 ACTIVATING THE DISARM FEATURE ON ALERT MODULE - OPTIONAL
1.Remove screw and front cover by using a
#1 Phillips-head screwdriver.
DO NOT lose the screw.
2. Open the gate. Gate must be open in order
to activate the Disarm feature.
NOTE: Ensure battery is properly inserted
with (+) symbol on top and (-) on bottom.
NOTE: The gate must be open whenever
activating or deactivating the Disarm feature
and when using the disarm feature itself.
NOTE: The ALERT comes from the factory
with the Disarm feature de-activated.
1
•owners manual ML3 alert_ENGLISH.indd 8 22/10/14 2:43 PM

9
MagnaLatch®ALERT Gate Alarm System
3.3 POWERING UP - CONTINUED
3.Open & close the gate 5 times to calibrate
the system. This will also ensure the battery
operates at peak performance (see section 2.2).
NOTE: A false sounding of a low battery
(ramp down) may occur during the calibration
process. If this continues, replace with new
battery or contact D&D Technologies.
4. Re-attach front cover and screw by using
#1 Phillips-head screwdriver.
3.4 ACTIVATING THE DISARM FEATURE ON ALERT MODULE - OPTIONAL
1.Remove screw and front cover by using a
#1 Phillips-head screwdriver.
DO NOT lose the screw.
2. Open the gate. Gate must be open in order
to activate the Disarm feature.
NOTE: Ensure battery is properly inserted
with (+) symbol on top and (-) on bottom.
NOTE: The gate must be open whenever
activating or deactivating the Disarm feature
and when using the disarm feature itself.
NOTE: The ALERT comes from the factory
with the Disarm feature de-activated.
1 2
•owners manual ML3 alert_ENGLISH.indd 9 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
10
3.4 ACTIVATING THE DISARM FEATURE ON ALERT - OPTIONAL (CONT)
1.Insert a paper clip into the hole located
between the paper clip image and On/Off
symbol. Press once to activate the Disarm
feature. A “ramp-up” sound will be heard.
2.Close the gate and re-attach the front cover
with screw using a #1 Phillips-head screwdriver.
Disarm sounder Icon
On/O Icon
Paper Clip Icon
Hole
Paper clip
NOTE: If paper clip is pressed twice, a “ramp-
down” sound will be heard, indicating the
Disarm feature has been de-activated.
NOTE: The gate must be open whenever
activating or de-activating the Disarm feature,
and when using the Disarm feature.
3.5 DISARMING THE ALERT TEMPORARILY - OPTIONAL
1.To temporarily disarm the ALERT for a
maximum of 15 minutes, open the gate and
hold open until the second beep sounds.
NOTE: Do not wear gloves when disarming. The
Disarm Sensor is touch-sensitive to skin only.
NOTE: Closing and latching the gate at any
time will re-arm the ALERT Module.
2. Place finger on top of the Disarm Sensor
and hold for 5 seconds. You will then hear 4
beeps followed by a “ramp-up” sound.
NOTE: The ALERT is now de-activated for up
to 15 minutes as long as the gate is held open.
After 15 minutes, or if closing the gate at any
time, the ALERT Module will re-arm itself.
A
Disarm
Touch Sensor
NOTE: The Disarm Sensor is touch sensitive and does not require to be pushed inward. It
responds to contact with your skin and will not operate when wearing gloves.
WARNING: DO NOT disarm the ALERT on a pool or spa gate. Activating
the Disarm feature and using it is the sole responsibility of the user and
not the manufacturer.
STOPPING THE ALARM - Closing and latching the gate will silence the alarm.
•owners manual ML3 alert_ENGLISH.indd 10 22/10/14 2:43 PM

11
MagnaLatch®ALERT Gate Alarm System
3.4 ACTIVATING THE DISARM FEATURE ON ALERT - OPTIONAL (CONT)
1.Insert a paper clip into the hole located
between the paper clip image and On/Off
symbol. Press once to activate the Disarm
feature. A “ramp-up” sound will be heard.
2.Close the gate and re-attach the front cover
with screw using a #1 Phillips-head screwdriver.
Disarm sounder Icon
On/O Icon
Paper Clip Icon
Hole
Paper clip
NOTE: If paper clip is pressed twice, a “ramp-
down” sound will be heard, indicating the
Disarm feature has been de-activated.
NOTE: The gate must be open whenever
activating or de-activating the Disarm feature,
and when using the Disarm feature.
3.5 DISARMING THE ALERT TEMPORARILY - OPTIONAL
1.To temporarily disarm the ALERT for a
maximum of 15 minutes, open the gate and
hold open until the second beep sounds.
NOTE: Do not wear gloves when disarming. The
Disarm Sensor is touch-sensitive to skin only.
NOTE: Closing and latching the gate at any
time will re-arm the ALERT Module.
2. Place finger on top of the Disarm Sensor
and hold for 5 seconds. You will then hear 4
beeps followed by a “ramp-up” sound.
NOTE: The ALERT is now de-activated for up
to 15 minutes as long as the gate is held open.
After 15 minutes, or if closing the gate at any
time, the ALERT Module will re-arm itself.
A
Disarm
Touch Sensor
NOTE: The Disarm Sensor is touch sensitive and does not require to be pushed inward. It
responds to contact with your skin and will not operate when wearing gloves.
WARNING: DO NOT disarm the ALERT on a pool or spa gate. Activating
the Disarm feature and using it is the sole responsibility of the user and
not the manufacturer.
STOPPING THE ALARM - Closing and latching the gate will silence the alarm.
•owners manual ML3 alert_ENGLISH.indd 11 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
12
WARNING: The alarm is very loud. Never hold the alarm next to ears, as it
may affect hearing.
3.9 ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
3.7 CHANGING THE BATTERY
When the battery strength goes below an acceptable level, a “ramp-down” sound will occur every
time the gate is opened. When replacing the battery, refer to section 3.3. For best results, use
battery type ER14250 (1/2 AA - 3.6V)
3.8 DISPOSAL OF BATTERIES
AU/NZ/EU: Do not dispose of batteries in household waste. Please return to point of purchase or
appropriate battery collection centre for recycling. For recycling locations in Australia, go to
www.recyclingnearyou.com.au
US/CA: Do not dispose of batteries in household waste. All Lithium Thionyl Chloride batteries
(Li-SOCl2) should be given to an appropriate household hazardous waste facility for recycling.
3.6 OPERATIONAL SEQUENCE
CLOSING GATE
AND ENGAGING
LATCH AT
ANY TIME
RESETS THE
ALARM
LIFT ML3 KNOB
LIFT ML3 KNOB
SYSTEM ACTIVE
ACKNOWLEDGMENT
ACKNOWLEDGMENT
OPEN GATE
DELAY (8 seconds)
1st WARNING
1st WARNING
DELAY (2 seconds)
DELAY (15 minutes)
2nd WARNING
DELAY (2 seconds)
3rd WARNING
FULL ALARM FULL ALARM
DISARM (SILENCE CYCLE)
- can only be activated after 1st warning
Place finger on disarm
sensor for 5 seconds
Delay (8 seconds)
or shut gate to reset alarm
+
Resets when gate is shut or battery drains out
ACKNOWLEDGMENT (immediate) Low
Battery
FLASHING
LIGHTS or
BEEP Ramp Down Sound
Ramp Up Sound
See section 3.3 on page 7
+
+
BEEP
+
BEEP
+
BEEP
ACCELERATING ALARM +
BEEPS
∞
FLASHING
LIGHTS
+
BEEP
BEEP
BEEP
x 5
FLASHING
LIGHTS
FLASHING
LIGHTS
FLASHING
LIGHTS
FLASHING
LIGHTS
+
BEEPS
∞FLASHING
LIGHTS
FLASHING
LIGHTS
+FLASHING
LIGHTS
Resets when gate is latched or battery drains out
•owners manual ML3 alert_ENGLISH.indd 12 22/10/14 2:43 PM

13
MagnaLatch®ALERT Gate Alarm System
WARNING: The alarm is very loud. Never hold the alarm next to ears, as it
may affect hearing.
3.9 ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
3.7 CHANGING THE BATTERY
When the battery strength goes below an acceptable level, a “ramp-down” sound will occur every
time the gate is opened. When replacing the battery, refer to section 3.3. For best results, use
battery type ER14250 (1/2 AA - 3.6V)
3.8 DISPOSAL OF BATTERIES
AU/NZ/EU: Do not dispose of batteries in household waste. Please return to point of purchase or
appropriate battery collection centre for recycling. For recycling locations in Australia, go to
www.recyclingnearyou.com.au
US/CA: Do not dispose of batteries in household waste. All Lithium Thionyl Chloride batteries
(Li-SOCl2) should be given to an appropriate household hazardous waste facility for recycling.
CLOSING GATE
AND ENGAGING
LATCH AT
ANY TIME
RESETS THE
ALARM
LIFT ML3 KNOB
LIFT ML3 KNOB
SYSTEM ACTIVE
ACKNOWLEDGMENT
ACKNOWLEDGMENT
OPEN GATE
DELAY (8 seconds)
1st WARNING
1st WARNING
DELAY (2 seconds)
DELAY (15 minutes)
2nd WARNING
DELAY (2 seconds)
3rd WARNING
FULL ALARM FULL ALARM
DISARM (SILENCE CYCLE)
- can only be activated after 1st warning
Place finger on disarm
sensor for 5 seconds
Delay (8 seconds)
or shut gate to reset alarm
+
Resets when gate is shut or battery drains out
ACKNOWLEDGMENT (immediate) Low
Battery
FLASHING
LIGHTS or
BEEP Ramp Down Sound
Ramp Up Sound
See section 3.3 on page 7
+
+
BEEP
+
BEEP
+
BEEP
ACCELERATING ALARM +
BEEPS
∞
FLASH
ING
LIGHTS
+
BEEP
BEEP
BEEP
x 5
FLASHING
LIGHTS
FLASHING
LIGHTS
FLASHING
LIGHTS
FLASHING
LIGHTS
+
BEEPS
∞FLASHING
LIGHTS
FLASH
ING
LIGHTS
+FLASH
ING
LIGHTS
Resets when gate is latched or battery drains out
•owners manual ML3 alert_ENGLISH.indd 13 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
14
4 STATEMENTS OF COMPLIANCE
Compliance Testing Report of a Pool Fence Alarm to FCC Part 15 (B) Class B (ANSI C63.4:2003)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate, radio frequency energy, and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area may cause harmful interference, in which case the user will be required to
correct the interference at their sole expense.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate, radio
frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
Compliance of a Pool Fence Alarm with the EU EMC Directive and Australian EMC Framework EN
61000-6-3:2007 and immunity to EN 61000-6-1:2007. Satisfied the requirements of the
Australian EMC Framework to AS/NZS 61000.6.3:2007.
Responsible supplier name: D&D Technologies Pty. Limited
Responsible supplier number: E1838 ABN/IRDN: 94059412430
NATA Certified compliance to AS1926-1 2012 - “Strength & Durability, Closing and Latching and
Security of Closure of Gate Units.” For copy of NATA test results, please contact D&D Technologies.
5 FREQUENTLY ASKED QUESTIONS
1
How does extreme weather and
long periods of non-usage effect
the battery?
Lithium batteries are designed for long life, but as with any battery used
outdoors, environmental conditions and long periods of non-usage can
effect their life-span. See section 3.3 on Powering Up.
2How will I know if the battery
is low?
A unique downward chirping sound will occur each time the gate is
opened, indicating the battery is running low.
3Where do I purchase a new
battery?
You can purchase a new battery from any leading electronics store or on
the internet. Order battery type 14250 (1/2 AA 3.6V).
4
If I remove the battery or it loses
power, will my MagnaLatch®still
work as a safety gate latch?
Yes, the MagnaLatch®will still latch independently.
5Can I re-program my
MagnaLatch®ALERT?
No, programming cannot be changed. You can only temporarily turn off
the alarm using the Disarm feature (Sections 3.4-3.6).
6Do I have to activate the Disarm
feature?
No, the Disarm feature is optional. Do not disarm the ALERT when using
on swimming pool/spa gates. The Disarm feature comes de-activated
from the factory.
7Can I turn off my MagnaLatch®
ALERT (sound & flashing light)?
You can disarm the ALERT sound for short periods only. Do not disarm
the ALERT when using on swimming pool gates, as this presents a
danger to children. See sections 3.4 to 3.6.
8
How do I refit the
MagnaLatch®ALERT Electronic
unit onto my MagnaLatch®?
Refer to Section 3.1. in the operation guide.
9
Will rain or snow damage
the electronics or cause it to
malfunction?
No, the MagnaLatch®ALERT has been designed for outdoor use.
For more information refer to section 2.3 in the operation guide.
10 What does my Warranty cover?
The MagnaLatch®gate latch comes with a limited Lifetime Warranty.
The ALERT alarm unit comes with a 2-Year limited Warranty from the date
of purchase. No warranty on battery (refer to Section 10.)
•owners manual ML3 alert_ENGLISH.indd 14 22/10/14 2:43 PM

15
MagnaLatch®ALERT Gate Alarm System
4 STATEMENTS OF COMPLIANCE
Compliance Testing Report of a Pool Fence Alarm to FCC Part 15 (B) Class B (ANSI C63.4:2003)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate, radio frequency energy, and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area may cause harmful interference, in which case the user will be required to
correct the interference at their sole expense.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate, radio
frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
Compliance of a Pool Fence Alarm with the EU EMC Directive and Australian EMC Framework EN
61000-6-3:2007 and immunity to EN 61000-6-1:2007. Satisfied the requirements of the
Australian EMC Framework to AS/NZS 61000.6.3:2007.
Responsible supplier name: D&D Technologies Pty. Limited
Responsible supplier number: E1838 ABN/IRDN: 94059412430
NATA Certified compliance to AS1926-1 2012 - “Strength & Durability, Closing and Latching and
Security of Closure of Gate Units.” For copy of NATA test results, please contact D&D Technologies.
5 FREQUENTLY ASKED QUESTIONS
1
How does extreme weather and
long periods of non-usage effect
the battery?
Lithium batteries are designed for long life, but as with any battery used
outdoors, environmental conditions and long periods of non-usage can
effect their life-span. See section 3.3 on Powering Up.
2How will I know if the battery
is low?
A unique downward chirping sound will occur each time the gate is
opened, indicating the battery is running low.
3Where do I purchase a new
battery?
You can purchase a new battery from any leading electronics store or on
the internet. Order battery type 14250 (1/2 AA 3.6V).
4
If I remove the battery or it loses
power, will my MagnaLatch®still
work as a safety gate latch?
Yes, the MagnaLatch®will still latch independently.
5Can I re-program my
MagnaLatch®ALERT?
No, programming cannot be changed. You can only temporarily turn off
the alarm using the Disarm feature (Sections 3.4-3.6).
6Do I have to activate the Disarm
feature?
No, the Disarm feature is optional. Do not disarm the ALERT when using
on swimming pool/spa gates. The Disarm feature comes de-activated
from the factory.
7Can I turn off my MagnaLatch®
ALERT (sound & flashing light)?
You can disarm the ALERT sound for short periods only. Do not disarm
the ALERT when using on swimming pool gates, as this presents a
danger to children. See sections 3.4 to 3.6.
8
How do I refit the
MagnaLatch®ALERT Electronic
unit onto my MagnaLatch®?
Refer to Section 3.1. in the operation guide.
9
Will rain or snow damage
the electronics or cause it to
malfunction?
No, the MagnaLatch®ALERT has been designed for outdoor use.
For more information refer to section 2.3 in the operation guide.
10 What does my Warranty cover?
The MagnaLatch®gate latch comes with a limited Lifetime Warranty.
The ALERT alarm unit comes with a 2-Year limited Warranty from the date
of purchase. No warranty on battery (refer to Section 10.)
•owners manual ML3 alert_ENGLISH.indd 15 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
16
6 TROUBLESHOOTING
Problem Solution
1 My gate is closed but the alarm won’t stop.
Be sure your MagnaLatch®ALERT is properly
aligned and securely latched.
See MagnaLatch® ALERT installation instructions.
2 My disarm touch sensor isn’t working. The Disarm feature comes de-activated from the
factory. To activate, refer Section 3.4.
3The alarm is making a downward chirping sound;
what does this mean?
The battery is low and time to replace.
Refer Section 3.3.
4 My alarm is not as loud as when first purchased.
The battery cover (or horn) may be blocked with
debris. Remove cover and clean opening of any
debris that may impede sound of alarm. Then
replace cover (see section 3.3).
5What if I tried everything but my MagnaLatch®ALERT
is still not working properly?
Contact D&D Technologies. See back page of this
manual for contact information.
7 POOL SAFETY INFORMATION
As the founding sponsor of the National Drowning Prevention Alliance (www.NDPA.org) and the
makers of the MagnaLatch®magnetic, self-latching gate latch and TruClose®, self-closing hinges,
D&D Technologies is committed to supporting efforts to prevent toddler drowning worldwide.
Always consult with local officials for pool barrier Standards/Codes in your area. For more
information on D&D’s products visit our website www.ddtechglobal.com
In the interest of public safety, D&D developed the "Blueprint for Pool Gate Safety,” as a checklist
and guide to help ensure your pool fence and gate meet pool barrier Standards/Codes. For a
free copy of this brochure, go to our website at www.ddtechglobal.com or contact the D&D
Technologies’ office in your region (see back page for locations).
8 CLEANING & MAINTENANCE
Always ensure the gate is self-closing and self-latching properly. Refer to hinge and latch
installation instructions for the proper adjustment procedures.
Always keep your MagnaLatch®ALERT clean and free of debris that may impair performance.
DO NOT use any abrasive or harsh chemicals when cleaning.
DO NOT use a pressure hose to clean.
•owners manual ML3 alert_ENGLISH.indd 16 22/10/14 2:43 PM

17
MagnaLatch®ALERT Gate Alarm System
6 TROUBLESHOOTING
Problem Solution
1 My gate is closed but the alarm won’t stop.
Be sure your MagnaLatch®ALERT is properly
aligned and securely latched.
See MagnaLatch® ALERT installation instructions.
2 My disarm touch sensor isn’t working. The Disarm feature comes de-activated from the
factory. To activate, refer Section 3.4.
3The alarm is making a downward chirping sound;
what does this mean?
The battery is low and time to replace.
Refer Section 3.3.
4 My alarm is not as loud as when first purchased.
The battery cover (or horn) may be blocked with
debris. Remove cover and clean opening of any
debris that may impede sound of alarm. Then
replace cover (see section 3.3).
5What if I tried everything but my MagnaLatch®ALERT
is still not working properly?
Contact D&D Technologies. See back page of this
manual for contact information.
7 POOL SAFETY INFORMATION
As the founding sponsor of the National Drowning Prevention Alliance (www.NDPA.org) and the
makers of the MagnaLatch®magnetic, self-latching gate latch and TruClose®, self-closing hinges,
D&D Technologies is committed to supporting efforts to prevent toddler drowning worldwide.
Always consult with local officials for pool barrier Standards/Codes in your area. For more
information on D&D’s products visit our website www.ddtechglobal.com
In the interest of public safety, D&D developed the "Blueprint for Pool Gate Safety,” as a checklist
and guide to help ensure your pool fence and gate meet pool barrier Standards/Codes. For a
free copy of this brochure, go to our website at www.ddtechglobal.com or contact the D&D
Technologies’ office in your region (see back page for locations).
8 CLEANING & MAINTENANCE
Always ensure the gate is self-closing and self-latching properly. Refer to hinge and latch
installation instructions for the proper adjustment procedures.
Always keep your MagnaLatch®ALERT clean and free of debris that may impair performance.
DO NOT use any abrasive or harsh chemicals when cleaning.
DO NOT use a pressure hose to clean.
•owners manual ML3 alert_ENGLISH.indd 17 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
18
1.GENERAL CONDITIONS
These Warranty conditions apply
to all products manufactured
by D&D Technologies (D&D)
except MagnaLatch®ALERT
Gate Alarm, KwikFit®Aluminium
Gate Hinges, SureClose®Gate
Closers & Hinges and D&D
Stainless Steel Gate Latches
and Hinges. See section 3
below for specific Warranty
details applying to these four
product lines.
1.1 Subject to the conditions
and limitations set out below,
D&D Technologies (D&D)
warrants that for so long as the
original purchaser of a product
manufactured by D&D owns
that product (the Product) it
will be free from all defects due
to faulty design, materials or
workmanship.
1.2. If a defect in the Product
appears the purchaser must
USA
American Academy of Pediatrics www.aap.org
American Red Cross www.redcross.org
APSP, the pool industry’s association www.theapsp.org
Arizona codes www.childrensafetyzone.com
Consumer Product Safety Commission www.poolsafety.gov
Drowning Prevention Coalition of Arizona www.preventdrownings.org
National Drowning Prevention Alliance www.NDPA.org
Safe Kids (search under drowning) www.usa.Safekids.org
AUSTRALIA & NEW ZEALAND
Kids Alive www.kidsalive.com.au
Kidsafe www.kidsafensw.org
Royal Life Saving Society (RLSSA) www.royallifesaving.com.au
Safewaters (NSW Govt) www.watersafety.nsw.gov.au
Water Safety NZ www.watersafety.org.nz
EUROPE
AFNOR Groupe www.afnor.fr
British Swimming Pool Federation www.bspf.org.uk
Child Safety Europe www.childsafetyeurope.org
International Life Saving Federation www.europe.ilsf.org
Swimming Pool Safety Guidelines www.swimireland.ie
9 POOL SAFETY RESOURCES 10 WARRANTY - LIMITED LIFETIME WARRANTY & LIMITATION OF LIABILITY
•owners manual ML3 alert_ENGLISH.indd 18 22/10/14 2:43 PM

19
MagnaLatch®ALERT Gate Alarm System
1.GENERAL CONDITIONS
These Warranty conditions apply
to all products manufactured
by D&D Technologies (D&D)
except MagnaLatch®ALERT
Gate Alarm, KwikFit®Aluminium
Gate Hinges, SureClose®Gate
Closers & Hinges and D&D
Stainless Steel Gate Latches
and Hinges. See section 3
below for specific Warranty
details applying to these four
product lines.
1.1 Subject to the conditions
and limitations set out below,
D&D Technologies (D&D)
warrants that for so long as the
original purchaser of a product
manufactured by D&D owns
that product (the Product) it
will be free from all defects due
to faulty design, materials or
workmanship.
1.2. If a defect in the Product
appears the purchaser must
advise D&D within 14 days of
discovering the defect and return
the defective item, comprising
either the Product or a defective
component of the Product (the
Item), to D&D or its agent, freight
prepaid, together with proof of
purchase, whereupon D&D will,
at its option and cost, repair
or replace the defective Item
with the same or an equivalent
Product or component. D&D
will not be liable for labour or
any other costs associated
with the dismantling, return or
reassembly of the Product or
any frame or structure to which
it is affixed.
1.3. This warranty does not
apply in respect of defects due
to or arising from:
(a) normal wear and tear;
(b) the failure to follow any
procedures specified or
recommended by D&D for
the installation, operation, and
maintenance of the Product;
(c) any act or circumstance
beyond D&D’s control including
tampering, unauthorised
repairs, misuse, abnormal
use, abuse, accident, damage
after delivery to the consumer,
damage caused by events
beyond human control including
but not limited to damage
caused by animals or natural
events, surface tarnishing and/
or damage to components
caused by corrosion or other
environmental conditions;
(d) any defect of or in any
framework or material
supporting the Product; or
(e) the faulty workmanship of
any person other than D&D,
including the installer of the
Product.
1.4. This warranty is personal
USA
American Academy of Pediatrics www.aap.org
American Red Cross www.redcross.org
APSP, the pool industry’s association www.theapsp.org
Arizona codes www.childrensafetyzone.com
Consumer Product Safety Commission www.poolsafety.gov
Drowning Prevention Coalition of Arizona www.preventdrownings.org
National Drowning Prevention Alliance www.NDPA.org
Safe Kids (search under drowning) www.usa.Safekids.org
AUSTRALIA & NEW ZEALAND
Kids Alive www.kidsalive.com.au
Kidsafe www.kidsafensw.org
Royal Life Saving Society (RLSSA) www.royallifesaving.com.au
Safewaters (NSW Govt) www.watersafety.nsw.gov.au
Water Safety NZ www.watersafety.org.nz
EUROPE
AFNOR Groupe www.afnor.fr
British Swimming Pool Federation www.bspf.org.uk
Child Safety Europe www.childsafetyeurope.org
International Life Saving Federation www.europe.ilsf.org
Swimming Pool Safety Guidelines www.swimireland.ie
10 WARRANTY - LIMITED LIFETIME WARRANTY & LIMITATION OF LIABILITY
•owners manual ML3 alert_ENGLISH.indd 19 22/10/14 2:43 PM

MagnaLatch®ALERT Gate Alarm System
20
to the original purchaser of the
Product or to the first consumer
where the Product has been
installed by a contractor for the
benefit of the consumer and
may not be assigned without
D&D’s prior written consent.
1.5. This warranty gives you
specific legal rights which are in
addition to, and do not replace,
other rights and remedies you
may have at law and which may
vary from state to state in your
jurisdiction.
1.6. Except as expressly granted
in this warranty or where to do
so would contravene a law in the
purchaser’s jurisdiction D&D’s
liability as regards any contractor
is limited in respect of all other
loss, damage or injury of any
kind whatsoever (including any
direct, indirect or consequential
loss or damage, loss of profits
or loss of opportunity) arising
in connection with the Product,
or the supply, condition or
use of the Product, including
as a result of any negligence,
misrepresentation, or other
default on the part of D&D, its
officers, employees, agents or
contractors or otherwise, to the
value paid by the contractor for
the Product giving rise to the
loss, damage or injury.
For any specific questions about
the D&D Technologies Warranty
or to make a warranty claim,
please visit our website at www.
ddtechglobal.com to locate your
nearest D&D Technologies office,
or contact D&D Technologies in:
AUSTRALIA: on 1800 500 203 or
[phone].
Email: [email protected]
NORTH AMERICA: on
[phone] or 714 677 1300.
Email: [email protected]
EUROPE: on [phone].
Email: [email protected]
UNITED KINGDOM: on
[phone].
Email: [email protected]
2. JURISDICTION SPECIFIC
WARRANTY DETAILS:
The warranty details in this
section apply to the jurisdictions
identified below in addition to the
conditions in section 1.
2.1 Australia
In Australia, the Product comes
with guarantees that cannot be
excluded under the Australian
Consumer Law (the ACL). You
are entitled to a replacement or
refund for a major failure and
compensation for any other
reasonably foreseeable loss or
damage. You are also entitled
to have the Product repaired
or replaced if the goods fail to
be of acceptable quality and
failure does not amount to
a major failure. To the extent
permitted under the ACL and
equivalent legislation, D&D’s
liability for failure to comply with
the consumer guarantees under
the ACL (other than sections 51,
52 and 53 of the ACL) in respect
of the supply of Products not
of a kind ordinarily acquired for
personal, domestic or household
use or consumption is limited at
D&D’s option, to:
(a) if the failure relates to
the supply of goods, the
replacement, repair or payment
of the cost of replacement or
repair of the goods; or,
(b) if the failure relates to the
supply of services, the supply
of those services again or the
payment of the cost of having
those services supplied again.
2.2 United Kingdom
In the United Kingdom,
consumers purchasing the
10 WARRANTY - CONT.10 WARRANTY - CONT.
•owners manual ML3 alert_ENGLISH.indd 20 22/10/14 2:43 PM
