Danfoss Optyma op-lphe series User manual

The condensing unit must only be used for

its designed purpose(s) and within its scope of

application.

Under all circumstances, the EN378 (or

other applicable local safety regulation)

requirements must be fullled.

The condensing unit is delivered under nitro-

gen gas pressure (1 bar) and hence it cannot

be connected as it is; refer to the «installation»

section for further details.

The condensing unit must be handled with cau-

tion in the vertical position (maximum oset

from the vertical : 15°)

Installation and servicing of the

condensing units by qualied

personnel only. Follow these instructions

and sound refrigeration engineering practice

relating to installation, commissioning,

maintenance and service.

A: Model

B: Code number

C: Application, Protection

D: Refrigerant

E: Housing Service Pressure

F: Supply voltage, Locked Rotor Ampere,

Maximum Current Consumption

G: Serial Number and bar code

H: Cable entry ports

I: Suction port

J: Liquid port

K: Microchannel heat exchanger

[mm]

250 650 550 550

Picture 1 : Minimum mounting distances

Picture 2

Picture 3

Mounting bolts

1 – Introduction

These instructions pertain to Optyma™ High

Ambient 52 Pack condensing units OP-LPHE/

MPZE (R404A, R134a) used for refrigeration sys-

tems. They provide necessary information regar-

ding safety and proper usage of this product.

The condensing unit includes following:

•Reciprocating compressor

•Microchannel heat exchanger

•Dual pressure switches

•Service valves suction/liquid

•Weather proof housing

•Filter drier

•Receiver with stop valve

•Sight glass

•Solenoid valve

•Oil separator (LBP only)

•Discharge thermostat (LBP Only)

2 – Handling and storage

•It is recommended not to open the packaging

before the unit is at the nal place for installation.

•Handle the unit with care. The packaging al-

lows for the use of a forklift or pallet jack. Use

appropriate and safe lifting equipment.

•Store and transport the unit in an upright position.

•Store the unit between -35°C and 60°C.

•Don’t expose the packaging to rain or corrosive

atmosphere.

•After unpacking, check that the unit is com-

plete and undamaged.

3 – Installation precautions

Do not braze as long the condensing unit is

under pressure.

Never place the unit in a ammable atmosphere

Place the unit in such a way that it is not blocking

or hindering walking areas, doors, windows or similar.

•Ensure adequate space around the unit for air

circulation and to open doors. Refer to picture1

for minimal values of distance to walls.

• Avoid installing the unit in locations which are daily

exposed to direct sunshine for longer periods.

•Avoid installing the unit in aggressive and dus-

ty environments.

•Ensure a foundation with horizontal surface

(less than 3° slope), strong and stable enough

to carry the entire unit weight and to eliminate

vibrations and interference.

•The unit ambient temperature may not exceed

52°C during o-cycle.

•Ensure that the power supply corresponds to

the unit characteristics (see nameplate).

•When installing units for HFC refrigerants, use

equipment specically reserved for HFC refri-

gerants which was never used for CFC or HCFC

refrigerants.

•Use clean and dehydrated refrigeration-grade

copper tubes and silver alloy brazing material.

•Use clean and dehydrated system components.

•The suction piping connected to the compres-

sor must be exible in 3 dimensions to dampen

vibrations. Furthermore piping has to be done

in such a way that oil return for the compres-

sor is ensured and the risk of liquid slug over in

compressor is eliminated.

• For all units factory setting of fan speed

controller to be 15 ±1 bar.

• For refrigerant R134a, adjust the factory pres-

sure setting of XGE-2C (code no: 061H3144)

from 15 ±1 bar to recommended setting 8 bar

by rotating the screw by 9 turns in counter

clockwise direction.

Instructions

Optyma™ High Ambient 52 Pack

OP-LPHE/MPZE

1 | © Danfoss | DCS (CC)| 2017.12 FRCC.PI.056.A2.02

4 – Installation

•The installation in which the condensing unit is ins-

talled must comply to EU Pressure directive (PED)

no. 2014/68/EU. The condensing unit itself is not a

”unit” in the scope this directive. Under all circum-

stances local safety regulations must be fullled.

•The unit must be securely installed on a stable

and rigid support, and xed from the begin-

ning. See picture 2.

•It is recommended to install the unit on rub-

ber grommets or vibration dampers . Rubber

pads with mounting bolts are supplied.

•Slowly release the nitrogen holding charge

through the schrader port.

• Connect the unit to the system as soon as possible

to avoid oil contamination from ambient moisture.

•Avoid material entering into the system while

cutting tubes. Never drill holes where burrs

cannot be removed.

•Braze with great care using state-of-the-art tech-

nique and vent piping with nitrogen gas ow.

•Connect the required safety and control de-

vices. When the schrader port is used for this,

remove the internal valve.

•CU function and reliability is ensured/veried

for super heat 10K (SH 10K) condition so, it is

recommended to insulate the suction pipe up

to the compressor inlet with 19 mm thick insu-

lation.

5 – Leak detection

Never pressurize the circuit with oxygen or

dry air. This could cause re or explosion.

•Do not use dye for leak detection.

•Perform a leak detection test on the complete

system.

•The maximum test pressure is 32 bar.

•When a leak is discovered, repair the leak and

repeat the leak detection.

6 – Vacuum dehydration

•Never use the compressor to evacuate the system.

•Connect a vacuum pump to both the LP & HP

sides.

•Pull down the system under a vacuum of 500

μm Hg (0.67 mbar) absolute.

•Do not use a megohmmeter nor apply power

to the compressor while it is under vacuum as

this may cause internal damage.

7 – Electrical connections

•Switch o and isolate the main power supply.

•Ensure that power supply can not be switched

on during installation.

•All electrical components must be selected as

per local standards and unit requirements.

•Refer to wiring diagram for electrical connec-

tions details.

•Ensure that the power supply corresponds

to the unit characteristics and that the power

supply is stable (nominal voltage ±10% and

nominal frequency ±2,5 Hz).

•Dimension the power supply cables according

to unit data for voltage and current.

•Protect the power supply and ensure correct

earthing.

•Make the power supply according to local stan-

dards and legal requirements.

•

The unit is equipped with high and low pressure

switches, which directly cut the power supply to

the compressor in case of activation.

8 – Filling the system

•Wear protective stu like goggles and protec-

tive gloves.

•Never start the compressor under vacuum.

Keep the compressor switched o.

•Before charging the refrigerant, verify that the

oil level is between ¼ and ¾ on the compressor

oil sight glass. If additional oil is required please

refer to the compressors label for type of oil.

•Use only the refrigerant for which the unit is

designed for.

•Fill the refrigerant in liquid phase into the

condenser or liquid receiver. Ensure a slow

charging of the system to 4 – 5 bar for R404A.

•Do not put liquid refrigerant through suction line.

•It is not allowed to mix additives with the oil

and/or refrigerant

•The remaining charge is done until the instal-

lation has reached a level of stable nominal

condition during operation.

•Never leave the lling cylinder connected to

the circuit.

9 – Verification before commissioning

Use safety devices in compliance with both

generally and locally applicable regulations and

safety standards.

• Verify that all electrical connections are properly

fastened and in compliance with local regulations.

•When a crankcase heater is required, it must be

energized at least 12 hours before initial start-

up and start-up after prolonged shut-down

period.

10 – Start-up

•Never start the unit when no refrigerant is char-

ged.

•All service valves must be in the open position.

See picture 3.

•Check compliance between unit and power

supply.

•Check that the crankcase heater is working.

•Check that the fan can rotate freely.

•Balance the High Pressure / Low Pressure.

•Energize the unit. It must start promptly. If

the compressor does not start, check wiring

conformity, voltage on terminals and sequence

phase.

11 – Check with running unit

•Check the fan rotation direction. Air must ow

from the condenser towards the fan.

•Check current draw and voltage.

•Check suction superheat to reduce risk of slug-

ging.

•When a sight glass is provided observe the oil

level at start and during operation to conrm

that the oil level remains visible.

•Respect the operating limits.

•Check all tubes for abnormal vibration. Move-

ments in excess of 1.5 mm require corrective

measures such as tube brackets.

•When needed, additional refrigerant in liquid

phase may be added in the low-pressure side as

far away as possible from the compressor. The

compressor must be operating during this pro-

cess.

•Do not overcharge the system.

•Never release refrigerant to atmosphere.

•Before leaving the installation site, carry out

a general installation inspection regarding

cleanliness, noise and leak detection.

•Record type and amount of refrigerant charge

as well as operating conditions as a reference

for future inspections.

12 – Maintenance

Always switch o the unit at main switch

before remove fan panel.

Internal pressure and surface temperature

are dangerous and may cause permanent injury.

Maintenance operators and installers require

appropriate skills and tools. Tubing temperature

may exceed 100°C and can cause severe burns.

Ensure that periodic service inspections to

ensure system reliability and as required by local

regulations are performed.

This appliance is not intended for use by per-

sons (including children) with reduced physical,

sensory or mental capabilities, or lack of expe-

rience and knowledge, unless they have been gi-

ven supervision or instruction concerning use of

the appliance by a person responsible for their

safety. Children should be supervised to ensure

that they do not play with the appliance

To prevent system related problems, following

Periodic maintenance is recommended:

•Verify that safety devices are operational and

properly set.

•Ensure that the system is leak tight.

•Check the compressor current draw.

•Conrm that the system is operating in a way

consistent with previous maintenance records

and ambient conditions.

•Check that all electrical connections are still

adequately fastened.

•Keep the unit clean and verify the absence of

rust and oxidation on the unit components,

tubes and electrical connections.

The condenser must be checked at least once

a year for clogging and be cleaned if deemed

necessary. Access to the internal side of the

condenser takes place through the fan panel.

Microchannel coils tend to accumulate dirt on

the surface rather than inside, which makes

them easier to clean than n-&-tube coils.

•Switch o the unit at main switch before re-

move any panel from the condensing unit.

•Remove surface dirt, leaves, bres, etc. with

a vacuum cleaner, equipped with a brush or

other soft attachment. Alternatively, blow com-

pressed air through the coil from the inside out,

and brush with a soft bristle. Do not use a wire

brush. Do not impact or scrape the coil with the

vacuum tube or air nozzle.

If the refrigerant system has been opened, the

system has to be ushed with dry air or nitrogen

to remove moisture and a new lter drier has to

be installed. If evacuation of refrigerant has to be

done, it shall be done in such a way that no refri-

gerant can escape to the environment.

13 - Warranty

Always transmit the model number and serial num-

ber with any claim led regarding this product.

The product warranty may be void in following

cases:

•Absence of nameplate.

•External modications; in particular, drilling,

welding, broken feet and shock marks.

•Compressor opened or returned unsealed.

•Rust, water or leak detection dye inside the

compressor.

•Use of a refrigerant or lubricant not approved

by Danfoss.

•Any deviation from recommended instructions

pertaining to installation, application or main-

tenance.

•Use in mobile applications.

•Use in explosive atmospheric environment.

•No model number or serial number transmit-

ted with the warranty claim.

14 – Disposal

Danfoss recommends that condensing

units and oil should be recycled by a

suitable company at its site.

Instructions

2 | © Danfoss | DCS (CC) | 2017.12 FRCC.PI.056.A2.02

2SW\PD+LJK$PELHQW3DFN

114X7142LBP

LBP

MBP

APP UNIT DESCRIPTION CHASSIS POWER SUPPLYCOMP

114X7154

114X7152

114X7121

114X7143

114X7126

114X7158

114X7147

114X7148

114X7159

NTZ108

NTZ136

MTZ036

MTZ040

OP-LPHE108NTW07Q

OP-LPHE108NTW07V

OP-LPHE108NTW07N

OP-LPHE136NTW07V

OP-LPHE136NTW07Q

OP-MPZE060MTW07V

OP-MPZE060MTW07Q

OP-MPZE060MTW07N

OP-MPZE068MTW07N

OP-MPZE068MTW07Q

230V/3/~60Hz

380V/3N/~60Hz

230V/1N/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

230V/1N/~60Hz

230V/3/~60Hz

MBP

114X7118

114X7149

114X7160

MTZ050

OP-MPZE086MTW07V

OP-MPZE086MTW07N

OP-MPZE086MTW07Q

380V/3N/~60Hz

230V/1N/~60Hz

230V/3/~60Hz

OP-MPZE060 - 068 - 086, OP-LPHE108-136

2SW\PD+LJK$PELHQW3DFN

114X7140LBP

LBP

MBP

APP UNIT DESCRIPTION CHASSIS POWER SUPPLYCOMP

114X7150

114X7153

114X7120

114X7141

114X7151

114X7146

114X7156

114X7117

114X7123

114X7157

NTZ048

NTZ068

MTZ018

MTZ028

OP-LPHE048NTW07Q

OP-LPHE048NTW07N

OP-LPHE048NTW07V

OP-LPHE068NTW07V

OP-LPHE068NTW07Q

OP-LPHE068NTW07N

OP-MPZE030MTW07N

OP-MPZE030MTW07Q

OP-MPZE048MTW07V

OP-MPZE048MTW07N

OP-MPZE048MTW07Q

230V/3/~60Hz

230V/1N/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

230V/1N/~60Hz

230V/3/~60Hz

380V/3N/~60Hz

230V/1N/~60Hz

230V/3/~60Hz

OP-MPZE030 - 048, OP-LPHE048 - 068

Instructions

FRCC.PI.056.A2.02

2SW\PD+LJK$PELHQW3DFN

114X7144LBP

LBP

MBP

APP UNITDESCRIPTION CHASSIS POWER SUPPLYCOMP

114X7155

114X7122

114X7145

114X7124

114X7127

114X7137

114X7128

114X7138

114X7119

114X7139

NTZ215

NTZ271

MTZ064

MTZ072

MTZ100

OP-LPHE215NTW07Q

OP-LPHE215NTW07V

OP-LPHE271NTW07V

OP-LPHE271NTW07Q

OP-MPZE108MTW07N

OP-MPZE108MTW07V

OP-MPZE108MTW07Q

OP-MPZE0121MTW07V

OP-MPZE121MTW07Q

OP-MPZE171MTW07V

OP-MPZE171MTW07Q

230V/3/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

230V/1N/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

380V/3N/~60Hz

230V/3/~60Hz

OP-MPZE108 - 121 - 171, OP-LPHE215 - 271

Instructions

4 | © Danfoss | DCS (CC) | 2017.12 FRCC.PI.056.A2.02

8510198 P03-A © Danfoss Commercial Compressors 03/05

Manual test

Convertible reset

KP 15 060-1154, 060-1220, 060-1261, 060-1263, 060-1 283

LP-man. LP-auto. LP-auto.LP-man.

HP-man. HP-man. HP-auto.HP-auto.

PHteser.nam,PLteser.tua,PL

AC1 16 ADC 11

LR 112A AC316 A400 V 12 W

AC11 10 A220 V

When used acc. to UL regulations

-1 bar (Pe)(30in.Hg)

Convertible reset

KP 15, 15A, 17W, 17B

KP 17B 060-539366, 060-539466

LP-auto. LP-auto.

HP-man.HP-auto.

Instructions

FRCC.PI.056.A2.02

Code N: OP-MPZE030 - 048, OP-LPHE048 - 068

Code N: OP-MPZE060 - 068 - 086, OP-LPHE108 - 136

A1 Power Supply Monitoring Relay

B1 Fan Speed Controller

B2 Dual Pressure Switch

C1 Start Capacitor- Compressor

C2 Run Capacitor-Compressor

C3,C4 Run capacitor-Fan

E1 Crankcase Heater

F1 Main Switch

F2 Overload Relay

F3,F4 Fuse Control Circuit

F5 Discharge Thermostat (LBP only)

M1 Compressor

M2,M3 Fan Motor

K1 Compressor contactor

K2 Start Relay

R1,R2 Bleeder Resistor

S1 Door Limit Switch

Legend

BK black

BU blue

BN brown

GY grey

RD red

WH white

Instructions

Code N: OP-MPZE108

Code V: OP-MPZE048, OP-LPHE048 - 068

A1 Power Supply Monitoring Relay

B1 Fan Speed Controller

B2 Dual Pressure Switch

C1 Start Capacitor- Compressor

C2 Run Capacitor-Compressor

C3,C4 Run capacitor-Fan

E1 Crankcase Heater

F1 Main Switch

F2 Overload Relay

F3,F4 Fuse Control Circuit

F5 Discharge Thermostat (LBP only)

M1 Compressor

M2,M3 Fan Motor

K1 Compressor contactor

K2 Start Relay

R1,R2 Bleeder Resistor

S1 Door Limit Switch

Legend

BK black

BU blue

BN brown

GY grey

RD red

WH white

Instructions

FRCC.PI.056.A2.02

Code V: OP-MPZE060 - 086, OP-LPHE108 - 136

Code V: OP-MPZE108 - 121 - 171, OP-LPHE215 - 271

A1 Power Supply Monitoring Relay

B1 Fan Speed Controller

B2 Dual Pressure Switch

C1 Start Capacitor- Compressor

C2 Run Capacitor-Compressor

C3,C4 Run capacitor-Fan

E1 Crankcase Heater

F1 Main Switch

F2 Overload Relay

F3,F4 Fuse Control Circuit

F5 Discharge Thermostat (LBP only)

M1 Compressor

M2,M3 Fan Motor

K1 Compressor contactor

K2 Start Relay

R1,R2 Bleeder Resistor

S1 Door Limit Switch

Legend

BK black

BU blue

BN brown

GY grey

RD red

WH white

Instructions

Code Q: OP-MPZE030 - 048, OP-LPHE048 - 068

Code Q: OP-MPZE060 - 068 - 086, OP-LPHE108 - 136

A1 Power Supply Monitoring Relay

B1 Fan Speed Controller

B2 Dual Pressure Switch

C1 Start Capacitor- Compressor

C2 Run Capacitor-Compressor

C3,C4 Run capacitor-Fan

E1 Crankcase Heater

F1 Main Switch

F2 Overload Relay

F3,F4 Fuse Control Circuit

F5 Discharge Thermostat (LBP only)

M1 Compressor

M2,M3 Fan Motor

K1 Compressor contactor

K2 Start Relay

R1,R2 Bleeder Resistor

S1 Door Limit Switch

Legend

BK black

BU blue

BN brown

GY grey

RD red

WH white

Instructions

FRCC.PI.056.A2.02

Code Q: OP-MPZE108 - 121 - 171, OP-LPHE215 - 271

Danfoss A/S

6430 Nordborg

Denmark

A1 Power Supply Monitoring Relay

B1 Fan Speed Controller

B2 Dual Pressure Switch

C1 Start Capacitor- Compressor

C2 Run Capacitor-Compressor

C3,C4 Run capacitor-Fan

E1 Crankcase Heater

F1 Main Switch

F2 Overload Relay

F3,F4 Fuse Control Circuit

F5 Discharge Thermostat (LBP only)

M1 Compressor

M2,M3 Fan Motor

K1 Compressor contactor

K2 Start Relay

R1,R2 Bleeder Resistor

S1 Door Limit Switch

Legend

BK black

BU blue

BN brown

GY grey

RD red

WH white

Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This

also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specications already agreed. All trade-
