MCI 50-3 I-O
Monta - Mounting - Montage
Jeżeli urządzenie jest zamontowane poziomo, to prąd
znamionowy musi zostać obniżony o 50%
If unit is mounted horizontally derate current by 50%
Falls Einheit horizontal montiert wird, reduziert sich der Strom
um 50%.
Wymiary - Dimensions - Abmessungen
Radiator należy utrzymywać w czystości oraz
nie należy zakłócać przepływu powietrza chłodzącego
ow should not be blocked
ießen
Podłączenie - Wiring - Verdrahtung
Nie przekraczać maksymalnego momentu obrotowego
Observe the maximum screw torque limits
Max. Drehmoment beachten
Na wyjściu softstartu nie wolno instalować baterii kondensatorów do kompensacji mocy biernej.
Do not mount powerfactor capacitors at the output side of the soft starter.
Am Ausgang der Sanftstarter dürfen keine Kondensatoren zur Kompensation der
Blindleistung verwendet werden.
©Danfoss A/S 03-2006 (IC-MC/mr) IC.PI.C50.D1.49 - 520B2566
5103C740
5
10
3C7
40
Instrukcja
75°C
Kabel/ Wire mm2(AWG) mm2(AWG)
4 - 35
(12 - 2)
0.5 - 4
(20 -12)
2 x 4 - 16
(2 x12 - 6)
2 x 0.5 - 0.75
(2 x 20 - 18)
4 - 35
(12 - 2)
0.5 - 4
(20 - 12)
2 x 4 - 10
(2 x 12 - 8)
2 x 0.5 - 2.5
(2 x 20 - 14)
4 - 16
(12 - 6)
25 - 50
(4 - 1)
0.5 - 6
(20 - 10)
2 x 4 - 16
(2 x12 - 6)
2 x 0.5 - 4
(2 x 20 - 12)
Pozidrive 3
4.0 Nm max.
35 lb-in max.
Pozidrive 3
5.5 Nm max.
49 lb-in max.
Pozidrive 1
0.6 Nm max.
5.3 lb-in max.
4 mm
0.6 Nm max.
5.3 lb-in max. W przypadku zabezpieczenia bezpiecznikiem i przekaźnikiem
termicznym sprawdź zalecenia w karcie katalogowej
If protection with fuses, see recommendations in data sheet
Falls Sicherungen verwendet werden, Empfehlungen im Datenblatt
beachten
Prąd In
A
Danfoss
CTI 45MB
23 - 32 047B3164
32 - 45 047B3165
Danfoss
CTI 100
40 - 63 047B3014
047C3015
047C3015
Nastawy - Settings - Einstellungen
UP
UP
Down
Initial
torque
Down
Kick-
start
Instrukcja
IC.PI.C50.D1.51-2566 ©Danfoss A/S 03-2006 IC-MC, mr
Uwagi - Remarks - Bemerkungen
NB!
Polski English Deutsch
tUżywać śrubokręta 2 mm x 0.5 mm.
tPokrętła nastaw nie powiny znajdować
się w położeniu pomiędzy nastawami.
tPowtarzalne rozruchy mogą wyzwolić
zabezpieczenie silnika.
tUse 2 mm x 0.5 mm screwdriver.
tMake sure that the switches click
into position, otherwise time and
torque settings will not be correct.
tThe motor controller will read time
and torque settings in the off state.
tSchraubenzieher 2 mm x 0.5 mm
verwenden.
tSchalter müssen einrasten, um
korrekte Funktion zu gewährleisten.
tEingestellte Werte werden im aus-
geschalteten Zustand abgelesen.
Ustawianie momentu rozruchowego - Initial torque setting - Einstellung der Startleistung
1. Ustawić Ramp-up (czas rozbiegu)
na maks.
2. Ustwić Ramp-down (czas wybiegu)
na min.
3. Ustawić Initial Torque (moment
rozruchowy) na min.
4. Zadać sygnał sterujący. Jeżeli nie
nastąpi natychmiastowy rozruch, to należy
zwiększyć moment rozruchowy o jeden
krok i spróbować ponownie. Powtarzać do
chwili uzyskania płynnego rozruchu.
1. Set Ramp-up switch to max.
2. Set Ramp-down switch to min.
3. Set Initial torque switch to min.
4. Apply control signal for a few seconds.
If the load does not rotate immediately
increase the Initial torque for one step
and try again. Repeat until the load
starts to rotate immediately on start up.
1. Ramp-up Schalter auf max. stellen
2. Ramp-down Schalter auf min. stellen
3. Initial torque Schalter auf min. stellen
4. Steuersignal einige Sekunden betäti-
gen. Falls der Motor nicht sofort an-
läuft Initital torque schrittweise erhö-
hen, bis der Motor anläuft.
Jeżeli nastawienie maks. momentu
rozruchowego nie wystarcza do
uruchomienia silnika, należy wykorzystać
funkcję Kick-start, aby doprowadzić do
zerwania tarcia statycznego.
1. Ustawić Ramp-up na maks.
2. Ustawić Ramp-down na min.
3. Ustawić Kick-start. na min.
4. Zadać sygnał sterujący. Jeżeli po
początkowym rozruchu silnik się zatrzyma,
należy zwiększyć wartość Kick-start.
Powtarzać do chwili, aż silnik będzie
pracował po ustaniu funkcji Kick-start.
If the maximum Initial torque setting
is not sufficient to start the motor, it
is necessary to use Kick-start
1. Set Ramp-up switch to max.
2. Set Ramp-down switch to min.
3. Set Initial torque switch to min. kick
start torque.
4. Apply control signal for a few seconds.
If the load stops right after the kick
start increase the Initial torque for one
step and try again. Repeat until the load
continues to rotate afte the "kick".
Falls Initial torque max. Einstellung
nicht ausreicht um den Motor zu starten,
muß Kick-start verwendet werden.
1. Ramp-up Schalter auf max. stellen
2. Ramp-down Schalter auf min. stellen
3. Initial torque Schalter auf min. Kick-
start stellen.
4. Steuersignal einige Sekunden betäti-
gen. Falls der Motor sofort wieder
stoppt, Initial torque schrittweise er-
höhen, bis der Motor sofort nach dem
"Kick" anläuft.
Ustawianie czasu rozbiegu - Ramp up settings - Einstellung der Startanstiegszeit
1. Ustawić pokrętło Ramp-up na maks.
i uruchomić silnik.
2. Zmniejszać czas rozbiegu Ramp-up,
aż do wystąpienia mechanicznego
szarpnięcia.
3. Zwiększyć czas rozbiegu o jeden stopień.
1. Set Ramp-up switch to max. and start
motor.
2. Decrease the Ramp-up time until
mechanical surge is observed.
3. Increase Ramp-up time one step.
1. Ramp-up Schalter auf max. stellen.
2. Ramp-up Zeit solange verkürzen bis
Überbelastung beobachtet wird.
3. Ramp-up Zeit um einen Schritt erhö-
hen.
Ustawianie czasu wybiegu - Ramp down settings - Einstellung der Startanstiegszeit
1. Ustawić Ramp-down na maks.
iodłączyć napięcie sterujące.
2. Zmniejszyć czas wybiegu Ramp-down
do chwili zauważenia szarpnięcia
przy zatrzymaniu silnika.
3. Zwiększyć czas wybiegu o jeden stopień.
1. Set Ramp-down switch to max.
and switch off the control voltage.
2. Decrease the Ramp-down time
until mechanical surge is observed.
3. Increase Ramp-up time one step.
1. Ramp-down Schalter auf max. stel-
en und Steuersignal ausschalten.
2. Ramp-down Zeit solange verkürzen
bis Überbelastung beobachtet wird.
3. Ramp-down Zeit um einen Schritt
erhöhen.
