A319.1, ex. a:
© Danfoss | 2018.12
VI.JM.I4.00 | 1
ECL Comfort 310, A319
(code no. 087H3831, 087H3847)
Installation Guide

A319.2, ex. a:
ECL 310, 230 V a.c.:
3-point:
M1 M2
A319.1 ü
A319.2 ü ü
230 V a.c., A319.1 / A319.2:
Installation Guide, ECL Comfort 310, A319
2 | © Danfoss | 2018.12
VI.JM.I4.00

ECA 32, 0 - 10 V out
ECA 35, PWM out
Installation Guide, ECL Comfort 310, A319
© Danfoss | 2018.12 | 3
VI.JM.I4.00

230 V a.c. / 24 V a.c., safety thermostat
1-step closing
Danfoss 87H2105.10
ECL 210 / 310
M1
Danfoss 87H2106.10
ECL 210 / 310
M2
Danfoss 87H2107.10
ECL 210 / 310
M1
ECL 210 / 310
Danfoss 87H2108.10
M2
Installation Guide, ECL Comfort 310, A319
4 | © Danfoss | 2018.12
VI.JM.I4.00

230 V a.c. / 24 V a.c., safety thermostat
2-step closing
ECL 210 / 310
Danfoss 87H2109.10
M1
ECL 210 / 310
Danfoss 87H2110.10
M2
Installation Guide, ECL Comfort 310, A319
© Danfoss | 2018.12 | 5
VI.JM.I4.00

ECL 310, 24 V a.c.:
3-point:
M1 M2
A319.1 ü
A319.2 ü ü
24 V a.c., A319.1 / A319.2
Installation Guide, ECL Comfort 310, A319
6 | © Danfoss | 2018.12
VI.JM.I4.00

Pt 1000 (1000 Ω / 0 °C)
87H1487.11 Danfoss
30
32
31
29
28 S2
S1
B
+
ECL 485
ECL Comfort 210 / 296 / 310
PE
N
L
230 V a.c.
S2 S1
30
32
31
29
28 S2
S1
B
+
ECL 485
ECL Comfort 210 / 296 / 310
PE
N
L
230 V a.c.
S2 S1
Input S1 - S6 and S8
S9 (0 - 10 V)
S10 (0 - 10 V)
Danfoss 87H2059.10
ECL 310
Installation Guide, ECL Comfort 310, A319
© Danfoss | 2018.12 | 7
VI.JM.I4.00

ECA 30 / 31
ECA 30 / 31
Installation Guide, ECL Comfort 310, A319
8 | © Danfoss | 2018.12
VI.JM.I4.00

Master / slave
Danfoss 87H2052.11
A
A
B
B
A
A
B
B
Modbus
ECL 210 / 296 / 310
Danfoss 87H2060.11
A
A
B
B
M-bus
ECL 296 / 310
Danfoss 87H2061.11
A
A
B
B
M-bus
30
87H1308.11 Danfoss
36
35
34
33
32
31
29 S1
S.Gnd
A
B
A
B
+
ECL 296 / 310
38
37
M-bus
METERMETER
Installation Guide, ECL Comfort 310, A319
© Danfoss | 2018.12 | 9
VI.JM.I4.00

Pt 1000 (IEC 751B, 1000 Ω / 0 °C)
-50
800
900
1000
1100
1200
1300
1400
1500
1600
-25 0255075 100 125 150
°C
Ω
Ω
803
843
882
922
961
1000
1039
1078
1117
1155
1194
1232
1271
1309
1347
1385
1423
1461
1498
1535
1573
°C
-50
-40
-30
-20
-10
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
120
110
100
90
80
70
60
50
40
30
20
10
-30 -20 -10 0 10 20
2.2 2.6 3.0 3.41.8
1.4
1.0
0.6
0.2
Installation Guide, ECL Comfort 310, A319
10 | © Danfoss | 2018.12
VI.JM.I4.00

ECA 30
 
 
 
 
Installation Guide, ECL Comfort 310, A319
© Danfoss | 2018.12 | 11
VI.JM.I4.00

12 | © Danfoss | DHS-SMT/DK | 2018.12
VI.JM.I4.00
