Danfoss VLT CDS 803 User manual

MAKING MODERN LIVING POSSIBLE
Quick Guide
VLT®Compressor Drive CDS 803
vlt-drives.danfoss.com

Contents
1 Quick Guide 2
1.1 Safety 2
1.1.1 Warnings 2
1.1.2 Safety Instructions 2
1.2 Introduction 2
1.2.1 Available Literature 2
1.2.2 Approvals 3
1.2.3 IT Mains 3
1.2.4 Avoid Unintended Start 3
1.3 Installation 3
1.3.1 Before Starting Repair Work 3
1.3.2 Enclosure Types 3
1.3.3 Side-by-side Installation 4
1.3.4 Electrical Installation in General 5
1.3.5 Connecting to Mains and Compressor 5
1.3.6 Fuses 7
1.3.7 EMC-Correct Electrical Installation 8
1.3.8 Control Terminals 9
1.3.9 Electrical Overview 10
1.4 Programming 11
1.4.1 Local Control Panel (LCP) 11
1.4.2 Main Menu Structure 20
1.5 Acoustic Noise or Vibration 22
1.6 Warnings and Alarms 22
1.7 General Specications 23
1.7.1 Mains Supply 3x200–240 V AC 23
1.7.2 Mains Supply 3x380–480 V AC 24
1.7.3 EMC Test Results 25
1.8 Special Conditions 28
1.8.1 Derating for Ambient Temperature and Switching Frequency 28
1.9 Options for VLT®Compressor Drive CDS 803 28
Contents Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 1

1 Quick Guide
1.1 Safety
1.1.1 Warnings
WARNING
HIGH-VOLTAGE WARNING
The voltage of the frequency converter is dangerous
whenever it is connected to mains. Incorrect installation
of the compressor or frequency converter may cause
death, serious injury, or equipment damage. To avoid
death, serious injury, or equipment damage:
•Comply with the instruction in this manual as
well as local and national rules and safety
regulations.
WARNING
DISCHARGE TIME!
Frequency converters contain DC-link capacitors that can
remain charged even when the frequency converter is
not powered. To avoid electrical hazards, disconnect AC
mains, any permanent magnet type compressors, and
any remote DC-link power supplies, including battery
back-ups, UPS, and DC-link connections to other
frequency converters. Wait for the capacitors to fully
discharge before performing any service or repair work.
The waiting time is listed in Table 1.1. Failure to wait the
specied time after power has been removed before
doing service or repair could result in death or serious
injury.
Voltage [V] Cooling capacity [TR] Minimum waiting time
(minutes)
3x200 4–6.5 15
3x400 4–5 4
3x400 6.5 15
Table 1.1 Discharge Time
CAUTION
Leakage Current
The ground leakage current from the frequency
converter exceeds 3.5 mA. According to IEC 61800-5-1 a
reinforced protective earth connection must be ensured
with a minimum 10 mm2Cu or an extra PE wire with the
same cable cross-section as the mains wiring. Terminate
the PE connection separately.
Residual Current Device
This product can cause a DC current in the protective
conductor. Where a residual current device (RCD) is used
for extra protection, only an RCD of Type B (time
delayed) shall be used on the supply side of this
product. See also Danfoss Application Note on RCD.
Protective earthing of the frequency converter and the
use of RCDs must always follow national and local
regulations.
NOTICE
INSTALLATION AT HIGH ALTITUDES
For altitudes above 2000 m, contact Danfoss regarding
PELV.
1.1.2 Safety Instructions
•Make sure that the frequency converter is
properly connected to ground.
•Do not remove mains connections, compressor
connections, or other power connections while
the frequency converter is connected to power.
•Protect users against supply voltage.
•Protect the compressor against overloading
according to national and local regulations.
•The ground leakage current exceeds 3.5 mA.
•The [O/Reset] key is not a safety switch. It does
not disconnect the frequency converter from
mains.
1.2 Introduction
1.2.1 Available Literature
This quick guide contains basic information necessary for
installing and running the frequency converter. Supple-
mentary publications and manuals are available from
Danfoss. See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/ Documentations/VLT+Technical+Documentation.htm
for listings.
Quick Guide VLT®Compressor Drive CDS 803
2 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

1.2.2 Approvals
Certication IP20
EC Declaration of
Conformity ✓
UL Listed ✓
C-tick ✓
Table 1.2 Approvals
The frequency converter complies with UL 508C thermal
memory retention requirements. For more information,
refer to the section Motor Thermal Protection in the
product-specic design guide.
1.2.3 IT Mains
CAUTION
IT MAINS
Installation on isolated mains source, that is, IT mains.
Maximum supply voltage allowed when connected to
mains: 440 V (3x380–480 V units).
Open the RFI switch by removing the screw on the side of
the frequency converter when at IT grid.
130BB612.10
1
1 RFI switch
Illustration 1.1 IP20
CAUTION
If reinserted, only use M3x12 screw.
1.2.4 Avoid Unintended Start
While the frequency converter is connected to mains, the
compressor can be started/stopped using digital
commands, bus commands, references or via the LCP.
•Disconnect the frequency converter from mains
whenever personal safety considerations make it
necessary to avoid unintended start of any
compressors.
•To avoid unintended start, always press [O/
Reset] before changing parameters.
Equipment containing electrical components
must not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
1.3 Installation
1.3.1 Before Starting Repair Work
1. Disconnect from mains (and external DC supply, if
present).
2. Wait as stated in Table 1.1 for discharge of the
DC-link.
3. Remove the compressor cable.
1.3.2 Enclosure Types
Cooling capacity 400 V IP20 enclosure
4 TR/VZH028 H3
5 TR/VZH035 H3
6.5 TR/VZH044 H4
Table 1.3 H3–H4, 400 V
Cooling capacity 200 V IP20 enclosure
4 TR/VZH028 H4
5 TR/VZH035 H4
6.5 TR/VZH044 H5
Table 1.4 H4–H5, 200 V
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 3
11

1.3.3 Side-by-side Installation
The frequency converter can be mounted side-by-side and requires the clearance above and below for cooling.
Enclosure IP class Clearance above/below [mm/(in)]
H3 IP20 100/(4)
H4 IP20 100/(4)
H5 IP20 100/(4)
Table 1.5 Clearance
NOTICE
With IP21/NEMA Type1 option kit mounted, a distance of 50 mm (2 in) between the units is required.
NOTICE
The illustration in Table 1.6 is with LCP, but all dimensions are the same without LCP.
A
a
b
B
C
D
130BB614.10
e
f
a
e
130BC246.10
Enclosure Height [mm/(in)] Width [mm/(in)] Depth
[mm/
(in)]
Mounting hole [mm/(in)] Maximum
weight
Enclosure IP class A A1) a B b C d e f [kg/(lb)]
H3 IP20 255
(10.0)
329
(13.0)
240
(9.4)
100
(3.9)
74
(2.9)
206
(8.1)
11
(0.4)
5.5
(0.2)
8.1
(0.3)
4.5
(9.9)
H4 IP20 296
(11.7)
359
(14.1)
275
(10.8)
135
(5.3)
105
(4.1)
241
(9.5)
12.6
(0.5)
7
(0.3)
8.4
(0.3)
7.9
(17.4)
H5 IP20 334
(13.1)
402
(15.8)
314
(12.4)
150
(5.9)
120
(4.7)
255
(10.0)
12.6
(0.5)
7
(0.3)
8.5
(0.3)
9.5
(20.9)
Table 1.6 Dimensions
1) Including decoupling plate
The dimensions are only for the physical units, but when installing in an application, it is necessary to add space for free air
passage both above and below the units. The amount of space for free air passage is listed in Table 1.5.
Quick Guide VLT®Compressor Drive CDS 803
4 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

1.3.4 Electrical Installation in General
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper
conductors required, (75 °C/167 °F) recommended.
Enclosure Torque [Nm(in-lb)]
Enclosure IP class Line Compressor
connection
DC connection Control
terminals
Ground Relay
H3 IP20 1.4 (12.4) 0.8 (7.1) 0.8 (7.1) 0.5 (4.4) 0.8 (7.1) 0.5 (4.4)
H4 IP20 1.2 (10.6) 1.2 (10.6) 1.2 (10.6) 0.5 (4.4) 0.8 (7.1) 0.5 (4.4)
H5 IP20 1.2 (10.6) 1.2 (10.6) 1.2 (10.6) 0.5 (4.4) 0.8 (7.1) 0.5 (4.4)
Table 1.7 Enclosure H3–H5
1.3.5 Connecting to Mains and Compressor
The frequency converter is designed to operate Danfoss
VZH Compressors. For maximum cross-section on wires, see
chapter 1.7 General Specications.
•To comply with EMC emission specications, use
a shielded/armored compressor cable and
connect this cable to both the decoupling plate
and the compressor metal.
•Keep compressor cable as short as possible to
reduce the noise level and leakage currents.
•For further details on mounting of the decoupling
plate, see VLT
®
Compressor Drive CDS 803
Decoupling Plate Installation Instructions.
•Also see EMC-Correct Installation in the VLT
®
Compressor Drive CDS 803 Design Guide.
1. Mount the ground wires to ground terminal.
2. Connect compressor to terminals U, V, and W, see
Table 1.8.
U T1
V T2
W T3
Table 1.8 Connection of Compressor to Terminals
3. Mount mains supply to terminals L1, L2, and L3
and tighten.
130BB634.10
1
2
2
3
4
Motor
UVW-DC+DC
MAINS
1 Line
2 Ground
3 Compressor
4 Relays
Illustration 1.2 H3–H5 Enclosure
IP20 200–240 V 4–6.5 tons
IP20 380–480 V 4–6.5 tons
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 5
11

-DC+DC
BR- BR+ U V W
99
M A I N S
95
RELAY 1 RELAY 2
- LC +
130BA261.10
Illustration 1.3 Mount the 2 screws in the mounting plate,
slide it into place and tighten fully.
MOTOR
MOTOR
U V W
99
130BT302.12
Illustration 1.4 H3–H5 Enclosure
130BA262.10
M
I N S
+DC
BR- BR+ UVW
RELAY 1 RELAY 2
95
Illustration 1.5 When mounting cables, rst mount and tighten
the ground cable.
130BA263.10
95
MAINS
+DC
BR- BR+ UVW
91 92 93
L1 L2 L3
RELAY 1 RELAY 2
Illustration 1.6 Mount mains plug and tighten wires.
Quick Guide VLT®Compressor Drive CDS 803
6 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

+DC
BR- BR+ UVW
MAINS
L1 L2 L3
91 92 93
RELAY 1 RELAY 2
99
- LC -
130BA264.10
Illustration 1.7 Tighten support bracket on mains wires.
1.3.6 Fuses
Branch circuit protection
To protect the installation against electrical and re hazard, all branch circuits in an installation, switch gear, machines, and
so on, must be short circuit and overcurrent protected according to national and local regulations.
Short-circuit protection
Danfoss recommends using the fuses listed in Table 1.9 to protect service personnel or equipment if there is an internal
failure in the unit or a short circuit on the DC-link. The frequency converter provides full short-circuit protection if there is a
short circuit on the compressor.
Overcurrent protection
To avoid overheating of the cables in the installation, provide overload protection. Overcurrent protection must always be
carried out according to local and national regulations. Design circuit breakers and fuses for protection in a circuit capable
of supplying a maximum of 100000 Arms (symmetrical), 480 V maximum.
UL/Non UL compliance
To ensure compliance with UL or IEC 61800-5-1, use the fuses listed in Table 1.9.
NOTICE
In the event of malfunction, failure to follow the protection recommendation may result in damage to the frequency
converter.
Fuse
UL Non-UL
CDS 803 Bussmann
Type RK5
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Maximum fuse
Type G
3x200–240 V IP20
4 TR/VZH028 FRS-R-50 KTN-R50 JKS-50 JJN-50 50
5 TR/VZH035 FRS-R-50 KTN-R50 JKS-50 JJN-50 50
6.5 TR/VZH044 FRS-R-80 KTN-R80 JKS-80 JJN-80 65
3x380–480 V IP20
4 TR/VZH028 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
5 TR/VZH035 FRS-R-25 KTS-R25 JKS-25 JJS-25 25
6.5 TR/VZH044 FRS-R-50 KTS-R50 JKS-50 JJS-50 50
Table 1.9 Fuses
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 7
11

1.3.7 EMC-Correct Electrical Installation
General points to be observed to ensure EMC-correct electrical installation.
•Use only screened/armoured motor cables and screened/armoured control cables.
•Connect the screen to ground at both ends.
•Avoid installation with twisted screen ends (pigtails), since this ruins the screening eect at high frequencies. Use
the cable clamps provided instead.
•Ensure the same potential between frequency converter and ground potential of the PLC.
•Use star washers and galvanically conductive installation plates.
B
a
c
k
OK
Com.
On
Warn.
Alarm
Hand
On Reset Auto
On
Menu Status Quick
Menu Main
Menu
L1
L2
L3
PE
Minimum 16 mm2
equalizing cable
Control cables
All cable entries in
one side of panel
Earthing rail
Cable insula-
tion stripped
Output con-
tactor
Motor cable
Motor, 3 phases and
PLC Panel
Mains-supply
Minimum 200 mm
between control
cable, mains cable
and between mains
motor cable
PLC
protective earth
Reinforced protective earth
130BB761.11
Illustration 1.8 EMC-correct Electrical Installation
Quick Guide VLT®Compressor Drive CDS 803
8 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

1.3.8 Control Terminals
130BB622.10
Illustration 1.9 Location of Control Terminals
1. To activate the snap, place a screwdriver behind
the terminal cover.
2. Tilt the screwdriver outwards to open the cover.
Control terminals
To make the compressor run:
1. Apply start signal on terminal 18.
2. Connect terminals 12, 27, and terminal 53, 54, or
55.
130BB625.11
12 20 55
20 27 29 42 45 55
50 53 54
GND GND DIGI IN/OUT DIGI IN/OUT
61 68 69
N P COMM. GND
+24 V
DIGI IN DIGI IN
10 V/20 mA IN 10 V/20 mA IN
0/4-20m A A OUT/DIG OUT 0/4-20 mA A OUT/DIG OUT
10 V OUT
BUS TER.
OFF ON
Illustration 1.10 Control Terminals
Set the functions of digital input 18, 19, and 27 in
parameter 5-00 Digital Input Mode (PNP is default value).
Set the function of digital input 29 in
parameter 5-03 Digital Input 29 Mode (PNP is default value).
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 9
11

1.3.9 Electrical Overview
L1
L2
L3
3 Phase
power
input
PE PE
+10 V DC
0-10 V DC-
0-10 V DC-
50 (+10 V OUT)
54 (A IN)
53 (A IN)
55 (COM A IN/OUT)
0/4-20 mA
0/4-20 mA
42 0/4-20 mA A OUT / DIG OUT
45 0/4-20 mA A OUT / DIG OUT
18 (DIGI IN)
19 (DIGI IN)
27 (DIGI IN)
29 (DIGI IN)
12 (+24 V OUT)
24 V (NPN)
20 (COM D IN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
Bus ter.
Bus ter.
RS485
Interface RS485
(N RS485) 69
(P RS485) 68
(Com RS485 ) 61
(PNP)-Source
(NPN)-Sink
ON=Terminated
OFF=Unterminated
ON
1 2
240 V AC 3 A
Not present on all power sizes
Do not connect shield to 61
01
02
03
relay1
relay2
UDC+
UDC-
Motor
U
V
W
130BD467.10
06
05
04
240 V AC 3 A
Illustration 1.11 Basic Wiring Schematic Drawing
Quick Guide VLT®Compressor Drive CDS 803
10 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

1.4 Programming
1.4.1 Local Control Panel (LCP)
NOTICE
LCP is NOT supported in SW 1.0X!
The LCP is divided into 4 functional sections.
A. Display
B. Menu key
C. Navigation keys and indicator lights (LEDs)
D. Operation keys and indicator lights (LEDs)
130BB765.11
Com.
1-20 Motor Power
[5] 0.37kW - 0.5HP
Setup 1
A
B
1
12
13 14 15
11
11
10
9
8
7
6
5
4
3
2
C
D
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset
Auto
On
Alarm
Warn.
On
11
Back
Illustration 1.12 Local Control Panel (LCP)
A. Display
The LCD-display is back-lit with 2 alphanumeric lines. All
data is displayed on the LCP.
Information can be read from the display.
1 Parameter number and name.
2 Parameter value.
3 Set-up number shows the active set-up and the edit set-
up. If the same set-up acts as both active and edit set-up,
only that set-up number is shown (factory setting). When
active and edit set-ups dier, both numbers are shown in
the display (set-up 12). The number ashing, indicates the
edit set-up.
4 Compressor direction is shown to the bottom left of the
display – indicated by a small arrow pointing either
clockwise or counterclockwise.
5 The triangle indicates if the LCP is in Status, Quick Menu,
or Main Menu.
Table 1.10 Legend to Illustration 1.12
B. Menu key
Press [Menu] to select between Status, Quick Menu, or
Main Menu.
C. Navigation keys and indicator lights (LEDs)
6 Com LED: Flashes when bus communication is communi-
cating.
7 Green LED/On: Control section is working.
8 Yellow LED/Warn.: Indicates a warning.
9 Flashing Red LED/Alarm: Indicates an alarm.
10 [Back]: For moving to the previous step or layer in the
navigation structure.
11 [▲] [▼] [►]: For maneuvering between parameter groups,
parameters and within parameters. Can also be used for
setting local reference.
12 [OK]: For selecting a parameter and for accepting changes to
parameter settings.
Table 1.11 Legend to Illustration 1.12
D. Operation keys and indicator lights (LEDs)
13 [Hand On]: Starts the compressor and enables control of
the frequency converter via the LCP.
NOTICE
Terminal 27 Digital Input (parameter 5-12 Terminal
27 Digital Input) has stop inverse as default setting.
This means that [Hand On] does not start the
compressor if there is no 24 V to terminal 27.
Connect terminal 12 to terminal 27.
14 [O/Reset]: Stops the compressor (O). If in alarm mode,
the alarm is reset.
15 [Auto On]: Frequency converter is controlled either via
control terminals or serial communication.
Table 1.12 Legend to Illustration 1.12
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 11
11

English
OK
5
if
Select Language
... the CDS 803 Quick Menu starts
Size related
Select Grid Type
4
Select Main Menu Password 6
[0]
[0]
OK
B
a
c
k
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
Status Screen
The quick guide can always be
entered via the Quick Menu!
Power-up screen
At power-up the user is
asked to choose the
prefered laguage.
Select language
[1] English
0.0 Hz
0.0 kW
Setup 1
Setup 1
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
Press OK to start Quick Guide
Press Back to skip it
Setup 1
Status Main
Menu
Quick
Menu
Hand
On
OK
Menu
Reset Auto
On
Alarm
Warn.
On
The next screen will be
the quick guide screen.
Quick guide screen
1
2
if
3
B
a
c
k
B
a
c
k
B
a
c
k
Com.
Com.
Com.
130BD873.13
Size related
Select Compressor Selection 7
200 Hz
Select Max. reference 8
Analog in 53
Select Reference 1 Source 9
[1]
30 s
Select Ramp 1 Ramp Up Time 10
30 s
Select Ramp 1 Ramp Down Time 11
Stop inverse
Select Terminal 27 Digital In 12
Alarm
Select Relay 1 13
Drive Running
Select Relay 2 14
0.07 V
Select Terminal 53 Low Voltage 15
10 V
Select Terminal 53 High Voltage 16
Digital and ctrl.word
Select Control Site 17
[0]
FC
Select Protocol 18
[0]
Setup 1
1
Select Address 19
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
[6]
[9]
[5]
Illustration 1.13 Open-Loop Applications
Quick Guide VLT®Compressor Drive CDS 803
12 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

The Start-up quick guide for open-loop applications
Parameter Option Default Function
Parameter 0-01 Language [0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[0] English Select the language for the display.
Parameter 0-06 GridType [0] 200–240 V/50 Hz/IT-grid
[1] 200–240 V/50 Hz/Delta
[2] 200–240 V/50 Hz
[10] 380–440 V/50 Hz/IT-grid
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[30] 525–600 V/50 Hz/IT-grid
[31] 525–600 V/50 Hz/Delta
[32] 525–600 V/50 Hz
[100] 200–240 V/60 Hz/IT-grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT-grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
Size related Select operating mode for restart after
reconnection of the frequency converter to
mains voltage after power-down.
Parameter 0-60 Main Menu Password 0–999 0 Dene the password for access to the LCP.
Parameter 1-13 Compressor Selection [24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
Size related Select which compressor to use.
Parameter 3-03 Maximum Reference 0–200 Hz 200 Hz The maximum reference is the highest
obtainable by summing all references.
Parameter 3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
Parameter 3-41 Ramp 1 Ramp Up
Time
0.05–3600.0 s 30.00 s Ramp-up time from 0 to parameter 1-25 Motor
Nominal Speed.
Parameter 3-42 Ramp 1 Ramp Down
Time
0.05–3600.0 s 30.00 s Ramp-down time from nominal motor speed
to 0.
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 13
11

Parameter Option Default Function
Parameter 5-12 Terminal 27 Digital
Input
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[6] Stop inverse Select the input function for terminal 27.
Parameter 5-40 Function Relay [0]
Function relay
See parameter 5-40 Function
Relay
Alarm Select the function to control output relay 1.
Parameter 5-40 Function Relay [1]
Function relay
See parameter 5-40 Function
Relay
Drive running Select the function to control output relay 2.
Parameter 6-10 Terminal 53 Low
Voltage
0–10 V 0.07 V Enter the voltage that corresponds to the low
reference value.
Parameter 6-11 Terminal 53 High
Voltage
0–10 V 10 V Enter the voltage that corresponds to the high
reference value.
Parameter 8-01 Control Site [0] Digital and ctrl.word
[1] Digital only
[2] Controlword only
[0] Digital and
ctrl. word
Select if digital, bus, or a combination of both
should control the frequency converter.
Parameter 8-30 Protocol [0] FC
[2] Modbus RTU
[0] FC Select the protocol for the integrated RS485
port.
Parameter 8-32 Baud Rate [0] 2400 Baud [1]
4800 Baud
*[2] 9600 Baud
[3] 19200 Baud
4] 38400 Baud
5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
9600 Select the baud rate for the RS485 port.
Table 1.13 Open-loop Applications Set-up
Quick Guide VLT®Compressor Drive CDS 803
14 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

The Start-up quick guide for compressor functions
28-13 Boost Duration
60 s
5
28-01 Interval between Starts
130BD874.12
28-02 Minimum Run Time
3
28-00 Short Cycle Protection
[1] Enabled
1
28-10 Oil Return Management
[1] On
4
2
300 s
60 s
Illustration 1.14 Compressor Function Quick Guide
Compressor function quick guide
Parameter Option Default Function
Parameter 28-00 Short Cycle
Protection
[0] Disabled
[1] Enabled
[1] Enabled Select if short cycle protection is to be used.
Parameter 28-01 Interval between
Starts
0–3600 s 300 s Enter the minimum allowed time between
starts.
Parameter 28-02 Minimum Run Time 10–3600 s 60 s Enter the minimum allowed time to run
before stop.
Parameter 28-10 Oil Return
Management
[0] O
[1] On
[1] On Select if oil return management is to be used.
Parameter 28-13 Boost Duration 0–300 s 60 s Enter the boost duration for the oil return.
Table 1.14 Compressor Function
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 15
11

The Start-up quick guide for compressor closed-loop applications
6-24 Terminal 54 Low Ref./Feedb.
0
6-23 Terminal 54 High Current
6-22 Terminal 54 Low Current
4.00
6-15 Terminal 53 High Ref./Feedb.
200.000
6-10 Terminal 53 Low Voltage
0.07 V
6-11 Terminal 53 High Voltage
13
14
15
16
18
19
21
22
5-40 Function Relay 1
5-40 Function Relay 2
Drive running
130BD875.12
6-25 Terminal 54 High Ref./Feedb.
0-60 Main Menu Password
[0]
3
0-01 Language
[0] English
1
4
20-06 Grid Type
Size related
3-10 Preset Reference
0%
3-02 Minimum Reference
0 Hz
1-00 Conguration Mode
Size related
3-03 Maximum Reference
200
3-42 Ramp 1 Ramp Down Time
5
5-12 Terminal 27 Digital Input
3-41 Ramp 1 Ramp Up Time
5
6
7
8
9
10
11
12
3-15 Reference 1 Source
6-14 Terminal 53 Low Ref./Feedb.
30.000
17
20
8-30 Protocol
[0] FC
8-01 Control Site
20-04 Feedback 2 Conversion
20-00 Feedback 1 Source
0.00
23
24
26
27
8-31 Address
Digital and ctrl.word
25
[0]
Hz
Analog in 53
[1]
10 V
[0]
30.00
s
30.00
s
Stop inverse
[6]
mA
20.00 mA
4999.000
Analog input 54
[2]
Linear
[0]
1
1-13 Compressor Selection
Alarm
Closed loop
[1]
Hz
Hz
0.000
Illustration 1.15 Closed-loop Quick Guide
Quick Guide VLT®Compressor Drive CDS 803
16 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11

Closed-loop quick guide
Parameter Option Default Function
Parameter 0-01 Language [0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
0 Select the language for the display.
Parameter 0-06 GridType [0] 200–240 V/50 Hz/IT-grid
[1] 200–240 V/50 Hz/Delta
[2] 200–240 V/50 Hz
[10] 380–440 V/50 Hz/IT-grid
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[30] 525–600 V/50 Hz/IT-grid
[31] 525–600 V/50 Hz/Delta
[32] 525–600 V/50 Hz
[100] 200–240 V/60 Hz/IT-grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT-grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
Size related Select the operating mode for restart after
reconnection of the frequency converter to
mains voltage after power-down.
Parameter 0-60 Main Menu Password 0–999 0 Dene the password for access to the LCP.
Parameter 1-00 Conguration Mode [0] Open loop
[3] Closed loop
[0] Open loop Select closed loop.
Parameter 1-13 Compressor Selection [24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
Size related Select the used compressor.
Parameter 3-02 Minimum Reference -4999.0 – 200 Hz 0 Hz The minimum reference is the lowest value
obtainable by summing all references.
Parameter 3-03 Maximum Reference 0–200 Hz 200 Hz The maximum reference is the highest
obtainable by summing all references.
Parameter 3-10 Preset Reference -100 – 100 % 0% Set up a x setpoint in preset reference [0].
Parameter 3-15 Reference 1 Source [0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
Parameter 3-41 Ramp 1 Ramp Up
Time
0.05–3600.0 s 30.00 s Ramp-up time from 0 to parameter 1-25 Motor
Nominal Speed.
Parameter 3-42 Ramp 1 Ramp Down
Time
0.05–3600.0 s 30.00 s Ramp-down time from nominal motor speed
to 0.
Quick Guide Quick Guide
MG18M202 Danfoss A/S © 12/2015 All rights reserved. 17
11

Parameter Option Default Function
Parameter 5-12 Terminal 27 Digital
Input
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[6] Stop inverse Select the input function for terminal 27.
Parameter 5-40 Function Relay [0]
Function relay
See parameter 5-40 Function
Relay
Alarm Select the function to control output relay 1.
Parameter 5-40 Function Relay [1]
Function relay
See parameter 5-40 Function
Relay
Drive running Select the function to control output relay 2.
Parameter 6-10 Terminal 53 Low
Voltage
0–10 V 0.07 V Enter the voltage that corresponds to the low
reference value.
Parameter 6-11 Terminal 53 High
Voltage
0–10 V 10 V Enter the voltage that corresponds to the high
reference value.
Parameter 6-14 Terminal 53 Low Ref./
Feedb. Value
-4999 – 4999 30 Enter the reference value that corresponds to
the voltage set in parameter 6-10 Terminal 53
Low Voltage.
Parameter 6-15 Terminal 53 High Ref./
Feedb. Value
-4999 – 4999 200 Enter the reference value that corresponds to
the voltage set in parameter 6-11 Terminal 53
High Voltage.
Parameter 6-22 Terminal 54 Low
Current
0.00–20.00 mA 4.00 mA Enter the current that corresponds to the low
reference value.
Parameter 6-23 Terminal 54 High
Current
0–10 V 10 V Enter the current that corresponds to the high
reference value.
Parameter 6-24 Terminal 54 Low Ref./
Feedb. Value
-0.00–20.00 mA 20.00 mA Enter the reference value that corresponds to
the current set in parameter 6-20 Terminal 54
Low Voltage.
Parameter 6-25 Terminal 54 High Ref./
Feedb. Value
-4999 – 4999 Size related Enter the reference value that corresponds to
the current set in parameter 6-21 Terminal 54
High Voltage.
Quick Guide VLT®Compressor Drive CDS 803
18 Danfoss A/S © 12/2015 All rights reserved. MG18M202
11
